Biodur CCM Cobalt-Chrome

Brief description

Designation Klein:Biodur CCM Cobalt-Chrome
Class of metals:Co-Cr-Ni-Mo alloy
Standard ISO:5832-12
Melting:VIM
Micro-Melt®, Powder metallurgy
Biocompatibility:very good
Machinability:up to satisfactory
Hardening capability:can be hardened
Cold forming:can be cold formed (difficult)
Cold working:can be cold worked (difficult)
Polishing ability:suitable for mirror polishing
Corrosion resistance:very good, Implant quality
Magnetism:non magnetic
Applications:Implants
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
31.75075113331750

Brief description

Designation Klein:Biodur CCM Cobalt-Chrome
Class of metals:Co-Cr-Ni-Mo alloy
Standard ISO:5832-12
Melting:VIM
Micro-Melt®, Powder metallurgy
Biocompatibility:very good
Machinability:up to satisfactory
Hardening capability:can be hardened
Cold forming:can be cold formed (difficult)
Cold working:can be cold worked (difficult)
Polishing ability:suitable for mirror polishing
Corrosion resistance:very good, Implant quality
Magnetism:non magnetic
Applications:Implants
bars 3mgroundh 9

850 kg

0
Product total
Options total
Grand total
250 619 - 850.20031-750bars-3mgroundh-9-en
110.0007511381016

Biodur CCM / BC
Cobalt-Chrome for implants
per ASTM F-799-06,
ASTM F-799-06, ISO 5832-12
unanealed, rolled, in short lengths
diam. 110 mm,

bars 3mgroundspec.

53 kg

0
Product total
Options total
Grand total
180 111 - 52.500110-000bars-3mgroundspec-en
0.00075177800000

Micro-Melt Biodur CCM P
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537 (chem.only)
powder, ” AM fraction 325M +16my”
(16 – 45 my)
in 1lbs (0.454kg) plastic bottles

powderpowderspec.

8 kg

0
Product total
Options total
Grand total
010 616 - 8.0000-000powderpowderspec-en
4.50075113804500

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, in 3m bars
end of bars: pointed/chamfered
diam. 4.50 mm, tolerance 0/-0.028mm

bars 3mgroundspec.

1272 kg

0
Product total
Options total
Grand total
230 812 - 352.000|220 812 - 332.000|101 212 - 409.750|090 323 - 178.0004-500bars-3mgroundspec-en
7.10075113307100

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unannealed, ground, in 3m bars
eddy current tested
diam. 7.10 mm, tolerance ISO h9

bars 3mgroundh 9

273 kg

0
Product total
Options total
Grand total
260 612 - 183.000|050 712 - 90.0007-100bars-3mgroundh-9-en
14.20075113314200

Micro-Melt Biodur CCM / BC
per ISO 5832-12:2019 ASTM F-1537-20
Alloy 1, ISO 22674 Type 2,3,4
Cobalt-Chrome for implants
unanealed, ground, in 3m bars (+30/0mm)
ultrasonic inspected
end of bars pointed and chamfered
diam. 14.20 mm, tolerance ISO h9

bars 3mgroundh 9

949 kg

0
Product total
Options total
Grand total
160 522 - 458.000|191 222 - 491.00014-200bars-3mgroundh-9-en
12.70075113312700

Micro-Melt Biodur CCM / BC
per ISO 5832-12, and ASTM F-1537-11
Cobalt-Chrome for implants, powder metallurgy
warm worked, ground, in 3m bars (+/-50mm)
end of bars: pointed, chamfered
ultrasonic crack tested
diam. 12.70 mm (1/2″), tolerance ISO h9

bars 3mgroundh 9

333 kg

0
Product total
Options total
Grand total
221 019 - 286.000|201 119 - 47.25012-700bars-3mgroundh-9-en
8.10075113308100

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537-11, Alloy 1
unannealed, ground, tensile Rm > 1300 MPa
in 3 m bars (+/- 40mm)
end of bars: pointed/chamfered
ultrasonic immerson inspected
Diam. 8.10 mm, tolerance ISO h9

bars 3mgroundh 9

152 kg

460
Product total
Options total
Grand total
201 119 - 152.0008-100bars-3mgroundh-9-en
15.87575113815875

Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, bars of 3.6 – 3.7 m
diam. 15.875 mm (5/8”), tolerance +/-0.0254 mm

bars 3mgroundspec.

129 kg

0
Product total
Options total
Grand total
130 415 - 128.99215-875bars-3mgroundspec-en
6.10075113306100

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12 (2019)
Alloy 1 (2020), ASTM F-1537-20
unanealed, ground, in 3m bars (+30/0mm)
end of bars: pointed and chamfered
ultrasonic inspected as
per ISO 22674 Type 2, 3, 4 Rev
diam. 6.10 mm, tolerance ISO h9

bars 3mgroundh 9

177 kg

506
Product total
Options total
Grand total
170 119 - 57.0006-100bars-3mgroundh-9-en
14.000751138140001

Micro-Melt Biodur CCM / HC
Cobalt-Chrome for implants, high carbon
as per ISO 5832-12, and ASTM F-1537
unanealed ground bars in 70 cm length
round 14.00 mm, +/-0.05mm

bars 3mgroundspec.

47 kg

0
Product total
Options total
Grand total
231 210 - 46.68514-000bars-3mgroundspec-en
36.50075113836500

Biodur CCM Implant  micromelt
Stryker IMS0014 Rev 15 (12/11/17)
Howmedica HMS 1023 “warm worked, Rev 20
ASTM F-1537-20 Alloy 1, warm worked alloy
Cobalt-Chrome for implants
unanealed ground bars in 3.7 – 3.,9mm lengths
round 36.5 mm, tolerance +/-0.065mm

bars 3mgroundspec.

245 kg

0
Product total
Options total
Grand total
210 921 - 245.00036-500bars-3mgroundspec-en
22.00075113822000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, in 3 m bars
100% eddy current crack tested
Diam. 22.00 mm, tolerance +/-0.06 mm

bars 3mgroundspec.

189 kg

0
Product total
Options total
Grand total
160 810 - 189.44822-000bars-3mgroundspec-en
25.00075113825000

Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, ASTM F1537-07
KS 0406 Rev. A, ALR-Low Carbon
ultrasonically inspected per AMS 2630 class A1
annealed, ground bars in 3 m length
round 25.00 mm, +/-0.03 mm

bars 3mgroundspec.

549 kg

0
Product total
Options total
Grand total
110 719 - 376.800|120 719 - 171.80025-000bars-3mgroundspec-en
25.40075113825400

Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, bars in 2.4 – 4.27 m length
diam. 25.40 mm, tolerance +/-0.06 mm

bars 3mgroundspec.

19 kg

0
Product total
Options total
Grand total
010 711 - 19.05025-400bars-3mgroundspec-en
29.00075113829000

Biodur CCM Implant
Cobalt-Chrome for implants
as per ISO 5832-12, ASTM F-1537-08
unanealed ground bars in 1.5m (+50/0mm) length
round 29.00 mm, +/-0.058mm

bars 3mgroundspec.

821 kg

0
Product total
Options total
Grand total
010 210 - 20.350|300 821 - 528.000|310 821 - 273.00029-000bars-3mgroundspec-en
39.00075113839000

Micro-Melt Biodur CCM / High carbon
Cobalt-Chrome for implants
powder melted
per ISO 5832-12, and ASTM F-1537
unanealed ground bars in 0.8 m length
diam. 39.00 mm, tolerance +/-0.05 mm

bars 3mgroundspec.

1452 kg

0
Product total
Options total
Grand total
221 210 - 1452.40039-000bars-3mgroundspec-en
41.27575113841275

Micro-Melt Biodur CCM / High carbon
powder melted Cobalt-Chrome for implants
as per ASTM F-1537-07
ASTM F-799-06 (chemistry only)
unanealed ground
bars 2.38 – 4.27 m length
round 41.275 mm, +/-0.063mm

bars 3mgroundspec.

11 kg

0
Product total
Options total
Grand total
190 310 - 11.10041-275bars-3mgroundspec-en
43.00075113843000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants, worm worked
DIN CoCr28Mo, ISO 5832-12, ASTM F-1537-00
unanealed ground bars in 0.8 m length
round 43.00 mm, +/-0.05mm

bars 3mgroundspec.

216 kg

0
Product total
Options total
Grand total
221 210 - 215.65043-000bars-3mgroundspec-en
45.00075113845000

Biodur CCM Implant
Greatbatch MS-S1011, Alloy 1 Rev. H
Greatactch MPS-S2114 Rev. C
Depuy Ortho WI-6583 Rev. 19
gemäss ISO 5832-12 (2019)
ASTM F-1537-20 Alloy 1, warm worked alloy
Cobalt-Chrome for implants
unanealed ground bars in 3-3.5m lengths
ultrasonic inspected per AMS 2630 class A
round 45.00 mm, tolerance +/-0.058mm

bars 3mgroundspec.

627 kg

0
Product total
Options total
Grand total
100 821 - 45.500|110 821 - 581.00045-000bars-3mgroundspec-en
63.50075113863500

Biodur CCM Implant
ISO 5832-12 Alloy 1
ASTM F-1537-11 Alloy 1, ASTM F799-11 (chem.)
ultrasonic inspected as per AMS-STD-2154,
Type 1, class AA, Rev. C and AMS 2630
Class AA, Rev. D
Depuy MS-10301000 Rev. 7
Cobalt-Chrome for implants
warm worked, unannealed ground
bars in 2.4-4.2 m lengths
round 63.50 mm (2”), +/-0.0762 mm

bars 3mgroundspec.

207 kg

0
Product total
Options total
Grand total
190 820 - 62.200|180 820 - 145.00063-500bars-3mgroundspec-en
50.80075113850800

Biodur CCM / BC
Cobalt-Chrome for implants
per ASTM F-1537-11, Alloy 1
ASTM F-799-06, ISO 5832-12
unanealed ground
bars 1.60 – 2.20 m length
round 50.80 mm (2”), +/-0.07mm

bars 3mgroundspec.

42 kg

0
Product total
Options total
Grand total
280 120 - 41.70050-800bars-3mgroundspec-en
5.10075113305100

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
tensile strength Rm >1300 MPa
unannealed, ground, in 3m bars
eddy current tested
diam. 5.10 mm, tolerance ISO h9

bars 3mgroundh 9

776 kg

0
Product total
Options total
Grand total
090 610 - 5.840|180 112 - 35.000|070 113 - 558.000|270 313 - 177.0005-100bars-3mgroundh-9-en
5.60075113305600

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants, Low Nickel
per ISO 5832-12, and ASTM F-1537
Alloy 1, warm worked 3rd Ed. 02/19
unanealed, ground, in 3m bars (+/-25mm)
100% eddy current crack tested
Dia. 5.60 mm, tolerance ISO h9

bars 3mgroundh 9

450 kg

662
Product total
Options total
Grand total
120 112 - 12.300|230 223 - 438.0005-600bars-3mgroundh-9-en
5.99075113805990

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed ground bars
in 3 – 3.65m length
round 5.99 mm, 0/-0.058mm

bars 3mgroundspec.

0 kg

0
Product total
Options total
Grand total
301 122 - 12.3005-990bars-3mgroundspec-en
8.10075113208100

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, in 3m bars
eddy current tested
diam. 8.10 mm, tolerance ISO h8

bars 3mgroundh 8

67 kg

0
Product total
Options total
Grand total
160 609 - 67.1008-100bars-3mgroundh-8-en
3.00075113003000

CCM / BC
Cobalt-Chrome for implants, 9.9135HL
low carbon, hot worked condtion, Alloy 1
per ISO 5832-12, and ASTM F-1537:2008
unanealed, ground,in 3m bars +30/0mm
end of bars: pointed, chamfered
100% eddy current crack tested as per
DIN EN 10277-1: 2008, Tab. 1, Kl. 4
diam. 3.00 mm, tolerance ISO h6

bars 3mgroundh 6

42 kg

0
Product total
Options total
Grand total
050 315 - 41.6893-000bars-3mgroundh-6-en
0.00055577800000

1.4441 IMPLANT
gemäss ASTM F138/F139, ISO 5832-1
AISI 316L, ~316LVM, (chem. only)
powder, ” AM fraction -270 +16my
(AM fraction 16 – 53 my)
in 1lbs (0.454kg) plastic bottles

powderpowderspec.

10 kg

0
Product total
Options total
Grand total
010 317 - 10.0000-000powderpowderspec-en
9.00075111009000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832.12, and ASTM F-1537
unanealed, ground, in 3.65m bars
pointed, chamfered
diam. 9.00 mm, tolerance ISO h6

special lengthgroundh 6

20 kg

0
Product total
Options total
Grand total
121 108 - 19.7509-000special-lengthgroundh-6-en
5.50075111205500

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants worm worked
per ISO 5832-12 Alloy 1, and ASTM F-1537
unanealed, ground, in 3-3.65m bars
end of bars: pointed, chamfered
diam. 5.50 mm, tolerance ISO h8

special lengthgroundh 8

0 kg

0
Product total
Options total
Grand total
250 612 - 34.3505-500special-lengthgroundh-8-en
14.00075113014000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12 and ASTM F-1537
unanealed, ground, in 3m bars
pointed/chamfered, eddy current crack tested
diam. 14.00 mm, tolerance ISO h6

bars 3mgroundh 6

409 kg

0
Product total
Options total
Grand total
160 522 - 409.00014-000bars-3mgroundh-6-en
9.52075111809520

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed ground, in 3.65m bars
diam. 9.52 mm, tolerance +/-0.038mm

special lengthgroundspec.

58 kg

0
Product total
Options total
Grand total
121 108 - 57.6509-520special-lengthgroundspec-en
12.70075111812700

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537-11
unanealed, ground, in approx. 3.65m bars
diam. 12.70 mm, tolerance 0/-0.028 mm

special lengthgroundspec.

5 kg

0
Product total
Options total
Grand total
290 415 - 4.69012-700special-lengthgroundspec-en
22.00075111822000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537-08
unanealed, ground,
in 3.04 – 3.66 m bars
diam. eddy current tested
22.00 mm, tolerance +/-0.06 mm

special lengthgroundspec.

123 kg

0
Product total
Options total
Grand total
131 211 - 122.88322-000special-lengthgroundspec-en
2.00075113002000

Ergiloy 9.9135HN
Cobalt-Chrome for implants
low carbon, hot worked condition, Alloy 1
per ISO 5832-12, and ASTM F-1537
anealed, drawn, grounded, in 3m bars +30/0m
end of bars: pointed and chamfered
100% eddycurrent crack tested (classe 4)
diam. 2.00 mm, tolerance ISO h6

bars 3mgroundh 6

191 kg

0
Product total
Options total
Grand total
041 215 - 24.509|130 121 - 166.3002-000bars-3mgroundh-6-en
2.50075113002500

Ergiloy 9.9135HN
Cobalt-Chrome for implants
low carbon, hot worked condition, Alloy 1
per ISO 5832-12, and ASTM F-1537-11
hot worked, drawn, grounded polished
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested (classe 4)
diam. 2.50 mm, tolerance ISO h6

bars 3mgroundh 6

292 kg

0
Product total
Options total
Grand total
161 220 - 292.0002-500bars-3mgroundh-6-en
7.93075111807930

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, in 3.65m bars
diam. 7.93 mm, tolerance +/-0.03

special lengthgroundspec.

4 kg

0
Product total
Options total
Grand total
030 308 - 4.2597-930special-lengthgroundspec-en
3.50075113003500

Micro-Melt Biodur CCM / BC
gemäss ISO 5832-12 Alloy 1, ASTM F-1537-08
auch gem. ASTM F-1537-11
Cobalt-Chrome for implants
low carbon, warm worked, powder melted
unanealed, ground, in 3m bars
end of bars: pointed, chamfered
ultrasonic inspected per AMS 2630 Rev. C
diam. 3.50 mm, tolerance ISO h6

bars 3mgroundh 6

30 kg

0
Product total
Options total
Grand total
080 113 - 29.6053-500bars-3mgroundh-6-en
8.00075113008000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537-11
unanealed, ground, in 3m bars
eddy current crack tested
diam. 8.00 mm, tolerance ISO h6

bars 3mgroundh 6

455 kg

0
Product total
Options total
Grand total
201 119 - 3.870|280 422 - 451.0008-000bars-3mgroundh-6-en
4.00075113004000

Micro-Melt Biodur CCM / BC
per ISO 5832-12, and F-1537-08, Alloy 1
Cobalt-Chrome for implants
low carbon, warm worked, powder melted
unanealed, ground, in 3m bars
eddy current crack tested
diam. 4.00 mm, tolerance ISO h6

bars 3mgroundh 6

181 kg

0
Product total
Options total
Grand total
240 512 - 108.590|090 320 - 13.500|130 612 - 59.0004-000bars-3mgroundh-6-en
12.00075113012000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537-11
unanealed, ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 12.00 mm, tolerance ISO h6

bars 3mgroundh 6

158 kg

0
Product total
Options total
Grand total
300 419 - 157.92412-000bars-3mgroundh-6-en
9.00075113009000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, in 3 m bars
100% eddy current crack tested
9.00 mm, tolerance ISO h6

bars 3mgroundh 6

430 kg

0
Product total
Options total
Grand total
120 215 - 430.3009-000bars-3mgroundh-6-en
10.00075113010000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, alloy 1 warm worked
ASTM F-1537, ISO 22674
unanealed, ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 10.00 mm, tolerance ISO h6

bars 3mgroundh 6

1112 kg

0
Product total
Options total
Grand total
250 915 - 89.285|240 919 - 508.000|160 320 - 514.50010-000bars-3mgroundh-6-en
7.00075113007000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12 and ASTM F-1537
unanealed, ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 7.00 mm, tolerance ISO h6

bars 3mgroundh 6

287 kg

0
Product total
Options total
Grand total
120 612 - 286.7367-000bars-3mgroundh-6-en
6.35075113006350

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12 and ASTM F-1537
warm worked, unanealed, ground,
in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current tested
diam. 6.35 mm (1/4”), tolerance ISO h6

bars 3mgroundh 6

68 kg

0
Product total
Options total
Grand total
070 812 - 68.0006-350bars-3mgroundh-6-en
6.00075113006000

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants, warm worked
DIN CoCr28Mo, ISO 5832-12, ASTM F-1537
unanealed, ground, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
ultrasonic inspected as per AMS 2632 Class A1
Material complies with the RoHS Directive
diam. 6.00 mm, tolerance ISO h6

bars 3mgroundh 6

362 kg

0
Product total
Options total
Grand total
190 922 - 350.9006-000bars-3mgroundh-6-en
5.50075113005500

Micro-Melt Biodur CCM / BC
Cobalt-Chrome for implants
per ISO 5832-12, and ASTM F-1537
unanealed, ground, in 3m bars
end of bars: pointed, chamfered
diam. 5.50 mm, tolerance ISO h6

bars 3mgroundh 6

292 kg

0
Product total
Options total
Grand total
250 912 - 1.500|140 122 - 6.200|190 522 - 38.000|310 822 - 346.0005-500bars-3mgroundh-6-en
5.00075113005000

Micro-Melt Biodur CCM / BC
alloy Cobalt-Chrome for implants
DIN CoCr28Mo, ISO 5832-12,ASTM F-1537-08
warm worked, low carbon
unanealed, ground, in 3m bars
end of bars: pointed, chamfered
diam. 5.00 mm, tolerance ISO h6
material complies with the RoHS Directive

bars 3mgroundh 6

323 kg

0
Product total
Options total
Grand total
240 112 - 0.290|210 513 - 322.3665-000bars-3mgroundh-6-en
Werkstoff-Nr.
DIN
AFNOR
AISI
ISO
Euronorm
Andere
C %
Si %
Mn %
P %
S %
Cr %
Mo %
Ni %
Cu %
Pb %
Zn %
Sn %
Fe %
O %
N %
H %
Ti %
Schnittgeschwindigkeit
Standardabmessung an Lager
