CHRONIFER 17-4PH A

Brief description
Designation Klein:CHRONIFER 17-4PH A
Class of metals:Precipitation hardening stainless steel
Material number:1.4542
Standard EN:X 5 CrNiCuNb 16-4
Re-melting:ESR
Machinability:up to satisfactory
Hardening capability:up to 44 HRc
Polishing ability:adapted for mirror polishing
Corrosion resistance:satisfactory in the hardened polished
and passivized condition
Magnetism:magnetic
Uses:medical, surgical and dental
instruments
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
3.82051113103820
Brief description
Designation Klein:CHRONIFER 17-4PH A
Class of metals:Precipitation hardening stainless steel
Material number:1.4542
Standard EN:X 5 CrNiCuNb 16-4
Re-melting:ESR
Machinability:up to satisfactory
Hardening capability:up to 44 HRc
Polishing ability:adapted for mirror polishing
Corrosion resistance:satisfactory in the hardened polished
and passivized condition
Magnetism:magnetic
Uses:medical, surgical and dental
instruments
bars 3mgroundh 7

232 kg

0
Product total
Options total
Grand total
090 408 - 227.6413-820bars-3mgroundh-7-en
3.25051100703250

Chronifer 17-4PH
no 1.4542, X5CrNiCuNb16.4
EN10088-3, UNS S17400
ASTM F-899-20, NF S94090
ASTM A959, AMS 5622, AMS 5643
solution annealed (cond. A)
cold drawn, in coils of ~30kg
diam. 3.25 mm, tolerance fg7

in spoolsdrawnfg 7

0 kg

0
Product total
Options total
Grand total
030 323 - 504.0003-250in-spoolsdrawnfg-7-en
2.500511131025001

Chronifer 17-4PH
AISI 630, as per EN 10088-3, ASTM F-899
UNS S17400, AISI 630, NF S94 090 (chem.)
ASTM A564/A564M
stainless steel for precipitation hardening purpose,
ESR remelted, condition A
ground, polished, in 3m bars (+30/0mm)
pointed and chamfered end of bars
100% eddycurrent crack tested
diam. 2.50 mm, tolerance ISO h7

bars 3mgroundh 7

2 kg

0
Product total
Options total
Grand total
230 708 - 2.4622-500bars-3mgroundh-7-en
2.70051113102700

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb 16 4
per DIN EN 10088-3, ESU
AISI/SUS 630, ASTM F-899
as per ASTM F-899, ASTM A-582, NF S94 090
UNS S17400, AISI 630, ASTM A564/A564M
solution annealed (cond. A), ESR remelted
stainless steel for precipitation hardening
cold drawn, ground, polished, in 3m bars
end of bar: pointed, chamfered
100% eddycurrent crack tested
diam. 2.70 mm, tolerance ISO h7

bars 3mgroundh 7

184 kg

0
Product total
Options total
Grand total
230 708 - 124.9152-700bars-3mgroundh-7-en
3.17051113103170

Chronifer 17-4PH
as per DIN EN 10088-3, AISI 630
as per ASTM F-899 and NF S94-090
stainless steel for precipitation hardening purpose
solution annealed (cond. A),
cold worked (cold finished), ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested
diam. 3.17 mm (1/8″), tolerance ISO h7

bars 3mgroundh 7

359 kg

0
Product total
Options total
Grand total
070 808 - 358.7973-170bars-3mgroundh-7-en
3.170511131031702

Chronifer 17-4PH Aisi 630
as per DIN EN 10088-3
stainless steel for precipitation hardening purpose
cond. H1150 (P930), ground, polished, in 3m bars
end of bars: pointed, chamfered
eddycurrent crack tested
diam. 3.17 mm (1/8″), tolerance ISO h7

bars 3mgroundh 7

64 kg

0
Product total
Options total
Grand total
061 103 - 63.9003-170bars-3mgroundh-7-en
3.500511131035001

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630, ASTM F-899
as per DIN EN 10088-3
solution annealed (cond. A), ESR remelted
stainless steel for precipitation hardening
cold drawn, ground, polished, in 3m bars
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 3.50 mm, tolerance ISO h7

bars 3mgroundh 7

114 kg

0
Product total
Options total
Grand total
070 808 - 114.5383-500bars-3mgroundh-7-en
4.75051113104750

Chronifer 17-4PH AISI 630
stainless steel for precipitation hardening
purpose, as per ASTM F-899
cond. A (solution annealed)
ground, polished, in 3m bars
end of bars: pointed, chamfered,
eddy current crack tested
diam. 4.75 mm (3/16″), tolerance ISO h7

bars 3mgroundh 7

100 kg

0
Product total
Options total
Grand total
020 605 - 99.6264-750bars-3mgroundh-7-en
4.00051113104000

Chronifer 17-4PH AISI 630
German no 1.4542, DIN EN 10088-3, NF S94-090
ASTM F-899, ASTM A564/A564M, UNS S17400
stainless steel for precipitation hardening
condition A, ESR remelted
ground, polished, in 3m bars (+30/0mm)
pointed, chamfered, eddy current crack tested
diam. 4.00 mm, tolerance ISO h7

bars 3mgroundh 7

2 kg

0
Product total
Options total
Grand total
121 108 - 2.1734-000bars-3mgroundh-7-en
4.50051113104500

Chronifer 17-4PH
AISI 630, mat.no 1.4542, X5CrNiCuNb 16 4
as per DIN EN 10088-3 9/05
as per ASTM A564 (chem. only) UNS S17400
stainless steel for precipitation hardening purpose
solution annealed (cond. A)
ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 4.50 mm, tolerance ISO h7

bars 3mgroundh 7

460 kg

0
Product total
Options total
Grand total
260 805 - 460.3064-500bars-3mgroundh-7-en
2.30051113102300

Chronifer 17-4PH Aisi 630
as per DIN EN 10088-3
as per ASTM F-899
stainless steel for precipitation hardening purpose, ESR remelted
condition A (solution annealed)
ground, polished, in 3m bars
pointed, chamfered, eddy current tested
diam. 2.30 mm, tolerance ISO h7

bars 3mgroundh 7

138 kg

0
Product total
Options total
Grand total
070 808 - 137.8002-300bars-3mgroundh-7-en
5.50051113105500

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
AISI 630, 17-4PH, AISI 630,
as per EN 10088-3, ASTM F-899
ASTM A564/A564M Type 630,(chemistry only)
condition A (solution annealed)
ground, polished, in 3m bars
pointed, chamfered, eddy current tested
diam. 5.50 mm, tolerance ISO h7

bars 3mgroundh 7

90 kg

0
Product total
Options total
Grand total
160 306 - 89.6405-500bars-3mgroundh-7-en
6.000511131060001

Chronifer 17-4PH
German no 1.4542, X5CrNiCuNb16.4, UNS S17400
ASTM F-899, NF S 94090
ASTM A564/A564M, AMS 5643 (chem.)
Zustand P930 (H1150), DIN EN 10088-3
stainless steel for precipitation hardening
ground, polished, in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 6.00mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
051 213 - 317.0706-000bars-3mgroundh-7-en
9.50051113109500

Chronifer 17-4PH
no mat. 1.4542, X5CrNiCuNb 16 4
as per DIN EN 10088-3, AISI 630
as per ASTM A564
stainless steel for precipitation hardening purpose
cond. A (solution annealed)
ground, polished, in 3m bars +30/0mm
end of bars: pointed, chamfered,
100 % eddy current crack tested
diam. 9.50 mm, tolerance ISO h7

bars 3mgroundh 7

457 kg

0
Product total
Options total
Grand total
150 205 - 457.2309-500bars-3mgroundh-7-en
11.50051113111500

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening purpose
cond. A, as per ASTM F-899
ESR remelted, as per DIN EN 10088-3
ground, polished, in 3m bars (+30/0mm)
pointed, chamfered, eddy current tested
diam. 11.50mm, tolerance ISO h7

bars 3mgroundh 7

141 kg

0
Product total
Options total
Grand total
150 908 - 141.30011-500bars-3mgroundh-7-en
27.00051113027000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05, AMS 5643
Aisi 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-09
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 27.00mm, tolerance ISO h6

bars 3mgroundh 6

236 kg

1600
Product total
Options total
Grand total
170 210 - 115.800|101 110 - 164.700|120 213 - 131.900|020 914 - 553.10027-000bars-3mgroundh-6-en
47.00051113047000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
gemäss DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899-20, NF S94 090
ASTM A564/A564M-13, ASTM 959-16 (chem.)
UNS S17400, AMS 5643 Rev. V, EN10277-3
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm), Ultrasonic inspected
100% eddy current crack tested cl. 4
diam. 47.00mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

408 kg

0
Product total
Options total
Grand total
270 721 - 408.00047-000bars-3mgroundh-6-en
1.000511131010001

Chronifer 17-4PH AISI 630
stainless steel for precipitation hardening
as per ASTM F-899
conforme per EG/2002/95 to ROHS directive
condition H900 (40-44 HRC)
ground, polished, in 3m bars
diam. 1.00 mm, tolerance ISO h7

bars 3mgroundh 7

8 kg

0
Product total
Options total
Grand total
130 810 - 7.8001-000bars-3mgroundh-7-en
33.00051113033000

Chronifer 17-4PH
no 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899, NF S94 090
ASTM A564/A564M, ASTM 959
UNS S 17400, AMS 5643 Rev. V (chem.)
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: chamfered,
100% eddy current crack tested cl.4
diam. 33.00mm, tolerance ISO h6

bars 3mgroundh 6

1758 kg

0
Product total
Options total
Grand total
221 221 - 1418.000|211 221 - 340.00033-000bars-3mgroundh-6-en
12.70051113112700

Chronifer 17-4PH
AISI 630, german no 1.4542
DIN X5CrNiCuNb16.4, ASTM A564
as per DIN EN 10088-3, ASTM F-899
stainless steel for precipitation
hardening purpose, ESR remelted
Condition A (solution annealed)
ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam.12.70 mm (1/2″), Toleranz ISO h7

bars 3mgroundh 7

9 kg

0
Product total
Options total
Grand total
020 205 - 0.600|030 205 - 2.200|150 205 - 6.30012-700bars-3mgroundh-7-en
28.00051113028000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05,
UNS S17400, AMS 5643 (chem.only)
AISI/SUS 630, ASTM F-899, NF S 94 090
ASTM A564/A564M-04,ASTM 959-09
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 28.00mm, tolerance ISO h6

bars 3mgroundh 6

749 kg

0
Product total
Options total
Grand total
090 615 - 748.80028-000bars-3mgroundh-6-en
31.00051113031000

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14,
AISI 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04, ASTM 959-16
UNS S17400, ~AMS5643V
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm), end of bars: chamfered,
100% eddy current crack tested cl. 4
diam. 31.00mm, tolerance ISO h6

bars 3mgroundh 6

821 kg

1600
Product total
Options total
Grand total
061 020 - 1142.00031-000bars-3mgroundh-6-en
32.00051113032000

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05, AMS 5643
AISI 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04, ASTM 959-09
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm), end of bars: chamfered,
100% eddy current crack tested cl. 4
diam. 32.00mm, tolerance ISO h6 (DIN 286-2)

bars 3mgroundh 6

1383 kg

1600
Product total
Options total
Grand total
221 010 - 2.000|130 716 - 80.200|140 519 - 565.100|070 120 - 288.400|110 820 - 542.40032-000bars-3mgroundh-6-en
32.000511130320001

Chronifer 17-4PH H-900
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05
AISI 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-09
cond. H-900 (40-44 HRC)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
100% eddy current crack tested
diam. 32.00mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
150 411 - 2.15032-000bars-3mgroundh-6-en
32.000511130320003

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, condition H-1025
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 32.00 mm, tolerance ISO h8

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
32-000bars-3mgroundh-6-en
35.00051113035000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 , AMS 5643
AISI 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-09
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 35.00mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1183 kg

0
Product total
Options total
Grand total
030 913 - 5.600|201 014 - 4.700|260 515 - 293.500|220 323 - 879.00035-000bars-3mgroundh-6-en
50.00051113050000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
gemäss DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899-20, NF S94 090
ASTM A564/A564M-13, ASTM 959-16 (chem.)
UNS S17400, AMS 5643 Rev. V, UNS S17400
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
end of bars: chamfered at both ends
100% eddy current tested cl. 4, ultrasonic insp.
diam. 50.00mm, tolerance ISO h6 (ISO 268-2)

bars 3mgroundh 6

826 kg

0
Product total
Options total
Grand total
270 721 - 825.80050-000bars-3mgroundh-6-en
35.000511130350001

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05, AMS 5643
AISI 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-09
ESR remelted
solution treated to cond. H1150
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 35.00mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
190 815 - 1262.20035-000bars-3mgroundh-6-en
36.00051113036000

Chronifer 17-4PH
W-Nr. 1.4542,  X5CrNiCuNb17.4
UNS S17400, AISI/SUS 630, 17-4PH
gem. EN 10088-3 12/14, NF S94 090
ASTM A564/A564M-19A, ASTM F-899-20
ASTM A959-16
SAE-AMS 5643 Rev. V 2018-01 (chem.)
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
ultrasonic inspected
diam. 36.00mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

829 kg

0
Product total
Options total
Grand total
280 323 - 381.500|270 323 - 447.50036-000bars-3mgroundh-6-en
40.00051113040000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-09
UNS S17400, AMS 5643
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
end of bars: chamfered at both ends
100% eddy current crack tested cl. 4
diam. 40.00mm, tolerance ISO h6

bars 3mgroundh 6

631 kg

1600
Product total
Options total
Grand total
100 913 - 193.300|281 014 - 614.000|310 119 - 992.00040-000bars-3mgroundh-6-en
42.00051113042000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
gemäss DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899-12b, NF S94 090
ASTM A564/A564M-13, ASTM 959-09 (chem.)
UNS S17400, AMS 5643 Rev. V, UNS S17400
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
end of bars: chamfered at both ends
100% eddy current crack tested cl. 4
diam. 42.00mm, tolerance ISO h6 (ISO 268-2)

bars 3mgroundh 6

905 kg

0
Product total
Options total
Grand total
161 220 - 904.70042-000bars-3mgroundh-6-en
45.00051113045000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
gemäss DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899-12b, NF S94 090
ASTM A564/A564M-13, ASTM 959-09 (chem.)
UNS S17400, AMS 5643 Rev. V, UNS S17400
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
end of bars: chamfered at both ends
100% eddy current crack tested cl. 4
diam. 45.00mm, tolerance ISO h6 (ISO 268-2)

bars 3mgroundh 6

962 kg

0
Product total
Options total
Grand total
161 220 - 962.00045-000bars-3mgroundh-6-en
48.00051113048000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
gemäss DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899-20, NF S94 090
ASTM A564/A564M-19A, ASTM 959-19 (chem.)
UNS S17400, AMS 5643 Rev. V, UNS S17400
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
100% eddy current crack tested cl. 4
ultrasonic inspected
diam. 48.00mm, tolerance ISO h6 (ISO 268-2)

bars 3mgroundh 6

292 kg

1000
Product total
Options total
Grand total
270 721 - 292.40048-000bars-3mgroundh-6-en
12.50051113112500

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening purpose
as per ASTM F-899
condition A (solution annealed)
ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 12.50 mm, tolerance ISO h7

bars 3mgroundh 7

416 kg

0
Product total
Options total
Grand total
230 909 - 415.60012-500bars-3mgroundh-7-en
12.70051113212700

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S 94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
RoHS conforme
AMS 5643 Rev. V, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 12.70 mm (1/2”), tolerance ISO h8

bars 3mgroundh 8

761 kg

0
Product total
Options total
Grand total
260 219 - 760.91912-700bars-3mgroundh-8-en
17.00051113117000

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening
purpose, as per ASTM F-899
as per DIN EN 10088-3
condition A, ESR remelted
ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 17.00mm, tolerance ISO h7

bars 3mgroundh 7

5 kg

0
Product total
Options total
Grand total
090 108 - 4.60017-000bars-3mgroundh-7-en
32.000511132320001

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, condition H-1075
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 32.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
030 217 - 739.700|040 419 - 944.20032-000bars-3mgroundh-8-en
19.00051113219000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16 (chem.)
W-Nr. 1.4542 Rev. V, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 19.00 mm, tolerance ISO h8

bars 3mgroundh 8

1299 kg

0
Product total
Options total
Grand total
201 218 - 1299.20019-000bars-3mgroundh-8-en
25.00051113225000

Chronifer 17-4PH
AISI 630, ASTM F-899, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4,UNS S17400
AMS 5643, DIN EN 10088-3 (chem.)
AS9100 Rev. D, AS 6279 Rev. A
ESR remelted, condition H900
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev. D
diam. 25.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
191 217 - 50.10025-000bars-3mgroundh-8-en
28.00051113228000

Chronifer 17-4PH
AISI 630, ASTM F-899, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
AS9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 28.00 mm, tolerance ISO h8

bars 3mgroundh 8

290 kg

0
Product total
Options total
Grand total
191 118 - 290.30028-000bars-3mgroundh-8-en
30.00051113230000

Chronifer 17-4PH
AISI 630, ASTM F-899, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-09
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 30.00 mm, tolerance ISO h8

bars 3mgroundh 8

1196 kg

0
Product total
Options total
Grand total
071 118 - 1196.30030-000bars-3mgroundh-8-en
30.000511132300001

Chronifer 17-4PH
AISI 630, ASTM F-899, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-09
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted
solution treated to cond. H1150
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 30.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
170 913 - 344.10030-000bars-3mgroundh-8-en
32.00051113232000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 32.00 mm, tolerance ISO h8

bars 3mgroundh 8

36 kg

0
Product total
Options total
Grand total
031 118 - 35.90032-000bars-3mgroundh-8-en
48.00051113248000

Chronifer 17-4PH
AISI 630, ASTM F-899-19, NF S94 090 (chem.)
ASTM A564/A564M-19A, ASTM 959-19
german no 1.4542, X5CrNiCuNb16.4 (chem.)
AMS 5643, DIN EN 10088-3 (chem.)
gemäss UNS S17400, AMS 5600-5699 Serien
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
ultrasonic tested per AMS2630A, Rev.C
diam. 48.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
080 321 - 548.00048-000bars-3mgroundh-8-en
17.00051113217000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16 (chem.)
W-Nr. 1.4542, X5CrNiCuNb16.4, RoHS conforme
AMS 5643 Rev. V, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A, RoHS conforme
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 17.00 mm, tolerance ISO h8

bars 3mgroundh 8

847 kg

0
Product total
Options total
Grand total
290 319 - 847.30017-000bars-3mgroundh-8-en
20.00051113820000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
AS 9100 Rev D, AS 6279 Rev A
ESR remelted, cond. H900 (age hardened)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 20.00 mm, tolerance 0/-0.025mm

bars 3mgroundspec.

447 kg

0
Product total
Options total
Grand total
080 119 - 447.20020-000bars-3mgroundspec-en
30.00051113830000

Chronifer 17-4PH
AISI 630,ASTM F-899-12B,NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
AS9100 Rev. D, AS 6279 Rev. A
ESR remelted, condition H900 (41-44HRC)
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 30.00 mm, tolerance 0/-0.030mm

bars 3mgroundspec.

763 kg

0
Product total
Options total
Grand total
191 118 - 763.30030-000bars-3mgroundspec-en
30.000511138300001

Chronifer 17-4PH
AISI 630,ASTM F-899-12B,NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
AS9100 Rev. D, AS 6279 Rev. A
ESR remelted, condition H1025 (P1070)
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 30.00 mm, tolerance 0/-0.030mm

bars 3mgroundspec.

0 kg

0
Product total
Options total
Grand total
30-000bars-3mgroundspec-en
40.00051113840000

Chronifer 17-4PH
AISI 630, ASTM F-899, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 40.00 mm, tolerance 0/-0.040mm

bars 3mgroundspec.

1039 kg

0
Product total
Options total
Grand total
071 118 - 1039.20040-000bars-3mgroundspec-en
60.00051132860000

Chronifer 17-4PH
W-Nr. 1.4542, 17/4 PH
K-N700-Extra, nach AMS 5643, EN10088-3
DMD 229-20, ASTM A564-04
rough ground, polished, in 2m bars
diam. 60.0 mm, tolerance ISO h11

bars 2mscaledspec.

0 kg

0
Product total
Options total
Grand total
180 913 - 308.35060-000bars-2mscaledspec-en
25.40051113025400

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05, AMS 5643
AISI 630, ASTM F-899, NF S94 090
ASTM A564/A564M-04,ASTM 959-09
cond. A (solution annealed), RoHS conforme
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 25.40mm (1″), tolerance ISO h6

bars 3mgroundh 6

1186 kg

0
Product total
Options total
Grand total
270 911 - 236.200|111 219 - 950.00025-400bars-3mgroundh-6-en
18.00051113218000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16 (chem.)
W-Nr. 1.4542 Rev. V, X5CrNiCuNb16.4
AMS 5643 Rev. V, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A, Reach conforme
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 18.00 mm, tolerance ISO h8

bars 3mgroundh 8

1770 kg

103
Product total
Options total
Grand total
201 218 - 7.300|180 119 - 265.200|231 122 - 1497.00018-000bars-3mgroundh-8-en
15.00051113215000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev V, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 15.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
090 414 - 246.50015-000bars-3mgroundh-8-en
18.000511131180001

Chronifer 17-4PH
AISI 630, German no 1.4542, ASTM F-899
EN 10088-3 9/05, X5CrNiCuNb16.4
stainless steel for precipitation hardening purpose
condition H-900 (40-44 HRC)
ESR remelted, ground, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 18.00 mm, tolerance ISO h7

bars 3mgroundh 7

64 kg

0
Product total
Options total
Grand total
180 506 - 64.00018-000bars-3mgroundh-7-en
27.000511131270001

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev.W, DIN EN 10088-3 (chem.)
AS 9100 Rev D, AS 6279 Rev A, UNS S17400
ESR remelted, condition H900
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev. C
diam. 27.00 mm, tolerance ISO h7

bars 3mgroundh 7

802 kg

0
Product total
Options total
Grand total
090 323 - 802.00027-000bars-3mgroundh-7-en
20.000511131200001

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening purpose
as per ASTM F-899
condition H900 (40-44 HRC)
ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 20.00 mm, tolerance ISO h7

bars 3mgroundh 7

7 kg

0
Product total
Options total
Grand total
190 506 - 7.20020-000bars-3mgroundh-7-en
22.00051113122000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16 (chem.)
W-Nr. 1.4542 Rev. V, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 22.00 mm, tolerance ISO h7

bars 3mgroundh 7

342 kg

0
Product total
Options total
Grand total
211 218 - 341.70022-000bars-3mgroundh-7-en
22.000511131220001

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev.V, DIN EN 10088-3 (chem.)
AS 9100 Rev D, AS 6279 Rev A
ESR remelted, condition H900
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev. C
diam. 22.00 mm, tolerance ISO h7

bars 3mgroundh 7

1233 kg

0
Product total
Options total
Grand total
260 219 - 568.000|250 419 - 665.30022-000bars-3mgroundh-7-en
22.000511131220002

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
no. 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev.V, DIN EN 10088-3 (chem.)
AS 9100 Rev D, AS 6279 Rev A
ESR remelted, hardness 40-44 HRC
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 22.00 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
180 314 - 95.500|090 518 - 265.10022-000bars-3mgroundh-7-en
23.00051113123000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 23.00 mm, tolerance ISO h7

bars 3mgroundh 7

357 kg

0
Product total
Options total
Grand total
290 319 - 356.70023-000bars-3mgroundh-7-en
24.00051113124000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev. V, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 24.00 mm, tolerance ISO h7

bars 3mgroundh 7

1819 kg

0
Product total
Options total
Grand total
040 219 - 326.300|170 619 - 1492.80024-000bars-3mgroundh-7-en
30.000511131300001

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
no. 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev.V, DIN EN 10088-3 (chem.)
AS 9100 Rev D, AS 6279 Rev A
ESR remelted, hardness 40-44 HRC
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 30.00 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
290 513 - 427.97530-000bars-3mgroundh-7-en
13.00051113213000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
AS 9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 13.00 mm, tolerance ISO h8

bars 3mgroundh 8

535 kg

0
Product total
Options total
Grand total
080 119 - 534.60013-000bars-3mgroundh-8-en
40.00051113140000

Chronifer 17-4PH
~German no 1.4542, ~X5CrNiCuNb16.4
AISI/SUS 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-09
UNS S17400, AMS 5643
cond. A (solution annealed)
ESR remelted, ground, polished,
in 3m bars (+50/0mm)
end of bars: chamfered at both ends
100% eddy current crack tested
ulrasonic tested as per AMS 2630A
diam. 40.00mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
290 212 - 1.740|140 318 - 3.000|120 320 - 30.150|120 820 - 336.40040-000bars-3mgroundh-7-en
8.00051113208000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NF S94 090 (chem.)
ASTM A564/A564M, ASTM 959-16
EN 10088-3, (1.4542) X5CrNiCuNb16.4
as per AMS 5643 Rev. V, RoHS conforme
AS 9100 Rev. D, AS 6279 Rev. A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 8.00 mm, tolerance ISO h8

bars 3mgroundh 8

808 kg

0
Product total
Options total
Grand total
080 119 - 808.1008-000bars-3mgroundh-8-en
10.000511132100001

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NFS 94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev V, DIN EN 10088-3 (chem.)
AS 9100 Rev D, AS 6279 Rev A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 10.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
230 616 - 8.700|260 619 - 6.300|260 820 - 479.50010-000bars-3mgroundh-8-en
10.20051113210200

Chronifer 17-4PH
AISI 630, ASTM F-899, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 10.20 mm, tolerance ISO h8

bars 3mgroundh 8

268 kg

0
Product total
Options total
Grand total
131 218 - 268.00010-200bars-3mgroundh-8-en
12.00051113212000

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NFS 94 090 (chem.)
ASTM A564/A564M-13, ASTM 959-16 (chem.)
no. 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev V, DIN EN 10088-3 (chem.)
AS 9100 Rev D, AS 6279 Rev A
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev. D
diam. 12.00 mm, tolerance ISO h8

bars 3mgroundh 8

585 kg

0
Product total
Options total
Grand total
160 919 - 585.10012-000bars-3mgroundh-8-en
12.000511132120001

Chronifer 17-4PH
AISI 630, ASTM F-899-20, NFS 94 090 (chem.)
ASTM A564/A564M-19A, ASTM 959-19 (chem.)
no. 1.4542, X5CrNiCuNb16.4
AMS 5643 Rev V, DIN EN 10088-3 (chem.)
ESR remelted, cond. H-900 (aged to 40-44HRC)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev. D
diam. 12.00 mm, tolerance ISO h8

bars 3mgroundh 8

657 kg

0
Product total
Options total
Grand total
250 522 - 656.80012-000bars-3mgroundh-8-en
26.00051113026000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 UNS S17400,
AMS 5643, RoHS guidline conform
AISI/SUSi 630, ASTM F-899, NF S 94 090
ASTM A564/A564M-04,ASTM 959-09
guideline 2011/65/EC (RoHS Reach)
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 26.00 mm, tolerance ISO h6

bars 3mgroundh 6

2222 kg

0
Product total
Options total
Grand total
130 911 - 3.000|190 312 - 7.600|200 514 - 9.500|020 914 - 10.800|100 215 - 959.100|140 715 - 1232.00026-000bars-3mgroundh-6-en
3.70051113003700

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
DIN EN 10088-3, ESR remelted
ASTM F-899, AISI 630
ASTM A582/A582M, NF S94 090 (chem.)
UNS S17400, ASTM A564/A564M,
ASTM A959, AMS 5643, AMS 5622
solution annealed (cond. A), RoHs conforme
stainless steel for precipitation hardening
ground, polished, in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested class 4
diam. 3.70 mm, tolerance ISO h6

bars 3mgroundh 6

231 kg

0
Product total
Options total
Grand total
300 920 - 230.7003-700bars-3mgroundh-6-en
25.00051113025000

Chronifer 17-4PH
no 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14
AISI 630, ASTM F-899, NF S94 090
ASTM A564/A564M-04,ASTM 959-09
UNS S17400, AMS 5643
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 25.00mm, tolerance ISO h6

bars 3mgroundh 6

1152 kg

0
Product total
Options total
Grand total
080 610 - 2.800|230 118 - 3.600|191 119 - 1145.60025-000bars-3mgroundh-6-en
1.25051103001250

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
UNS S17400, AISI 630
ESR remelted, as per ASTM A564
and ASTM F-899, NF S94 090
solution annealed (condition A)
precipitation hardening stainless steel
cold drawn, in 3m bars
diam. 1.25 mm, tolerance h6 (0/-0.006mm)

bars 3mdrawnh 6

0 kg

0
Product total
Options total
Grand total
1-250bars-3mdrawnh-6-en
3.000511130030001

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
DIN EN 10088-3, AISI 630,ASTM F-899
as per NF S94090, UNS S17400, A582
stainless steel for precipitation hardening purpose ESR
RoHS, Reach conforme
under DFARS 252.225.7009 in conjunction with DFARS 225.003
remelted, cond. H900 (42-46 HRC)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 3.00 mm, tolerance ISO h6

bars 3mgroundh 6

38 kg

0
Product total
Options total
Grand total
070 808 - 38.0833-000bars-3mgroundh-6-en
3.00051113003000

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14, ASTM F-899-20
ASTM A582/A582M, NF S94 090
solution annealed (cond. A),RoHS conforme
ESR, AISI 630, ASTM A582/A582M
UNS S17400, AMS 5643, AMS 5622
ASTM A564/A564M, ASTM A959
stainless steel for precipitation hardening
ground, polished, tensile Rm: 900-1100 MPa
in 3m bars (+30/0 mm)
end of bar: pointed, chamfered
100% eddycurrent crack tested class 4
diam. 3.00 mm, tolerance ISO h6

bars 3mgroundh 6

424 kg

600
Product total
Options total
Grand total
301 122 - 524.1503-000bars-3mgroundh-6-en
2.40051113002400

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
AISI 630, 17-4PH, AISI 630, ASTM A959
as per EN 10088-3, ASTM F-899, RoHS conforme
ASTM A564/A564M-04, NF S94-090
AMS 5643, AMS 5622, UNS S17400
Chrome-Nickel medical steel for instruments
ESR remelted, condition A
drawn, ground, stress relieved
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 2.40 mm, tolerance ISO h6

bars 3mgroundh 6

344 kg

0
Product total
Options total
Grand total
171 019 - 343.6502-400bars-3mgroundh-6-en
2.20051113002200

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
AISI 630, 17-4PH, AISI 630, ASTM A959
as per EN 10088-3, ASTM F-899
ASTM A564/A564M-04, NF S 94-090
AMS 5643, AMS 5622, UNS S17400
Chrome-Nickel medical steel for instruments
ESR remelted, condition A
drawn, ground, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 2.20 mm, tolerance ISO h6

bars 3mgroundh 6

296 kg

0
Product total
Options total
Grand total
231 019 - 295.8202-200bars-3mgroundh-6-en
2.10051113002100

Chronifer 17-4PH
no mat. 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630, ASTM F-899, A959
DIN EN 10088-3 12/14, NF S94 090
UNS S17400, ASTM A564/A564M
suivant AMS 5643 et AMS 5622
stainless steel for precipitation hardening purpose, ESR remelted
cond. A (solution annealed)
cold drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl, 4
diam. 2.10 mm, tolerance ISO h6

bars 3mgroundh 6

685 kg

0
Product total
Options total
Grand total
100 816 - 187.018|181 219 - 498.0002-100bars-3mgroundh-6-en
2.00051113002000

Chronifer 17-4PH
no mat. 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630, ASTM F-899, ESR remelted
DIN EN 10088-3, NF S94 090
UNS S17400, ASTM A564/A564M
AMS 5643 et AMS 5622
stainless steel for precipitation hardening purpose,
cond. A (solution annealed)
cold drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 2.00 mm, tolerance ISO h6

bars 3mgroundh 6

279 kg

800
Product total
Options total
Grand total
241 110 - 7.080|070 417 - 275.5062-000bars-3mgroundh-6-en
1.80051113001800

Chronifer 17-4PH
no mat. 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630, ASTM F-899
DIN EN 10088-3, NF S94 090
UNS S17400, ASTM A564/A564M
suivant AMS 5643 et AMS 5622
stainless steel for precipitation
hardening purpose, ESR remelted
condition H900 (42-44 HRC)
cold drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
eddycurrent crack tested
diam. 1.80 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
171 121 - 43.200|210 422 - 968.9501-800bars-3mgroundh-6-en
1.500511130015001

Chronifer 17-4PH
German no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3, AISI 630
stainless steel for precipitation hardening purpose
cond. H900 (-> 40-44 HRC)
precision ground, in 3m bars (+30/0mm)
diam. 1.50 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
180 913 - 281.900|170 913 - 52.4001-500bars-3mgroundh-6-en
1.50051113001500

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
AISI 630, ASTM F-899, UNS S17400
EN 10088-3, NF S94 090
stainless steel for precipitation hardening
purpose, condition A (+AT), ESR remelted
drawn, ground, polished, in 3m bars (+30/0mm)
diam. 1.50 mm, tolerance ISO h6

bars 3mgroundh 6

345 kg

0
Product total
Options total
Grand total
280 710 - 12.444|230 621 - 332.5001-500bars-3mgroundh-6-en
2.60051103302600

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
EN10088-3 12/14, UNS S17400, ESR
gemäss ASTM F-899, NF S94 090
ASTM 564/A564M (chem. only)
ASTM A959, AMS 5622, AMS 5643
solution annealed (cond. A)
cold drawn, in 3m bars
diam. 2.60 mm, tolerance ISO h9

bars 3mdrawnh 9

23 kg

0
Product total
Options total
Grand total
050 220 - 23.0002-600bars-3mdrawnh-9-en
1.65051103201650

Chronifer 17-4PH Aisi 630
German no 1.4542, condition A
as per ASTM F-899
cold drawn, in 3m bars
diam. 1.65 mm, tolerance ISO h8

bars 3mdrawnh 8

9 kg

0
Product total
Options total
Grand total
231 204 - 9.9501-650bars-3mdrawnh-8-en
1.60051103101600

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
X5CrNiCuNb16.4, EN10088-3
ESR remelted, ASTM A564
gemäss ASTM F-899, NFS 94090
UNS S17400, AISI 630
stainless steel for medical application
condition A (solution annealed)
cold drawn, in 3m bars
diam. 1.60 mm, tolerance ISO h7

bars 3mdrawnh 7

24 kg

0
Product total
Options total
Grand total
280 710 - 24.0841-600bars-3mdrawnh-7-en
24.00051113024000

Chronifer 17-4PH
no 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14
UNS S 17400, AMS 5643,
AISI/SUS 630, ASTM F-899, NF S94 090
ASTM A564/A564M, ASTM 959
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 24.00 mm, tolerance ISO h6

bars 3mgroundh 6

3100 kg

0
Product total
Options total
Grand total
150 719 - 636.800|180 719 - 456.000|100 123 - 501.000|090 123 - 1506.00024-000bars-3mgroundh-6-en
1.10051103101100

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening purpose, condition A
cold drawn, in 3m bars
diam. 1.10 mm, tolerance ISO h7

bars 3mdrawnh 7

0 kg

0
Product total
Options total
Grand total
130 810 - 0.4001-100bars-3mdrawnh-7-en
1.00051103001000

Chronifer 17-4PH
mat. no 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3, AISI 630
stainless steel for precipitation hardening purpose
annealed, cold drawn, in 3m bars
diam. 1.00 mm, tolerance ISO h6

bars 3mdrawnh 6

3 kg

0
Product total
Options total
Grand total
280 710 - 3.3281-000bars-3mdrawnh-6-en
3.30051113003300

Chronifer 17-4PH
as per DIN EN 10088-3, ASTM F-899
ASTM A582/A582M, NF S94090
ESR, AISI 630, ASTM A582/A582M
UNS S17400, AMS 5643, AMS 5622
ASTM A564/A564M, ASTM A959
stainless steel for precipitation hardening
solution annealed (cond. A),RoHS conforme
ground,polished,tensile Rm:900-1100MPa
in 3m bars (+30/0 mm)
end of bar: pointed, chamfered
100% eddycurrent crack tested class 4
diam. 3.30 mm, tolerance ISO h6

bars 3mgroundh 6

338 kg

500
Product total
Options total
Grand total
090 120 - 337.9003-300bars-3mgroundh-6-en
0.80051102000800

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3
ESR remelted, as per ASTM A564
and ASTM F-899, NFS 94090
UNS S17400, AISI 630
precipitation hardening stainless steel
solution annealed (condition A)
cold drawn, in 2m bars (+/- 10mm)
diam. 0.80 mm, tolerance ISO h6

bars 2mdrawnh 6

0 kg

0
Product total
Options total
Grand total
021 221 - 5.400|020 223 - 88.800|170 223 - 15.2000-800bars-2mdrawnh-6-en
3.30051100803300

Chronifer 17-4PH Aisi 630
German no 1.4542, cond.P 930
cold drawn coils for ESCO
diam. 3.30 mm, tolerance fg8

in spoolsdrawnspec.

34 kg

0
Product total
Options total
Grand total
170 999 - 34.1003-300in-spoolsdrawnspec-en
4.00051100704000

Chronifer 17-4PH
German no. 1.4542, X5CrNiCuNb16.4
AISI/SUS 630
NF S94 090, ASTM F-899, A959
UNS S17400, EN 10088-3
AMS 5622, AMS 5643
solution annealed (cond.A)
cold drawn, in coils
diam. 4.00 mm, tolerance fg7

in spoolsdrawnfg 7

401 kg

0
Product total
Options total
Grand total
180 413 - 401.0004-000in-spoolsdrawnfg-7-en
3.50051100703500

Chronifer 17-4PH
no mat. 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630, ASTM F-899-20, ESR remelted
DIN EN 10088-3 12/14, NF S94 090
UNS S17400, ASTM A564/A564M-19
AMS 5643 et AMS 5622
stainless steel for precipitation hardening purpose,
cond. A (solution annealed)
cold drawn, polished, in coils for ESCO
diam. 3.50 mm, tolerance ISO 286-2/fg7

in spoolsdrawnfg 7

0 kg

0
Product total
Options total
Grand total
3-500in-spoolsdrawnfg-7-en
2.60051100702600

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
EN10088-3 12/14, UNS S17400, ESR
gemäss ASTM F-899, NF S94 090
ASTM 564/A564M (chem. only)
ASTM A959, AMS 5622, AMS 5643
solution annealed (cond. A)
cold drawn, in coils of apprx. 20kg
diam. 2.60 mm, tolerance fg7 (-0.004/-0.014)

in spoolsdrawnfg 7

178 kg

0
Product total
Options total
Grand total
050 220 - 178.0002-600in-spoolsdrawnfg-7-en
2.30051100702300

Chronifer 17-4PH
mat.no. 1.4542, X5CrNiCuNb16.4
EN10088-3 12/14, UNS S17400
as per ASTM F-899, NF S94 090
ATM A564/564M (chem. only)
ASTM A959, AMS 5622, AMS 5643
ESR remeldted, solution annealed (cond. A)
cold drawn,annealed, in coils of ~ 25kg
diam. 2.30 mm, tolerance ISO fg7

in spoolsdrawnfg 7

322 kg

0
Product total
Options total
Grand total
271 119 - 322.3002-300in-spoolsdrawnfg-7-en
2.10051100702100

Chronifer 17-4PH
mat.no. 1.4542, X5CrNiCuNb16.4
EN10088-3 12/14, UNS S17400
as per ASTM F-899, NF S94 090
ASTM A959, AMS 5622, AMS 5643
solution annealed (cond. A)
cold drawn, in coils of apprx. 25kg
diam. 2.10 mm, tolerance fg7

in spoolsdrawnfg 7

341 kg

0
Product total
Options total
Grand total
140 218 - 340.9502-100in-spoolsdrawnfg-7-en
1.60051100701600

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
ESR remelted, as per ASTM A564
and ASTM F-899, NFS 94090
UNS S17400, AISI 630
precipitations hardening stainless steel
solution annealed (condition A)
cold drawn, in coils for ESCO machines
diam. 1.60 mm, tolerance ISO fg7

in spoolsdrawnfg 7

374 kg

0
Product total
Options total
Grand total
280 710 - 120.500|160 920 - 253.8001-600in-spoolsdrawnfg-7-en
1.40051100701400

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
UNS S17400, AISI 630
ESR remelted, as per ASTM A564
and ASTM F-899, NFS 94090
precipitation hardening stainless steel
solution annealed (condition A)
cold drawn, in coils for ESCO machines
diam. 1.40 mm, tolerance fg7

in spoolsdrawnfg 7

115 kg

0
Product total
Options total
Grand total
280 710 - 114.9001-400in-spoolsdrawnfg-7-en
1.20051100701200

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
precipitation hardening stainless steel
ESR remelted, as per ASTM A564
and ASTM F-899, NFS 94090
UNS S17400, Aisi 630
solution annealed (condition A)
cold drawn, in coils for ESCO machines
diam. 1.20 mm, tolerance fg7

in spoolsdrawnfg 7

119 kg

0
Product total
Options total
Grand total
210 710 - 119.0001-200in-spoolsdrawnfg-7-en
1.10051100701100

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3
ESR remelted, as per ASTM A564
and ASTM F-899, NFS 94090
UNS S17400, AISI 630
precipitation hardening stainless steel
solution annealed (condition A)
cold drawn, in coils for ESCO machines
diam. 1.10 mm, tolerance ISO fg7

in spoolsdrawnfg 7

13 kg

0
Product total
Options total
Grand total
130 810 - 13.1001-100in-spoolsdrawnfg-7-en
4.30051100504300

Chronifer 17-4PH
no 1.4542, X5CrNiCuNb16.4
EN10088-3, UNS S17400
ASTM F-899, NF S94090
ASTM A959, AMS 5622, AMS 5643
solution annealed (cond. A)
cold drawn, in coils of > 30kg
diam. 4.30 mm, tolerance fg8

in spoolsdrawnfg 8

802 kg

0
Product total
Options total
Grand total
090 113 - 802.1004-300in-spoolsdrawnfg-8-en
3.10051100503100

Chronifer 17-4PH
as per ASTM F-899, AISI 630
as per DIN EN 10088-3
precipitation hardening steel
solution annealed (cond. A)
cold drawn, in coils of apprx. 30kg
diam. 3.10 mm, tolerance ISO fg8

in spoolsdrawnfg 8

150 kg

0
Product total
Options total
Grand total
230 505 - 149.5003-100in-spoolsdrawnfg-8-en
1.65051100501650

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
condition A
cold drawn, on spools
diam. 1.65 mm, tolerance fg8

in spoolsdrawnfg 8

107 kg

0
Product total
Options total
Grand total
231 204 - 107.4261-650in-spoolsdrawnfg-8-en
3.20051113003200

Chronifer 17-4PH
mat.no. 1.4542, X5CrNiCuNb 16 4
as per DIN EN 10088-3 (AISI 630)
stainless steel for precipitation hardening purpose
cond. A (solution annealed)
ground polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 3.20 mm, tolerance ISO h6

bars 3mgroundh 6

129 kg

0
Product total
Options total
Grand total
200 603 - 128.8003-200bars-3mgroundh-6-en
1.20051103101200

Chronifer 17-4PH
German no 1.4542 AISI 630,
as per ASTM F-899, NF S94 090 (chem.)
stainless steel for precipitation hardening purpose,
cold drawn condtion A
in 3m bars (+30/0mm)
diam. 1.20 mm, tolerance ISO h7

bars 3mdrawnh 7

8 kg

0
Product total
Options total
Grand total
210 710 - 8.5651-200bars-3mdrawnh-7-en
4.50051113004500

Chronifer 17-4PH
as per DIN EN 10088-3 12/14, AISI 630
ASTM F-899-20, ESR remelted, AISI 630
ASTM A582/A582M, NF S94090
UNS S17400, AMS 5643, AMS 5622
ASTM A564/A564M, ASTM A959
solution annealed (cond. A),
stainless steel for precipitation hardening
ground, polished, in 3m bars (+40/0 mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested class 4
diam. 4.50 mm, tolerance ISO h6

bars 3mgroundh 6

939 kg

0
Product total
Options total
Grand total
290 622 - 274.000|140 922 - 665.3004-500bars-3mgroundh-6-en
8.50051113008500

Chronifer 17-4PH AISI 630
stainless steel for precipitation hardening purpose,
DIN EN 10088-3, AMS 5643
cond. A
ground, polished, in 3m bars
end of bars: pointed, chamfered,
eddy current crack tested
diam. 8.50 mm, tolerance ISO h6

bars 3mgroundh 6

186 kg

0
Product total
Options total
Grand total
150 302 - 185.9008-500bars-3mgroundh-6-en
22.000511130220002

Chronifer 17-4PH
AISI 630, ASTM F-899-12B, NFS 94 090 (chem.)
ASTM A564/A564M, ASTM 959-16 (chem.)
german no 1.4542, X5CrNiCuNb16.4
AMS 5643, DIN EN 10088-3 (chem.)
ESR remelted, condition H1025
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic tested per AMS2630A, Rev.C
diam. 22.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
170 913 - 282.400|070 420 - 1039.00022-000bars-3mgroundh-6-en
21.00051113021000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05
AISI/SUS 630, ASTM F-899, NF S 94 090
ASTM A564/A564M-04,ASTM 959-09
UNS S17400, AMS 5643, chem.Analysis
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 21.00mm, tolerance ISO h6

bars 3mgroundh 6

643 kg

0
Product total
Options total
Grand total
070 114 - 17.300|250 619 - 625.50021-000bars-3mgroundh-6-en
20.00051113020000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 ~AMS 5643
AISI 630, ASTM F-899, NF S94 090
ASTM A564/A564M-04, ASTM 959-09
SAE 51440C, UNS S17400, AMS 5643
stainless steel for medical instruments RoHs conform
ESR remelted, cond. A (solution annealed)
ground, polished, in 3m bars(+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 20.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

2190 kg

800
Product total
Options total
Grand total
120 812 - 3.900|210 415 - 5.000|121 022 - 404.500|060 223 - 344.000|070 223 - 1052.000|080 223 - 431.40020-000bars-3mgroundh-6-en
19.00051113019000

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05, AMS 5643
Aisi 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-09
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 19.00 mm, tolerance ISO h6

bars 3mgroundh 6

697 kg

0
Product total
Options total
Grand total
110 719 - 697.20019-000bars-3mgroundh-6-en
18.00051113018000

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05, AMS 5643
AISI/SUS 630, ASTM F-899, NFS 94 090
ASTM A564/A564M-04,ASTM 959-16
UNS S17400
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 18.00mm, tolerance ISO h6

bars 3mgroundh 6

1219 kg

1600
Product total
Options total
Grand total
061 011 - 5.100|280 420 - 20.800|040 423 - 1193.00018-000bars-3mgroundh-6-en
17.000511130170001

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening purpose
as per ASTM F-899,
condition H-900 (40-44 HRC)
ESR remelted, ground, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 17.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
151 221 - 451.00017-000bars-3mgroundh-6-en
17.00051113017000

Chronifer 17-4PH
mat.no 1.4542, X5CrNiCuNb17 4
as per EN 10088-3 9/05,NF S 94 090
Type 630,UNS S17400, ASTM F-899,
ASTM A564/A564M-04,ASTM 959-09
cond. A (solution annealed), AMS 5643
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 17.00 mm, tolerance ISO h6

bars 3mgroundh 6

1066 kg

0
Product total
Options total
Grand total
201 112 - 4.100|180 919 - 12.600|170 919 - 1049.20017-000bars-3mgroundh-6-en
16.00051113016000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
stainless steel, precipitation hardenable
as per DIN EN 10088-3 12/14, AMS 5643
AISI 630, ASTM F-899, NFS 94 090
ASTM A564/A564M, ASTM 959-16
cond. A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 16.00mm, tolerance ISO h6

bars 3mgroundh 6

1267 kg

1600
Product total
Options total
Grand total
050 319 - 1036.300|161 219 - 230.20016-000bars-3mgroundh-6-en
14.00051113014000

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14
AISI/SUS 630, ASTM F-899-20, NF S94 090
ASTM A564/A564M-13, ASTM 959-16
UNS S 17400, AMS 5643 (chem.only)
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 14.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1820 kg

1400
Product total
Options total
Grand total
140 323 - 413.000|130 323 - 970.000|210 223 - 484.20014-000bars-3mgroundh-6-en
13.00051113013000

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 12/14
AISI 630, ASTM F-899, NF S94 090
ASTM A564/A564M, ASTM 959
as per AMS 5643 (chemical only)
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 13.00 mm, tolerance ISO h6

bars 3mgroundh 6

2379 kg

1600
Product total
Options total
Grand total
050 319 - 9.850|040 521 - 773.600|060 323 - 394.000|070 323 - 894.000|080 323 - 308.00013-000bars-3mgroundh-6-en
11.00051113011000

Chronifer 17-4 PH
mat. no 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630,ASTM F-899-20, ESR remelted
selon DIN EN 10088-3, NF S94 090
ASTM A564/A564M,
UNS S17400, AMS 5643 (chemical only)
condition A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
US inspeted per DIN EN 10308, Tab.1, Typ 1a
diam. 11.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1666 kg

0
Product total
Options total
Grand total
250 220 - 613.800|090 822 - 291.500|031 122 - 761.00011-000bars-3mgroundh-6-en
10.00051113010000

Chronifer 17-4 PH
mat. no 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630,ASTM F-899, ESR remelted
selon EN 10088-3 12/14, NF S94 090
ASTM A564/A564M, RoHS conforme
UNS S17400, AMS 5643 (chemical only)
stainless steel for medical application
RoHS, Reach conform
condition A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 10.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1607 kg

0
Product total
Options total
Grand total
190 520 - 441.200|151 122 - 1217.00010-000bars-3mgroundh-6-en
9.53051113009530

Chronifer 17-4 PH
mat. no 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630,ASTM F-899, ESR remelted
selon EN 10088-3, NF S 94 090, RoHs conforme
ASTM A564/A564M-04, ASTM A959-09
UNS S17400, AMS 5643 (chemical only)
condition A (solution annealed), RoHS
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 9.53 mm (3/8″), tolerance ISO h6

bars 3mgroundh 6

368 kg

0
Product total
Options total
Grand total
040 517 - 367.6509-530bars-3mgroundh-6-en
9.00051113009000

Chronifer 17-4PH
mat.no. 1.4542, X5CrNiCuNb17.4
EN 10088-3, ASTM F-899-12b,
Type 630, UNS S17400
NF S94 090, ASTM A564/A564M
ASTM A959-09, AMS 5643 (chem.analyse)
ESR remelted, condition A
drawn, ground, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 9.00 mm, tolerance ISO h6

bars 3mgroundh 6

885 kg

0
Product total
Options total
Grand total
190 121 - 364.500|270 721 - 540.0009-000bars-3mgroundh-6-en
23.00051113023000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3 9/05
AISI 630, ASTM F-899, NF S 94 090
ASTM A564/A564M-04,ASTM 959-09
SUS 630,UNS S17400,AMS 5643 (chem)
cond. A (solution annealed)
ground, polished, in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 23.00mm, tolerance ISO h6

bars 3mgroundh 6

791 kg

0
Product total
Options total
Grand total
080 414 - 791.20023-000bars-3mgroundh-6-en
7.500511130075001

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening purpose,
ESR remelted
as per ASTM F-899 / DIN EN 10088-3
ASTM 564/A564M, ASTM A959
cond. H900 (40-44HRC), AMS 5643
ground, polished, in 3m bars
end of bars: pointed, chamfered,
eddy current crack tested
diam. 7.50 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
260 514 - 92.2007-500bars-3mgroundh-6-en
6.00051113006000

Chronifer 17-4PH
stainless steel for precipitation hardening purpose,
conforme EG/2002/95 ROHS directive
ESU , as per EN 10088-3 12/14, AISI 630
ASTM F-899, NF S94 090, UNS S17400
ASTM A564/A564M, AMS 5643 (chem.)
Cond. A solution annealed
ground, polished, in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested class 4
diam. 6.00 mm, tolerance ISO h6

bars 3mgroundh 6

1764 kg

0
Product total
Options total
Grand total
250 320 - 162.700|040 423 - 1267.000|030 423 - 342.0006-000bars-3mgroundh-6-en
4.76051113004760

Chronifer 17-4PH
stainless steel for precipitation hardening purpose,
conforme EG/2002/95 ROHS directive
ESU , as per EN 10088-3 12/14, AISI 630
ASTM F-899-20, NF S94 090, UNS S17400
ASTM A564/A564M, AMS 5643 (chem.)
AMS 5622, ASTM A959
Cond. A solution annealed
ground, polished, in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested class 4
diam. 4.76 mm (3/16”), tolerance ISO h6

bars 3mgroundh 6

533 kg

0
Product total
Options total
Grand total
160 222 - 216.000|280 422 - 317.0004-760bars-3mgroundh-6-en
4.80051113004800

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
AISI 630, 17-4PH, AISI 630
as per EN 10088-3, ASTM F-899
ASTM A564/A564M-04, NF S 94-090
ESR remelted, condition A
drawn, ground, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 4.80 mm, tolerance ISO h6

bars 3mgroundh 6

45 kg

500
Product total
Options total
Grand total
140 715 - 45.2404-800bars-3mgroundh-6-en
5.00051113005000

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
AISI 630, 17-4PH, AISI 630,
as per AMS5643 (chemical only)
as per EN 10088-3, ASTM F-899
ASTM A564/A564M, NF S 94-090
Material complies with the RoHS Directive
ESR remelted, solution annealed (cond. A)
drawn, ground, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 5.00 mm, tolerance ISO h6

bars 3mgroundh 6

40 kg

3200
Product total
Options total
Grand total
151 221 - 46.0505-000bars-3mgroundh-6-en
5.30051113005300

Chronifer 17-4PH
stainless steel for precipitation hardening purpose,
AISI 630, ESR remelted, cond. A, AMS 5643
as per ASTM F-899 / DIN EN 10088-3
ground, polished, in 3m bars
end of bars: pointed, chamfered,
eddy current crack tested
diam. 5.30 mm, tolerance ISO h6

bars 3mgroundh 6

23 kg

0
Product total
Options total
Grand total
201 103 - 23.4005-300bars-3mgroundh-6-en
5.70051113005700

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
AISI 630, 17-4PH, AISI 630, ASTM A959
as per AMS5643 (chemical only)
as per EN 10088-3 12/14, ASTM F-899-20
ASTM A564/A564M-19a, NF S94-090
Material complies with the RoHS Directive
ESR remelted, condition A
drawn, ground, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 5.70 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

699 kg

0
Product total
Options total
Grand total
180 123 - 699.4005-700bars-3mgroundh-6-en
5.50051113005500

Chronifer 17-4PH
W-Nr. 1.4542, X5CrNiCuNb16.4
AISI 630, 17-4PH, AISI 630, ASTM A959
as per AMS5643 (chemical only)
as per EN 10088-3, ASTM F-899
ASTM A564/A564M-04, NF S94-090
Material complies with the RoHS Directive
ESR remelted, condition A
drawn, ground, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 5.50 mm, tolerance ISO h6

bars 3mgroundh 6

730 kg

0
Product total
Options total
Grand total
260 618 - 170.100|300 119 - 560.0005-500bars-3mgroundh-6-en
6.000511130060002

Chronifer 17-4PH
no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3, AISI 630
ASTM F-899, NF S 94 090
ASTM A564/A564M, AMS 5643 (chem)
stainless steel for precipitation hardening purpose
ESR remelted, cond. H900 (42-46 HRC
ground, polished, in 3m bars
end of bars: pointed, chamfered,
1’00% eddycurrent crack tested
diam. 6.00 mm, tolerance ISO h6

bars 3mgroundh 6

38 kg

0
Product total
Options total
Grand total
230 517 - 38.4906-000bars-3mgroundh-6-en
6.10051113006100

Chronifer 17-4PH
ESU , as per EN 10088-3 12/14 UNS S17400
ASTM F-899, NF S 94090, AISI 630
ASTM A564/A564M, AMS 5643 (chem.)
stainless steel for precipitation hardening purpose,
conforme EG/2002/95 ROHS directive
Cond. A solution annealed
ground, polished, in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 6.10mm, tolerance ISO h6

bars 3mgroundh 6

214 kg

0
Product total
Options total
Grand total
230 517 - 214.1006-100bars-3mgroundh-6-en
6.35051113006350

Chronifer 17-4PH
mat.no. 1.4542, X5CrNiCuNb16.4
as per DIN EN 10088-3, NF S94-090
AMS 5643, AMS 5622, ASTM F-899, A959
ASTM A564/A564M (chemical only)
stainless steel for precipitation hardening purpose, ESR remelted
Cond. A solution annealed
ground, polished, in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 6.35 mm (1/4″), tolerance ISO h6

bars 3mgroundh 6

0 kg

800
Product total
Options total
Grand total
300 611 - 0.2506-350bars-3mgroundh-6-en
6.50051113006500

Chronifer 17-4PH
Typ 630, UNS S17400, ASTM AF56/A564M
ASTM A959, ASTM F-899, NFS 94 090
ESR remelted, as per EN 10088-3, AMS 5643
stainless steel for precipitation hardening purpose,
Cond. A solution annealed
ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 6.50 mm, tolerance ISO h6

bars 3mgroundh 6

461 kg

0
Product total
Options total
Grand total
240 216 - 10.800|250 216 - 450.5006-500bars-3mgroundh-6-en
6.80051113006800

Chronifer 17-4PH
ESU remelted, as per EN 10088-3
ASTM F-899, NFS 94090, AISI 630
ASTM A564/A564M, AMS 5643 (chem)
stainless steel for precipitation hardening purpose,
conforme EG/2002/95 ROHS directive
Cond. A solution annealed
ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 6.80 mm, tolerance ISO h6

bars 3mgroundh 6

284 kg

0
Product total
Options total
Grand total
201 216 - 284.3006-800bars-3mgroundh-6-en
7.00051113007000

Chronifer 17-4 PH
no. 1.4542, X5CrNiCuNb 16 4
ESU remelted, as per EN 10088-3
ASTM F-899, NF S94 090, AISI 630
ASTM A564/A564M, AMS 5643 (chem)
ASTM A959-09
stainless steel for precipitation hardening purpose,
conforme EG/2002/95 ROHS directive
Cond. A solution annealed
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 7.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

366 kg

800
Product total
Options total
Grand total
070 617 - 243.500|080 617 - 122.9007-000bars-3mgroundh-6-en
7.10051113007100

Chronifer 17-4PH
German no. 1.4542, X5CrNiCuNb16.4
ESU remelted, as per EN 10088-3 12/14
ASTM F-899, NF S94 090, AISI 630
ASTM A564/A564M, AMS 5643 (chem)
stainless steel for precipitation hardening purpose,
conforme EG/2002/95 ROHS directive
Cond. A solution annealed
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 7.10 mm, tolerance ISO h6

bars 3mgroundh 6

487 kg

0
Product total
Options total
Grand total
170 719 - 487.0007-100bars-3mgroundh-6-en
7.50051113007500

Chronifer 17-4PH Aisi 630
stainless steel for precipitation hardening purpose,
ESR remelted
as per ASTM F-899 / DIN EN 10088-3
ASTM 564/A564M, ASTM A959
cond. A, AMS 5643
ground, polished, in 3m bars
end of bars: pointed, chamfered,
eddy current crack tested
diam. 7.50 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1351 kg

0
Product total
Options total
Grand total
170 112 - 11.300|131 119 - 483.600|301 122 - 590.000|310 123 - 266.0007-500bars-3mgroundh-6-en
10.20051113010200

Chronifer 17-4 PH
mat. no 1.4542, X5CrNiCuNb 16 4
AISI/SUS 630,ASTM F-899-20, ESR remelted
selon EN 10088-3 12/14, NF S94 090
NACE MR 0175 ISO 15156-3
ASTM A564/A564M-13, RoHS conforme
UNS S17400, AMS 5643 (chemical only)
stainless steel for medical application
RoHS, Reach conform
condition A (solution annealed)
ground, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
US inspected per DIN EN 10308, Tab.1, Typ 1a
diam. 10.20 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

0 kg

800
Product total
Options total
Grand total
050 516 - 13.450|291 117 - 321.63410-200bars-3mgroundh-6-en
Werkstoff-Nr.1.4542 (ESU)
DINX 5 CrNiCuNb 16-4
AFNORX 5 CrNiCuNb 16-4
AISI630 (17-4 PH) F 899
ISOX 5 CrNiCuNb 16-4
EuronormX 5 CrNiCuNb 16-4
Andere
C %≤ 0.07
Si %≤ 0.70
Mn %≤ 1.00
P %≤ 0.04
S %≤ 0.03
Cr %15.0-17.0
Mo %≤ 0.60
Ni %3.00-5.00
Cu %3.00-5.00
Pb %
Zn %
Sn %
Fe %
O %
N %
H %
Ti %
Schnittgeschwindigkeit~ 25-35
Standardabmessung an Lager1.0-40 mm
