CHRONIFER L 18 solenoid

Brief description

Klein designation:CHRONIFER L 18 solenoid
Class of steels:
Material number:
Standard UNS:
RoHS 2 – 2011/65/EU:
Machinability:
Hardening capability:
Forming:
Cold working hardening:
Polishing ability:
Magnetism:
Corrosion resistance:
Uses:
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
31.00040513331000

Brief description

Klein designation:CHRONIFER L 18 solenoid
Class of steels:
Material number:
Standard UNS:
RoHS 2 – 2011/65/EU:
Machinability:
Hardening capability:
Forming:
Cold working hardening:
Polishing ability:
Magnetism:
Corrosion resistance:
Uses:
bars 3mgroundh 9

1044 kg

0
Product total
Options total
Grand total
191 020 - 1044.00031-000bars-3mgroundh-9-en
32.00040513232000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
hardness: 80 – 88 HRB
in 3m lengths +30/0mm, end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 32.00 mm tolerance ISO h8

bars 3mgroundh 8

2483 kg

0
Product total
Options total
Grand total
280 918 - 7.900|171 120 - 555.10032-000bars-3mgroundh-8-en
69.00040513869000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed ground, hardness 80-88 HRB
in 3m lengths (+25.4/0 mm)
100% eddycurrent + Ultrasonic tested
diam. 69.00 mm, 0/-0.076mm

bars 3mgroundspec.

0 kg

300
Product total
Options total
Grand total
121 022 - 695.80069-000bars-3mgroundspec-en
27.00040513327000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+200/0mm)
end of bars: chamfered,
100% eddy current crack tested cl. 3
diam. 27.00 mm, tolerance ISO h9

bars 3mgroundh 9

962 kg

0
Product total
Options total
Grand total
220 818 - 127.000|060 219 - 835.00027-000bars-3mgroundh-9-en
4.00040513304000

Chronifer L 18
1.4105 IL, X6CrMoS18, ~Aisi 430FR
as per DIN EN 10088-3
stainless steel, for solenoid valves
drawn,ground, polished, in 3m bars
pointed/chamfered, eddy current tested
diam. 4.00 mm, tolerance ISO s6 (+0.019/+0.027)

bars 3mgroundh 9

3 kg

0
Product total
Options total
Grand total
060 902 - 3.2704-000bars-3mgroundh-9-en
35.00040513235000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
in 3m lengths +25.4/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 35.00 mm tolerance ISO h8

bars 3mgroundh 8

1314 kg

0
Product total
Options total
Grand total
221 117 - 216.000|301 118 - 1098.00035-000bars-3mgroundh-8-en
31.75040513231750

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
hardness: 80 – 88 HRB
in 3m lengths +30/0mm, end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 31.75 mm (1 1/4”), tolerance ISO h8

bars 3mgroundh 8

717 kg

0
Product total
Options total
Grand total
080 321 - 72.10031-750bars-3mgroundh-8-en
25.40040513225400

Chronifer L 18
~German no. ~1.4105 IL, ~X6CrMoS17,
AISI 430FR Solenoid,
ASTM -838-18 Alloy 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 25.40 mm (1”), tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
190 804 - 292.90025-400bars-3mgroundh-8-en
18.00040513218000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3
ASTM A959, UNS S43020
ASTM A838, Alloy 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished, in 3m bars
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 18.00 mm, tolerance ISO h8

bars 3mgroundh 8

12 kg

0
Product total
Options total
Grand total
090 611 - 12.20018-000bars-3mgroundh-8-en
25.00040513225000

Chronifer L 18
~German no. ~1.4105 IL, ~X6CrMoS17,
AISI 430FR Solenoid,
ASTM -838-18 Alloy 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 25.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
010 916 - 74.500|220 217 - 414.50025-000bars-3mgroundh-8-en
22.00040513222000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: chamfered,
100% eddy current crack tested cl. 4
diam. 22.00 mm, tolerance ISO h8

bars 3mgroundh 8

607 kg

2400
Product total
Options total
Grand total
200 313 - 2.500|240 518 - 8.900|070 922 - 1010.800|210 218 - 87.60022-000bars-3mgroundh-8-en
20.00040513220000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid,
as per DIN EN 10088-3, UNS S43020
ASTM F-899, ASTM A959
ASTM A581/A581M (chem. only)
ASTM A0838-02R07 Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars:chamfered,
100% eddy current crack tested
diam. 20.00 mm, tolerance ISO h8

bars 3mgroundh 8

2 kg

0
Product total
Options total
Grand total
030 311 - 1.80020-000bars-3mgroundh-8-en
16.00040513216000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
gemäss DIN EN 10088-3
ASTM A959, UNS S43020
conforme EG/2002/95 ROHS directive
stainless steel, for solenoid valves
annealed, ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested cl,. 3
diam. 16.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
260 500 - 10.19016-000bars-3mgroundh-8-en
15.00040513215000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3
ASTM A959, UNS S43020
stainless steel, for solenoid valves
drawn, annealed, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.3
diam. 15.00 mm, tolerance ISO h8

bars 3mgroundh 8

75 kg

0
Product total
Options total
Grand total
291 015 - 75.10015-000bars-3mgroundh-8-en
12.00040513212000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838, Alloy 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 12.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
040 521 - 13.639|200 422 - 750.700|260 922 - 884.000|270 922 - 888.00012-000bars-3mgroundh-8-en
11.00040513211000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3
ASTM A959, UNS S43020
stainless steel, for solenoid valves
drawn,ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 11.00 mm, tolerance ISO h8

bars 3mgroundh 8

86 kg

0
Product total
Options total
Grand total
280 105 - 4.360|161 111 - 81.20011-000bars-3mgroundh-8-en
12.50040513812500

Chronifer L 18
Ergste 1.4105 IL
X6CrMoS18, ~AISI 430FR, RoHS conforme
as per EN 10088-3, UNS S43020
ASTM A838 Alloy Type 2, Grade 1
ASTM A581/A581M (chem. only)
stainless steel, for solenoid valves
drawn,ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed,chamfered,
100% eddy current crack tested cl.4
diam. 12.50 mm, +0.020/-0.010 mm

bars 3mgroundspec.

1333 kg

0
Product total
Options total
Grand total
120 122 - 120.800|061 022 - 1332.50012-500bars-3mgroundspec-en
32.00040513332000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
hardness: 80 – 88 HRB
ground, in 3m bars +30/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 32.00 mm, tolerance ISO h9

bars 3mgroundh 9

269 kg

1367
Product total
Options total
Grand total
140 120 - 268.90032-000bars-3mgroundh-9-en
50.00040513850000

Chronifer L 18,
AISI 430FR solenoid Quality,
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
in 3m lengths +30/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 50.00 mm, tolerance 0/-0.040 mm

bars 3mgroundspec.

1385 kg

1364
Product total
Options total
Grand total
200 515 - 114.231|191 122 - 1271.00050-000bars-3mgroundspec-en
26.00040513826000

Chronifer L 18,
AISI 430FR, ASTM A838-02, Alloy 2,Gr. 1
mat.no ~1.4105 (IL), ~X6CrMoS17, EN 10088-3 430FR solenoid Quality
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed, ground, hardness 80 – 88 HRB
in 3m lengths (+25.4/0mm)
end of bars: chamfered
eddycurrent & ultrasonic crack tested
diam. 26.00 mm 0/-0.060 mm

bars 3mgroundspec.

770 kg

0
Product total
Options total
Grand total
310 317 - 769.80026-000bars-3mgroundspec-en
63.50040513863500

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed ground, hardness 80-88 HRB
in 3m lengths (+25.4/0 mm)
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 63.50 mm (2 1/2″), tolerance 0/-0.076mm

bars 3mgroundspec.

1003 kg

0
Product total
Options total
Grand total
030 822 - 1002.80063-500bars-3mgroundspec-en
8.50040513208500

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
Aisi 430FR Solenoid
as per DIN EN 10088-3
stainless steel, for solenoid valves
annealed, ground, polished,
tensile strength Rm: 350-550 MPa
in 3m bars (+40/0mm)
pointed, chamfered end of bars
eddy current crack tested
diam. 8.50 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
8-500bars-3mgroundh-8-en
4.29540513904295

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Typ 2, Grade 1
stainless steel, for solenoid valves
drawn, annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddycurrent crack tested
diam. 4.295 mm, tolerance ISO h5

bars 3mgroundh 5

0 kg

0
Product total
Options total
Grand total
100 908 - 282.2004-295bars-3mgroundh-5-en
82.55040513882550

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed ground, hardness 80-88 HRB
in 3m lengths (+25.4/0 mm)
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 82.55 mm (3 1/4″), 0/-0.076mm

bars 3mgroundspec.

614 kg

738
Product total
Options total
Grand total
260 218 - 261.500|030 822 - 352.00082-550bars-3mgroundspec-en
75.00040513875000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
solenoid qualidy (MACH)
D.C. Coercimeter max 286 A/m
annealed ground, hardness 80-88 HRB
in 3m lengths (+25.4/0 mm)
100% eddycurrent + Ultrasonic tested
diam. 75.00 mm, tolerance 0/-0.076mm

bars 3mgroundspec.

608 kg

631
Product total
Options total
Grand total
010 722 - 608.00075-000bars-3mgroundspec-en
70.00040513870000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed ground, hardness 80-88 HRB
in 3m lengths (+25.4/0 mm)
100% eddycurrent + Ultrasonic tested
diam. 70.00 mm, 0/-0.076mm

bars 3mgroundspec.

879 kg

976
Product total
Options total
Grand total
290 323 - 352.000|130 423 - 527.00070-000bars-3mgroundspec-en
65.00040513865000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed ground, hardness 80-88 HRB
in 3m lengths (+25.4/0 mm)
100% eddycurrent + Ultrasonic tested
diam. 65.00 mm, 0/-0.076mm

bars 3mgroundspec.

1341 kg

0
Product total
Options total
Grand total
290 323 - 1134.000|160 323 - 207.00065-000bars-3mgroundspec-en
55.00040513855000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, hardness: 80 – 88 HRB
in 3m lengths +30/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 55.00 mm, tolerance 0/-0.076 mm

bars 3mgroundspec.

0 kg

1300
Product total
Options total
Grand total
300 418 - 108.00055-000bars-3mgroundspec-en
28.00040513828000

Chronifer L 18
AISI 430FR, ASTM A838-02, Alloy 2,Gr. 1
German no ~1.4105 (IL), ~X6CrMoS17,
EN 10088-3, 430FR solenoid Quality
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed, ground, hardness 80 – 88 HRB
in 3m lengths (+25.4/0mm)
end of bars: chamfered
eddycurrent crack tested
diam. 28.00 mm 0/-0.052mm (ISO h9)

bars 3mgroundspec.

979 kg

488
Product total
Options total
Grand total
110 211 - 4.700|070 922 - 281.000|080 922 - 631.000|120 922 - 62.60028-000bars-3mgroundspec-en
45.00040513845000

Chronifer L 18
AISI 430FR solenoid, EN10088-3 (09/05)
ASTM A838-02 Alloy 2, Grade 1,
no mat. ~1.4105(IL), ~X6CrMoS17,
stainless steel, for solenoid valves
Hardness 80 – 88 HRB
D.C. Coercimeter max 286 A/m
in 3m lengths +25.4/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 45.00 mm, tolerance 0/-0.076 mm

bars 3mgroundspec.

793 kg

1618
Product total
Options total
Grand total
190 618 - 327.000|170 119 - 45.000|030 822 - 326.400|181 022 - 95.00045-000bars-3mgroundspec-en
42.00040513842000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
in 3m lengths +25.4/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 42.00 mm, tolerance 0/-0.040 mm

bars 3mgroundspec.

1298 kg

627
Product total
Options total
Grand total
270 922 - 694.000|140 223 - 732.00042-000bars-3mgroundspec-en
40.00040513840000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, hardness 80 – 88 HRB
D.C. Coercimeter max 286 A/m
in 3m lengths +40/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 40.00 mm, tolerance 0/-0.070 mm

bars 3mgroundspec.

1020 kg

780
Product total
Options total
Grand total
200 720 - 299.500|290 323 - 720.00040-000bars-3mgroundspec-en
38.10040513838100

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
in 3m lengths +25.4/0mm
end of bars: chamfered
100% eddycurrent + Ultrasonic tested
diam. 38.10 mm (1 1/2″), 0/-0.040mm

bars 3mgroundspec.

1082 kg

305
Product total
Options total
Grand total
120 816 - 169.300|230 223 - 912.60038-100bars-3mgroundspec-en
30.17040513830170

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17,
as per DIN EN 10088-3 9/05
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max. 286 A/m
annealed, ground, hardness 80 – 88 HRB
in 3.05m lengths (+25.4/0mm)
diam. 30.17 mm, toleance +/- 0.033 mm

bars 3mgroundspec.

547 kg

0
Product total
Options total
Grand total
300 610 - 6.000|270 212 - 540.50030-170bars-3mgroundspec-en
30.00040513830000

Chronifer L 18,
Aisi 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17,
as per DIN EN 10088-3
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
annealed, ground, hardness 80 – 88 HRB
in 3m lengths (+25.4/0mm)
end of bars: chamfered, eddycurrent- and
ultrasonic inspected.
diam. 30.00 mm, tolerance ISO h9

bars 3mgroundspec.

1200 kg

513
Product total
Options total
Grand total
200 819 - 327.200|140 223 - 873.00030-000bars-3mgroundspec-en
10.00040513210000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid
as per EN 10088-3, UNS S43020
ASTM F-899, ASTM A959
stainless steel, for solenoid valves
annealed,ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 10.00 mm, tolerance ISO h8

bars 3mgroundh 8

4 kg

0
Product total
Options total
Grand total
160 512 - 3.60010-000bars-3mgroundh-8-en
28.00040511228000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A581/A581M (chem. only)
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 2.8m bars (+/-200 mm)
end of bars: chamfered,
100% eddy current crack tested cl. 3
diam. 28.00 mm, tolerance ISO h8

special lengthgroundh 8

672 kg

0
Product total
Options total
Grand total
280 819 - 218.300|250 919 - 454.00028-000special-lengthgroundh-8-en
8.00040513208000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, UNS S43020
as per DIN EN 10088-3,ASTM F-899
ASTM A959, AISI 430F
stainless steel, for solenoid valves
annealed, ground, polished,
tensile strength Rm: 350-550 MPa
in 3m bars (+40/0mm)
end of bars: chamfered
100% eddy current crack tested cl. 3
diam. 8.00 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
211 004 - 4.9008-000bars-3mgroundh-8-en
5.00040513105000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899-20
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
RoHS (Reach) conforme
drawn, annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddycurrent crack tested cl. 4
diam. 5.00 mm, tolerance ISO 286-2/h7

bars 3mgroundh 7

4031 kg

0
Product total
Options total
Grand total
210 318 - 733.450|210 219 - 1798.000|091 122 - 1500.0005-000bars-3mgroundh-7-en
10.00040513110000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid
as per EN 10088-3, UNS S43020
ASTM F-899, ASTM A959
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed,ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 10.00 mm, tolerance ISO h7

bars 3mgroundh 7

1820 kg

0
Product total
Options total
Grand total
190 418 - 166.800|300 119 - 1653.00010-000bars-3mgroundh-7-en
9.00040513109000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
Aisi 430FR Solenoid,as per EN 10088-3
UNS S43020, AISI 430F, ASTM F-899
ASTM A959, ASTM A582/A582M
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 9.00 mm, tolerance ISO h7

bars 3mgroundh 7

2445 kg

1600
Product total
Options total
Grand total
270 218 - 2445.3009-000bars-3mgroundh-7-en
8.00040513108000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR solenoid,
ASTM A838 Alloy Type 2, Grade 1
gemäss DIN EN 10088-3 12/14
ASTM A959, UNS S43020
conforme EG/2002/95 ROHS directive
stainless steel, for solenoid valves
annealed, ground, polished,
tensile strength Rm: 350-550 MPa
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl.4
diam. 8.00 mm, tolerance ISO h7

bars 3mgroundh 7

6134 kg

5000
Product total
Options total
Grand total
060 722 - 230.400|071 222 - 801.000|080 323 - 5104.0008-000bars-3mgroundh-7-en
7.00040513207000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
Aisi 430FR Solenoid, ASTM A959
UNS S43020, ASTM F-899, AISI 430F
as per DIN EN 10088-3
stainless steel, for solenoid valves
drawn,annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 7.00 mm, tolerance ISO h8

bars 3mgroundh 8

4 kg

0
Product total
Options total
Grand total
010 211 - 0.800|251 012 - 2.7007-000bars-3mgroundh-8-en
6.50040513106500

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, UNS S43020
as per DIN EN 10088-3 12/14
ASTM A581/A581M (chem. only)
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
drawn, annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddycurrent crack tested (cl. 4)
diam. 6.50 mm, tolerance ISO h7

bars 3mgroundh 7

1410 kg

0
Product total
Options total
Grand total
290 421 - 94.900|210 422 - 1314.8006-500bars-3mgroundh-7-en
6.00040513106000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430F, (corresp. AISI 430FR Solenoid)
as per DIN EN 10088-3 12/14
ASTM A838, Alloy Type 2, Grade 1
UNS S43020, RoHS confome
stainless steel, for solenoid valves
drawn, annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddycurrent crack tested (cl. 4)
diam. 6.00 mm, tolerance ISO h7

bars 3mgroundh 7

3792 kg

0
Product total
Options total
Grand total
241 022 - 1838.800|220 223 - 2263.0006-000bars-3mgroundh-7-en
4.50040513104500

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Typ 2, Grade 1
stainless steel, for solenoid valves
drawn, annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddycurrent crack tested
diam. 4.50 mm, tolerance ISO h7

bars 3mgroundh 7

1324 kg

0
Product total
Options total
Grand total
141 118 - 1324.1734-500bars-3mgroundh-7-en
12.00040513112000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17
AISI 430FR Solenoid, UNS S43020
as per DIN EN 10088-3, ASTM F-899
ASTM A582/A582M, A581/A581M (chem)
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 12.00 mm, tolerance ISO h7

bars 3mgroundh 7

2268 kg

0
Product total
Options total
Grand total
230 817 - 590.100|210 922 - 1677.60012-000bars-3mgroundh-7-en
4.00040513104000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899-12B
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
drawn, annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100 % eddycurrent crack tested cl. 4
diam. 4.00 mm, tolerance ISO h7

bars 3mgroundh 7

678 kg

800
Product total
Options total
Grand total
080 622 - 678.3004-000bars-3mgroundh-7-en
3.50040513103500

Chronifer L 18
Ergste 1.4105 IL, AISI 430FR
X6CrMoS18, as per DIN EN 10088-3
as per ASTM F-899, ASTM A959, UNS S43020
and ASTM A582/A582M
ASTM A838 Alloy Type 2, Grade 1, RoHS conforme
stainless steel, for solenoid valves
drawn, annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed/chamfered
eddycurrent crack tested class 4
diam. 3.50 mm, tolerance ISO h7

bars 3mgroundh 7

541 kg

0
Product total
Options total
Grand total
270 618 - 540.6003-500bars-3mgroundh-7-en
3.00040513103000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
suivant DIN EN 10088-3
ASTM A959, UNS S43020
stainless steel, for solenoid valves
RoHS directive confirm
drawn, ground, annealed, in 3m bars
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 3.00 mm, tolerance ISO h7

bars 3mgroundh 7

896 kg

0
Product total
Options total
Grand total
051 111 - 1.096|140 716 - 6.966|190 918 - 172.700|130 423 - 715.0003-000bars-3mgroundh-7-en
30.00040511230000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A581/A581M (chem. only)
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (0/-100mm)
end of bars: chamfered,
100% eddy current crack tested cl. 3
diam. 30.00 mm, tolerance ISO h8

special lengthgroundh 8

437 kg

0
Product total
Options total
Grand total
271 221 - 437.00030-000special-lengthgroundh-8-en
29.00040511229000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A581/A581M (chem. only)
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 2.8m bars (+/-200 mm)
end of bars: chamfered,
100% eddy current crack tested cl. 3
diam. 29.00 mm, tolerance ISO h8

special lengthgroundh 8

473 kg

0
Product total
Options total
Grand total
260 820 - 473.00029-000special-lengthgroundh-8-en
5.00040511005000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
RoHS (Reach) conforme
drawn, annealed, ground, polished,
in 1.5m bars (-20/+30 mm)
end of bars: chamfered,
100% eddycurrent crack tested cl. 3
diam. 5.00 mm, tolerance ISO h7

special lengthgroundh 6

1043 kg

0
Product total
Options total
Grand total
250 418 - 1042.6005-000special-lengthgroundh-6-en
11.30040513111300

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
(AISI 430FR Solenoid), UNS S43020
as per DIN EN 10088-3 12/14
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
drawn,annealed, ground, polished,
in 3m lengths (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested, cl.4
diam. 11.30 mm, tolerance ISO h7

bars 3mgroundh 7

6111 kg

0
Product total
Options total
Grand total
280 922 - 741.600|081 122 - 757.800|091 122 - 1515.000|151 122 - 3096.80011-300bars-3mgroundh-7-en
7.00040513107000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, RoHS conforme
gemäss DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
drawn, annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddycurrent crack tested (cl. 4)
diam. 7.00 mm, tolerance ISO h7

bars 3mgroundh 7

2510 kg

0
Product total
Options total
Grand total
280 318 - 255.500|011 221 - 642.400|161 122 - 1611.6007-000bars-3mgroundh-7-en
30.00040513130000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17,
as per DIN EN 10088-3 9/05
as per ASTM A838-02, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max. 286 A/m
annealed, ground, hardness 80 – 88 HRB
in 3.05m lengths (+25.4/0mm)
diam. 30.00 mm, toleance ISO h7

bars 3mgroundh 7

84 kg

0
Product total
Options total
Grand total
270 212 - 201.00030-000bars-3mgroundh-7-en
22.00040513122000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: chamfered,
100% eddy current crack tested cl. 4
diam. 22.00 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
071 004 - 183.08022-000bars-3mgroundh-7-en
3.70040513203700

Chronifer L 18
X6CrMoS17, AISI 430FR Solenoid
as per DIN EN 10088-3 12/14, UNS S43020
ASTM A581/A581M (chem.), ASTM A959
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+30/0 mm)
end of bars: chamfered,
eddycurrent cracked tested per EN10277-1, cl. 3
diam. 3.70 mm, tolerance ISO h8

bars 3mgroundh 8

300 kg

0
Product total
Options total
Grand total
300 119 - 300.0003-700bars-3mgroundh-8-en
12.70040513112700

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17
AISI 430FR Solenoid, UNS S43020
as per DIN EN 10088-3, ASTM F-899
ASTM A582/A582M, A581/A581M (chem)
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 12.70 mm (1/2”), tolerance ISO h7

bars 3mgroundh 7

645 kg

0
Product total
Options total
Grand total
240 719 - 645.30012-700bars-3mgroundh-7-en
25.40040513125400

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid,
as per DIN EN 10088-3, UNS S43020
ASTM F-899, ASTM A959
ASTM A581/A581M (chem. only)
ASTM A0838-02R07 Type 2 Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars:chamfered,
100% eddy current crack tested cl. 4
diam. 25.4 mm (1”), tolerance ISO h7

bars 3mgroundh 7

496 kg

0
Product total
Options total
Grand total
040 919 - 496.20025-400bars-3mgroundh-7-en
25.00040513125000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3
ASTM A959, UNS S43020
conforme EG/2002/95 ROHS directive
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl. 4
diam. 25.00 mm, tolerance ISO h7

bars 3mgroundh 7

1436 kg

0
Product total
Options total
Grand total
131 217 - 672.810|030 419 - 763.40025-000bars-3mgroundh-7-en
24.00040513124000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, AISI 430F
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A581/A581M (chem. only)
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: chamfered,
100% eddy current crack tested cl. 4
diam. 24.00 mm, tolerance ISO h7

bars 3mgroundh 7

1686 kg

0
Product total
Options total
Grand total
180 522 - 103.500|100 822 - 558.000|030 822 - 1024.00024-000bars-3mgroundh-7-en
23.00040513123000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, AISI 430F
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A581/A581M (chem. only)
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: chamfered,
100% eddy current crack tested cl. 3
diam. 23.00 mm, tolerance ISO h7

bars 3mgroundh 7

2164 kg

0
Product total
Options total
Grand total
210 218 - 1109.200|081 221 - 1055.00023-000bars-3mgroundh-7-en
21.00040513121000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
ASTM A959, UNS S43020
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: chamfered,
100% eddy current crack tested cl. 4
diam. 21.00 mm, tolerance ISO h7

bars 3mgroundh 7

1551 kg

0
Product total
Options total
Grand total
290 323 - 1551.00021-000bars-3mgroundh-7-en
19.00040513119000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
ASTM A581/A581M (chem. only)
ASTM A838 Alloy Type 2 Grade 1
as per DIN EN 10088-3
ASTM A959, UNS S43020
stainless steel, for solenoid valves
annealed, ground, polished, in 3m bars
end of bars: pointed/chamfered,
100% eddy current crack tested cl. 4
diam. 19.00 mm, tolerance ISO h7

bars 3mgroundh 7

1966 kg

0
Product total
Options total
Grand total
170 118 - 307.000|091 220 - 1659.20019-000bars-3mgroundh-7-en
17.00040513117000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid,as per EN 10088-3 12/14
AISI 430F UNS S43020, ASTM A959
ASTM A581/A581M (chem.), ASTM F-899
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
drawn,ground, polished, in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl.4
diam. 17.00 mm, tolerance ISO h7

bars 3mgroundh 7

4181 kg

1600
Product total
Options total
Grand total
240 719 - 7.000|230 322 - 1140.200|121 022 - 1430.400|290 323 - 1603.00017-000bars-3mgroundh-7-en
16.00040513116000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid,as per EN 10088-3 12/14
AISI 430F UNS S43020, ASTM A959
ASTM A581/A581M (chem.), ASTM F-899
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
drawn,ground, polished, in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl.4
diam. 16.00 mm, tolerance 286-2/h7

bars 3mgroundh 7

3632 kg

53
Product total
Options total
Grand total
091 220 - 302.800|071 222 - 1782.400|040 523 - 1547.00016-000bars-3mgroundh-7-en
15.00040513115000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, per EN 10088-3 12/14
AISI 430F UNS S43020,
ASTM A838 Alloy Type 2, Grade 1
stainless steel, for solenoid valves
drawn,ground, polished, in 3m bars (+50/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl.4
diam. 15.00 mm, tolerance ISO h7

bars 3mgroundh 7

1747 kg

0
Product total
Options total
Grand total
160 119 - 181.300|231 122 - 1565.60015-000bars-3mgroundh-7-en
14.00040513114000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
Aisi 430FR Solenoid
as per DIN EN 10088-3,ASTM F-899, UNS S43020
ASTM A581/A581M, (chem. only)
ASTM A582/A582M, ASTM A959
ASTM A838 AlloyType 2, Grade 1
stainless steel, for solenoid valves
annealed, ground, polished, in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100 % eddy current crack tested cl. 4
diam. 14.00 mm, tolerance ISO h7

bars 3mgroundh 7

385 kg

1600
Product total
Options total
Grand total
060 820 - 16.800|180 123 - 375.20014-000bars-3mgroundh-7-en
13.00040513113000

Chronifer L 18
Ergste 1.4105 IL, X6CrMoS17,
AISI 430FR Solenoid, ASTM F-899
as per DIN EN 10088-3 12/14
~ASTM A959, UNS S43020, RoHS conforme
ASTM A838 Alloy Type 2 Grade 1
stainless steel, for solenoid valves
annealed,ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 13.00 mm, tolerance ISO h7

bars 3mgroundh 7

1536 kg

0
Product total
Options total
Grand total
080 818 - 1213.600|130 319 - 321.90013-000bars-3mgroundh-7-en
60.00040513860000

Chronifer L 18,
AISI 430FR solenoid Quality
~1.4105 IL, ~X6CrMoS17, EN10088-3
as per ASTM A838-18, Alloy 2, Grade 1
stainless steel, for solenoid valves
D.C. Coercimeter max 286 A/m
in 3m lengths +25.4/0mm
end of bars: chamfered Ultrasonic crack tested
diam. 60.0 mm, tolerance 0/-0.0762 mm

bars 3mgroundspec.

1289 kg

0
Product total
Options total
Grand total
300 123 - 1096.000|150 223 - 193.00060-000bars-3mgroundspec-en
Werkstoff-Nr.1.4105 (IL)
DINX 6 CrMoS 17
AFNOR~ X 6 CrMoS 17 (alt Z8CF17)
AISI430 FR/430 F F 899
ISOX 6 CrMoS 17
EuronormX 6 CrMoS 17
Andere
C %≤ 0.08
Si %≤ 1.50
Mn %≤ 1.00
P %≤ 0.04
S %0.15-0.35
Cr %16.0-18.0
Mo %0.20-0.60
Ni %≤ 1.00
Cu %
Pb %
Zn %
Sn %
Fe %
O %
N %
H %
Ti %
Schnittgeschwindigkeit~ 50-60
Standardabmessung an Lager3-63.5 mm
