CHRONIFER LABOR M-PLUS

Brief description
Klein designation:CHRONIFER LABOR M-PLUS
Class of steels:free machining hardenable martensitic
stainless steel with addition of S
Material number:1.4197
StandardAISI:420 F Mod
Machinability:good
Hardening capability:up to 48 – 52 HRc
Polishing ability:not adapted for mirror polishing
Magnetism:ferromagnetic
Corrosion resistance:up to satisfactory in the hardened, polished and passivized condition
Uses:parts for numerous industrial applications
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
7.00046513007000
Brief description
Klein designation:CHRONIFER LABOR M-PLUS
Class of steels:free machining hardenable martensitic
stainless steel with addition of S
Material number:1.4197
StandardAISI:420 F Mod
Machinability:good
Hardening capability:up to 48 – 52 HRc
Polishing ability:not adapted for mirror polishing
Magnetism:ferromagnetic
Corrosion resistance:up to satisfactory in the hardened, polished and passivized condition
Uses:parts for numerous industrial applications
bars 3mgroundh 6

2042 kg

1600
Product total
Options total
Grand total
030 420 - 57.600|231 122 - 1324.9007-000bars-3mgroundh-6-en
5.00046513105000

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, ground, polished,
annealed,in 3m bars (+30/0mm)
pointed/chamfered, eddy current tested cl. 4
diam. 5.00 mm, tolerance ISO 286-2l/h7

bars 3mgroundh 7

0 kg

1600
Product total
Options total
Grand total
260 123 - 352.4505-000bars-3mgroundh-7-en
9.50046513009500

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 9.50 mm, tolerance ISO286-2/ h6

bars 3mgroundh 6

1925 kg

1020
Product total
Options total
Grand total
230 119 - 121.660|100 523 - 883.800|050 423 - 525.600|130 423 - 393.5009-500bars-3mgroundh-6-en
7.20046513007200

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
Swissline execution
diam. 7.20 mm, tolerance ISO h6

bars 3mgroundh 6

851 kg

0
Product total
Options total
Grand total
201 119 - 851.0007-200bars-3mgroundh-6-en
6.50046513006500

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars (+40/0mm)
stress relieved)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
Swissline (AMS-STD 2154A/AMS 2632A)
diam. 6.50 mm, tolerance ISO h6

bars 3mgroundh 6

237 kg

2400
Product total
Options total
Grand total
220 415 - 2.200|121 120 - 234.9006-500bars-3mgroundh-6-en
7.50046513007500

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, annealded, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
Swissline (AMS-STD 2154A , AMS 2630A)
diam. 7.50 mm, tolerance ISO h6

bars 3mgroundh 6

1041 kg

0
Product total
Options total
Grand total
170 914 - 116.300|291 117 - 372.200|190 619 - 552.4007-500bars-3mgroundh-6-en
8.10046513008100

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, annealed, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested, cl.4
diam. 8.10 mm, tolerance ISO h6

bars 3mgroundh 6

195 kg

800
Product total
Options total
Grand total
031 215 - 31.200|230 222 - 164.1008-100bars-3mgroundh-6-en
9.00046513009000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, annealded ground, polished,
stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current and ultrasonic instpected
Swissline AMS-STD 2154A, AMS 2632A
diam. 9.00 mm, tolerance ISO h6

bars 3mgroundh 6

984 kg

1600
Product total
Options total
Grand total
280 312 - 6.000|280 819 - 22.200|260 423 - 814.800|050 423 - 291.4009-000bars-3mgroundh-6-en
16.00046513016000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable, RoHS conforme
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
Swissline execution
diam. 16.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1382 kg

0
Product total
Options total
Grand total
300 414 - 9.300|230 920 - 9.200|080 921 - 83.100|151 122 - 1280.10016-000bars-3mgroundh-6-en
10.20046513010200

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
conforme EG/2002/95 ROHS directive
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+/-50mm)
end of bars: chamfered,
100% eddy current crack tested cl. 4
Swissline execution
diam. 10.20 mm, tolerance ISO h6

bars 3mgroundh 6

620 kg

0
Product total
Options total
Grand total
210 916 - 314.900|050 918 - 305.30010-200bars-3mgroundh-6-en
12.00046513012000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable, RoHS conforme
cold drawn, annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
Swissline (AMS-STD 2154A and AMS 2632A)
diam. 12.00 mm, tolerance ISO h6

bars 3mgroundh 6

1193 kg

800
Product total
Options total
Grand total
010 323 - 639.500|050 423 - 653.80012-000bars-3mgroundh-6-en
12.70046513012700

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 12.70 mm (1/2″), tolerance ISO h6

bars 3mgroundh 6

801 kg

0
Product total
Options total
Grand total
020 414 - 801.20012-700bars-3mgroundh-6-en
19.00046513019000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
Swissline execution as per AMS-STD 2154A, and AMS 2630C
diam. 19.00 mm, tolerance ISO h6

bars 3mgroundh 6

392 kg

0
Product total
Options total
Grand total
220 519 - 392.40019-000bars-3mgroundh-6-en
13.00046513013000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
Swissline, AMS-STD 2154A & AMS 2630C
diam. 13.00 mm, tolerance ISO h6

bars 3mgroundh 6

760 kg

800
Product total
Options total
Grand total
300 119 - 763.45013-000bars-3mgroundh-6-en
15.00046513015000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 3
diam. 15.00 mm, tolerance ISO h6

bars 3mgroundh 6

733 kg

2400
Product total
Options total
Grand total
080 720 - 16.200|270 121 - 733.80015-000bars-3mgroundh-6-en
17.00046513017000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 3
Swissline (US insp. AMS-STD 2154A, AMS 2630A)
diam. 17.00 mm, tolerance ISO h6

bars 3mgroundh 6

1423 kg

0
Product total
Options total
Grand total
081 117 - 80.000|231 019 - 801.400|161 220 - 691.60017-000bars-3mgroundh-6-en
6.20046513006200

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars
end of bars: pointed/chamered,
100% eddy current crack tested
Swissline execution
diam. 6.20 mm, tolerance ISO h6

bars 3mgroundh 6

80 kg

0
Product total
Options total
Grand total
030 616 - 79.9006-200bars-3mgroundh-6-en
18.00046513018000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered, Swissline
100% eddy current crack tested cl. 4
ultrasonic crack tested per AMS2630B
diam. 18.00 mm, tolerance ISO h6

bars 3mgroundh 6

824 kg

0
Product total
Options total
Grand total
070 212 - 79.400|020 513 - 383.800|250 919 - 361.20018-000bars-3mgroundh-6-en
6.35046513006350

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable, RoHS conforme
drawn, annealed, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
Swissline (Ultrasonic test as per
AMS-STD 2154A, AMS 2632A)
diam. 6.35 mm (1/4″), tolerance ISO h6

bars 3mgroundh 6

512 kg

800
Product total
Options total
Grand total
260 918 - 511.6006-350bars-3mgroundh-6-en
2.50046513002500

Chronifer Labor M-Plus
~mat. no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, ground, polished
stress relieved, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 2.50 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

3200
Product total
Options total
Grand total
181 018 - 478.2002-500bars-3mgroundh-6-en
5.10046513005100

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn,ground,polished,stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 5.10 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

800
Product total
Options total
Grand total
291 019 - 133.200|090 720 - 20.600|080 720 - 744.2005-100bars-3mgroundh-6-en
3.00046513003000

Chronifer Labor M-Plus
~mat.no 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
conforme EG/2002/95 ROHS directive
stainless steel, hardenable
drawn, annealed, ground, polished,
in 3m bars (+30/0mm)
stress relived by heat treatment
end of bars: pointed and chamfered
100% eddycurrent crack tested class 4
diam. 3.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

11200
Product total
Options total
Grand total
020 622 - 32.7563-000bars-3mgroundh-6-en
21.00046513021000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
Swissline execution as per AMS-STD 2154A, and AMS 2630C
diam. 21.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
290 622 - 767.60021-000bars-3mgroundh-6-en
2.20046513002200

Chronifer Labor M-Plus
~mat.no 1.4197, ~X20CrNiMoS13 1
per AISI 420F mod, ASTM F-899-20
stainless steel, hardenable
cold drawn, annealded,ground, polished, stress relieved
in 3m bars (+30/0mm)
end of bars. pointed, chamfered
eddycurrent crack tested cl.ass 4
diam. 2.20 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

3200
Product total
Options total
Grand total
160 222 - 171.6002-200bars-3mgroundh-6-en
2.30046513002300

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
as per EN 10088-3
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
eddy current crack tested
diam. 2.30 mm, tolerance ISO h6

bars 3mgroundh 6

193 kg

1000
Product total
Options total
Grand total
060 619 - 192.8002-300bars-3mgroundh-6-en
2.35046513002350

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
eddy current crack tested
diam. 2.35 mm, tolerance ISO h6

bars 3mgroundh 6

332 kg

800
Product total
Options total
Grand total
051 212 - 332.3952-350bars-3mgroundh-6-en
2.40046513002400

Chronifer Labor M-Plus
~no 1.4197, ~X20CrNiMoS13 1
ASTM F-899, AISI 420F mod,.
stainless steel, hardenable
cold drawn, annealed, ground polished,
stress relieved, in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl,. 4
diam. 2.40 mm, tolerance ISO h6

bars 3mgroundh 6

177 kg

1600
Product total
Options total
Grand total
211 020 - 176.8002-400bars-3mgroundh-6-en
2.80046513002800

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
ASTM F-899,as per AISI 420F mod.
stainless steel, hardenable
drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 2.80 mm, tolerance ISO h6

bars 3mgroundh 6

690 kg

0
Product total
Options total
Grand total
271 112 - 2.350|260 613 - 687.5002-800bars-3mgroundh-6-en
3.10046513003100

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars
end of bars: pointed/chamfered,
100 % eddy current crack tested
diam.3.10 mm, tolerance ISO h6

bars 3mgroundh 6

375 kg

0
Product total
Options total
Grand total
230 113 - 375.0003-100bars-3mgroundh-6-en
3.15046513003150

Chronifer Labor M-Plus
~no 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
stress relieved, RoHS conforme
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current tested, cl. 4
diam. 3.15 mm, tolerance ISO h6

bars 3mgroundh 6

219 kg

800
Product total
Options total
Grand total
160 817 - 218.5323-150bars-3mgroundh-6-en
3.17546513003175

Chronifer Labor M-Plus
no 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars
pointed/chamfered, eddy current tested
diam. 3.175 mm (1/8”), tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
261 017 - 110.900|260 219 - 1690.600|130 820 - 846.000|140 820 - 989.0003-175bars-3mgroundh-6-en
3.20046513003200

Chronifer Labor M-Plus
no 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars
pointed/chamfered, eddy current tested
diam.3.20 mm, tolerance ISO h6

bars 3mgroundh 6

336 kg

0
Product total
Options total
Grand total
080 812 - 39.900|130 515 - 296.0003-200bars-3mgroundh-6-en
3.50046513003500

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
drawn, ground, polished, stress relieved
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
100%, eddy current crack tested cl. 4
diam. 3.50 mm, tolerance ISO h6

bars 3mgroundh 6

898 kg

800
Product total
Options total
Grand total
251 018 - 170.600|010 223 - 827.5003-500bars-3mgroundh-6-en
4.00046513004000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished,
stress relieved, in 3m bars (+ 30/0 mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested cl.4
diam. 4.00 mm, tolerance ISO h6

bars 3mgroundh 6

717 kg

3200
Product total
Options total
Grand total
250 719 - 8.786|240 523 - 1770.2004-000bars-3mgroundh-6-en
4.10046513004100

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, stress relieved
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested cl. 4
diam. 4.10 mm, tolerance ISO h6

bars 3mgroundh 6

1036 kg

0
Product total
Options total
Grand total
251 012 - 347.600|150 818 - 688.5004-100bars-3mgroundh-6-en
4.20046513004200

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished,
stress relieved, in 3m bars (+ 30/0 mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested cl.4
diam. 4.20 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
170 919 - 135.100|050 520 - 879.000|080 322 - 728.000|070 322 - 1154.0004-200bars-3mgroundh-6-en
4.50046513004500

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, annealed ground,
polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested cl. 4
diam. 4.50 mm, tolerance ISO h6

bars 3mgroundh 6

1064 kg

800
Product total
Options total
Grand total
161 019 - 249.070|010 623 - 915.5004-500bars-3mgroundh-6-en
20.00046513020000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
Swissline execution as per AMS-STD 2154A, and AMS 2630C
diam. 20.00 mm, tolerance ISO h6

bars 3mgroundh 6

1283 kg

0
Product total
Options total
Grand total
190 320 - 92.700|050 423 - 1243.00020-000bars-3mgroundh-6-en
4.000465139040001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
end of bars: pointed, chamfered
diam. 4.00 mm, tolerance ISO h5

bars 3mgroundh 5

37 kg

0
Product total
Options total
Grand total
300 822 - 37.2004-000bars-3mgroundh-5-en
22.00046513022000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1, RoHS konform
as per AISI 420F mod. and ASTM F-899-20
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
Swissline execution as per AMS-STD 2154A, and AMS 2630C
diam. 22.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

494 kg

0
Product total
Options total
Grand total
060 722 - 493.90022-000bars-3mgroundh-6-en
5.00046513905000

Chronifer Labor M-Plus
~German no. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl.4
diam. 5.00 mm, tolerance ISO h5

bars 3mgroundh 5

195 kg

800
Product total
Options total
Grand total
240 523 - 642.4005-000bars-3mgroundh-5-en
1.50046513901500

Chronifer Labor M-Plus
~no.mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+30/0 mm)
end of bars: chamfered,
diam. 1.50 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

332 kg

0
Product total
Options total
Grand total
300 119 - 66.000|090 519 - 2.853|161 019 - 262.8001-500bars-3mgroundh-5-en
1.80046513901800

Chronifer Labor M-Plus
~no.mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899-20
stainless steel, hardenable
cold drawn, ground, polished, stress relieved
in 3m bars (+30/0 mm)
end of bars: chamfered,
diam. 1.80 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

0 kg

500
Product total
Options total
Grand total
170 712 - 760.4001-800bars-3mgroundh-5-en
2.30046513902300

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod
EN 10088-3 and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
eddy current crack tested
diam. 2.30 mm, tolerance ISO h5

bars 3mgroundh 5

56 kg

0
Product total
Options total
Grand total
251 012 - 16.200|160 113 - 40.2002-300bars-3mgroundh-5-en
3.50046513903500

Chronifer Labor M-Plus
~Mat no. 1.4197, ~X20CrNiMoS13 1
as per ASTM 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, in 3m bars (+30/0mm)
pointed/chamfered, eddy current tested
diam. 3.50 mm, tolerance ISO h5

bars 3mgroundh 5

387 kg

0
Product total
Options total
Grand total
220 212 - 387.2003-500bars-3mgroundh-5-en
4.00046513904000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899-20
stainless steel, hardenable
drawn, annealed, ground, stress relieved
in 3m bars (+40/0mm)
pointed/chamfered, eddy current tested cl.4
diam. 4.00 mm, tolerance ISO h5

bars 3mgroundh 5

390 kg

800
Product total
Options total
Grand total
010 721 - 390.0004-000bars-3mgroundh-5-en
4.20046513904200

Chronifer Labor M-Plus
~Mat no. 1.4197, ~X20CrNiMoS13 1
as per ASTM 420F mod
EN 10088-3 and ASTM F-899
stainless steel, hardenable
tensile strength Rm: 850 +/-75 MPa
cold drawn, ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 4.20 mm, tolerance ISO h5

bars 3mgroundh 5

48 kg

0
Product total
Options total
Grand total
231 013 - 48.4004-200bars-3mgroundh-5-en
5.000465139050001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
end of bars: pointed, chamfered
diam. 5.00 mm, tolerance ISO h5

bars 3mgroundh 5

79 kg

0
Product total
Options total
Grand total
300 822 - 78.8005-000bars-3mgroundh-5-en
1.20046513901200

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899-19
stainless steel, hardenable
drawn, ground, polished,
in 3m bars (+30/0mm)
diam. 1.20 mm, tolerance ISO h5

bars 3mgroundh 5

0 kg

250
Product total
Options total
Grand total
151 116 - 650.000|040 520 - 872.0001-200bars-3mgroundh-5-en
6.00046513906000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, stress relieved
in 3m bars (+40/0mm), straightness 0.4mm/m
end of bars: pointed, chamfered,
eddy current tested per EN10277-1,tab.1,cl. 4
100% ultrasonic tested as per AMS 2632A
and AMS-STD 2154A, Swissline
diam. 6.00 mm, tolerance ISO h5

bars 3mgroundh 5

495 kg

1600
Product total
Options total
Grand total
230 616 - 8.700|260 619 - 6.300|260 820 - 479.5006-000bars-3mgroundh-5-en
6.000465139060001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
end of bars: pointed/chamered,
diam. 6.00 mm, tolerance ISO h5

bars 3mgroundh 5

12 kg

0
Product total
Options total
Grand total
290 822 - 11.5006-000bars-3mgroundh-5-en
7.00046513907000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished,
stress relieved,in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
Swissline execution
diam. 7.00 mm, tolerance ISO h5

bars 3mgroundh 5

321 kg

1600
Product total
Options total
Grand total
300 322 - 421.1007-000bars-3mgroundh-5-en
9.00046513909000

Chronifer Labor M-Plus
~mat.no. 1.4197, ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested (cl. 4)
Swissline with ultrasonic test
diam. 9.00 mm, tolerance ISO h5

bars 3mgroundh 5

75 kg

800
Product total
Options total
Grand total
250 412 - 154.900|070 417 - 220.9009-000bars-3mgroundh-5-en
10.00046513910000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
conforme EG/2002/95 ROHS directive
stainless steel, hardenable
drawn, annealed, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl.4
Swissline AMS-STD 2154A, AMS 2632A
diam. 10.00 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

261 kg

1600
Product total
Options total
Grand total
231 019 - 261.00010-000bars-3mgroundh-5-en
11.00046513911000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899-20
conforme EG/2002/95 ROHS directive
stainless steel, hardenable
drawn, annealed, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl.4
Swissline AMS-STD 2154A, AMS 2632A
diam. 11.00 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

0 kg

800
Product total
Options total
Grand total
300 112 - 11.000|230 316 - 815.00011-000bars-3mgroundh-5-en
1.50046513001500

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, annealded,ground, polshied,
in 3m bars +/- 10 mm
eddycurrent crack tested Class 1
diam. 1.50 mm, tolerance ISO h6

bars 3mgroundh 6

353 kg

500
Product total
Options total
Grand total
200 319 - 3.400|210 619 - 274.500|021 220 - 110.2001-500bars-3mgroundh-6-en
1.30046513901300

Chronifer Labor M-Plus
~no.mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 3m bars (+30/0 mm)
diam. 1.30 mm, tolerance ISO h5

bars 3mgroundh 5

503 kg

0
Product total
Options total
Grand total
300 311 - 6.200|030 719 - 497.0001-300bars-3mgroundh-5-en
10.00046513810000

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars
end of bars: pointed/chamered,
diam. 10.00 mm, tolerance ISO h5

bars 3mgroundspec.

0 kg

0
Product total
Options total
Grand total
241 121 - 846.74810-000bars-3mgroundspec-en
25.00046513025000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899-20
stainless steel, hardenable, RoHS, conforme
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
Swissline execution as per AMS-STD 2154A, and AMS 2630C
diam. 25.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

511 kg

0
Product total
Options total
Grand total
010 323 - 511.20025-000bars-3mgroundh-6-en
6.10046513106100

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
as per AISI 420F mod
EN 10088-3 and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars
pointed/chamfered, eddy current tested
diam. 6.10 mm, tolerance ISO h7

bars 3mgroundh 7

202 kg

0
Product total
Options total
Grand total
150 803 - 201.7006-100bars-3mgroundh-7-en
2.000465131020001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
diam. 2.00 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
120 612 - 270.900|181 213 - 14.701|181 019 - 225.5002-000bars-3mgroundh-7-en
2.10046513102100

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, polished, in 3m bars
pointed, chamfered
eddycurrent crack tested
diam. 2.10 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
151 204 - 187.000|300 615 - 268.0002-100bars-3mgroundh-7-en
3.000465131030001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
diam. 3.00 mm, tolerance ISO h7

bars 3mgroundh 7

81 kg

0
Product total
Options total
Grand total
010 922 - 80.5333-000bars-3mgroundh-7-en
3.500465131035001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
diam. 3.50 mm, tolerance ISO h7

bars 3mgroundh 7

67 kg

0
Product total
Options total
Grand total
270 822 - 67.4003-500bars-3mgroundh-7-en
3.60046513103600

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, polished, in 3m bars
pointed/chamfered, eddy current tested
diam. 3.60 mm, tolerance ISO h7

bars 3mgroundh 7

87 kg

0
Product total
Options total
Grand total
150 307 - 87.3003-600bars-3mgroundh-7-en
4.80046513104800

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
as per EN 10088-3
stainless steel, hardenable
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 4.80 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
190 808 - 34.0004-800bars-3mgroundh-7-en
5.000465131050001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
RoHS, Reach konform
drawn, ground, in 3m bars (+50/0mm)
diam. 5.00 mm, tolerance ISO h7

bars 3mgroundh 7

1 kg

0
Product total
Options total
Grand total
090 622 - 0.6605-000bars-3mgroundh-7-en
6.500465131065001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
end of bars: pointed/chamered,
diam. 7.00 mm, tolerance ISO h7

bars 3mgroundh 7

98 kg

0
Product total
Options total
Grand total
090 622 - 98.2006-500bars-3mgroundh-7-en
8.00046513808000

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
end of bars: pointed/chamered,
diam. 8.00 mm, tolerance ISO h5

bars 3mgroundspec.

0 kg

0
Product total
Options total
Grand total
040 321 - 53.2628-000bars-3mgroundspec-en
7.000465131070001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars (+50/0mm)
end of bars: pointed/chamered,
diam. 7.00 mm, tolerance ISO h7

bars 3mgroundh 7

79 kg

0
Product total
Options total
Grand total
160 522 - 79.4007-000bars-3mgroundh-7-en
7.20046513107200

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 7.20 mm, tolerance ISO h7

bars 3mgroundh 7

293 kg

0
Product total
Options total
Grand total
160 714 - 293.0007-200bars-3mgroundh-7-en
8.00046513108000

Chronifer Labor M-Plus
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
Swissline (AMS-STD2154A/AMS 2632A)
diam. 8.00 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
030 310 - 42.822|060 612 - 504.6008-000bars-3mgroundh-7-en
8.000465131080001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars
end of bars: pointed/chamered,
diam. 8.00 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
250 809 - 29.390|071 216 - 293.0008-000bars-3mgroundh-7-en
8.50046513108500

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars
end of bars: pointed/chamered,
diam. 8.50 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
051 207 - 50.9088-500bars-3mgroundh-7-en
10.000465131100001

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 3m bars
end of bars: pointed/chamered,
diam. 10.00 mm, tolerance ISO h7

bars 3mgroundh 7

1 kg

0
Product total
Options total
Grand total
180 522 - 1.30010-000bars-3mgroundh-7-en
10.50046513110500

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
as per EN 10088-3
stainless steel, hardenable
drawn, ground, polished, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 10.50 mm, tolerance ISO h7

bars 3mgroundh 7

40 kg

0
Product total
Options total
Grand total
220 207 - 26.350|291 107 - 13.30010-500bars-3mgroundh-7-en
13.50046513113500

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 3m bars
pointed/chamfered, eddy current tested
diam. 13.50 mm, tolerance ISO h7

bars 3mgroundh 7

379 kg

0
Product total
Options total
Grand total
210 504 - 379.00013-500bars-3mgroundh-7-en
1.60046513001600

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
AISI 420F mod. ASTM F-899
hardenable stainless steel,
cold drawn, annealed, ground, polished,
stress relieved, in 3m bars (+/- 10 mm)
end of bars: chamfered
diam. 1.60 mm, tolerance ISO h6

bars 3mgroundh 6

738 kg

0
Product total
Options total
Grand total
281 118 - 6.653|060 219 - 44.800|090 322 - 686.1001-600bars-3mgroundh-6-en
1.40046500301400

Chronifer Labor M-Plus
~no 1.4197, ~X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
cold drawn, annealed,
designed for redrawing purposes
tensile strength Rm 750-850MPa
in coils of apprx. 25kg
diam. 1.40 mm, tolerance ISO fg7

in spoolsdrawnh 9

1015 kg

0
Product total
Options total
Grand total
121 218 - 510.400|090 119 - 504.5501-400in-spoolsdrawnh-9-en
1.30046513001300

Chronifer Labor M-Plus
~nol mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
stainless steel, hardenable
precisely cold drawn, ground, polished
in 3m bars (+/-10mm)
diam. 1.30 mm, tolerance ISO h6

bars 3mgroundh 6

586 kg

0
Product total
Options total
Grand total
121 016 - 148.200|170 419 - 149.100|240 221 - 488.5001-300bars-3mgroundh-6-en
0.60046500900600

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, polished,
on spools type SK370 (max 10kg)
diam. 0.60 mm, tolerance ISO fg5

in spoolsdrawnh 5

173 kg

0
Product total
Options total
Grand total
250 918 - 173.2000-600in-spoolsdrawnh-5-en
1.65046500701650

Chronifer Labor M-Plus
~no 1.4197 ~ X20CrNiMoS13 1
as per ASTM F-899, AISI 420F mod.
stainless steel, hardenable
precisely cold drawn, polished, in coils
diam. 1.65 mm, tolerance ISO fg7

in spoolsdrawnfg 7

892 kg

0
Product total
Options total
Grand total
140 812 - 13.900|100 719 - 476.850|020 621 - 401.6001-650in-spoolsdrawnfg-7-en
1.70046500701700

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, polished, in coils
diam. 1.70 mm, tolerance ISO fg7

in spoolsdrawnfg 7

0 kg

0
Product total
Options total
Grand total
111 109 - 447.9001-700in-spoolsdrawnfg-7-en
2.00046500702000

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod, ASTM F-899
stainless steel, hardenable
precisely cold drawn, polished,
in coils for ESCO machines
diam. 2.00 mm, tolerance ISO fg7

in spoolsdrawnfg 7

262 kg

0
Product total
Options total
Grand total
060 618 - 262.0002-000in-spoolsdrawnfg-7-en
2.10046500702100

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in coils
diam. 2.10 mm, tolerance ISO fg7

in spoolsdrawnfg 7

200 kg

1200
Product total
Options total
Grand total
200 411 - 199.7002-100in-spoolsdrawnfg-7-en
2.50046500702500

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, polished,
in coils of 25 +/-5kg
diam. 2.50 mm, tolerance ISO fg7

in spoolsdrawnfg 7

658 kg

0
Product total
Options total
Grand total
030 719 - 657.8002-500in-spoolsdrawnfg-7-en
0.35046500800350

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, polished, on spool
diam. 0.35 mm, tolerance ISO js3

in spoolsdrawnspec.

0 kg

0
Product total
Options total
Grand total
0-350in-spoolsdrawnspec-en
0.70046500900700

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, polished
on spools SK370 (~10 kg)
diam. 0.70 mm, tolerance ISO fg5

in spoolsdrawnh 5

145 kg

0
Product total
Options total
Grand total
150 818 - 144.7460-700in-spoolsdrawnh-5-en
1.50046500701500

Chronifer Labor M-Plus
~no 1.4197 ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
cold drawn, polished, in coils
diam. 1.50 mm, tolerance ISO fg7

in spoolsdrawnfg 7

57 kg

0
Product total
Options total
Grand total
090 518 - 57.4001-500in-spoolsdrawnfg-7-en
1.00046502001000

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable, RoHS conforme
cold drawn, polished, in 2m bars
diam. 1.00 mm, tolerance ISO h6

bars 2mdrawnh 6

0 kg

0
Product total
Options total
Grand total
161 012 - 0.600|030 316 - 217.100|040 419 - 48.4001-000bars-2mdrawnh-6-en
2.00046502002000

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in 2m bars
end of bars: pointed, chamfered
diam. 2.00 mm, tolerance ISO h6

bars 2mdrawnh 6

0 kg

0
Product total
Options total
Grand total
111 120 - 639.6002-000bars-2mdrawnh-6-en
0.80046502100800

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
~W-Nr. 1.4197, ~X20CrNiMoS13 1
gemäss AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, in 2m bars
diam. 0.80 mm, tolerance ISO h7

bars 2mdrawnh 7

10 kg

0
Product total
Options total
Grand total
051 006 - 9.9000-800bars-2mdrawnh-7-en
1.00046502101000

Chronifer Labor M-Plus
~no 1.4197, ~X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
cold drawn, polished, in 2m bars (+/-10 mm)
diam. 1.00 mm, tolerance ISO h7

bars 2mdrawnh 7

0 kg

0
Product total
Options total
Grand total
210 121 - 37.500|080 922 - 460.8101-000bars-2mdrawnh-7-en
1.25046502101250

Chronifer Labor M-Plus
~mat.no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, in 2m bars
pointed/chamfered
diam. 1.25 mm, tolerance ISO h7

bars 2mdrawnh 7

0 kg

0
Product total
Options total
Grand total
220 507 - 0.2301-250bars-2mdrawnh-7-en
1.40046502101400

Chronifer Labor M-Plus
~Mat no. 1.4197, ~X20CrNiMoS13 1
as per ASTM 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, polished, in 2m bars
diam. 1.40 mm, tolerance ISO h7

bars 2mdrawnh 7

91 kg

0
Product total
Options total
Grand total
231 019 - 79.600|280 922 - 10.9001-400bars-2mdrawnh-7-en
1.50046502101500

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, polished, in 2m bars
diam. 1.50 mm, tolerance ISO h7

bars 2mdrawnh 7

92 kg

0
Product total
Options total
Grand total
120 314 - 21.840|211 118 - 70.0001-500bars-2mdrawnh-7-en
1.60046500701600

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
AISI 420 F mod. ASTM F-899
stainless steel, hardenable
drawn, polished, in coils
diam. 1.60 mm, tolerance ISO fg7

in spoolsdrawnfg 7

1520 kg

0
Product total
Options total
Grand total
121 218 - 263.000|160 119 - 372.200|180 919 - 438.000|250 919 - 446.3001-600in-spoolsdrawnfg-7-en
1.30046500701300

Chronifer Labor M-Plus
~mat. no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, polished, in coils
diam. 1.30 mm, tolerance ISO fg7

in spoolsdrawnfg 7

1131 kg

0
Product total
Options total
Grand total
141 118 - 359.000|121 218 - 402.850|270 219 - 369.0001-300in-spoolsdrawnfg-7-en
2.00046502102000

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
cold drawn, in 2m bars (+30/0mm)
end of bars: chamfered
diam. 2.00 mm, tolerance ISO h7

bars 2mdrawnh 7

0 kg

0
Product total
Options total
Grand total
110 717 - 307.3002-000bars-2mdrawnh-7-en
1.00046500601000

Chronifer Labor M-Plus
~no 1.4197 ~ X20CrNiMoS13 1
as per ASTM F-899, AISI 420F mod.
stainless steel, hardenable
precisely cold drawn, polished,
in coils of apprx. 20kg
diam. 1.00 mm, tolerance ISO fg6

in spoolsdrawnfg 6

674 kg

0
Product total
Options total
Grand total
051 218 - 158.800|250 919 - 515.0001-000in-spoolsdrawnfg-6-en
1.60046512901600

Chronifer Labor M-Plus
~no.mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, ground, polished,
in 2m bars +/- 10 mm
end of bars: chamfered,
eddycurrent crack tested
diam. 1.60 mm, tolerance ISO h5

bars 2mgroundh 5

0 kg

0
Product total
Options total
Grand total
230 622 - 39.9731-600bars-2mgroundh-5-en
0.50046500100500

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, on spool
diam. 0.50 mm, tolerance ISO h7

in spoolsdrawnh 7

0 kg

0
Product total
Options total
Grand total
130 612 - 98.700|270 922 - 801.0000-500in-spoolsdrawnh-7-en
1.70046500301700

Chronifer Labor M-Plus
~no 1.4197, ~X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
cold drawn, annealed,
designed for redrawing purposes
tensile strength Rm 750-850MPa
in coils of apprx. 25kg
diam. 1.70 mm, tolerance ISO fg7

in spoolsdrawnh 9

1324 kg

0
Product total
Options total
Grand total
080 119 - 436.300|090 119 - 458.500|100 119 - 429.4001-700in-spoolsdrawnh-9-en
1.10046500501100

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, polished, in coils
diam. 1.10 mm, tolerance ISO fg8

in spoolsdrawnfg 8

186 kg

0
Product total
Options total
Grand total
080 405 - 186.4001-100in-spoolsdrawnfg-8-en
2.40046500502400

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in coils
diam. 2.40 mm, tolerance ISO fg8

in spoolsdrawnfg 8

0 kg

0
Product total
Options total
Grand total
140 710 - 133.8002-400in-spoolsdrawnfg-8-en
3.00046500503000

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, polished, in coils
diam. 3.00 mm, tolerance ISO fg8

in spoolsdrawnfg 8

165 kg

0
Product total
Options total
Grand total
241 204 - 165.1003-000in-spoolsdrawnfg-8-en
0.80046500600800

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
precisely cold drawn, polished,
in coils of ~10kg each
diam. 0.80 mm, tolerance ISO fg6

in spoolsdrawnfg 6

159 kg

0
Product total
Options total
Grand total
050 918 - 159.3500-800in-spoolsdrawnfg-6-en
1.10046500601100

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
AISI 420F mod. , ASTM F-899-20
stainless steel, hardenable
precisely drawn, polished,
in coils of 10-13kg
diam. 1.10 mm, tolerance ISO fg6

in spoolsdrawnfg 6

0 kg

500
Product total
Options total
Grand total
100 610 - 41.700|220 420 - 146.5001-100in-spoolsdrawnfg-6-en
1.25046500701250

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, polished, stress relieved
in coils of apprx. 20kg
diam. 1.25 mm, tolerance ISO fg7

in spoolsdrawnfg 7

317 kg

500
Product total
Options total
Grand total
240 822 - 317.0001-250in-spoolsdrawnfg-7-en
1.20046500601200

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
AISI 420F mod. , ASTM F-899-20
stainless steel, hardenable
precisely drawn, polished,
in coils of 10-13kg
diam. 1.20 mm, tolerance ISO fg6

in spoolsdrawnfg 6

0 kg

1300
Product total
Options total
Grand total
030 912 - 234.000|231 019 - 624.0001-200in-spoolsdrawnfg-6-en
1.50046500601500

Chronifer Labor M-Plus
~no 1.4197 ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899-20
stainless steel, hardenable
cold drawn, polished, in coils of 10-13kg
diam. 1.50 mm, tolerance ISO fg6

in spoolsdrawnfg 6

0 kg

500
Product total
Options total
Grand total
260 612 - 719.5001-500in-spoolsdrawnfg-6-en
1.80046500601800

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
AISI 420 F mod., ASTM F-899-20
stainless steel, hardenable
cold drawn, polished, stress relieved
in coils of 20-25kg
diam. 1.80 mm, tolerance ISO fg6

in spoolsdrawnfg 6

0 kg

1600
Product total
Options total
Grand total
260 514 - 23.9781-800in-spoolsdrawnfg-6-en
1.90046500601900

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod, ASTM F-899
stainless steel, hardenable, RoHS conform
precisely cold drawn, polished,
in coils for ESCO machines
diam. 1.90 mm, tolerance ISO fg6

in spoolsdrawnfg 6

100 kg

800
Product total
Options total
Grand total
280 721 - 100.0001-900in-spoolsdrawnfg-6-en
0.80046500700800

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, in coils
diam. 0.80 mm, tolerance ISO fg7

in spoolsdrawnfg 7

25 kg

0
Product total
Options total
Grand total
051 006 - 25.3000-800in-spoolsdrawnfg-7-en
0.90046500700900

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, polished, in coils
diam. 0.90 mm, tolerance ISO fg7

in spoolsdrawnfg 7

263 kg

0
Product total
Options total
Grand total
200 510 - 236.100|031 210 - 26.9000-900in-spoolsdrawnfg-7-en
1.20046500701200

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, polished, in coils
diam. 1.20 mm, tolerance ISO fg7

in spoolsdrawnfg 7

91 kg

0
Product total
Options total
Grand total
171 018 - 91.2001-200in-spoolsdrawnfg-7-en
1.55046502101550

Chronifer Labor M-Plus
~mat.no. ~1.4197, X20CrNiMoS13 1
ASTM F-899, AISI 420 F mod.
stainless steel, hardenable
cold drawn, polished, in 2m bars
end of bars: pointed, chamfered
diam. 1.55 mm, tolerance ISO h7

bars 2mdrawnh 7

50 kg

0
Product total
Options total
Grand total
100 914 - 49.9001-550bars-2mdrawnh-7-en
1.40046500701400

Chronifer Labor M-Plus
~mat. no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
drawn, polished, in coils
diam. 1.40 mm, tolerance ISO fg7

in spoolsdrawnfg 7

713 kg

800
Product total
Options total
Grand total
231 019 - 140.000|280 922 - 573.0001-400in-spoolsdrawnfg-7-en
0.90046502200900

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, in 2m bars
diam. 0.90 mm, tolerance ISO h8

bars 2mdrawnh 8

88 kg

0
Product total
Options total
Grand total
290 410 - 88.0000-900bars-2mdrawnh-8-en
1.20046512001200

Chronifer Labor M-Plus
~mat.no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, annealed, ground, polished
in 2m bars (+/-10 mm)
diam. 1.20 mm, tolerance ISO h6

bars 2mgroundh 6

0 kg

300
Product total
Options total
Grand total
101 110 - 46.600|220 212 - 102.0501-200bars-2mgroundh-6-en
1.10046503201100

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in 3m bars
diam. 1.10 mm, tolerance ISO h8

bars 3mdrawnh 8

74 kg

0
Product total
Options total
Grand total
261 101 - 74.2501-100bars-3mdrawnh-8-en
1.40046503201400

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
precisely cold drawn, polished,
in 3m bars (+40/0mm)
diam. 1.40 mm, tolerance ISO h8

bars 3mdrawnh 8

15 kg

0
Product total
Options total
Grand total
200 902 - 0.750|270 505 - 6.300|301 007 - 8.2001-400bars-3mdrawnh-8-en
1.70046503201700

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, polished, in 3m bars
diam. 1.70 mm, tolerance ISO h8

bars 3mdrawnh 8

84 kg

0
Product total
Options total
Grand total
161 204 - 0.742|220 611 - 83.6001-700bars-3mdrawnh-8-en
2.40046503202400

Chronifer Labor M-Plus
~mat. no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, polished, in 3m bars
pointed/chamfered
diam. 2.40 mm, tolerance ISO h8

bars 3mdrawnh 8

0 kg

0
Product total
Options total
Grand total
140 218 - 159.7502-400bars-3mdrawnh-8-en
1.60146503801601

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
as per ASTM F-899, AISI 420F mod.
stainless steel, hardenable
drawn, polished, in 3m bars
diam. 1.601 mm, tolerance 0/-0.005 mm

bars 3mdrawnspec.

45 kg

0
Product total
Options total
Grand total
220 611 - 45.3001-601bars-3mdrawnspec-en
1.00046512001000

Chronifer Labor M-Plus
~German no 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, ground, in 2m bars (+/- 10mm)
diam. 1.00 mm, tolerance ISO h6

bars 2mgroundh 6

214 kg

0
Product total
Options total
Grand total
230 119 - 213.6001-000bars-2mgroundh-6-en
1.10046512001100

Chronifer Labor M-Plus
~mat.no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, annealed, ground, polished
in 2m bars (+/- 10 mm)
diam. 1.10 mm, tolerance ISO h6

bars 2mgroundh 6

4 kg

0
Product total
Options total
Grand total
170 908 - 3.8001-100bars-2mgroundh-6-en
1.30046512001300

Chronifer Labor M-Plus
~nol mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
stainless steel, hardenable
precisely cold drawn, annealed,
ground, polished
in 2m bars (+30/0mm)
diam. 1.30 mm, tolerance ISO h6

bars 2mgroundh 6

349 kg

0
Product total
Options total
Grand total
060 319 - 29.800|300 920 - 319.5001-300bars-2mgroundh-6-en
1.50046512901500

Chronifer Labor M-Plus
~no.mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, annealed, ground, polished,
stress relieved
in 2m bars (+/- 10mm)
end of bars: chamfered,
eddycurrent crack tested cl. 4
diam. 1.50 mm, tolerance ISO h5

bars 2mgroundh 5

0 kg

1226
Product total
Options total
Grand total
130 422 - 19.917|060 422 - 111.200|010 323 - 149.300|220 323 - 24.5001-500bars-2mgroundh-5-en
1.40046512001400

Chronifer Labor M-Plus
~nol mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod.,ASTM F-899
stainless steel, hardenable
precisly cold drawn, ground, polished
in 2m bars (+/- 10mm)
diam. 1.40 mm, tolerance ISO h6

bars 2mgroundh 6

0 kg

500
Product total
Options total
Grand total
250 412 - 484.5001-400bars-2mgroundh-6-en
1.60046512001600

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
gemäss AISI 420F mod. und ASTM F-899
hardenable stainless steel,
drawn, annealed, ground, polished
stress relieved
in 2m bars (+/-10mm)
end of bars: chamfered, crack tested cl. 1
diam. 1.60 mm, tolerance ISO h6

bars 2mgroundh 6

228 kg

500
Product total
Options total
Grand total
010 822 - 227.8001-600bars-2mgroundh-6-en
2.00046512002000

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod and ASTM F-899-20
stainless steel, hardenable
drawn, annealed, ground, polished,
stress relieved, in 2m bars (+/- 10mm)
end of bars: pointed, chamfered,
eddy current crack tested cl. 4
diam. 2.00 mm, tolerance ISO 286-2/h6

bars 2mgroundh 6

188 kg

1300
Product total
Options total
Grand total
100 816 - 0.860|170 821 - 0.500|231 122 - 333.9522-000bars-2mgroundh-6-en
2.20046512002200

Chronifer Labor M-Plus
~German no 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod
EN 10088-3 and ASTM F-899
stainless steel, hardenable
drawn, annealded, ground, polished,
stress relieved
in 2m bars (+20/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 2.20 mm, tolerance ISO h6

bars 2mgroundh 6

198 kg

500
Product total
Options total
Grand total
141 222 - 197.9002-200bars-2mgroundh-6-en
2.50046512102500

Sandvik 4C27A
~no 1.4197, ~X20CrNiMoS13 1
stainless steel, hardenable
drawn, ground, in 2m bars (+50/0mm)
diam. 2.50 mm, tolerance ISO h7

bars 2mgroundh 7

34 kg

0
Product total
Options total
Grand total
130 922 - 34.3002-500bars-2mgroundh-7-en
1.20046512901200

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 2m bars
diam. 1.20 mm, tolerance ISO h5

bars 2mgroundh 5

44 kg

300
Product total
Options total
Grand total
120 521 - 43.7641-200bars-2mgroundh-5-en
1.40046512901400

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, ground, polished, in 2m bars
diam. 1.40 mm, tolerance ISO h5

bars 2mgroundh 5

31 kg

0
Product total
Options total
Grand total
211 118 - 30.7001-400bars-2mgroundh-5-en
1.00046503201000

Chronifer Labor M-Plus
mat. no 1.4197, ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
cold drawn, polished, in 3m bars
diam. 1.00 mm, tolerance ISO h8

bars 3mdrawnh 8

43 kg

0
Product total
Options total
Grand total
231 205 - 9.854|251 109 - 32.7001-000bars-3mdrawnh-8-en
2.50046503102500

Chronifer Labor M-Plus
~mat. no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
diam. 2.50 mm, tolerance ISO h7

bars 3mdrawnh 7

0 kg

0
Product total
Options total
Grand total
230 709 - 2.995|190 220 - 642.5002-500bars-3mdrawnh-7-en
1.30046502201300

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in 2m bars
diam. 1.30 mm, tolerance ISO h8

bars 2mdrawnh 8

9 kg

0
Product total
Options total
Grand total
230 311 - 8.7001-300bars-2mdrawnh-8-en
1.00046503001000

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in 3m bars
diam. 1.00 mm, tolerance ISO h6

bars 3mdrawnh 6

60 kg

0
Product total
Options total
Grand total
080 405 - 59.8071-000bars-3mdrawnh-6-en
1.65046502201650

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in 2m bars
diam. 1.65 mm, tolerance ISO h8

bars 2mdrawnh 8

14 kg

0
Product total
Options total
Grand total
140 812 - 13.6001-650bars-2mdrawnh-8-en
2.00046502202000

Chronifer Labor M-Plus
~W-Nr. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod, ASTM F-899
stainless steel, hardenable
drawn, polished, in 2m bars
diam. 2.00 mm, tolerance ISO h8

bars 2mdrawnh 8

0 kg

0
Product total
Options total
Grand total
2-000bars-2mdrawnh-8-en
2.10046502202100

Chronifer Labor M-Plus
no 1.4197 X22CrNiMoS13 1
stainless steel, hardenable
drawn, polished, in 2m bars
diam. 2.10 mm, tolerance ISO h8

bars 2mdrawnh 8

35 kg

0
Product total
Options total
Grand total
290 803 - 34.5452-100bars-2mdrawnh-8-en
0.40246502800402

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, in 2m bars
diam. 0.402 mm, tolerance ISO js5 (+/-0.002)

bars 2mdrawnspec.

0 kg

0
Product total
Options total
Grand total
050 314 - 69.4790-402bars-2mdrawnspec-en
0.60046502800600

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
stainless steel, hardenable
cold drawn, in 2m bars
diam. 0.60 mm, tolerance ISO h4

bars 2mdrawnspec.

1 kg

0
Product total
Options total
Grand total
150 818 - 0.7110-600bars-2mdrawnspec-en
0.60246502800602

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, in 2m bars
diam. 0.402 mm, tolerance ISO js5 (+/-0.002)

bars 2mdrawnspec.

0 kg

0
Product total
Options total
Grand total
100 712 - 4.690|250 619 - 22.2000-602bars-2mdrawnspec-en
1.50046502901500

Chronifer Labor M-Plus
~no.mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
cold drawn, polished,
in 2m bars (+/- 10mm)
end of bars: chamfered,
diam. 1.50 mm, tolerance ISO h5

bars 2mdrawnh 5

153 kg

0
Product total
Options total
Grand total
200 411 - 12.360|190 418 - 140.2001-500bars-2mdrawnh-5-en
1.20046503101200

Chronifer Labor M-Plus
~German no. 1.4197, ~X20CrNiMoS13 1
AISI 420F mod. ASTM F-899
stainless steel, hardenable
cold drawn, polished, in 3m bars
diam. 1.20 mm, tolerance ISO h7

bars 3mdrawnh 7

0 kg

0
Product total
Options total
Grand total
230 622 - 39.9731-200bars-3mdrawnh-7-en
2.20046503102200

Chronifer Labor M-Plus
~mat. no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, polished, in 3m bars (+30/0mm)
end of bars: pointed, chamfered
diam. 2.20 mm, tolerance ISO h7

bars 3mdrawnh 7

0 kg

0
Product total
Options total
Grand total
070 414 - 168.1452-200bars-3mdrawnh-7-en
1.25046503101250

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
precisely cold drawn, in 3m bars
diam. 1.25 mm, tolerance ISO h7

bars 3mdrawnh 7

0 kg

0
Product total
Options total
Grand total
251 018 - 40.0001-250bars-3mdrawnh-7-en
1.30046503101300

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899
stainless steel, hardenable
drawn, polished, in 3m bars
diam. 1.30 mm, tolerance ISO h7

bars 3mdrawnh 7

3 kg

0
Product total
Options total
Grand total
171 018 - 3.4001-300bars-3mdrawnh-7-en
1.40046503101400

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
AISI 420F mod., ASTM F-899
stainless steel, hardenable
cold drawn, polished, in 3m bars
diam. 1.40 mm, tolerance ISO h7

bars 3mdrawnh 7

132 kg

0
Product total
Options total
Grand total
231 019 - 127.700|080 622 - 4.6001-400bars-3mdrawnh-7-en
1.50046503101500

Chronifer Labor M-Plus
no 1.4197 X20CrNiMoS13 1
AISI 420F mod. gemäss ASTM F-899
stainless steel, hardenable
drawn, polished, in 3m bars
diam. 1.50 mm, tolerance ISO h7

bars 3mdrawnh 7

25 kg

0
Product total
Options total
Grand total
090 518 - 24.9241-500bars-3mdrawnh-7-en
1.55046503101550

Chronifer Labor M-Plus
~mat.no. ~1.4197, X20CrNiMoS13 1
ASTM F-899, AISI 420 F mod.
stainless steel, hardenable
cold drawn, polished, in 3m bars
end of bars: pointed, chamfered
diam. 1.55 mm, tolerance ISO h7

bars 3mdrawnh 7

60 kg

0
Product total
Options total
Grand total
250 816 - 60.0001-550bars-3mdrawnh-7-en
1.60046503101600

Chronifer Labor M-Plus
~mat.no. ~1.4197, X20CrNiMoS13 1
ASTM F-899, AISI 420 F mod.
stainless steel, hardenable
cold drawn, polished, in 3m bars
diam. 1.60 mm, tolerance ISO h7

bars 3mdrawnh 7

5 kg

0
Product total
Options total
Grand total
190 418 - 5.0001-600bars-3mdrawnh-7-en
1.65046503101650

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
stainless steel, hardenable
drawn, polished, surface Ra 0.6 max
in 3m bars, straightness 4mm/m max.
diam. 1.65 mm, tolerance ISO h7

bars 3mdrawnh 7

31 kg

0
Product total
Options total
Grand total
010 714 - 31.3001-650bars-3mdrawnh-7-en
1.80046503101800

Chronifer Labor M-Plus
~no. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod, ASTM F-899
stainless steel, hardenable
cold drawn, polished, in 3m bars
pointed/chamfered
diam. 1.80 mm, tolerance ISO h7

bars 3mdrawnh 7

66 kg

0
Product total
Options total
Grand total
201 222 - 20.400|180 123 - 45.2001-800bars-3mdrawnh-7-en
5.50046513005500

Chronifer Labor M-Plus
~no 1.4197, ~ X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899-20
stainless steel, hardenable, RoHS conforme
cold drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 5.50 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

39 kg

2400
Product total
Options total
Grand total
221 117 - 36.500|080 223 - 502.7005-500bars-3mgroundh-6-en
1.70046513901700

Chronifer Labor M-Plus
~no.mat. 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod. and ASTM F-899-20
stainless steel, hardenable
cold drawn, ground, polished, stress relieved
in 3m bars (+30/0 mm)
end of bars: chamfered,
diam. 1.70 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

211 kg

0
Product total
Options total
Grand total
220 223 - 210.5001-700bars-3mgroundh-5-en
5.50046513105500

Chronifer Labor M-Plus
~no 1.4197 ~X20CrNiMoS13 1
DIN EN 10088-3, ASTM F-899-20
stainless steel, hardenable
drawn, ground, polished
in 3m bars (+30/0mm)
pointed/chamfered, eddy current tested cl.4
diam. 5.50 mm, tolerance ISO 286-2/h7

bars 3mgroundh 7

0 kg

500
Product total
Options total
Grand total
270 407 - 0.7555-500bars-3mgroundh-7-en
13.00046513113000

Chronifer Labor M-Plus
~no mat. 1.4197, ~X20CrNiMoS13 1
suivant AISI 420F mod
EN 10088-3 und ASTM F-899
stainless steel, hardenable
drawn, ground, polished,
in 3m bars (+30/0mm)
pointed/chamfered, eddy current tested cl.4
ultrasonic inspected per EN10308, Tab. 1
diam. 13.00 mm, tolerance ISO 286-2/h7

bars 3mgroundh 7

351 kg

0
Product total
Options total
Grand total
070 223 - 350.60013-000bars-3mgroundh-7-en
1.00046512901000

Chronifer Labor M-Plus
~German no 1.4197, ~X20CrNiMoS13 1
as per AISI 420F mod., ASTM F-899
stainless steel, hardenable
drawn, ground, in 2m bars (+/- 10mm)
diam. 1.00 mm, tolerance ISO h5

bars 2mgroundh 5

0 kg

0
Product total
Options total
Grand total
300 609 - 334.7001-000bars-2mgroundh-5-en
Werkstoff-Nr.~1.4197
DIN~X 20 CrNiMoS 13-1
AFNOR
AISI420 F MOD F 899
ISO
Euronorm
Andere
C %0.20-0.26
Si %≤ 1.00
Mn %≤ 2.00
P %≤ 0.04
S %0.15-0.27
Cr %12.5-14.0
Mo %1.10-1.50
Ni %0.75-1.50
Cu %
Pb %
Zn %
Sn %
Fe %
O %
N %
H %
Ti %
Schnittgeschwindigkeit~ 40-55
Standardabmessung an Lager0.4-20 mm
