CHRONIFER M-15 KL

Brief description
Designation Klein:CHRONIFER M-15 KL
Class of metals:Hardenable martensitic stainless steel
with N and V additions
Material number:1.4123
Standard EN:X 40 CrMoVN 16-2
Remelting:ESR
Machinability:up to satisfactory
Hardening capability:up to 58 HRc
Polishing ability:adapted for mirror polishing
Corrosion resistance:satisfactory up to good in the hardened,
polished and passivized condition
Magnetism:magnetic
Uses:medical, surgical and dental
instruments
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
23.50046713023500
Brief description
Designation Klein:CHRONIFER M-15 KL
Class of metals:Hardenable martensitic stainless steel
with N and V additions
Material number:1.4123
Standard EN:X 40 CrMoVN 16-2
Remelting:ESR
Machinability:up to satisfactory
Hardening capability:up to 58 HRc
Polishing ability:adapted for mirror polishing
Corrosion resistance:satisfactory up to good in the hardened,
polished and passivized condition
Magnetism:magnetic
Uses:medical, surgical and dental
instruments
bars 3mgroundh 6

75 kg

0
Product total
Options total
Grand total
270 110 - 74.90023-500bars-3mgroundh-6-en
65.00046733465000

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoVN16.2
as per ASTM F-899-20, NF S94-090 (chem.)
as per AISI 420 mod. UNS S42025/S42000
as per AMS 5925 Rev. B (chem. only)
hardenable stainless medical steel
(not certified for aeronautical purposes)
annealed, peeled surface
hardness: < 265 HB, ultrasonic inspected as per DIN EN 10308 Tab. 1, Typ 1a, Tab. 2, cl. 4 eddycurrent crack inspected per ISO 9443,cl.C in bars of 3m lengths (+/-50 mm) diam. 65.00 mm, tolerance ISO 286-2/h11

bars 3mscaledh 11

1404 kg

0
Product total
Options total
Grand total
070 323 - 1404.00065-000bars-3mscaledh-11-en-2
63.50046733463500

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per AISI 420 mod.UNS S42025 (chem.)
chemical .comp.as per AMS 5925 Rev.A
as per ASTM F-899-20, NF S94-090,
hardenable stainless medical steel
rolled, annealed execution
in bars of 3m lengths (+50/0mm)
100% ultrasonic inspected
diam. 63.50 mm (2.5”), tolerance ISO 286-2/h11

bars 3mscaledh 11

1560 kg

0
Product total
Options total
Grand total
070 323 - 1560.00063-500bars-3mscaledh-11-en-2
7.50046713007500

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 7.50 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

0 kg

800
Product total
Options total
Grand total
240 309 - 101.5547-500bars-3mgroundh-6-en
28.00046713028000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 28.00 mm, tolerance ISO h6

bars 3mgroundh 6

307 kg

0
Product total
Options total
Grand total
140 211 - 301.900|160 211 - 5.20028-000bars-3mgroundh-6-en
27.00046713027000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000
chem.comp. per AMS 5925, UNS S42025
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 27.00 mm, tolerance ISO h6

bars 3mgroundh 6

720 kg

0
Product total
Options total
Grand total
260 612 - 719.50027-000bars-3mgroundh-6-en
26.00046713026000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 26.00 mm, tolerance ISO h6

bars 3mgroundh 6

448 kg

0
Product total
Options total
Grand total
111 109 - 447.90026-000bars-3mgroundh-6-en
25.40046713025400

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 25.40mm (1″), tolerance ISO h6

bars 3mgroundh 6

812 kg

0
Product total
Options total
Grand total
260 612 - 82.000|200 819 - 730.00025-400bars-3mgroundh-6-en
25.00046713025000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 25.00 mm, tolerance ISO h6

bars 3mgroundh 6

2301 kg

0
Product total
Options total
Grand total
130 819 - 748.700|280 323 - 1552.00025-000bars-3mgroundh-6-en
24.000467130240001

Chronifer M-15 KL
W-Nr. 1.4123, X40CrMoVN16.2
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
AISI 420 mod., ASTM F-899,
NF S94 090,UNS S42025
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 24.00 mm, tolerance ISO h6

bars 3mgroundh 6

4 kg

0
Product total
Options total
Grand total
220 207 - 3.50024-000bars-3mgroundh-6-en
24.00046713024000

Chronifer M-15 KL
W-Nr. 1.4123, X40CrMoVN16.2
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
AISI 420 mod., ASTM F-899,
NF S94 090,UNS S42025
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 24.00 mm, tolerance ISO h6

bars 3mgroundh 6

4284 kg

0
Product total
Options total
Grand total
051 217 - 22.100|200 318 - 12.100|210 318 - 643.500|090 419 - 1492.000|100 419 - 1554.000|110 419 - 560.00024-000bars-3mgroundh-6-en
23.00046713023000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090 (chem.only)
as per AISI 420 mod. UNS S42025, UNS S42000
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 23.00 mm, tolerance ISO h6

bars 3mgroundh 6

1225 kg

0
Product total
Options total
Grand total
100 118 - 1224.90023-000bars-3mgroundh-6-en
30.00046713030000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000
chemical .comp. AMS 5925
UNS S42025 (chem.only)
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 30.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

5500
Product total
Options total
Grand total
231 109 - 5.800|250 411 - 739.000|260 411 - 133.800|270 912 - 380.00030-000bars-3mgroundh-6-en
22.00046713022000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94 090 (chem.)
as per AISI 420 mod.
UNS S42025 und UNS S42000
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 22.00 mm, tolerance ISO h6

bars 3mgroundh 6

2896 kg

0
Product total
Options total
Grand total
170 919 - 135.100|050 520 - 879.000|080 322 - 728.000|070 322 - 1154.00022-000bars-3mgroundh-6-en
21.00046713021000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 21.00 mm, tolerance ISO h6

bars 3mgroundh 6

1028 kg

0
Product total
Options total
Grand total
230 211 - 240.300|090 320 - 788.00021-000bars-3mgroundh-6-en
20.00046713020000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090 (chem.)
as per AISI 420 mod. UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 20.00 mm, tolerance ISO h6

bars 3mgroundh 6

861 kg

0
Product total
Options total
Grand total
231 109 - 19.050|220 415 - 19.900|250 220 - 822.00020-000bars-3mgroundh-6-en
19.05046713019050

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per ASTM F-899-20, NF S 94-090 (chem.)
as per AISI 420 mod. UNS S42000,
UNS S42025 (chem. only)
chemical .comp.as per AMS 5925 Rev. A 08/06
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
ultrasonic inspected per DIN EN 10308 Tab.1
diam. 19.05 mm (3/4”), tolerance ISO h6

bars 3mgroundh 6

437 kg

0
Product total
Options total
Grand total
110 521 - 436.80019-050bars-3mgroundh-6-en
18.00046713018000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 18.00 mm, tolerance ISO h6

bars 3mgroundh 6

248 kg

1600
Product total
Options total
Grand total
111 209 - 3.000|131 112 - 245.40018-000bars-3mgroundh-6-en
17.00046713017000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod., UNS S42025, S42000
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
ultrasonic tested per DIN 10308-1
100% eddycurrent crack tested cl. 4
diam. 17.00 mm, tolerance ISO h6

bars 3mgroundh 6

649 kg

1600
Product total
Options total
Grand total
210 622 - 186.000|110 521 - 462.50017-000bars-3mgroundh-6-en
15.00046713015000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per AISI 420 mod. UNS S42025
as per ASTM F-899 and NF S94-090
chemical .comp.as per AMS 5925
hardenable stainless medical steel, ESR
annealed, drawn, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 15.00 mm, tolerance ISO h6

bars 3mgroundh 6

858 kg

0
Product total
Options total
Grand total
030 912 - 234.000|231 019 - 624.00015-000bars-3mgroundh-6-en
29.00046713029000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod., UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 29.00 mm, tolerance ISO h6

bars 3mgroundh 6

695 kg

0
Product total
Options total
Grand total
210 812 - 357.000|161 012 - 338.00029-000bars-3mgroundh-6-en
32.00046713032000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 32.00 mm, tolerance ISO h6

bars 3mgroundh 6

617 kg

1000
Product total
Options total
Grand total
241 114 - 635.60032-000bars-3mgroundh-6-en
6.00046713906000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000 and
UNS S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 6.00 mm, tolerance ISO h5

bars 3mgroundh 5

238 kg

0
Product total
Options total
Grand total
310 120 - 237.7006-000bars-3mgroundh-5-en
50.00046713050000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod. UNS S42000
chemical .comp. AMS 5925, UNS S42025
RoHs, Reach conform
hardenable stainless medical steel, RoHS conform
annealed, ground, polished
in bars of 3m lengths (+40/0mm)
ultrasonic tested,
100% eddycurrent crack tested
diam. 50.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

5500
Product total
Options total
Grand total
101 209 - 8.050|041 012 - 300.945|020 523 - 1076.00050-000bars-3mgroundh-6-en
20.00046731820000

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoVN16.2
as per NFS 94-090 and ASTM F-899
hardenable stainless steel
rough ground, anneald, in bars
diam. 20.00 mm, tolerance ISO js10

special lengthscaledspec.

8 kg

0
Product total
Options total
Grand total
010 207 - 7.70020-000special-lengthscaledspec-en
60.00046713360000

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoVN16.2
as per ASTM F-899 and NF S94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
100% eddycurrent crack tested
diam. 60.00 mm, tolerance ISO 286-2/h9

bars 3mgroundh 9

258 kg

0
Product total
Options total
Grand total
110 719 - 258.00060-000bars-3mgroundh-9-en
60.00046713060000

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoVN16.2
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod., RoHS, Reach conform
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
100% eddycurrent crack tested cl. 4
ultrasonic inspected
diam. 60.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

956 kg

2000
Product total
Options total
Grand total
221 122 - 956.00060-000bars-3mgroundh-6-en
57.00046713057000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod. UNS S42000
chemical .comp. AMS 5925, UNS S42025
RoHs, Reach conform
hardenable stainless medical steel, RoHS conform
annealed, ground, polished
in bars of 3m lengths (+40/0mm)
ultrasonic tested,
100% eddycurrent crack tested
diam. 57.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

1500
Product total
Options total
Grand total
141 018 - 5.700|260 521 - 23.000|140 223 - 1721.00057-000bars-3mgroundh-6-en
55.00046713055000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000
UNS S42025
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: chamfered
100% eddycurrent crack tested cl. 4
diam. 55.00 mm, tolerance ISO h6

bars 3mgroundh 6

583 kg

0
Product total
Options total
Grand total
110 719 - 583.48155-000bars-3mgroundh-6-en
52.00046713052000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod. UNS S42000
chemical .comp. AMS 5925, UNS S42025 (chem.)
RoHs, Reach conform
hardenable stainless medical steel, RoHS conform
annealed, ground, polished
in bars of 3m lengths (+40/0mm)
ultrasonic tested,
100% eddycurrent crack tested
diam. 52.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

1500
Product total
Options total
Grand total
250 418 - 3.150|170 519 - 1125.300|090 920 - 1649.00052-000bars-3mgroundh-6-en
47.00046713047000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per AISI 420 mod.UNS S42025 (chem.)
chemical .comp.as per AMS 5925 Rev.A
as per ASTM F-899-20, NF S94-090,
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
100% eddycurrent crack tested cl. 4
ultrasonic tested
diam. 47.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1130 kg

0
Product total
Options total
Grand total
110 122 - 1130.00047-000bars-3mgroundh-6-en
33.00046713033000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per ASTM F-899-20, NF S 94-090 (chem.)
as per AISI 420 mod. UNS S42000,
UNS S42025 (chem. only)
chemical .comp.as per AMS 5925 Rev. A 08/06
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: chamfered both ends
100% eddycurrent crack tested cl. 4
ultrasonic inspected per DIN EN 10308 Tab.1
diam. 33.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1076 kg

0
Product total
Options total
Grand total
031 122 - 1076.00033-000bars-3mgroundh-6-en
45.00046713045000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per AISI 420 mod.
chemical .comp.as per AMS 5925
as per ASTM F-899, NF S94-090, UNS S42025
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 45.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1532 kg

0
Product total
Options total
Grand total
050 116 - 285.600|211 221 - 1246.00045-000bars-3mgroundh-6-en
43.00046713043000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per AISI 420 mod. UNS S42000
chemical .comp.as per AMS 5925
as per ASTM F-899, NF S 94-090, UNS S42025
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 43.00 mm, tolerance ISO h6

bars 3mgroundh 6

538 kg

0
Product total
Options total
Grand total
230 518 - 538.00043-000bars-3mgroundh-6-en
42.00046713042000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per AISI 420 mod. UNS S42000
chemical .comp.as per AMS 5925
ASTM F-899, NF S94-090, UNS S42025
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: chamfered at both ends
100% eddycurrent crack tested
diam. 42.00 mm, tolerance ISO h6

bars 3mgroundh 6

1909 kg

0
Product total
Options total
Grand total
050 116 - 84.500|141 122 - 1503.000|151 122 - 321.00042-000bars-3mgroundh-6-en
13.00046713013000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 13.00 mm, tolerance ISO h6

bars 3mgroundh 6

118 kg

800
Product total
Options total
Grand total
220 211 - 117.93213-000bars-3mgroundh-6-en
40.00046713040000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod., UNS S42025
chemical .comp.as per AMS 5925 Rev. A
hardenable stainless medical steel, RoHS conform
annealed, drawn, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 40.00 mm, tolerance ISO h6

bars 3mgroundh 6

1064 kg

1000
Product total
Options total
Grand total
010 719 - 105.800|280 223 - 958.00040-000bars-3mgroundh-6-en
38.00046713038000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000, UNS S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 38.00 mm, tolerance ISO h6

bars 3mgroundh 6

403 kg

0
Product total
Options total
Grand total
211 211 - 402.90038-000bars-3mgroundh-6-en
35.00046713035000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 35.00 mm, tolerance ISO h6

bars 3mgroundh 6

1621 kg

0
Product total
Options total
Grand total
251 114 - 260.800|160 523 - 1360.00035-000bars-3mgroundh-6-en
34.00046713034000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per ASTM F-899-20, NF S 94-090 (chem.)
as per AISI 420 mod. UNS S42000,
UNS S42025 (chem. only)
chemical .comp.as per AMS 5925 Rev. A 08/06
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+50/0mm)
end of bars: chamfered both ends
100% eddycurrent crack tested cl. 4
ultrasonic inspected per DIN EN 10308 Tab.1
diam. 34.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

592 kg

0
Product total
Options total
Grand total
210 622 - 592.00034-000bars-3mgroundh-6-en
14.00046713014000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod. UNS S42000, S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
ultrasonic inspected per EN 10308, Tab. 1
diam. 14.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

768 kg

800
Product total
Options total
Grand total
290 622 - 767.60014-000bars-3mgroundh-6-en
85.00046711485000

Chronifer M 15 KL
mat.no 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14
AISI 420 mod., UNS S42000
Analyse: AMS 5925B 04/18, UNS S42025
as per ASTM F-899-20, NF S94 090
hardenable stainless medical steel (not certified for aeronautical purposes9
annealed, peeled surface
in bars of 2m lengths (+/-50 mm)
crack proofed as per DIN/EN/ISO 9443 Kl. C
ultrasonic inspected per DIN
EN 10308 Teb.1, Type 1a
round 85.00mm, tolerance ISO 286-2/h11

special lengthgroundh 11

0 kg

5000
Product total
Options total
Grand total
281 021 - 524.00085-000special-lengthgroundh-11-en-2
12.70046713012700

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
equivalent to X15TN
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod., UNS S42000
chemical .comp.as per AMS 5925 Rev. A
RoHs conforme
hardenable stainless medical steel
ESR remelted,annealed, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 12.70 mm (1/2″), tolerance ISO h6

bars 3mgroundh 6

27 kg

1600
Product total
Options total
Grand total
100 712 - 4.690|250 619 - 22.20012-700bars-3mgroundh-6-en
70.00046711470000

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoVN16.2
as per ASTM F-899-20, NF S94-090 (chem.)
as per AISI 420 mod. UNS S42025/S42000
as per AMS 5925 Rev. B (chem. only)
hardenable stainless medical steel
annealed, peeled surface
hardness: < 265 HB, ultrasonic inspected as per DIN EN 10308 Tab. 1, Typ 1a, Tab. 2, cl. 4 eddycurrent crack inspected per ISO 9443,cl.C in bars of 2m lengths (+/-50 mm) diam. 70.00 mm, tolerance ISO h11 (ISO 286-2)

special lengthgroundh 11

0 kg

4500
Product total
Options total
Grand total
140 921 - 1509.40070-000special-lengthgroundh-11-en-2
3.10046713003100

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
Type 420 mod. UNS S42000, ASTM F-899
chem.: NF S94 090 + AMS 5925 + UNS S42025
hardenable stainless high end medical steel
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested class 4
diam. 3.10 mm, tolerance ISO h6

bars 3mgroundh 6

780 kg

0
Product total
Options total
Grand total
200 218 - 779.5003-100bars-3mgroundh-6-en
3.00046713003000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 3.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1185 kg

0
Product total
Options total
Grand total
201 112 - 437.099|100 523 - 236.000|110 523 - 512.0003-000bars-3mgroundh-6-en
2.50046713002500

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
diam. 2.50 mm, tolerance ISO h6

bars 3mgroundh 6

481 kg

0
Product total
Options total
Grand total
170 310 - 116.299|080 512 - 364.6002-500bars-3mgroundh-6-en
2.00046713002000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
diam. 2.00 mm, tolerance ISO h6

bars 3mgroundh 6

228 kg

0
Product total
Options total
Grand total
310 310 - 228.4222-000bars-3mgroundh-6-en
90.00046711490000

Chronifer M 15 KL
mat.no 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14
AISI 420 mod., UNS S42000
Analyse: AMS 5925B 04/18, UNS S42025
as per ASTM F-899-20, NF S94 090
hardenable stainless medical steel
annealed, peeled surface
in bars of 2m lengths (+/-50 mm)
crack proofed as per DIN/EN/ISO 9443 Kl. C
ultrasonic inspected per DIN
EN 10308 Teb.1, Typ1a
round 90.00mm, tolerance ISO h11 (ISO 286-2)

special lengthgroundh 11

0 kg

4500
Product total
Options total
Grand total
060 312 - 369.500|140 921 - 490.00090-000special-lengthgroundh-11-en-2
80.00046711480000

Chronifer M 15 KL
mat.no 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14
AISI 420 mod., UNS S42000
Analyse: AMS 5925B 04/18, UNS S42025
as per ASTM F-899-20, NF S94 090
hardenable stainless medical steel
annealed, peeled surface
in bars of 2m lengths (+/-50 mm)
crack proofed as per DIN/EN/ISO 9443 Kl. C
ultrasonic inspected per DIN
EN 10308 Teb.1, Typ1a
round 80.00mm, tolerance ISO h11 (ISO 286-2)

special lengthgroundh 11

1527 kg

1000
Product total
Options total
Grand total
140 921 - 1527.10080-000special-lengthgroundh-11-en-2
75.00046711475000

Chronifer M 15 KL
mat.no 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14
AISI 420 mod., UNS S42000
Analyse: AMS 5925B 04/18, UNS S42025
as per ASTM F-899-20, NF S94 090
hardenable stainless medical steel
annealed, peeled surface
in bars of 2m lengths (+/-50 mm)
crack proofed as per DIN/EN/ISO 9443 Kl. C
ultrasonic inspected per DIN
EN 10308 Teb.1, Typ1a
round 75.00mm, tolerance ISO h11 (ISO 286-2)

special lengthgroundh 11

2359 kg

0
Product total
Options total
Grand total
080 512 - 94.508|010 317 - 748.000|140 921 - 1516.00075-000special-lengthgroundh-11-en-2
65.00046711465000

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoVN16.2
as per ASTM F-899-20, NF S94-090 (chem.)
as per AISI 420 mod. UNS S42025/S42000
as per AMS 5925 Rev. B (chem. only)
hardenable stainless medical steel
(not certified for aeronautical purposes)
annealed, peeled surface
hardness: < 265 HB, ultrasonic inspected as per DIN EN 10308 Tab. 1, Typ 1a, Tab. 2, cl. 4 eddycurrent crack inspected per ISO 9443,cl.C in bars of 2m lengths (+/-50 mm) diam. 65.00 mm, tolerance ISO 286-2/h11

special lengthgroundh 11

0 kg

0
Product total
Options total
Grand total
310 518 - 621.00065-000special-lengthgroundh-11-en-2
3.30046713003300

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per EN 10088-3 12/14
AISI 420 mod., Analyse: SAE-AMS 5925 Rev. B
as per ASTM F-899-20, NF S94 090
UNS S42000, UNS S42025 (chem only)
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 3.30 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

521 kg

0
Product total
Options total
Grand total
061 222 - 272.000|051 222 - 254.0003-300bars-3mgroundh-6-en
105.00046711410500

Chronifer M 15 KL
mat.no 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14
AISI 420 mod., UNS S42000
Analyse: AMS 5925B 04/18, UNS S42025
as per ASTM F-899-20, NF S94 090
hardenable stainless medical steel
annealed, peeled surface
in bars of 2m lengths (+/-50 mm)
crack proofed as per DIN/EN/ISO 9443 Kl. C
ultrasonic inspected per DIN
EN 10308 Teb.1, Typ1a
round 105mm, tolerance ISO h11 (ISO 286-2)

special lengthgroundh 11

0 kg

3000
Product total
Options total
Grand total
070 803 - 4.600105-000special-lengthgroundh-11-en-2
1.80046702101800

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoNV 16-2
AISI 420 mod., Analyse: AMS 5925
as per ASTM F-899, NFS 94090
hardenable stainless medical steel
anneald, drawn, in 2m bars (+30/0mm)
diam. 1.80 mm, tolerance ISO h7

bars 2mdrawnh 7

10 kg

0
Product total
Options total
Grand total
060 911 - 10.0001-800bars-2mdrawnh-7-en
3.10046700703100

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoNV 16-2
DIN EN 10088-3 12/14
AISI 420 mod. ASTM F-899, NF S94 090
hardenable stainless medical steel
annealed, cold drawn, in coils
diam. 3.10mm, tolerance ISO fg7

in spoolsdrawnfg 7

244 kg

0
Product total
Options total
Grand total
250 919 - 243.6003-100in-spoolsdrawnfg-7-en
12.00046713012000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
Type 420 mod. UNS S42000
Analyse: AMS 5925, UNSS42025
nach ASTM F-899, NF S 94 090
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl.4
diam. 12.00 mm, tolerance ISO h6

bars 3mgroundh 6

998 kg

1600
Product total
Options total
Grand total
240 419 - 7.700|271 119 - 989.80012-000bars-3mgroundh-6-en
1.80046700701800

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoNV 16-2
AISI 420 mod., Analyse: AMS 5925
as per ASTM F-899, NFS 94090
hardenable stainless medical steel
annealed, cold drawn, in coils
diam. 1.80 mm, tolerance ISO fg7

in spoolsdrawnfg 7

230 kg

0
Product total
Options total
Grand total
060 911 - 230.0001-800in-spoolsdrawnfg-7-en
1.65046700701650

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoNV 16-2
as per DIN EN 10088-3
AISI 420 mod., Analyse: AMS 5925
as per ASTM F-899, NFS 94090
hardenable stainless medical steel
annealed, cold drawn, in coils
diam. 1.65 mm, tolerance ISO fg7

in spoolsdrawnfg 7

172 kg

0
Product total
Options total
Grand total
300 811 - 172.3001-650in-spoolsdrawnfg-7-en
3.15046713003150

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 3.15 mm, tolerance ISO h6

bars 3mgroundh 6

597 kg

0
Product total
Options total
Grand total
170 117 - 94.366|280 223 - 508.0003-150bars-3mgroundh-6-en
2.10046700702100

Chronifer M 15 KL
W-Nr. 1.4123, X40CrMoNV 16-2
AISI 420 mod., Analyse: AMS 5925
as per ASTM F-899, NFS 94090
hardenable stainless medical steel
annealed, cold drawn, in coils
diam. 2.10mm, tolerance ISO fg7

in spoolsdrawnfg 7

222 kg

0
Product total
Options total
Grand total
130 911 - 221.6002-100in-spoolsdrawnfg-7-en
3.50046713003500

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 3.50 mm, tolerance ISO h6

bars 3mgroundh 6

618 kg

0
Product total
Options total
Grand total
250 811 - 254.414|280 812 - 364.0003-500bars-3mgroundh-6-en
7.00046713007000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod., ESR remelted
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 7.00 mm, tolerance ISO h6

bars 3mgroundh 6

1603 kg

800
Product total
Options total
Grand total
230 311 - 0.900|050 219 - 60.030|260 319 - 732.000|070 323 - 810.0007-000bars-3mgroundh-6-en
4.00046713004000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
as per ASTM F-899 and NF S94-090
as per AISI 420 mod., UNS S42000
chemical .comp.as per AMS 5925
hardenable stainless medical steel
cold worked, annealed, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 4.00 mm (0.1574″), ISO h6

bars 3mgroundh 6

744 kg

0
Product total
Options total
Grand total
100 216 - 2.700|291 116 - 512.000|260 918 - 236.8004-000bars-3mgroundh-6-en
11.00046713011000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod. UNS S42000
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 11.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

474 kg

1600
Product total
Options total
Grand total
141 004 - 1.700|271 112 - 472.60011-000bars-3mgroundh-6-en
10.00046713010000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
AISI 420 mod., UNS S42000
nach ASTM F-899-12b, NF S94 090
Analyse: AMS 5925 Rev. A, UNS S42025
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 10.00 mm, tolerance ISO h6

bars 3mgroundh 6

2168 kg

1600
Product total
Options total
Grand total
190 814 - 1.400|030 419 - 1.600|021 019 - 590.250|090 822 - 469.000|080 822 - 1148.00010-000bars-3mgroundh-6-en
9.52046713009520

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
equivalent to X15TN
as per DIN EN 10088-3, ESR remelted
Type 420 mod., UNS 42000,ASTM F-899
Analyse: NF S94 090, AMS 5925,UNS S42025
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 9.52 mm (3/8″), tolerance ISO h6

bars 3mgroundh 6

688 kg

0
Product total
Options total
Grand total
280 420 - 688.0009-520bars-3mgroundh-6-en
9.00046713009000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod.
chemical .comp.as per AMS 5925
gemäss UNS S42025 und S42000
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 9.00 mm, tolerance ISO h6

bars 3mgroundh 6

663 kg

800
Product total
Options total
Grand total
170 112 - 662.8009-000bars-3mgroundh-6-en
8.50046713008500

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
AISI 420 mod. UNS S42025
Analyse: AMS 5925 Rev. A, UNS S42000
ASTM F-899-12B, NF S94 090,
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 8.50 mm, tolerance ISO h6

bars 3mgroundh 6

361 kg

1600
Product total
Options total
Grand total
211 221 - 84.600|110 122 - 506.0008-500bars-3mgroundh-6-en
8.00046713008000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod.
UNS S42025, UNS S42000
chemical .comp.as per AMS 5925
hardenable stainless medical steel
Reach/RoHS conforme
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 8.00 mm, tolerance ISO h6

bars 3mgroundh 6

1373 kg

1600
Product total
Options total
Grand total
161 214 - 11.900|041 218 - 1.300|310 123 - 1638.0008-000bars-3mgroundh-6-en
10.000467130100001

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
AISI 420 mod., ASTM F-899, NF S94 090
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
Swissline (AMS-STD 2154A/AMS2632A)
diam. 10.00 mm, tolerance ISO h6

bars 3mgroundh 6

325 kg

0
Product total
Options total
Grand total
190 619 - 324.50010-000bars-3mgroundh-6-en
6.50046713006500

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S 94-090
as per AISI 420 mod. ESR remelted
chemical .comp.as per AMS 5925
per TST N 051 12.20 (chem.Analyse)
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 6.50 mm, tolerance ISO h6

bars 3mgroundh 6

719 kg

0
Product total
Options total
Grand total
050 411 - 86.100|240 117 - 632.6006-500bars-3mgroundh-6-en
4.50046713004500

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
as per AISI 420 mod. ESR remelted
as per ASTM F-899 and NF S 94-090
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 4.50 mm, tolerance ISO h6

bars 3mgroundh 6

847 kg

0
Product total
Options total
Grand total
130 410 - 20.800|091 110 - 1.500|131 118 - 825.0004-500bars-3mgroundh-6-en
6.00046713006000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000 and
UNS S42025
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 6.00 mm, tolerance ISO h6

bars 3mgroundh 6

734 kg

800
Product total
Options total
Grand total
100 919 - 1.900|080 622 - 777.2006-000bars-3mgroundh-6-en
5.50046713005500

Chronifer M 15 KL
no. 1.4123, X40CrMoVN16.2
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
per ASTM F-899-12B, NF S94-090, UNS S42025
as per AISI 420 mod. UNS S42000
chemical .comp.as per AMS 5925 Rev. A
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 5.50 mm, tolerance ISO h6

bars 3mgroundh 6

900 kg

0
Product total
Options total
Grand total
130 612 - 98.700|270 922 - 801.0005-500bars-3mgroundh-6-en
5.00046713005000

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3, ESR remelted
as per ASTM F-899 and NF S94-090
as per AISI 420 mod. UNS S42000
chemical .comp.as per AMS 5925
and UNS S42025 (chem. only)
hardenable stainless medical steel
annealed, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl.4
diam. 5.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1475 kg

1600
Product total
Options total
Grand total
180 419 - 9.500|080 622 - 310.500|050 722 - 337.000|301 122 - 818.0005-000bars-3mgroundh-6-en
4.76046713004760

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
Type 420 mod. UNS S42000
Analyse: AMS 5925 UNS S42025
as per ASTM F-899, NF S94 090
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 4.76mm 0.1875” (3/16″), tolerance ISO h6

bars 3mgroundh 6

492 kg

0
Product total
Options total
Grand total
261 015 - 134.000|271 015 - 358.0004-760bars-3mgroundh-6-en
4.65046713004650

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3
Type 420 mod. UNS S42000
Analyse: AMS 5925 UNS S42025
as per ASTM F-899, NF S94 090
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 4.65 mm, tolerance ISO h6

bars 3mgroundh 6

849 kg

0
Product total
Options total
Grand total
270 209 - 55.595|070 910 - 81.600|060 212 - 712.2004-650bars-3mgroundh-6-en
6.35046713006350

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
equivalent to X15TN, RoHS conforme
as per DIN EN 10088-3 12/14,
as per DIN EN 10277 09/18, Tab. 3
as per ASTM F-899 and NF S94-090 (chem.)
as per AISI 420 mod. ESR remelted
chemical .comp.as per AMS 5925
UNS S42000 and S42025
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 6.35 mm (1/4″), tolerance ISO h6

bars 3mgroundh 6

751 kg

800
Product total
Options total
Grand total
120 520 - 288.000|200 721 - 463.4006-350bars-3mgroundh-6-en
31.75046713031750

Chronifer M 15 KL
German no. 1.4123, X40CrMoVN16.2
as per DIN EN 10088-3 12/14, ESR remelted
as per ASTM F-899-20 and NF S94-090
as per AISI 420 mod., UNS S42025, S42000
chemical .comp.as per AMS 5925
hardenable stainless medical steel
annealed, drawn, ground, polished
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered
ultrasonic tested per DIN 10308-1
100% eddycurrent crack tested cl. 4
diam. 31.75 mm (1 1/4”), tolerance ISO h6

bars 3mgroundh 6

0 kg

1000
Product total
Options total
Grand total
200 710 - 582.60031-750bars-3mgroundh-6-en
Werkstoff-Nr.1.4123 ESU
DINX 40 CrMoVN 16-2
AFNORX 40 CrMoVN 16-2 Z 40 CDV 16.02
AISI420 MOD F 899
ISO
EuronormX 40 CrMoVN 16-2
Andere
C %0.37-0.45
Si %≤ 0.60
Mn %≤ 0.60
P %≤ 0.02
S %≤ 0.005
Cr %15.0-16.0
Mo %1.50-1.90
Ni %≤ 0.50
Cu %
Pb %
Zn %
Sn %
Fe %
O %
N %0.16-0.25
H %
Ti %
Schnittgeschwindigkeit~ 20-30
Standardabmessung an Lager1.5-105.0 mm
