CHRONIFER M-17 C

Brief description
Designation Klein:CHRONIFER M-17 C
Class of metals:Hardenable martensitic stainless steel
Material number:1.4125
Standard EN:X105CrMo17, AISI 440C
Re-melting:ESR
Machinability:up to satisfactory
Hardening capability:up to 60 HRc
Polishing ability:adapted for mirror polishing
Corrosion resistance:satisfactory in the hardened polished
and passivized condition
Magnetism:magnetic
Uses:medical, surgical and dental
instruments
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
19.00046413019000
Brief description
Designation Klein:CHRONIFER M-17 C
Class of metals:Hardenable martensitic stainless steel
Material number:1.4125
Standard EN:X105CrMo17, AISI 440C
Re-melting:ESR
Machinability:up to satisfactory
Hardening capability:up to 60 HRc
Polishing ability:adapted for mirror polishing
Corrosion resistance:satisfactory in the hardened polished
and passivized condition
Magnetism:magnetic
Uses:medical, surgical and dental
instruments
bars 3mgroundh 6

664 kg

0
Product total
Options total
Grand total
030 608 - 664.20019-000bars-3mgroundh-6-en
14.50046413014500

Chronifer M 17 C
mat. 1.4125,X105CrMo17,AISI/SUS440C
per DIN EN 10088-3 9/05, NFS94090
UNS S44004, ASTM F899-07, A276-08
ASTM A959-09, QQS-763F, SAE 51400C
AMS 5630J, AMS 5880C
hardenable stainless steel ESR remelted
drawn, ground, polished, in 3m bars
pointed and chamfered end of bars
100% eddy current crack tested cl.4
diam. 14.50 mm, tolerance ISO h6

bars 3mgroundh 6

1041 kg

0
Product total
Options total
Grand total
091 018 - 618.000|081 018 - 422.90014-500bars-3mgroundh-6-en
15.00046413015000

Chronifer M 17 C
mat.no.1.4125, X105CrMo17, EN 10088-3 12/14
AISI/SUS 440C, QQ-S 763F, ASTM F-899-12B,
ASTM A276/276M-17, UNS S44004,
ASTM A949-16, NF S94 090
SAE 51440C, AMS 5630 Rev.L, AMS 5880 Rev. C
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 15.00 mm, tolerance ISO h6

bars 3mgroundh 6

718 kg

800
Product total
Options total
Grand total
171 219 - 230.900|130 423 - 297.000|110 423 - 490.00015-000bars-3mgroundh-6-en
16.00046413016000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3 9/05
ASTM F-899, QQ-S-763, cond. A
hardenable stainless steel, ESR
annealed, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 16.00 mm, tolerance ISO h6

bars 3mgroundh 6

380 kg

800
Product total
Options total
Grand total
150 211 - 460.90016-000bars-3mgroundh-6-en
22.00046413022000

Chronifer M 17 C
mat.1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3, QQ-S 763F
UNS S44004, ASTM A276-08a, A959-09
ASTM F899-07, AMS 5630J, AMS 5880C
hardenable stainless steel
annealed, ground, polished
in 3m bars (+50/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 22.00 mm, tolerance ISO h6

bars 3mgroundh 6

530 kg

0
Product total
Options total
Grand total
290 114 - 69.000|281 019 - 11.200|291 019 - 450.00022-000bars-3mgroundh-6-en
20.00046413020000

Chronifer M 17 C
German no.1.4125, X105CrMo17, AISI 440C,
as per ASTM F-899, NF S94 040, A959
AMS QQ-S-763F, SAE51440C, AMS5630J
AMS5880C, SUS 440C ASTM A276-08a
as per EN 10088-3 12/14, ESR remelted
hardenable stainless steel
annealed, ground, polished
in 3m bars (+50/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 20.00 mm, tolerance ISO h6

bars 3mgroundh 6

922 kg

0
Product total
Options total
Grand total
251 115 - 107.900|271 020 - 924.00020-000bars-3mgroundh-6-en
21.00046413021000

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17
as per DIN EN 10088-3
AISI/SUS 440C, QQ-S 763F
UNS44004,ASTM F-899, NFS94-090
ASTM A276-08a, A959-09
AMS 5880C, AMS5630J
hardenable stainless steel,
ESR remelted,annealed, ground, polished
in 3m bars (+50/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 21.00 mm, tolerance ISO h6

bars 3mgroundh 6

665 kg

0
Product total
Options total
Grand total
200 410 - 170.800|210 812 - 494.00021-000bars-3mgroundh-6-en
23.00046413023000

Chronifer M 17 C
mat.no1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3 9/05
NF S94 090 (chem. Analysis)
Type 440C, UNS S44004, ASTM F-899
ASTM A276, A959, QQS 763F,
AMS 5630J, AMS 5880C, SUS 440C
hardenable stainless steel
ESR remelted,
annealed (condition A), ground, polished
in 3m bars (+50/0mm)
pointed/chamfered, eddy current tested
diam. 23.00 mm, tolerance ISO h7

bars 3mgroundh 6

498 kg

0
Product total
Options total
Grand total
121 113 - 498.00023-000bars-3mgroundh-6-en
24.00046413024000

Chronifer M 17 C
mat.no..1.4125, X105CrMo17
as per EN 10088-3,UNS S44004,AISI 440C,
ASTM F-899,NF S 94-090
ASTM A276-08a, A959-09
AMS 5630J, AMS 5880C, SUS440C
SAE 51440C, AMS QQ-S 763F
hardenable stainless steel
ESR remelted, annealed, ground, polished,
in 3m bars (+50/0mm)
pointed and chamfered end of bars
eddycurrent crack tested
diam. 24.00 mm, tolerance ISO h6

bars 3mgroundh 6

1442 kg

0
Product total
Options total
Grand total
140 512 - 371.719|300 321 - 1070.00024-000bars-3mgroundh-6-en
25.00046413025000

Chronifer M 17 C
mat.no1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3, RoHS conforme
NF S94 090 (chem. Analysis)
Type 440C, UNS S44004, ASTM F-899
ASTM A276, A959, QQS 763F,
AMS 5630J, AMS 5880C, SUS 440C
hardenable stainless steel, ESR remelted,
annealed (condition A), ground, polished
in 3m bars (+50/0mm)
pointed/chamfered, eddy current tested
diam. 25.00 mm, tolerance ISO h7

bars 3mgroundh 6

845 kg

0
Product total
Options total
Grand total
260 111 - 16.700|121 012 - 203.000|131 012 - 625.70025-000bars-3mgroundh-6-en
14.00046413014000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per EN 10088-3 and ASTM F-899
ASTM A276-08a, A959-09, NF S94 090
AMS 5630J, AMS5880C, UNS S44004
hardenable stainless steel, ESR
annealed, ground, polished, in 3m bars
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 14.00 mm, tolerance ISO h6

bars 3mgroundh 6

1341 kg

0
Product total
Options total
Grand total
280 911 - 13.100|230 512 - 538.200|030 523 - 790.00014-000bars-3mgroundh-6-en
14.10046413014100

Chronifer M 17 C
mat. 1.4125, X105CrMo17, AISI/SUS440C
per DIN EN 10088-3 12/14, NF S94 090
UNS S44004, ASTM F899-12b, A276/276M-17
ASTM A959-16, QQS-763F, SAE 51400C
AMS 5630L, AMS 5880C, UNS S44004
hardenable stainless steel ESR remelted
annealed, ground, polished, in 3m bars (+30/0mm)
pointed and chamfered end of bars
100% eddy current crack tested cl.4
diam. 14.50 mm, tolerance ISO h6

bars 3mgroundh 6

426 kg

0
Product total
Options total
Grand total
110 719 - 426.00014-100bars-3mgroundh-6-en
10.20046413010200

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3. UNS S44004
as per ASTM F-899 and NF S94 090
and QQ-S-763, ASTM A276-08, A959
chemical: AMS 5630J, AMS 5880C
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 10.20 mm, tolerance ISO h6

bars 3mgroundh 6

443 kg

0
Product total
Options total
Grand total
110 614 - 443.40010-200bars-3mgroundh-6-en
13.00046413013000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3, ASTM F-899
QQ-S-763F, cond. A, ESR remelted
AMS 5630J, AMS 5880C, SUS 440C
SAE 51440C, UNS S44004 (chem.Analy)
hardenable stainless steel
conform to ROHS directive
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl. 4
diam. 13.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1308 kg

0
Product total
Options total
Grand total
130 312 - 4.000|261 115 - 11.700|270 819 - 107.900|261 022 - 873.000|031 122 - 311.80013-000bars-3mgroundh-6-en
12.70046413012700

Chronifer M 17 C
mat. 1.4125, X105CrMo17,AISI/SUS 440C
QQ-S 763F,ASTM F-899, NF S 94-090
EN 10088-3, ASTM A276-08a, A959-09
chemical: AMS 5630J, AMS 5880C
conforme EG/2002/95 ROHS directive
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 12.70 mm (1/2″), tolerance ISO h6

bars 3mgroundh 6

369 kg

800
Product total
Options total
Grand total
130 312 - 12.800|180 719 - 295.000|170 719 - 61.20012-700bars-3mgroundh-6-en
12.00046413012000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per EN 10088-3 12/14, NF S94 090
chem only: ASTM F899,
ASTM A276/A276M, ASTM A959
QQS 763F, SUS 440C, NF S94 090
AMS 5630J, AMS 5880C, UNS S44004
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 12.00 mm, tolerance ISO h6

bars 3mgroundh 6

1183 kg

800
Product total
Options total
Grand total
090 822 - 1290.000|100 822 - 93.40012-000bars-3mgroundh-6-en
11.000464130110002

Chronifer M 17 C
AISI/SUS 440C ARC/VAR,
QQ-S-763F, AMS5630 Rev. L
ASTM F899-12B, ASTM A276/A276M-17
AMS 5880E, ASTM A580/A580M-18 (chem.)
EN10088-3, no. 1.4125, X105CrMo17
hardenable stainless steel, bearing quality
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
ultrasonic inspected per AMS2630A, Rev.C
diam. 11.00 mm, tolerance ISO h6

bars 3mgroundh 6

310 kg

0
Product total
Options total
Grand total
300 419 - 309.60011-000bars-3mgroundh-6-en
11.00046413011000

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17,
as per EN 10088-3 12/14, AISI/SUS 440C
UNS S44004, SAE 51440C, AMS 5630J
and NF S94 090, ASTM F-899
ASTM A276A, A959, AMS QQ-S-763F
hardenable stainless steel
as per Astm F-899, ESR remelted,
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 11.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1634 kg

1800
Product total
Options total
Grand total
070 519 - 2.300|270 422 - 600.500|021 122 - 1031.00011-000bars-3mgroundh-6-en
10.50046413010500

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3. UNS S44004
as per ASTM F-899 and NF S94 090
and QQ-S-763, ASTM A276-08, A959
chemical: AMS 5630J, AMS 5880C
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 10.50 mm, tolerance ISO h6

bars 3mgroundh 6

306 kg

0
Product total
Options total
Grand total
161 018 - 306.20010-500bars-3mgroundh-6-en
8.20046413108200

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3
hardenable stainless steel
drawn, ground and polished
in 3m bars (+30/0mm)
pointed and chamfered ends
eddy current crack tested
diam. 8.20 mm, tolerance ISO h7

bars 3mgroundh 7

22 kg

0
Product total
Options total
Grand total
220 305 - 22.4008-200bars-3mgroundh-7-en
10.00046413010000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3 12/14
UNS S44004 (chem. only),
as per ASTM F-899 and NF S94 090
and QQ-S-763, ASTM A276-08, A959
chemical: AMS 5630J, AMS 5880C
conforme EG/2002/95 ROHS directive
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested class 4
diam. 10.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

2325 kg

0
Product total
Options total
Grand total
170 719 - 3.000|180 719 - 35.391|080 322 - 844.000|240 123 - 1457.00010-000bars-3mgroundh-6-en
9.60046413009600

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3. UNS S44004
as per ASTM F-899-20 and NF S94 090
and QQ-S-763, ASTM A276/A286M, A959
chemical: AMS 5630J, AMS 5880C
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 9.60 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

661 kg

0
Product total
Options total
Grand total
180 123 - 660.6009-600bars-3mgroundh-6-en
9.00046413009000

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17,
as per DIN EN 10088-3, NF S94 090
chem. Analyse: ASTM F-899, AISI 440C,
QQ-S-763F, UNS S44004, ASTM A276-08
ASTM A959-09, SAE 51440C,
AMS 5630J, AMS 5880C, SUS 440C
hardenable stainless steel. ESR remelted
RoHS, Reach conforme
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl. 4
diam. 9.00 mm, tolerance ISO h6

bars 3mgroundh 6

826 kg

0
Product total
Options total
Grand total
270 415 - 31.000|030 320 - 794.6009-000bars-3mgroundh-6-en
8.40046413008400

Chronifer M 17 C
mat.no.1.4125,X105CrMo17,AISI/SUS440C
as per DIN EN 10088-3 12/14, AMS QQS-763F
NF S94 090, ASTM F-899, UNS S44004
ASTM A276-08a,ASTM A959, AMS 5630J
AMS 5880C, QQ-S-763, SAE 51440C
hardenable stainless steel
ESR remelted,annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested class 4
diam. 8.40 mm, tolerance ISO h6

bars 3mgroundh 6

162 kg

0
Product total
Options total
Grand total
150 519 - 162.0008-400bars-3mgroundh-6-en
8.20046413008200

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per EN 10088-3
hardenable stainless steel
remelted ESR
annealed, ground polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current tested
diam. 8.20 mm, tolerance ISO h6

bars 3mgroundh 6

340 kg

0
Product total
Options total
Grand total
160 107 - 339.7008-200bars-3mgroundh-6-en
8.10046413008100

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3, UNS S44044
ESR remelted, as per ASTM F-899
NF S94 090,ASTM A276, ASTM A959
QQS763F,SAE 51440C,AMS 5630J (chem)
hardenable stainless steel
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 8.10 mm, tolerance ISO h6

bars 3mgroundh 6

1127 kg

0
Product total
Options total
Grand total
190 911 - 317.500|250 815 - 809.0008-100bars-3mgroundh-6-en
2.50046413102500

Chronifer M 17 C
no 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
drawn and ground, in 3m bars
diam. 2.50 mm, tolerance ISO h8

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
170 513 - 262.600|231 122 - 362.000|201 222 - 445.0002-500bars-3mgroundh-7-en
10.00046413310000

Chronifer M 17 C
AISI/SUS 440C ARC/VAR, QQ-S-763F,
ASTM F899-12B, ASTM A276/A276M-17
UNS S44004, AMS 5630 Rev. L
AMS 5880E, ASTM A580/A580M-18 (chem. only)
EN10088-3, W-Nr.1.4125, X105CrMo17,
hardenable stainless steel, bearing quality
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic inspected per AMS2630A, Rev.C
diam. 10.00 mm, tolerance ISO h9

bars 3mgroundh 9

174 kg

0
Product total
Options total
Grand total
260 219 - 173.80010-000bars-3mgroundh-9-en
8.50046413108500

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per EN 10088-3
hardenable stainless steel
drawn and ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 8.50 mm, tolerance ISO h7

bars 3mgroundh 7

178 kg

0
Product total
Options total
Grand total
290 301 - 177.7008-500bars-3mgroundh-7-en
27.00046413327000

Chronifer M 17 C
DIN EN 10088-3, W-Nr.1.4125, X105CrMo17
gemäss ASTM F-899-20, AMS 5630, AISI 440C
AMS 5880, ASTM A580/A580M-18, QQ-S-763F
ASTM 5618 Rev. J, AMS A276/A276M-17 (chem.)
hardenable stainless steel, bearing quality
annealed ground, in 3m bars (+30/0mm)
end of bars: chamfered
100% ultrasonic inspected per AMS 2630 Rev. J,cl.AA
diam. 27.00 mm, tolerance ISO h9

bars 3mgroundh 9

668 kg

0
Product total
Options total
Grand total
290 322 - 62.000|160 522 - 606.00027-000bars-3mgroundh-9-en
45.00046413845000

Chronifer M 17 C
AISI 440C, ARC/VAR
~W-Nr.1.4125, ~X105CrMo17,
hardenable stainless steel,
as per ASTM A276-10, ASTM F-899
QQS-S-763F, AMS 5630 Rev K,
ASTM A-580-12A (chemistry only)
annealed, ground, in 3m bars
chamfered at both ends,
100% eddycurrent crack tested
ultrasonic tested as per AMS 2630
diam. 45.00 mm, tolerance ISO h10

bars 3mgroundspec.

464 kg

0
Product total
Options total
Grand total
180 413 - 463.70045-000bars-3mgroundspec-en
7.60046413007600

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17, AISI440C
as per DIN EN 10088-3 12/14
AMS QQ-S 763F, ASTM A276/A276M
ASTM F-899, NF S94 090, ASTMA959
UNS S44004,AMS 5630J,AMS5880C (chem)
as per EN 10088-3, ESR remelted
hardenable stainless steel
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 7.60 mm, tolerance ISO h6

bars 3mgroundh 6

853 kg

0
Product total
Options total
Grand total
270 819 - 44.700|260 819 - 4.400|250 122 - 804.0007-600bars-3mgroundh-6-en
40.00046413840000

Chronifer M 17 C
AISI 440C, ARC/VAR
~W-Nr.1.4125, ~X105CrMo17,
hardenable stainless steel, EN10088-3
as per ASTM A276-13A, ASTM F-899
QQS-S-763F, AMS 5630 L, AMS5880 E,
ASTM A-580-13B (chemistry only)
annealed, ground, in 3m bars +30/0mm
chamfered at both ends,
100% eddycurrent crack tested
ultrasonic tested as per AMS 2630A
diam. 40.00 mm, tolerance ISO h10

bars 3mgroundspec.

1269 kg

0
Product total
Options total
Grand total
140 115 - 1269.10040-000bars-3mgroundspec-en
38.10046413838100

Chronifer M 17 C
Aisi 440C, ~no 1.4125, X105CrMo17,
bearing quality, as per ASTM A276-06
QQS-S-763F, AMS 5630 Rev J, ASTM F-899
AMS 5880 Rev C, ASTM A580-06
hardenable stainless steel
annealed, ground, in 3m bars (+30/0mm)
end of bars: chamfered at both ends
ultrasonic inspected as per AMS 2630A Rev.C
ultrasonic inspected
diam. 38.10 mm (1 1/2″), 0/-0.066mm

bars 3mgroundspec.

813 kg

0
Product total
Options total
Grand total
080 212 - 813.00038-100bars-3mgroundspec-en
28.57046413828570

Chronifer M 17 C
AISI 440C, ~no 1.4125, X105CrMo17,
as per ASTM A276-06, ASTM F-899
QQS-S-763F, AMS 5630 Rev L,
as per EN 10088-3 09/05
AMS 5880 Rev E, ASTM A580 (chem. only)
hardenable stainless steel, bearing quality ARC/AOD +VAR remelted
annealed, ground, in 3m bars (+30/0mm)
end of bars: chamfered at both ends
ultrasonic inspected as per AMS2630A, Rev.C
diam. 28.57 mm (1 1/8″), 0/-0.066 mm

bars 3mgroundspec.

597 kg

1270
Product total
Options total
Grand total
031 018 - 597.00028-570bars-3mgroundspec-en
1.90046413801900

Chronifer M 17 C
no. 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3
AISI 440C, QQ-S 763F
ASTM F-899 und NF S 94-090
ASTM A276-08a, A959-09
hardenable stainless steel, ESR remelted
drawn, ground, polished, in 3m bars (+30/0mm)
pointed and chamfered end of bars
100% eddycurrent crack tested
diam. 1.90 mm, tolerance 0/+0.005 mm

bars 3mgroundspec.

0 kg

0
Product total
Options total
Grand total
080 720 - 16.200|270 121 - 733.8001-900bars-3mgroundspec-en
52.00046413352000

Chronifer M 17 C
~mat.1.4125, ~X105CrMo17, AISI 440C
bearing quality Co<0.10%) EN10088-3, selon ASTM F-899-20, A276/276M-17, AMS 5630 Rev. L, AMS 5618 Rev. J AMS 5880 Rev.E, AMS QQ-S-763F ASTM A580/580M-18 (chem.) hardenable stainless steel (ARC/VAR) annealed ground, in 3m bars (+30/0mm) end of bars: chamfered 100% eddy current crack tested ultrasonic inspected as per AMS2630 Cl. AA Rev. D diam. 52.00 mm, tolerance ISO h9

bars 3mgroundh 9

383 kg

1241
Product total
Options total
Grand total
211 221 - 383.10052-000bars-3mgroundh-9-en
48.00046413348000

Chronifer M 17 C
~mat.1.4125, ~X105CrMo17, AISI 440C
bearing quality Co<0.10%) EN10088-3, selon ASTM F-899-20, A276/276M-17, AMS 5630 Rev. L, AMS 5618 Rev. J AMS 5880 Rev.E, AMS QQ-S-763F ASTM A580/580M-18 (chem.) hardenable stainless steel (ARC/VAR) annealed ground, in 3m bars (+30/0mm) end of bars: chamfered 100% eddy current crack tested ultrasonic inspected as per AMS2630 Cl. AA Rev. D diam. 48.00 mm, tolerance ISO h9

bars 3mgroundh 9

565 kg

0
Product total
Options total
Grand total
220 322 - 564.70048-000bars-3mgroundh-9-en
42.00046413342000

Chronifer M 17 C
AISI 440C, no 1.4125, X105CrMo17,
bearing quality, ARC/VAR
hardenable stainless steel
as per ASTM A276/A276M-17, ASTM F-899-19
QQS-S-763F, AMS 5630 Rev J,
AMS 5880 Rev E, ASTM A580/A580M-18
annealed, precision ground,
in 3m bars (+30/0mm)
100% ultrasonic crack tested as per
AMS 2630 class A, Rev. D
diam. 42.00 mm, tolérance ISO h9

bars 3mgroundh 9

1150 kg

0
Product total
Options total
Grand total
231 120 - 1150.00042-000bars-3mgroundh-9-en
35.00046413335000

Chronifer M 17 C
AISI 440C, ~no 1.4125, X105CrMo17,
bearing quality, ASTM A276-08A,
hardenable stainless steel
QQS-S-763F, AMS 5630 Rev J,
ASTM A-580-08, ASTM F-899
annealed, ground, in 3-3.7m bars
chamfered at both ends,
100% eddycurrent crack tested
diam. 35.00 mm, ISO h9

bars 3mgroundh 9

1076 kg

0
Product total
Options total
Grand total
080 212 - 347.300|270 313 - 729.00035-000bars-3mgroundh-9-en
32.00046413332000

Chronifer M 17 C
AISI 440C, ~no 1.4125, X105CrMo17,
bearing quality, ARC/VAR
hardenable stainless steel
as per ASTM A276-10, ASTM F-899-09
QQS-S-763F, AMS 5630 Rev J,
AMS 5880 Rev C, ASTM A580-08
annealed, precision ground,
in 3m bars (+30/0mm)
chamfered at both ends,
100% ultrasonic crack tested as per
AMS 2630 class A, Rev. C
diam. 32.00 mm, tolérance ISO h9

bars 3mgroundh 9

2456 kg

0
Product total
Options total
Grand total
011 013 - 4.400|020 516 - 6.100|071 118 - 200.400|221 019 - 2245.00032-000bars-3mgroundh-9-en
30.00046413330000

Chronifer M 17 C
Aisi 440C, ~no 1.4125, X105CrMo17,
bearing quality, ARC/AOD
hardenable stainless steel,
as per ASTM A276-10, ASTM F-899-09
QQS-S-763F, AMS 5630 Rev J,
AMS 5880 Rev C, ASTM A580-08
annealed, precision ground,
in 3m bars (+30/0mm)
chamfered at both ends,
100% eddycurrent crack tested
diam. 30.00 mm, ISO h9

bars 3mgroundh 9

360 kg

1391
Product total
Options total
Grand total
110 412 - 360.10030-000bars-3mgroundh-9-en
28.00046413328000

Chronifer M 17 C
~mat.1.4125, X105CrMo17, AISI 440C
bearing quality Co<0.10%) EN10088-3, 1.4125, ~X105CrMo17 selon ASTM F-899-20, A276/276M-17, AMS 5630 Rev. L, AMS 5618 Rev. J AMS 5880 Rev.E, AMS QQ-S-763F ASTM A580/580M-18 (chem.) hardenable stainless steel (ARC/VAR) annealed ground, in 3m bars (+30/0mm) end of bars: chamfered 100% eddy current crack tested ultrasonic inspected as per AMS2630 Cl. AA Rev. D diam. 28.00 mm, tolerance ISO h9

bars 3mgroundh 9

650 kg

0
Product total
Options total
Grand total
200 422 - 595.000|280 422 - 55.00028-000bars-3mgroundh-9-en
26.00046413326000

Chronifer M 17 C
~mat.1.4125, X105CrMo17, AISI 440C
as per ASTM F-899, A276-10, AMS 5630
AMS 5880, ASTM A580-08 QQ-S-763F
hardenable stainless steel, (ARC/VAR)
annealed ground, in 3m bars (+30/0mm)
end of bars: chamfered
100% eddy current crack tested
diam. 26.00 mm, tolerance ISO h9

bars 3mgroundh 9

505 kg

0
Product total
Options total
Grand total
080 611 - 505.30026-000bars-3mgroundh-9-en
9.50046413109500

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
hardenable stainless steel
drawn and ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 9.50 mm, tolerance ISO h7

bars 3mgroundh 7

222 kg

0
Product total
Options total
Grand total
100 702 - 221.6009-500bars-3mgroundh-7-en
25.40046413325400

Chronifer M 17 C
Aisi 440C, ~W-Nr.1.4125, ~105CrMo17
AMS 5630 Rev.J, AMS 5880 Rev C
ASTM A276-06, Type 440C
AMS 5880 rev C, QQ S 763F,
ASTM A580-06 (chem.Analyse) F-899-09
annealed, ground, in 3m bars
end of bars: chamfered
diam. 25.40 mm, tolerance ISO h9

bars 3mgroundh 9

769 kg

0
Product total
Options total
Grand total
210 311 - 769.10025-400bars-3mgroundh-9-en
25.00046413325000

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
hardenable stainless steel
drawn and ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 25.00 mm, tolerance ISO h9

bars 3mgroundh 9

2 kg

0
Product total
Options total
Grand total
300 903 - 2.40025-000bars-3mgroundh-9-en
17.70046413317700

Chronifer M 17 C
no 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
drawn and ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 17.70 mm, tolerance ISO h9

bars 3mgroundh 9

269 kg

0
Product total
Options total
Grand total
290 903 - 269.00017-700bars-3mgroundh-9-en
16.70046413316700

Chronifer M 17 C
no 1.4125, X105CrMo17, ~AISI 440C
hardenable stainless steel
drawn and ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 16.70 mm, tolerance ISO h9

bars 3mgroundh 9

157 kg

0
Product total
Options total
Grand total
031 003 - 157.20016-700bars-3mgroundh-9-en
15.00046413315000

Chronifer M 17 C
mat.no.1.4125, X105CrMo17, EN10088-3
AISI 440C, ASTM F-899-12b, AMS 5880 Rev.E,
AMS 5630 Rev. L, ASTM A580/580M-18
ASTM A276/A276M-17, AMS QQS-763F,
hardenable stainless steel bearing quality
precision ground, in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
ultrasonic inspected as per AMS 2630A, Rev. C
diam. 15.00 mm, tolerance ISO h9

bars 3mgroundh 9

933 kg

0
Product total
Options total
Grand total
250 319 - 835.000|260 319 - 97.50015-000bars-3mgroundh-9-en
14.00046413314000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
hardenable stainless steel, ESR
as per EN 10088-3 and ASTM F-899
annealed, ground, polished, in 3m bars
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 14.00 mm, tolerance ISO h9

bars 3mgroundh 9

0 kg

0
Product total
Options total
Grand total
050 607 - 5.15914-000bars-3mgroundh-9-en
12.00046413312000

Chronifer M 17 C
AISI/SUS 440C ARC/VAR,
QQ-S-763F, AMS5630 Rev. L
ASTM F899-12B, ASTM A276/A276M-17
AMS 5880E, ASTM A580/A580M-18 (chem.)
EN10088-3, W-Nr.1.4125, X105CrMo17,
hardenable stainless steel, bearing quality
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic inspected per AMS2630A, Rev.C
diam. 12.00 mm, tolerance ISO h9

bars 3mgroundh 9

0 kg

709
Product total
Options total
Grand total
140 504 - 22.10012-000bars-3mgroundh-9-en
10.20046413310200

Chronifer M 17 C
no 1.4125, X105CrMo17, ~AISI 440C
hardenable stainless steel
annealed, ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 10.20 mm, tolerance ISO h9

bars 3mgroundh 9

41 kg

0
Product total
Options total
Grand total
031 003 - 41.20010-200bars-3mgroundh-9-en
3.70046413303700

Chronifer M 17 C
no 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
drawn and ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 3.70 mm, tolerance ISO h9

bars 3mgroundh 9

54 kg

0
Product total
Options total
Grand total
031 003 - 53.5003-700bars-3mgroundh-9-en
6.35046413206350

Chronifer M 17 C
per ASTM A276/A276M, QQ-S-763F
ASTM A580-16 (chem.), ASTM F-899-12B
AMS 5880 Rev. E, AMS 5630 Rev. L
W-Nr.1.4125, X105CrMo17, AISI 440C
gemäss DIN EN 10088-3 12/14
hardenable stainless steel
bearing quality, RoHS conforme
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
eddy current crack tested, ultrasonic
inspected as per AMS 2630 Class A, Rev. C
diam. 6.35 mm (1/4″), tolerance ISO h8

bars 3mgroundh 8

581 kg

0
Product total
Options total
Grand total
280 818 - 464.152|120 619 - 117.0006-350bars-3mgroundh-8-en
3.50046413203500

Chronifer M 17 C
no 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
drawn and ground, in 3m bars
diam. 3.50 mm, tolerance ISO h8

bars 3mgroundh 8

0 kg

0
Product total
Options total
Grand total
090 615 - 141.900|020 216 - 1433.0003-500bars-3mgroundh-8-en
18.00046413118000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3 9/05
hardenable stainless steel
annealed ground, polished, in 3m bars
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 18.00 mm, tolerance ISO h7

bars 3mgroundh 7

180 kg

0
Product total
Options total
Grand total
230 903 - 179.70018-000bars-3mgroundh-7-en
17.00046413117000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3, UNS S44004,
ASTM F-899, NF S 94-090
ASTM A276, ASTM A959
hardenable stainless steel
drawn, ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 17.00 mm, tolerance ISO h7

bars 3mgroundh 7

425 kg

0
Product total
Options total
Grand total
011 003 - 6.300|010 305 - 5.600|020 305 - 435.00017-000bars-3mgroundh-7-en
8.00046413008000

Chronifer M 17 C
mat..1.4125, X105CrMo17, AISI/SUS 440C
as per EN 10088-3, UNS S44004
QQ-S-763, ASTM F-899, A276-08a, A959
SAE 51440C, AMS 5880C, AMS 5630J
hardenable stainless steel, ESR remelted
annealed, ground, polished RoHS conform
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl. 4
diam. 8.00 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1505 kg

800
Product total
Options total
Grand total
060 422 - 392.000|050 422 - 304.300|301 122 - 642.000|291 122 - 166.4008-000bars-3mgroundh-6-en
1.65046403101650

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per ASTM F-899, NFS 94-040,
EN 10088-3, AMS QQS-763
hardenable stainless steel
ESR remelted
cold drawn, polished, in 3m bars
diam. 1.65 mm, tolerance ISO h7

bars 3mdrawnh 7

20 kg

0
Product total
Options total
Grand total
040 512 - 19.9001-650bars-3mdrawnh-7-en
7.50046413007500

Chronifer M 17 C
mat.no.4125, X105CrMo17,
AISI/SUS 440C, AMS 5630J
ASTM F-899, A276-08a, A959-09
QQS 763F, SAE 511440C, UNS S44004
AMS 5880C, NF S94 090,
as per DIN EN 10088-3 12/14
hardenable stainless steel, ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 7.50 mm, tolerance ISO h6

bars 3mgroundh 6

430 kg

800
Product total
Options total
Grand total
220 818 - 430.2007-500bars-3mgroundh-6-en
0.90046400800900

Chronifer M 17 C ARC/AOD
AISI 440C, ~no 1.4125,
as per AMS 5880, ASTM A580-08
hardenable stainless steel
hot drawn, annealed, in coils
dark surface (graphite layer)
diam. 0.90 mm, tolerance +/-0.0254 mm

in spoolsdrawnspec.

207 kg

544
Product total
Options total
Grand total
250 811 - 206.9900-900in-spoolsdrawnspec-en
2.30046403102300

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3
as per ASTM F-899, NF S94 040,
AMS QQS-763, ASTM A959, ASTM A276
hardenable stainless steel, ESR remelted
cold drawn, annealed, in 3m bars +/-10mm
diam. 2.30 mm, tolerance ISO h7

bars 3mdrawnh 7

47 kg

0
Product total
Options total
Grand total
160 311 - 47.1002-300bars-3mdrawnh-7-en
1.50046403101500

Chronifer M 17 C
no. 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
ESR remelted
cold drawn, in 3m bars
diam. 1.50 mm, tolerance ISO h7

bars 3mdrawnh 7

40 kg

0
Product total
Options total
Grand total
230 108 - 40.1001-500bars-3mdrawnh-7-en
1.40046403001400

Chronifer M 17 C
AISI 440C, ~no 1.4125, gemäss
ASTM A580-08, AMS 5880 Rev C.
as per AMS 5630, AMS 5880,ASTM A580
hardenable stainless steel, ARC/AOD
hot drawn, annealed, redrawn
in straight length of 3m (+20/0mm
end of bars, pointed, chamfered
diam. 1.40 mm, tolerance ISO h6

bars 3mdrawnh 6

17 kg

0
Product total
Options total
Grand total
180 112 - 17.4641-400bars-3mdrawnh-6-en
2.10046400802100

Chronifer M 17 C ARC/AOD
AISI 440C, ~no 1.4125, AMS 5630
as per AMS 5880, ASTM A580-08
hardenable stainless steel
hot drawn, annealed, in coils
dark surface (graphite layer)
diam. 2.10 mm, tolerance +/-0.0254 mm

in spoolsdrawnspec.

234 kg

0
Product total
Options total
Grand total
280 611 - 233.6002-100in-spoolsdrawnspec-en
1.93046400801930

Chronifer M 17 C
AISI 440C, ~no 1.4125, VAR remelted
hardenable stainless steel with extra
fine microstruture (for ballbarings)
annealed, in coils
diam. 1.93 mm, +/-0.0254mm

in spoolsdrawnspec.

163 kg

0
Product total
Options total
Grand total
310 315 - 163.4311-930in-spoolsdrawnspec-en
1.90046400801900

Chronifer M 17 C ARC/AOD
AISI 440C, ~no 1.4125,
as per AMS 5880, ASTM A580-08
and AMS 5630 Rev J 10/07
hardenable stainless steel
hot drawn, annealed, in coils
dark surface (graphite layer)
diam. 1.90 mm, +/-0.0254mm

in spoolsdrawnspec.

436 kg

544
Product total
Options total
Grand total
140 318 - 152.578|301 018 - 283.4001-900in-spoolsdrawnspec-en
1.80046400801800

Chronifer M 17 C ARC/AOD
AISI 440C, ~no 1.4125,
as per AMS 5880, ASTM A580-08
and AMS 5630 Rev J 10/07
hardenable stainless steel
hot drawn, annealed, in coils
dark surface (graphite layer)
diam. 1.80 mm, tolerance +/-0.0254 mm

in spoolsdrawnspec.

348 kg

0
Product total
Options total
Grand total
180 112 - 107.500|310 518 - 240.0001-800in-spoolsdrawnspec-en
1.60046400801600

Chronifer M 17 C
AISI 440C, ~no 1.4125,
as per AMS 5880, ASTM A580-08
hardenable stainless steel,
bearing quality ARC/AOD
hot drawn, annealed, on spools
dark surface (graphite layer)
diam. 1.60 mm, tolerance +/-0.0254 mm

in spoolsdrawnspec.

291 kg

0
Product total
Options total
Grand total
180 112 - 290.7921-600in-spoolsdrawnspec-en
1.50046400801500

Chronifer M 17 C
AISI 440C ARC/AOD, ~German no 1.4125,
ASTM A580-08, AMS 5880 Rev C.
as per AMS 5630J,
hardenable stainless steel
hot drawn, annealed, on spools
dark surface (graphite layer)
diam. 1.50 mm, +/-0.0254mm

in spoolsdrawnspec.

149 kg

0
Product total
Options total
Grand total
180 112 - 149.0001-500in-spoolsdrawnspec-en
1.40046400801400

Chronifer M 17 C
ARC/AOD melted, bearing quality
AISI 440C, ~German no 1.4125,
as per AMS 5880 Rev. E, ASTM A580/A580M
and AMS 5630 mod. Rev L (04/13)
hardenable stainless steel, (> 60 HRC)
hot drawn, annealed, in coils of 9-19kg
dark surface (graphite layer)
diam. 1.40 mm, tolerance +/-0.0254 mm

in spoolsdrawnspec.

559 kg

0
Product total
Options total
Grand total
110 418 - 269.994|190 718 - 288.6001-400in-spoolsdrawnspec-en
1.30046400801300

Chronifer M 17 C ARC/AOD
AISI 440C, ~no 1.4125,
as per AMS 5880, ASTM A580-08
hardenable stainless steel
hot drawn, annealed, on spools
dark surface (graphite layer)
diam. 1.30 mm, tolerance +/-0.0254 mm

in spoolsdrawnspec.

0 kg

0
Product total
Options total
Grand total
1-300in-spoolsdrawnspec-en
1.10046400801100

Chronifer M 17 C ARC/AOD
AISI 440C, ~no 1.4125,
as per AMS 5880, ASTM A580
AMS 5630 mod. cond. Rev. L
hardenable stainless steel
hot drawn, annealed, in coils of 8-15kg
dark surface (graphite layer)
diam. 1.10 mm, tolerance +/-0.0254 mm

in spoolsdrawnspec.

299 kg

544
Product total
Options total
Grand total
150 711 - 128.200|270 711 - 2.950|251 115 - 21.000|310 517 - 146.6511-100in-spoolsdrawnspec-en
3.00046400703000

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
as per Astm F-899, NFS 94-040, QQS-763
hardenable stainless steel,
ESR remelted
cold drawn, polished, in coils
diam. 3.00 mm, tolerance ISO fg7

in spoolsdrawnfg 7

232 kg

0
Product total
Options total
Grand total
050 811 - 232.1003-000in-spoolsdrawnfg-7-en
1.80046403301800

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
hardenable stainless steel
cold drawn, in 3m bars
diam. 1.80 mm, tolerance ISO h9

bars 3mdrawnh 9

77 kg

0
Product total
Options total
Grand total
310 518 - 77.2001-800bars-3mdrawnh-9-en
2.70046400702700

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17,
as per EN 10088-3, NF S94 090
AISI 440C, ASTM F-899,
and QQ-S-763, ASTM A959
UNS S44004, ASTM A580/A580M
hardenable stainless steel,ESR remelted
cold drawn, polished, in coils
diam. 2.70 mm, tolerance ISO fg7

in spoolsdrawnfg 7

302 kg

0
Product total
Options total
Grand total
290 812 - 301.7002-700in-spoolsdrawnfg-7-en
2.30046400702300

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per ASTM F-899, NFS 94-040,
AMS QQS-763, ASTM A959
hardenable stainless steel
ESR remelted
cold drawn, polished, in coils
diam. 2.30 mm, tolerance ISO fg7

in spoolsdrawnfg 7

340 kg

0
Product total
Options total
Grand total
101 018 - 339.6002-300in-spoolsdrawnfg-7-en
2.00046400702000

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17, AISI 440C
gemäss ASTM F-899, NFS 94-040,
AMS QQ-S-763, ASTM A580/A580M,
ASTM A959, EN 10088-3
hardenable stainless steel
ESR remelted
cold drawn, polished, in coils
diam. 2.00 mm, tolerance ISO fg7

in spoolsdrawnfg 7

513 kg

0
Product total
Options total
Grand total
260 912 - 512.5002-000in-spoolsdrawnfg-7-en
1.80046400701800

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per ASTM F-899, NF S94 040,
ASTM A959, ASTM A276 (chem. only)
ASTM A580/A580M, AMS QQS-763, ESU
hardenable stainless steel
cold drawn, polished, in coils
diam. 1.80 mm, tolerance ISO fg7

in spoolsdrawnfg 7

246 kg

0
Product total
Options total
Grand total
051 218 - 246.1001-800in-spoolsdrawnfg-7-en
1.70046400701700

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
W-Nr.1.4125, X105CrMo17, Aisi 440C
as per Astm F-899, NFS 94-040
as per QQS-763 Aisi 440C
hardenable stainless steel
cold drawn, in coils
diam. 1.70 mm, tolerance ISO fg7

in spoolsdrawnfg 7

15 kg

0
Product total
Options total
Grand total
110 595 - 15.2001-700in-spoolsdrawnfg-7-en
1.65046400701650

Chronifer M 17 C
mat.no 1.4125, X105CrMo17, AISI 440C
EN 10088-3, ASTM F-899, NFS 94-040,
UNS S44004, AMS QQS-763
ASTM A580M/A580M, ASTM A959
ASTM A276 (chem. only),
hardenable stainless steel, ESR remelted
cold drawn, polished, in coils
diam. 1.65 mm, tolerance ISO fg7

in spoolsdrawnfg 7

222 kg

0
Product total
Options total
Grand total
040 512 - 221.8001-650in-spoolsdrawnfg-7-en
1.55046400701550

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
as per EN 10088-3, UNS S44004
and ASTM A276, NF S 94090 (chem.only)
ASTM F-899, ASTM A580/A580M
and AMS QQ-S-763, ESR remelted
hardenable stainless steel
cold drawn, polished, in coils
diam. 1.55 mm, tolerance ISO fg7

in spoolsdrawnfg 7

194 kg

0
Product total
Options total
Grand total
250 412 - 193.6001-550in-spoolsdrawnfg-7-en
1.50046400701500

Chronifer M 17 C
no 1.4125, X105CrMo17, ~AISI 440C
hardenable stainless steel
ESR remelted
drawn, annealed, polished, in coils
diam. 1.50 mm, tolerance ISO fg7

in spoolsdrawnfg 7

214 kg

0
Product total
Options total
Grand total
230 108 - 117.500|020 710 - 96.9001-500in-spoolsdrawnfg-7-en
1.30046400701300

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3
hardenable stainless steel
ESR remelted
drawn, annealed, polished, in coils
diam. 1.30 mm, tolerance ISO fg7

in spoolsdrawnfg 7

0 kg

0
Product total
Options total
Grand total
310 822 - 518.2101-300in-spoolsdrawnfg-7-en
3.10046400503100

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per EN10088-3, ESR remelted
hardenable stainless steel
drawn, polished, in coils
diam. 3.10 mm, tolerance ISO fg8

in spoolsdrawnfg 8

148 kg

0
Product total
Options total
Grand total
110 712 - 147.9003-100in-spoolsdrawnfg-8-en
2.75046400202750

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17,
as per EN 10088-3, NF S94 090
AISI 440C, ASTM F-899,
and QQ-S-763, ASTM A959
UNS S44004, ASTM A580/A580M
hardenable stainless steel,ESR remelted
cold drawn, polished, in coils
diam. 2.75 mm, tolerance ISO fg7

in spoolsdrawnh 8

0 kg

0
Product total
Options total
Grand total
300 414 - 9.300|230 920 - 9.200|080 921 - 83.100|151 122 - 1280.1002-750in-spoolsdrawnh-8-en
0.00046400000000

Chronifer M 17 C
AISI 440C – Micro Melt
hardenable stainless steel
powder, ” Mesh + 140″
in ca. 5 kg plastic bottles

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
031 209 - 883.4000-000in-spoolsdrawnh-6-en
7.10046413007100

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3, NF S94 090
UNS S44004, ASTM F-899, ASTM A276,
QQ-S-763F, SAE 51440C, AMS 5630J,
AMS 5880C, SUS 440C (chem.analyse)
hardenable stainless steel, ESR
drawn and ground, in 3m bars +30/0mm
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 7.10 mm, tolerance ISO h6

bars 3mgroundh 6

636 kg

0
Product total
Options total
Grand total
100 106 - 18.900|130 808 - 9.800|100 112 - 19.500|180 912 - 588.1007-100bars-3mgroundh-6-en
2.70046403102700

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3
as per ASTM F-899, NF S94-040,
AMS QQS-763, ASTM A959, ASTM A276
hardenable stainless steel, ESR remelted
cold drawn, annealed, in 3m bars +/-10mm
end of bars: pointed, chamfered
diam. 2.70 mm, tolerance ISO h7

bars 3mdrawnh 7

0 kg

0
Product total
Options total
Grand total
060 619 - 192.8002-700bars-3mdrawnh-7-en
2.50046400702500

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per ASTM F-899, NF S 94-040, QQS-763
ASTM 276 (chem. only), ASTM A959
hardenable stainless steel,ESR remelted
cold drawn, polished, in coils
diam. 2.50 mm, tolerance ISO fg7

in spoolsdrawnfg 7

398 kg

0
Product total
Options total
Grand total
070 819 - 397.7002-500in-spoolsdrawnfg-7-en
1.30046403801300

Chronifer M 17 C ARC/AOD
AISI 440C, ~no 1.4125,
as per AMS 5880, ASTM A580-08
hardenable stainless steel
hot drawn, annealed, in 3m bars
dark surface (graphite layer)
diam. 1.30 mm, tolerance +/-0.0254 mm

bars 3mdrawnspec.

0 kg

0
Product total
Options total
Grand total
090 509 - 18.0001-300bars-3mdrawnspec-en
4.50046413004500

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per ASTM F-899, NF S94 090
UNS S44004, AMS 5630J, AMS 5880C
QQ-S-763F, ASTM A276, ASTM A959,
as per DIN EN 10088-3, ESR remelted
hardenable stainless steel
annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested cl.4
diam. 4.50 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

1555 kg

0
Product total
Options total
Grand total
161 214 - 7.600|131 119 - 590.000|210 223 - 957.0004-500bars-3mgroundh-6-en
7.00046413007000

Chronifer M 17 C
german.no.1.4125, X105CrMo17, SAE 51440C
as per DIN EN 10088-3 12/14
AISI 440C, QQ-S 763F, UNS S44004,
AMS 5880C, SAE 51440C, AMS5630J
ASTM F-899-20, NF S94-090, UNS S44004
ASTM A276/A276M,  ASTM A959-16
ESR remelted, drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 7.00 mm, tolerance ISO h6 (ISO 286-2)

bars 3mgroundh 6

1906 kg

1600
Product total
Options total
Grand total
200 421 - 44.000|190 421 - 26.900|130 922 - 1310.600|180 423 - 524.0007-000bars-3mgroundh-6-en
45.000464113450001

Chronifer M 17 C
no 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
ground, hardened/tempered
hardeness: approx. 54 HRC
in 1.10m bars
diam. 45.00 mm, tolerance ISO h9

special lengthgroundh 9

34 kg

0
Product total
Options total
Grand total
130 903 - 33.60045-000special-lengthgroundh-9-en
6.60046413006600

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3 9/05
hardenable stainless steel
annealed, ground polished, in 3m bars
pointed/chamfered, eddy current tested
diam. 6.60 mm, tolerance ISO h6

bars 3mgroundh 6

704 kg

0
Product total
Options total
Grand total
150 306 - 704.2006-600bars-3mgroundh-6-en
6.50046413006500

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI/SUS 440C
as per DIN EN 10088-3, UNS S44004
NF S94090, Chem: ASTM F-899-07
ASTM A276-08, A959-09, QQS763F
SAE5144C, AMS5630J, AMS5880C
hardenable stainless steel, ESR remelted
drawn and ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested cl. 4
diam. 6.50 mm, tolerance ISO h6

bars 3mgroundh 6

756 kg

0
Product total
Options total
Grand total
271 119 - 522.500|281 119 - 233.5006-500bars-3mgroundh-6-en
6.35046413006350

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per ASTM F-899, EN 10088-3
hardenable stainless steel
ESR remelted, RoHS conforme
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
eddy current crack tested
diam. 6.35 mm (1/4″), tolerance ISO h6

bars 3mgroundh 6

336 kg

0
Product total
Options total
Grand total
210 206 - 335.6006-350bars-3mgroundh-6-en
6.10046413006100

Chronifer M 17 C
mat.no. 1.4125, X105CrMo17, AISI 440C
as per EN 10088-3, NF S94 090
chem.Analyse: UNS S44004, ASTM F899
ASTM A276-08a, A959, QQS 763F
SAE 51440C, AMS2630J, AMS5880C
hardenable stainless steel, ESR
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 6.10 mm, tolerance ISO h6

bars 3mgroundh 6

731 kg

0
Product total
Options total
Grand total
280 415 - 180.500|140 219 - 550.0006-100bars-3mgroundh-6-en
6.00046413006000

Chronifer M 17 C
mat.no.1.4125, X105CrMo17, AISI 440C
as per EN 10088-3 12/14, UNS S44004
NF S 94-090, ASTM A276, ASTM F-899
ASTM A959 AMS-QQ-S 763F
SAE 51440C, AMS 5630J, AMS 5880C
hardenable stainless steel
ESR remelted, annealed, ground,polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 6.00 mm, tolerance ISO h6

bars 3mgroundh 6

1735 kg

0
Product total
Options total
Grand total
300 120 - 1144.000|290 120 - 607.0006-000bars-3mgroundh-6-en
5.50046413005500

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per NF S94090, ASTM F-899
and DIN EN 10088-3 9/05
ASTM A276, A959, QQS 763F,
~AMS5880C ~SAE 51440C~UNSS44044,
~AMS 5630J~AMS 5880C~,~SUS 440C,
hardenable stainless steel,ESR remelted
annealed, ground, polished
in 3m bars (+40/0mm)
pointed/chamfered, eddy current tested
diam. 5.50 mm, tolerance ISO h6

bars 3mgroundh 6

1043 kg

0
Product total
Options total
Grand total
110 614 - 165.750|261 022 - 455.000|040 423 - 422.0005-500bars-3mgroundh-6-en
5.10046413005100

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
EN 10088-3, NF S94 090, ASTM F-899
ASTM A276, A959, QQ-S-763F
hardenable stainless steel
ESR remelted, drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed/chamfered,
100% eddy current crack tested
diam. 5.10 mm, tolerance ISO h6

bars 3mgroundh 6

1078 kg

0
Product total
Options total
Grand total
061 211 - 200.300|230 413 - 878.0005-100bars-3mgroundh-6-en
5.00046413005000

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17, AISI 440C
chemical analyses as per
UNS S44004, NF S 94-090, ASTM A276
ASTM F-899, ASTM A959 AMS-QQ-S 763
SAE 51440C, AMS 5630J, AMS 5880C
as per DIN EN 10088-3, QQS 763F
hardenable stainless steel, RoHS conforme
ESR remelted, cleanliness as per K1
annealed, ground, polished in 3m bars (+30/0mm)
pointed,chamfered end of bars
100% eddy current crack tested cl., 4
diam. 5.00 mm, tolerance ISO h6

bars 3mgroundh 6

1023 kg

0
Product total
Options total
Grand total
181 218 - 7.636|250 919 - 10.900|240 919 - 268.400|161 122 - 396.000|151 122 - 340.0005-000bars-3mgroundh-6-en
4.90046413004900

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17, AISI 440C
chemical analyses as per
UNS S44004, NF S 94-090, ASTM A276
ASTM F-899, ASTM A959 AMS-QQ-S 763
SAE 51440C, AMS 5630J, AMS 5880C
as per DIN EN 10088-3, QQS 763F
hardenable stainless steel,
ESR remelted, cleanliness as per K1
annealed, ground, polished in 3m bars
pointed,chamfered end of bars
100% eddy current crack tested
diam. 4.90 mm, tolerance ISO h6

bars 3mgroundh 6

191 kg

0
Product total
Options total
Grand total
071 014 - 190.9004-900bars-3mgroundh-6-en
4.76046413004760

Chronifer M 17 C
no. 1.4125, X105CrMo17, AISI 440C
chemical analyses as per
UNS S44004, NF S 94-090, ASTM A276
ASTM F-899, ASTM A959 AMS-QQ-S 763
SAE 51440C, AMS 5630J, AMS 5880C
as per DIN EN 10088-3, QQS 763F
hardenable stainless steel,
ESR remelted, cleanliness as per K1
drawn ground, polished, in 3m bars
pointed,chamfered end of bars
100% eddy current crack tested
diam. 4.76 mm (3/16″), tolerance ISO h6

bars 3mgroundh 6

415 kg

0
Product total
Options total
Grand total
080 714 - 414.9004-760bars-3mgroundh-6-en
4.70046413004700

Chronifer M 17 C
no 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
ESR remelted
as per DIN EN 10088-3
drawn, ground, polished, in 3m bars
pointed, chamfered end of bars
100% eddy current crack tested
diam. 4.70 mm, tolerance ISO h6

bars 3mgroundh 6

13 kg

0
Product total
Options total
Grand total
071 014 - 12.8004-700bars-3mgroundh-6-en
5.30046413005300

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
hardenable stainless steel
as per EN 10088-3, ESR remelted
drawn and ground, in 3m bars
pointed/chamfered, eddy current tested
diam. 5.30 mm, tolerance ISO h6

bars 3mgroundh 6

386 kg

0
Product total
Options total
Grand total
250 907 - 10.200|190 416 - 375.5005-300bars-3mgroundh-6-en
4.30046413004300

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
hardenable stainless steel
as per EN 10088-3, ESR remelted
drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 4.30 mm, tolerance ISO h6

bars 3mgroundh 6

629 kg

0
Product total
Options total
Grand total
190 404 - 102.300|080 311 - 74.500|090 615 - 452.0004-300bars-3mgroundh-6-en
3.20046413003200

Chronifer M 17 C
German no 1.4125, X105CrMo17,
AISI 440C, as per DIN EN 10088-3
hardenable stainless steel
ESR remelted, drawn, annealed, ground,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 3.20 mm, tolerance ISO h6

bars 3mgroundh 6

369 kg

0
Product total
Options total
Grand total
110 406 - 140.600|120 406 - 228.0003-200bars-3mgroundh-6-en
4.20046413004200

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
as per DIN EN 10088-3
hardenable stainless steel
ESR remelted
annealed, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed chamfered
100% eddycurrent crack tested
diam. 4.20 mm, tolerance ISO h6

bars 3mgroundh 6

294 kg

0
Product total
Options total
Grand total
051 010 - 97.500|020 311 - 196.0004-200bars-3mgroundh-6-en
2.00046413002000

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3
AISI 440C, QQ-S 763F
ASTM F-899 and NF S 94-090
ASTM A276-08a, A959-09
hardenable stainless steel
ESR remelted, drawn, ground, polished,
in 3m bars (+30/0mm)
pointed and chamfered end of bars
100% eddycurrent crack tested
diam. 2.00 mm, tolerance ISO h6

bars 3mgroundh 6

194 kg

800
Product total
Options total
Grand total
280 109 - 1.627|200 213 - 192.1002-000bars-3mgroundh-6-en
2.10046413002100

Chronifer M 17 C
W-Nr.1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3 12/14
AISI 440C, UNS S44004, QQ-S 763F, ESR
ASTM F-899 and NF S 94-090
ASTM A276-08a (chem. only)
ASTM A580/A580M, ASTM A959
hardenable stainless steel
drawn, annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested class 4
diam. 2.10 mm, tolerance ISO h6

bars 3mgroundh 6

256 kg

0
Product total
Options total
Grand total
060 618 - 259.9002-100bars-3mgroundh-6-en
2.60046413002600

Chronifer M 17 C
no 1.4125, X105CrMo17, ~Aisi 440C
hardenable stainless steel
drawn and ground, in 3m bars
pointed and chamfered end of bars
diam. 2.60 mm, tolerance ISO h6

bars 3mgroundh 6

365 kg

0
Product total
Options total
Grand total
150 512 - 365.1002-600bars-3mgroundh-6-en
3.10046413003100

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3, ASTM A276
QQ S 763F, NF S94 090, ASTMF-899
ASTM A580/A580M (chem.), ASTM A959
SAE 51440C, AMS 5630J, AMS 5880C
ESR remelted, hardenable stainless steel
cold drawn and ground, polished
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
100% eddycurrent-crack tested
diam.3.10 mm, tolerance ISO h6

bars 3mgroundh 6

455 kg

0
Product total
Options total
Grand total
240 419 - 455.3003-100bars-3mgroundh-6-en
3.00046413003000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
ESR remelted, as per DIN EN 10088-3
as per ASTM F-899 and QQ-S-763F
ASTM A276-08a, ASTM A959-09,AMS5630J
UNS S44004, AMST 5880C, SUS 440C
hardenable stainless steel
annealed, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested as per
DIN 10277, Tab. 1, class 4
diam. 3.00 mm, tolerance ISO h6

bars 3mgroundh 6

793 kg

0
Product total
Options total
Grand total
190 618 - 75.400|240 419 - 718.0003-000bars-3mgroundh-6-en
3.30046413003300

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
as per DIN EN 10088-3 9/05
as per ASTM F-899 and NFS 94090
hardenable stainless steel
ESR remelted, drawn and ground
in 3m bars (+30/0mm)
pointed and chamfered ends
diam. 3.30 mm, tolerance ISO h6

bars 3mgroundh 6

47 kg

500
Product total
Options total
Grand total
220 208 - 47.1933-300bars-3mgroundh-6-en
3.50046413003500

Chronifer M 17 C
no 1.4125, X105CrMo17, Aisi 440C
as per DIN EN 10088-3, AMS QQ S763F
AMS 5630, ASTM F-899, NF S94 090 (chem. only)
ESR remelted
hardenable stainless steel
annealed, ground, polished
in 3m bars (+30/0mm)
diam. 3.50 mm, tolerance ISO h6

bars 3mgroundh 6

554 kg

0
Product total
Options total
Grand total
110 406 - 246.454|280 311 - 67.700|290 311 - 240.0003-500bars-3mgroundh-6-en
4.00046413004000

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
as per DIN EN 10088-3, ASTM A276
QQ S 763F, NF S94 090, ASTMF-899
ASTM A580/A580M (chem.), ASTM A959
ESR remelted, hardenable stainless steel
annealed, ground, polished
in 3m bars (+30/0mm)
pointed and chamfered end of bars
100% eddycurrent-crack tested
diam. 4.00 mm, tolerance ISO h6

bars 3mgroundh 6

240 kg

800
Product total
Options total
Grand total
301 012 - 2.500|260 613 - 237.5124-000bars-3mgroundh-6-en
4.10046413004100

Chronifer M 17 C
no 1.4125, X105CrMo17,
as per DIN EN 10088-3 12/14, AISI 440C,
QQ-S 763F, ASTM F-899 and NF S 94-090
ASTM A276/A276M/-17, ASTM A959-16
AMS 5630J, AMS 5880C, UNS S44004
hardenable stainless steel, ESR remelted
annealed ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested cl. 4
diam. 4.10 mm, tolerance ISO h6

bars 3mgroundh 6

466 kg

800
Product total
Options total
Grand total
270 721 - 466.2004-100bars-3mgroundh-6-en
1.20046413001200

Chronifer M 17 C
no 1.4125, X105CrMo17, AISI 440C
DIN EN 10088-3
hardenable stainless steel
drawn, ground, in 3m bars (+30/0mm)
diam. 1.20 mm, tolerance ISO h6

bars 3mgroundh 6

41 kg

0
Product total
Options total
Grand total
280 611 - 40.6001-200bars-3mgroundh-6-en
Werkstoff-Nr.1.4125 (ESU)
DINX 105 CrMo 17
AFNORX 105 CrMo 17 (alt Z100CD17)
AISI440 C F 899
ISO
EuronormX 105 CrMo 17
Andere
C %0.95-1.20
Si %≤ 1.00
Mn %≤ 1.00
P %≤ 0.04
S %≤ 0.03
Cr %16.0-18.0
Mo %0.40-0.75
Ni %
Cu %
Pb %
Zn %
Sn %
Fe %
O %
N %
H %
Ti %
Schnittgeschwindigkeit~ 20-30
Standardabmessung an Lager0.7-52 mm
