CHRONIFER SPECIAL FM

Brief description
Klein designation:CHRONIFER SPECIAL FM
Metal class:Austenitic stainless steel
with Cu addition
Material number:1.4310
Standard EN:X 10 CrNi 18-8
Machinability:good
Hardening capability:cannot be hardened
Forming:can be cold formed
Work hardening:can be cold worked
Polishing:adapted to mirror polishing
Corrosion resistance:from satisfactory to good in the polished
and passivized condition
Magnetism:can present traces of magnetism
Uses:Parts for numerous branches of the
industry
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
2.30050303202300
Brief description
Klein designation:CHRONIFER SPECIAL FM
Metal class:Austenitic stainless steel
with Cu addition
Material number:1.4310
Standard EN:X 10 CrNi 18-8
Machinability:good
Hardening capability:cannot be hardened
Forming:can be cold formed
Work hardening:can be cold worked
Polishing:adapted to mirror polishing
Corrosion resistance:from satisfactory to good in the polished
and passivized condition
Magnetism:can present traces of magnetism
Uses:Parts for numerous branches of the
industry
bars 3mdrawnh 8

49 kg

0
Product total
Options total
Grand total
100 604 - 49.2222-300bars-3mdrawnh-8-en
1.70050303201700

Chronifer Special FM
German no1.4310, X12CrNi17-7, ~ AISI 302
as per DIN EN 10270-3, ASTM F-899
stainless springsteel, hard
cold drawn, in 3m bars
dia. 1.70 mm, tolerance ISO h8

bars 3mdrawnh 8

0 kg

0
Product total
Options total
Grand total
110 107 - 0.2911-700bars-3mdrawnh-8-en
1.90050303201900

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 302
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn, in 3m bars
round 1.90 mm, tolerance ISO h8

bars 3mdrawnh 8

10 kg

0
Product total
Options total
Grand total
070 297 - 9.9541-900bars-3mdrawnh-8-en
2.10050303202100

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7,
as per DIN EN 10270-3, AISI 301
stainless springsteel, hard
cold drawn, in 3m bars
diam. 2.10 mm, tolerance ISO h8

bars 3mdrawnh 8

2 kg

0
Product total
Options total
Grand total
030 604 - 1.5902-100bars-3mdrawnh-8-en
2.00050312002000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899,
NFS 94090, ASTM A580/580M
stainless springsteel, hard
tensile strength Rm: 1575-1820 MPa
cold drawn, ground polished
in 2m lengths
end of bars: chamfered
eddycurrent crack tested
diam. 2.00 mm, tolerance ISO h6

bars 2mgroundh 6

40 kg

0
Product total
Options total
Grand total
231 210 - 39.8562-000bars-2mgroundh-6-en
1.25050303801250

Chronifer Special FM
W-Nr.1.4310, X12CrNi18-8, ~ Aisi 301
as per DIN EN 10270-3
stainless springsteel, hard
tensile strength: 1700-1850N/mm2
cold drawn, polished, in 3m bars
round 1.25 mm, +/-0.010 mm

bars 3mdrawnspec.

17 kg

0
Product total
Options total
Grand total
060 601 - 12.600|160 500 - 4.4651-250bars-3mdrawnspec-en
2.00050311002000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899,
NFS 94090, ASTM A580/580M
stainless springsteel, hard
tensile strength Rm: 1575-1820 MPa
cold drawn, ground polished
in 1m lengths
one end of bars: chamfered
eddycurrent crack tested
diam. 2.00 mm, tolerance ISO h6

special lengthgroundh 6

27 kg

0
Product total
Options total
Grand total
231 210 - 26.7962-000special-lengthgroundh-6-en
1.60050313001600

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
DIN EN 10088-3 12/14, UNS S30200
ASTM F-899-20, NF S94040, ASTM A959
ASTM A580, ASTM A313/A313M
ASTM A478, A493, A368, A276 (chem.only)
DIN EN 10270-3 (NS), ISO 6931-1 (X9CrNi18-8)
stainless springsteel, RoHS conforme
cold drawn, hard, ground, polished
tensile strength Rm: 1575-1775 MPa
in 3m bars (+30/0mm), end of bars: chamfered
diam. 1.60 mm, tolerance ISO 286-2/h6

bars 3mgroundh 6

325 kg

0
Product total
Options total
Grand total
020 822 - 324.9531-600bars-3mgroundh-6-en
1.50050313001500

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
DIN EN 10088-3 12/14, UNS S30200
ASTM F-899, NF S94040, ASTM A959
ASTM A580, ASTM A313/A313M
ASTM A478, A493, A368, A276 (chem.only)
DIN EN 10270-3 (NS), ISO 6931-1 (X9CrNi18-8)
stainless springsteel, RoHS conforme
cold drawn, hard, ground, polished
tensile strength Rm: 1500 – 1800 MPa
in 3m bars (+30/0mm), end of bars: chamfered
diam. 1.50 mm, tolerance ISO h6

bars 3mgroundh 6

332 kg

0
Product total
Options total
Grand total
040 919 - 332.2441-500bars-3mgroundh-6-en
1.00050303201000

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, AISI 302
as per EN 10270-3 and ASTM F-899
stainless springsteel, hard
cold drawn, in 3m bars
diam. 1.00 mm, tolerance ISO h8

bars 3mdrawnh 8

11 kg

0
Product total
Options total
Grand total
281 118 - 11.2481-000bars-3mdrawnh-8-en
1.40050303201400

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~AISI 302
as per DIN EN 10270-3, RoHS conform
stainless springsteel, hard
cold drawn, in 3m bars
round 1.40 mm, tolerance ISO h8

bars 3mdrawnh 8

32 kg

0
Product total
Options total
Grand total
161 209 - 31.7001-400bars-3mdrawnh-8-en
1.50050303101500

Chronifer Special FM
mat.no 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, EN 10088-3
NF S94 090, ASTM F-899, ASTM A959
ISO 6931-1, ASTM A368, ASTM A313/A313M
ASTM A478, A492, A493, A479/A479M, A276
stainless springsteel,
precisely cold drawn, hard, in 3m bars
diam. 1.50 mm, tolerance ISO h7

bars 3mdrawnh 7

135 kg

0
Product total
Options total
Grand total
130 319 - 135.0291-500bars-3mdrawnh-7-en
0.90050303200900

Chronifer Special FM
no 1.4310, X12CrNi17-7, AISI 302
as per DIN EN 10270-3, EN10088-3
and ASTM F-899-02
stainless springsteel, hard
cold drawn, in 3m bars
diam. 0.90 mm, tolerance ISO h8

bars 3mdrawnh 8

7 kg

0
Product total
Options total
Grand total
150 803 - 7.0800-900bars-3mdrawnh-8-en
0.80050303200800

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~AISI 301
as per DIN EN 10270-3, DIN 10088-3
stainless springsteel, hard
cold drawn, in 3m bars
diam. 0.80 mm, tolerance ISO h8

bars 3mdrawnh 8

2 kg

0
Product total
Options total
Grand total
290 703 - 2.3150-800bars-3mdrawnh-8-en
5.00050303105000

Chronifer Special FM
no. 1.4310, X10CrNi18-8,
DIN EN 10277, AISI 302
stainless springsteel,
cold drawn hard Rm >1400 MPa
in 3m bars (+/-10mm)
diam. 5.00 mm, tolerance ISO h7

bars 3mdrawnh 7

39 kg

0
Product total
Options total
Grand total
041 220 - 39.3805-000bars-3mdrawnh-7-en
2.34050303102340

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, EN 10088-3
ASTM F-899, NF S94 090, UNS S30200
stainless springsteel, hard (Rm 1500-1700MPa)
cold drawn, in 3m bars (+/-10mm)
end of bars: pointed/chamfered
diam. 2.34 mm, tolerance ISO h7

bars 3mdrawnh 7

0 kg

0
Product total
Options total
Grand total
280 812 - 25.8002-340bars-3mdrawnh-7-en
2.25050303102250

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899
stainless springsteel, extra hard
tensile strength Rm: 1775-2050 MPa
cold drawn, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
diam. 2.25 mm, tolerance ISO h7

bars 3mdrawnh 7

7 kg

0
Product total
Options total
Grand total
091 121 - 6.9802-250bars-3mdrawnh-7-en
1.90050303101900

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899,
stainless springsteel, hard
precisely cold drawn,
in 3m lengths (+/-10mm)
end of bars: pointed, chamfered
diam. 1.90 mm, tolerance ISO h7

bars 3mdrawnh 7

11 kg

0
Product total
Options total
Grand total
161 121 - 11.3601-900bars-3mdrawnh-7-en
1.80050303101800

Chronifer Special FM
mat.no 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, EN 10088-3
NF S94 090, ASTM F-899, ASTM A959
ISO 6931-1, ASTM A368, ASTM A313/A313M
stainless springsteel, hard
cold drawn, in 3m bars
pointed/chamfered
diam. 1.80 mm, tolerance ISO h7

bars 3mdrawnh 7

29 kg

0
Product total
Options total
Grand total
101 214 - 0.600|080 818 - 27.9001-800bars-3mdrawnh-7-en
1.60050303101600

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
ASTM F-899, NF S94 040,
DIN EN 10270-3 (NS)
stainless springsteel, hard
cold drawn, in 3m bars (+/-10mm)
diam. 1.60 mm, tolerance ISO h7

bars 3mdrawnh 7

45 kg

0
Product total
Options total
Grand total
091 121 - 44.5801-600bars-3mdrawnh-7-en
1.30050303101300

Chronifer Special FM
no 1.4310, X12CrNi17-7, Aisi 302
as per EN 10088-3
stainless springsteel, hard
cold drawn, in 3m bars
diam. 1.30 mm, tolerance ISO h7

bars 3mdrawnh 7

46 kg

0
Product total
Options total
Grand total
290 109 - 46.0971-300bars-3mdrawnh-7-en
1.10050303101100

Chronifer Special FM
mat.no. 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, EN 10088-3
NF S94 090, ASTM A276 (chem.), ASTM A478
ASTM A313/A313M, ASTM A368, A492, A493
ASTM F-899, A959, ISO 6931-1 (X9CrNi18-8)
stainless springsteel, hard
cold drawn, in 3m bars
diam. 1.10 mm, tolerance ISO h7

bars 3mdrawnh 7

51 kg

0
Product total
Options total
Grand total
101 121 - 51.0001-100bars-3mdrawnh-7-en
1.00050303101000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302,
as per DIN EN 10270-3, NF S94 090
UNS S30200, EN10088-3, ASTM F-899
ASTM A276, A478, A479/479M (chem.)
ASTM A492, A493, A580/580M,ISO 6931-1
stainless springsteel, hard
cold drawn, in 3m bars
diam. 1.00 mm, tolerance ISO h7

bars 3mdrawnh 7

100 kg

0
Product total
Options total
Grand total
210 116 - 0.108|070 721 - 99.7601-000bars-3mdrawnh-7-en
2.10050313002100

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8,
as per EN 10088-3, ASTM F-899,
NFS94 090, ASTM A580/580M
as per EN 10270-3
stainless springsteel, hard
cold drawn, ground polished
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested
diam. 2.10 mm, tolerance ISO h6

bars 3mgroundh 6

400 kg

0
Product total
Options total
Grand total
040 713 - 399.8602-100bars-3mgroundh-6-en
2.00050313002000

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899,
NFS 94090, ASTM A580/580M
ASTM 276, ASTM 313/313M (chem.)
ASTM A478, A479, A492, A959
UNS S30200, ASTM A368 (chem. only)
ISO 6931-1 (X9CrNi18-8, chem. only)
stainless springsteel, hard
tensile strength Rm: 1575-1775 MPa
cold drawn, ground polished
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested, cl. 4
diam. 2.00 mm, tolerance ISO h6

bars 3mgroundh 6

928 kg

0
Product total
Options total
Grand total
150 817 - 56.301|260 419 - 872.0002-000bars-3mgroundh-6-en
9.00050313009000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8,
as per EN 10088-3 12/14, AISI 302
ASTM A580/A580M (chem. only)
NFS 94090, ASTM F-899, ISO 6931-1
UNS S30200, ASTM 959, ASTM A492
ASTM A276, ASTM A479/479M, A493
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1215-1415 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 9.00 mm, tolerance ISO h6

bars 3mgroundh 6

834 kg

0
Product total
Options total
Grand total
120 810 - 3.500|060 319 - 196.100|241 121 - 634.0009-000bars-3mgroundh-6-en
2.20050313002200

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, NFS 94-090
ASTM F899, ASTM A580/A580M, A276
ASTM A368, A478, A492, A493 (chem)
ISO 6931-1 (X9CrNi 18-8) chem.only)
stainless springsteel, extra hard
tensile strength Rm: 1600-2000 MPa
cold drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested
diam. 2.20 mm, tolerance ISO h6

bars 3mgroundh 6

564 kg

0
Product total
Options total
Grand total
180 511 - 51.380|260 918 - 513.0002-200bars-3mgroundh-6-en
5.50050313005500

Chronifer Special FM
no 1.4310, X10CrNi18-8, Aisi 302
as per EN 10088-3, ASTM F-899, NFS 94090, ASTM A580/580M
ASTM A276, A479/A479M, A959
ASTM A313, A368, A478, A492, A493
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1350-1550 MPa
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 5.50 mm, tolerance ISO h6

bars 3mgroundh 6

412 kg

0
Product total
Options total
Grand total
130 716 - 411.8005-500bars-3mgroundh-6-en
4.20050313304200

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10088-3, UNS S30200
NF S94 090, ASTM F-899, A959
ASTM A368, A478, A580/A580M (chem)
ASTM A479/A479M, A492, A493 (chem)
ISO 6931-1 (X9CrNi18-8 chem only)
stainless springsteel,
cold drawn, ground, polished,
tensile strength: 1450-1650 MPa
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested cl.4
diam. 4.20 mm, tolerance ISO h6

bars 3mgroundh 9

0 kg

0
Product total
Options total
Grand total
171 112 - 265.0004-200bars-3mgroundh-9-en
7.00050313107000

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, Aisi 302
as per DIN EN 10088-3
stainless springsteel,
tensile strength Rm: 1250-1500 MPa
cold drawn, ground, polished,
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested
diam. 7.00 mm, tolerance ISO h7

bars 3mgroundh 7

6 kg

0
Product total
Options total
Grand total
020 307 - 6.3007-000bars-3mgroundh-7-en
2.35050313102350

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn, ground, in 3m bars
diam. 2.35 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
130 313 - 2.130|250 919 - 684.5502-350bars-3mgroundh-7-en
12.70050313012700

Chronifer Special FM
no. 1.4310, X10CrNi18-8,
as per EN 10088-3, AISI 302, UNS S30200
NFS 94090, ASTM F-899,
ASTM A276, ASTM A479/479M-08
ASTM A313/313M, A368, A478,
ASTM A492, A493 (chem.only)
stainless springsteel, hard
cold drawn, ground, polished
tensile strength Rm: 1215-1415 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl.4
diam. 12.70 mm (1/2″), tolerance ISO h6

bars 3mgroundh 6

597 kg

0
Product total
Options total
Grand total
070 813 - 599.91812-700bars-3mgroundh-6-en
12.00050313012000

Chronifer Special FM
no. 1.4310, X10CrNi18-8,
as per EN 10088-3, AISI 302, UNS S30200
NFS 94090, ASTM F-899, A959
ASTM A313/A313M, A368, A492,A493
ASTM A276, ASTM A479/479M-08
stainless springsteel, hard
cold drawn, ground, polished
tensile strength Rm: 1215-1415 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 12.00 mm, tolerance ISO h6

bars 3mgroundh 6

687 kg

0
Product total
Options total
Grand total
130 313 - 2.130|250 919 - 684.55012-000bars-3mgroundh-6-en
11.00050313011000

Chronifer Special FM
no. 1.4310, X10CrNi18-8,
as per EN 10088-3, UNS S30200,AISI 302
NFS 94090, ASTM F-899,
ASTM A276, ASTM A479/479M
ASTM A276, ASTM A479/479M, A368, A492
ASTM A493, A478 (chemistry only)
stainless springsteel, hard
cold drawn, ground, polished
tensile strength Rm: 1215-1415 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 11.00 mm, tolerance ISO h6

bars 3mgroundh 6

593 kg

0
Product total
Options total
Grand total
290 813 - 593.25611-000bars-3mgroundh-6-en
10.00050313010000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8,
as per EN 10088-3, UNS S30200
NF S94 090, ASTM F-899, AISI 302
ASTM A276, ASTM A479/479M-08
ASTM A368, A478, A492, A493, A959
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1215-1415 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 10.00 mm, tolerance ISO h6

bars 3mgroundh 6

89 kg

800
Product total
Options total
Grand total
290 120 - 88.70010-000bars-3mgroundh-6-en
8.00050313008000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3 12/14, ASTM F-899,
NF S 94090, ASTM A580/580M, ISO 6931-1
UNS S30200, ASTM A276, A313/313M
ASTM A368, A478, A479/A479M,A492
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1250-1450 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
as per EN10277-1, Tab.1, cl. 3
diam. 8.00 mm, tolerance ISO h6

bars 3mgroundh 6

94 kg

800
Product total
Options total
Grand total
300 512 - 1.700|081 117 - 104.6008-000bars-3mgroundh-6-en
6.50050313006500

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899,
NF S 94090, ASTM A580/580M
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1300-1500 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 6.50 mm, tolerance ISO h6

bars 3mgroundh 6

640 kg

0
Product total
Options total
Grand total
111 120 - 639.6006-500bars-3mgroundh-6-en
6.35050313006350

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, Aisi 302
as per EN 10088-3, ASTM F-899, NFS 94090, ASTM A580/580M
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1350-1550 MPa
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 6.35 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
270 612 - 10.000|191 218 - 332.1006-350bars-3mgroundh-6-en
6.00050313006000

Chronifer Special FM
mat.no.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, UNS S30200
ASTM F-899, NF S94 090, ASTM A276
ASTM A479/A479M, ASTM A959,
ASTM A368, A478, A580/A580M (chem)
ASTM A580/580M, A492/A493 (chem.)
ISO 6931-1 (X9CrNi 18-8) chem. only
conforme EG/2002/95 ROHS directive
stainless springsteel, hard
cold drawn, ground, polished
tensile strength Rm: 1350-1550 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 6.00 mm, tolerance ISO h6

bars 3mgroundh 6

200 kg

800
Product total
Options total
Grand total
110 320 - 199.8006-000bars-3mgroundh-6-en
5.00050313005000

Chronifer Special FM
no. 1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899, A959
ASTM A276, A580/A580M, A479/479M
ASTM A313/A313M, ISO 6931-1, (chem.)
ASTM A368, A478, A492, A493 (chem.)
stainless springsteel, hard
cold drawn, ground, polished
tensile strength Rm: 1350-1550 MPa
in 3m lengths (+40/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 5.00 mm, tolerance ISO h6

bars 3mgroundh 6

583 kg

0
Product total
Options total
Grand total
060 814 - 0.350|270 319 - 596.6005-000bars-3mgroundh-6-en
2.30050313002300

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, NFS 94-090
ASTM F899, ASTM A580/A580M, ASTM A276
ASTM A313/A313M (chem. only)
ASTM A368, A478, A479/A479M, A492 (chem.)
ISO 6931-1 (X9CrNi 18-8 (chem.) ASTM A959
stainless springsteel, extra hard
tensile strength Rm: 1775-1950 MPa
cold drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested
diam. 2.30 mm, tolerance ISO h6

bars 3mgroundh 6

247 kg

0
Product total
Options total
Grand total
180 511 - 2.100|200 417 - 245.8002-300bars-3mgroundh-6-en
4.50050313004500

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
suivant EN 10088-3, UNS S30200
ASTM F-899, NF S94 090
ASTM A276, ASTM A580/A580M
ASTM A479/A479M
stainless springsteel,
tensile strength Rm: 1300-1500 MPa
cold drawn, ground, in 3m bars
pointed, chamfered, eddycurrent
crack tested
diam. 4.50 mm, tolerance ISO h6

bars 3mgroundh 6

673 kg

0
Product total
Options total
Grand total
211 112 - 177.600|250 523 - 495.0004-500bars-3mgroundh-6-en
4.00050313004000

Chronifer Special FM
no. 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10088-3, UNS S30200
NF S94 090, ASTM F-899, A959
ASTM A368, A478, A580/A580M (chem)
ASTM A479/A479M, A492, A493 (chem)
ISO 6931-1 (X9CrNi18-8 chem only)
stainless springsteel
cold drawn, ground, polished
tensile strength: 1380-1580 MPa
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested cl. 4
diam. 4.00 mm, tolerance ISO h6

bars 3mgroundh 6

638 kg

0
Product total
Options total
Grand total
260 220 - 637.7004-000bars-3mgroundh-6-en
3.96050313003960

Chronifer Special FM
no. 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10088-3, UNS S30200
NF S94 090, ASTM F-899, A959
ASTM A368, A478, A580/A580M (chem)
ASTM A479/A479M, A492, A493 (chem)
ISO 6931-1 (X9CrNi18-8 chem only)
stainless springsteel,
cold drawn, ground, polished,
tensile strength: 1450-1650 MPa
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested cl.4
diam. 3.96 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
300 113 - 465.800|200 218 - 566.000|210 218 - 254.8003-960bars-3mgroundh-6-en
3.60050313003600

Chronifer Special FM
German no.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899-20,
NF S94-090, ASTM A276/A276M,
ASTM A313/A313M (chem.)
ISO 6931-1 (X9CrNi 18-8 chem.)
ASTM A580/580M, UNS S30200
ASTM A368/A478/A479,A493 (chem.)
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1350-1600 MPa
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 3.60 mm, tolerance ISO 286-2h6

bars 3mgroundh 6

331 kg

0
Product total
Options total
Grand total
121 022 - 331.1603-600bars-3mgroundh-6-en
3.50050313003500

Chronifer Special FM
no 1.4310, X10CrNi18-8, Aisi 302
as per EN 10088-3, ASTM F-899, NFS 94-090, ASTM A580/580M,UNS S30200
ASTM A368/A478/A479,A493 (chem.)
ASTM A276, ASTM A313/A313M (chem.)
ISO 6931-1 (X9CrNi 18-8 chem.)
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1500-1700 MPa
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 3
diam. 3.50 mm, tolerance ISO h6

bars 3mgroundh 6

495 kg

0
Product total
Options total
Grand total
060 313 - 0.610|020 513 - 1.673|300 119 - 492.9003-500bars-3mgroundh-6-en
3.40050313003400

Chronifer Special FM
German no.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, ASTM F-899-20,
NF S94-090, ASTM A276/A276M,
ASTM A313/A313M (chem.)
ISO 6931-1 (X9CrNi 18-8 chem.)
ASTM A580/580M, UNS S30200
ASTM A368/A478/A479,A493 (chem.)
stainless springsteel, hard
cold drawn, ground polished
tensile strength Rm: 1350-1600 MPa
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 3.40 mm, tolerance ISO 286-2h6

bars 3mgroundh 6

339 kg

0
Product total
Options total
Grand total
091 122 - 338.7003-400bars-3mgroundh-6-en
3.20050313003200

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
gemäss EN 10088-3 12/14, ASTM F-899, NF S 94-090, ASTM A580/580M, UNS S30200
ASTM A368/A478/A479,A493 (chem.)
ASTM A313/A313M, ISO 6931-1 (X9CrNi 18-8)
stainless springsteel, hard
cold drawn, ground, polished
tensile strength Rm: 1550-1700 MPa
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 3.20 mm, tolerance ISO h6

bars 3mgroundh 6

678 kg

0
Product total
Options total
Grand total
020 513 - 0.200|090 120 - 26.200|271 221 - 43.000|240 822 - 608.1003-200bars-3mgroundh-6-en
3.00050313003000

Chronifer Special FM
as per 1.4310, X10CrNi18-8, AISI 302
per EN 10088-3, ASTM F-899,
NF S94 090, ASTM A580/580M, UNS S30200
per ASTM A276, ASTM A479/A479M
ASTM A478, A492, A493, A368 (chem.)
ISO 6931-1 (X9CrNi 18-8 chem.)
stainless springsteel, hard
tensile strength Rm: 1550-1750 MPa
cold drawn, ground, polished
in 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 3.00 mm, tolerance ISO h6

bars 3mgroundh 6

1945 kg

0
Product total
Options total
Grand total
041 219 - 33.146|240 522 - 794.500|210 922 - 131.300|041 122 - 985.7003-000bars-3mgroundh-6-en
2.80050313002800

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, DIN EN 10088-3
UNS S30200, NF S94-090, ASTM A276
ASTM A316/A313M (chem.), ASTM F-899
ASTM A478, A492, A493, A959, A479 (chem)
ISO 6932-1 (X9CrNi 18-8 (chem.)
stainless springsteel, RoHS conform
tensile strength Rm: 1550-1760 MPa
cold drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested cl. 4
diam. 2.80 mm, tolerance ISO h6

bars 3mgroundh 6

69 kg

300
Product total
Options total
Grand total
160 518 - 68.6102-800bars-3mgroundh-6-en
2.50050313002500

Chronifer Special FM
mat.no 1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3 12/14, UNS S30200
ASTM F-899, NF S94 090, ASTM A492
ASTM A276, ASTM A580/A580M,
ASTM A368, A478/A479/A959 (chem)
ASTM A313/A313M, ASTM A493 (chem)
as per ISO 6931-1 (X9CrNi 18-8, chem.)
stainless springsteel, hard
cold worked, ground, polished,
tensile strength Rm: 1575 – 1810 MPa
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 2.50 mm, tolerance ISO h6

bars 3mgroundh 6

1298 kg

500
Product total
Options total
Grand total
090 720 - 606.836|180 123 - 824.5002-500bars-3mgroundh-6-en
2.40050313002400

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per EN 10088-3, NFS 94-090
ASTM F899, ASTM A580/A580M, A276
stainless springsteel, hard
cold drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 2.40 mm, tolerance ISO h6

bars 3mgroundh 6

547 kg

0
Product total
Options total
Grand total
030 310 - 42.822|060 612 - 504.6002-400bars-3mgroundh-6-en
1.35050303001350

Chronifer Special FM
no. 1.4310, X12CrNi17-7, AISI 302
as per DIN EN 10270-3
stainless springsteel, hard
Rm 1500-1800 MPa
cold drawn, in 3m bars (+/- 10 mm)
diam. 1.35 mm, tolerance ISO h6

bars 3mdrawnh 6

50 kg

0
Product total
Options total
Grand total
100 418 - 50.4301-350bars-3mdrawnh-6-en
1.20050303001200

Chronifer Special FM
no. 1.4310, X12CrNi18-8, AISI/SUS 302
as per DIN EN 10270-3, EN10088-3
as per ASTM F-899 and ASTM A276
stainless springsteel, hard
precisely cold drawn, Rm 1850-2050 MPa
in 3m bars (+/- 10 mm)
diam. 1.20 mm, tolerance ISO h6

bars 3mdrawnh 6

28 kg

0
Product total
Options total
Grand total
231 118 - 27.9831-200bars-3mdrawnh-6-en
1.00050303001000

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, AISI 302 (~AISI 301)
as per DIN EN 10270-3, DIN EN 10088-3
UNS S30200, ASTM A368 (chem.)
NF S94 909, ASTM A580/A580M, A478
ASTM A276, ASTM A479, ASTM A492 A959
stainless springsteel, hard (Rm: 1900-2100 MPa)
precisely cold drawn, in 3m bars (+/-10mm)
diam. 1.00 mm, tolerance ISO h6

bars 3mdrawnh 6

54 kg

0
Product total
Options total
Grand total
080 920 - 53.9901-000bars-3mdrawnh-6-en
0.70050300600700

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090, ASTM A478
ASTM A276, A313/A313M, A368,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
(for all only chemical analyses)
stainless springsteel, hard
cold drawn, bright surface
tensile strength Rm 1950-2150 MPa
on spool typ SH390, max. 10kg/spool
diam. 0.70 mm, tolerance ISO fg6

in spoolsdrawnfg 6

512 kg

0
Product total
Options total
Grand total
270 220 - 162.950|281 021 - 105.820|160 322 - 243.0000-700in-spoolsdrawnfg-6-en
0.50050300700500

Chronifer Special FM
no 1.4310, X10CrNi18-8, Aisi 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090, ASTM F-899
ASTM A276, A313/A313M, A368, A478,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
stainless springsteel, hard
tensile strength Rm: 2000-2200 MPa
cold drawn, on spools
diam. 0.50 mm, tolerance ISO fg7

in spoolsdrawnfg 7

41 kg

0
Product total
Options total
Grand total
041 110 - 8.464|050 811 - 32.1530-500in-spoolsdrawnfg-7-en
0.30050300700300

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, Aisi 302
ASTM F-899, NF S 94-040,
ASTM A580, ASTM A313/A313M
as per norms EN 10270-3 (NS)
stainless springsteel, hard
tensile strength Rm: 2150-2350 MPa
precisely cold finished, polished
in bobbins of. 5kg each
diam. 0.30 mm, tolerance ISO fg7

in spoolsdrawnfg 7

0 kg

0
Product total
Options total
Grand total
0-300in-spoolsdrawnfg-7-en
2.50050300602500

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3 12/24
and NF S 94-090, ASTM A478
ASTM A276, A313/A313M, A368,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
ISO 6931-1 (X9CrNi 18-8), UNS S30200
(for all only chemical analyses)
stainless springsteel, hard
cold drawn, bright surface
tensile strength Rm 1750-1850MPa
in coils for ESCO
diam. 2.50 mm, tolerance ISO fg6

in spoolsdrawnfg 6

312 kg

0
Product total
Options total
Grand total
230 622 - 312.1502-500in-spoolsdrawnfg-6-en
2.40050300602400

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3 12/24
and NF S 94-090, ASTM A478
ASTM A276, A313/A313M, A368,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
ISO 6931-1 (X9CrNi 18-8), UNS S30200
(for all only chemical analyses)
stainless springsteel, hard
cold drawn, bright surface
tensile strength Rm 1750-1850MPa
in coils for ESCO
diam. 2.40 mm, tolerance ISO fg6

in spoolsdrawnfg 6

338 kg

0
Product total
Options total
Grand total
310 118 - 338.1002-400in-spoolsdrawnfg-6-en
1.80050300601800

CChronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
ASTM F-899-20, NF S 94 040, ASTM A276
ASTM A580, ASTM A313/A313M
ASTM A368, ASTM A478, A479/479M
ASTM A492, A493, A959, ISO 6931-1
as per DIN EN 10270-3 (NS), EN10088-3
stainless springsteel, hard, VAR
drawn polished, tensile Rm 1900-2100 MPa
in coils of 15-25kg
diam. 1.80 mm, tolerance ISO fg6

in spoolsdrawnfg 6

533 kg

0
Product total
Options total
Grand total
151 122 - 533.2001-800in-spoolsdrawnfg-6-en
1.40050300601400

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
ASTM F-899-20, NF S 94 040, ASTM A276(chem.)
ASTM A580, ASTM A313/A313M, UNS S30200
ASTM A580/A580M, RoHS conform
ASTM A368, ASTM A478, A479/479M
ASTM A492, A493, A959, ISO 6931-1 (X9CrNi 18-8)
gemäss DIN EN 10270-3 (NS), EN10088-3
federhart, DIN 17224, Rm 1900-2100MPa
stainless springsteel, hard, VAR
drawn polished, tensile Rm 1900-2100 MPa
in coils of 15-25kg
diam. 1.40 mm, tolerance ISO fg6

in spoolsdrawnfg 6

323 kg

0
Product total
Options total
Grand total
221 122 - 322.7001-400in-spoolsdrawnfg-6-en
1.00050300601000

Chronifer Special FM
German no 1.4310,  X10CrNi18-8, AISI 302
UNS S30200, EN10088-3 12/14
gemäss DIN EN 10270-3 (NS)
ISO 6931-1 (X9CrNi 18-8)
ASTM F-899-20 Co<0.10%, NF S94 090,   ASTM A580/A580M, ASTM A313/A313M ASTM A492,  A493, A959, A368 ASTM A479/A479M (chem. only) ASTM A478, ASTM A276 (chem. only) stainless springsteel precisely cold drawn, polished tensile strength Rm: 2000-2200 MPa in coils for ESCO machine (10-13kg/coils) diam. 1.00 mm, tolerance ISO fg6

in spoolsdrawnfg 6

1076 kg

0
Product total
Options total
Grand total
070 721 - 160.000|171 121 - 915.7501-000in-spoolsdrawnfg-6-en
0.90050300600900

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090, ASTM A478
ASTM A276, A313/A313M, A368,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
(for all only chemical analyses)
stainless springsteel, hard
cold drawn, bright surface
tensile strength Rm 2000-2100 MPa
on spool typ SH390, max. 10kg/spool
diam. 0.90 mm, tolerance ISO fg6

in spoolsdrawnfg 6

159 kg

0
Product total
Options total
Grand total
270 220 - 159.4900-900in-spoolsdrawnfg-6-en
0.85050300600850

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090, ASTM A478
ASTM A276, A313/A313M, A368,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
(for all only chemical analyses)
stainless springsteel, hard
cold drawn, bright surface
tensile strength Rm:2000-2100 MPa
on spool typ SH390, max. 10kg/spool
diam. 0.85 mm, tolerance ISO fg6

in spoolsdrawnfg 6

160 kg

0
Product total
Options total
Grand total
270 220 - 160.1100-850in-spoolsdrawnfg-6-en
0.80050300600800

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090, ASTM A478
ASTM A276, A313/A313M, A368,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
(for all only chemical analyses)
stainless springsteel, hard
cold drawn, bright surface
tensile strength Rm >2000 MPa
on spool typ SH390, max. 10kg/spool
diam. 0.80 mm, tolerance ISO fg6

in spoolsdrawnfg 6

251 kg

0
Product total
Options total
Grand total
270 220 - 101.200|060 522 - 149.9400-800in-spoolsdrawnfg-6-en
0.60050300600600

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090
ASTM A276, A313/A313M, A368, A478,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
stainless springsteel, hard
precisely cold worked, bright surface
tensile strength Rm > 2000 MPa
on spool typ SH390, max. 10kg/spool
diam. 0.60 mm, tolerance ISO fg6

in spoolsdrawnfg 6

60 kg

0
Product total
Options total
Grand total
260 214 - 60.3950-600in-spoolsdrawnfg-6-en
1.10050300701100

Chronifer Special FM
mat.no.1.4310, X10CrNi18-8, Aisi 302
as per DIN EN 10270-3 (NS)
UNS S30200, EN10088-3
ISO 6931-1 (X9CrNi 18-8)
ASTM F-899, NF S 94090,
ASTM A580, ASTM A313/A313M
ASTM A492, A493, A959, A368
ASTM A478, ASTM A276 (chem.only)
stainless springsteel, hard
tensile strength Rm: 2000-2200 MPa
precisely cold drawn polished, in coils
diam. 1.10 mm, tolerance ISO fg7

in spoolsdrawnfg 7

217 kg

0
Product total
Options total
Grand total
101 121 - 217.4001-100in-spoolsdrawnfg-7-en
2.50050300502500

Chronifer Special FM
no 1.4310, X12CrNi17-7, ~Aisi 302,
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn in coils
diam. 2.50 mm, tolerance ISO fg8

in spoolsdrawnfg 8

31 kg

0
Product total
Options total
Grand total
100 604 - 30.5002-500in-spoolsdrawnfg-8-en
2.30050300502300

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn, in coils
round 2.30 mm, tolerance ISO fg8

in spoolsdrawnfg 8

127 kg

0
Product total
Options total
Grand total
100 604 - 126.6002-300in-spoolsdrawnfg-8-en
1.70050300501700

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~AISI 302
as per DIN EN 10270-3, ASTM F-899
stainless springsteel, hard
cold drawn in coils
round 1.70 mm, tolerance ISO fg8

in spoolsdrawnfg 8

153 kg

0
Product total
Options total
Grand total
110 107 - 152.7001-700in-spoolsdrawnfg-8-en
0.90050300500900

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, ASTM F-899
stainless springsteel, hard
cold drawn, in coils
diam. 0.90 mm, tolerance ISO fg8

in spoolsdrawnfg 8

0 kg

0
Product total
Options total
Grand total
120 912 - 91.6000-900in-spoolsdrawnfg-8-en
3.10050300203100

Chronifer Special FM
german no 1.4310 FB, AISI 302
EN 10088-3, ASTM F-899
X10CrNi18-8, ASTM A580/A580M
NF S94090, EN10270-3
ASTM A313/A313M, ASTM A368
ASTM A478, A492, A493
stainless springsteel, hard
tensile strength Rm: 1700 MPa apprx.
cold drawn in coils of apprx. 30kg
round 3.10 mm, tolerance ISO h8

in spoolsdrawnh 8

310 kg

0
Product total
Options total
Grand total
140 812 - 310.0003-100in-spoolsdrawnh-8-en
0.45050300000450

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090
ASTM A276, A313/A313M, A368, A478,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
stainless springsteel, hard
precisely cold worked, bright surface
tensile strength Rm > 2000 MPa
on spool typ SH390, max. 10kg/spool
diam. 0.45 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
070 819 - 152.250|151 221 - 275.0000-450in-spoolsdrawnh-6-en
0.40050300000400

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
stainless springsteel, hard
cold drawn, extra hard Rm: 2100-2416 MPa
on spools SH 390K (~5kg each)
diam. 0.40 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
280 812 - 217.9040-400in-spoolsdrawnh-6-en
0.30050300000300

Chronifer Special FM
no 1.4310, X10CrNi18-8,
AISI 302, ASTM F-899 (chem. only)
per DIN EN 10270-3, EN 10088-3
stainless springsteel, hard
cold drawn, extra hard Rm: 2150-2473 MPa
on spools SH 390K (~5kg each)
diam. 0.30 mm, tolerance ISO h6

in spoolsdrawnh 6

85 kg

0
Product total
Options total
Grand total
050 318 - 85.3930-300in-spoolsdrawnh-6-en
0.20050300000200

Chronifer Special FM
no 1.4310, X10CrNi18-8,
AISI 302, ASTM F-899 (chem. only)
per DIN EN 10270-3, EN 10088-3
stainless springsteel, hard
cold drawn, extra hard Rm: 2200-2530 MPa
on spools DIN 200 (~5kg each)
diam. 0.20 mm, tolerance ISO h6

in spoolsdrawnh 6

257 kg

0
Product total
Options total
Grand total
050 318 - 6.910|200 422 - 250.3750-200in-spoolsdrawnh-6-en
1.40050302801400

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn, in 2m bars
round 1.40 mm, tolerance +/-0.03mm

bars 2mdrawnspec.

1 kg

0
Product total
Options total
Grand total
160 594 - 0.7481-400bars-2mdrawnspec-en
1.00050300701000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302,
as per DIN EN 10270-3, NF S94 090
UNS S30200, EN10088-3, ASTM F-899
ASTM A276, A478, A479/479M (chem.)
ASTM A492, A493, A580/580M,ISO 6931-1
stainless springsteel
precisely cold drawn, polished
tensile strength Rm: 2000-2150 MPa
in coils for ESCO machine
diam. 1.00 mm, tolerance ISO fg7

in spoolsdrawnfg 7

3 kg

0
Product total
Options total
Grand total
210 116 - 3.4771-000in-spoolsdrawnfg-7-en
1.60050300601600

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
ASTM F-899-20, NF S 94 040, ASTM A276(chem.)
ASTM A580, ASTM A313/A313M, UNS S30200
ASTM A580/A580M, RoHS conform
ASTM A368, ASTM A478, A479/479M
ASTM A492, A493, A959, ISO 6931-1 (X9CrNi 18-8)
gemäss DIN EN 10270-3 (NS), EN10088-3
federhart, DIN 17224, Rm 1900-2100MPa
stainless springsteel, hard, VAR
drawn polished, tensile Rm 1900-2100 MPa
in coils of 15-25kg
diam. 1.60 mm, tolerance ISO fg6

in spoolsdrawnfg 6

423 kg

0
Product total
Options total
Grand total
160 222 - 422.9501-600in-spoolsdrawnfg-6-en
1.20050300701200

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~AISI 301,
as per DIN EN 10270-3, AISI 302
stainless springsteel
precisely cold drawn, polished
tensile strength Rm: 1900-2150 MPa
in coils of apprx. 20kg for ESCO
diam. 1.20 mm, tolerance ISO fg7

in spoolsdrawnfg 7

398 kg

0
Product total
Options total
Grand total
050 510 - 397.7001-200in-spoolsdrawnfg-7-en
1.00050300801000

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn in coils
round 1.00 mm, tolerance ISO +/-0.02

in spoolsdrawnspec.

10 kg

0
Product total
Options total
Grand total
200 600 - 10.4211-000in-spoolsdrawnspec-en
0.40050302800400

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
stainless springsteel, hard
cold drawn, in 2m bars
diam. 0.40 mm, tolerance +/-0.007 mm

bars 2mdrawnspec.

5 kg

0
Product total
Options total
Grand total
050 805 - 4.8000-400bars-2mdrawnspec-en
1.10050302201100

Chronifer Special FM
mat.no. 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, EN 10088-3
NF S94 090, ASTM A276 (chem.), ASTM A478
ASTM A313/A313M, ASTM A368, A492, A493
ASTM F-899, A959, ISO 6931-1 (X9CrNi18-8)
stainless springsteel, hard
cold drawn, in 2m bars (+/-10mm)
round 1.10 mm, tolerance ISO h8

bars 2mdrawnh 8

3 kg

0
Product total
Options total
Grand total
251 012 - 3.4001-100bars-2mdrawnh-8-en
0.60050302200600

Chronifer Special FM
mat.no.1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, ASTM F-899
stainless springsteel, hard
cold drawn, tensile strength Rm:1600-2000MPa
in 2m bars (+50/0mm)
diam. 0.60 mm, tolerance ISO h8

bars 2mdrawnh 8

72 kg

0
Product total
Options total
Grand total
071 221 - 71.7980-600bars-2mdrawnh-8-en
0.50050302200500

Chronifer Special FM
no. 1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, ASTM F-899
stainless springsteel, hard
tensile strength Rm > 2000 MPa
cold drawn, in 2m bars
diam. 0.50 mm, tolerance ISO h8

bars 2mdrawnh 8

8 kg

0
Product total
Options total
Grand total
041 110 - 7.5320-500bars-2mdrawnh-8-en
1.25050300701250

Chronifer Special FM
W-Nr.1.4310, X10CrNi17-7, AISI 302,
as per DIN EN 10270-3, NF S94 090
UNS S30200, EN10088-3 12/14, ASTM F-899
ASTM A276, A478, A479/479M (chem.)
ASTM A492, A493, A580/580M,ISO 6931-1
stainless springsteel, RoHs conforme
precisely cold drawn, polished
tensile strength Rm: 2000-2100 MPa
in coils for ESCO machine
diam. 1.25 mm, tolerance ISO fg7

in spoolsdrawnfg 7

223 kg

0
Product total
Options total
Grand total
311 018 - 223.2501-250in-spoolsdrawnfg-7-en
0.80050302100800

Chronifer Special FM
no 1.4310, X12CrNi17-7, AISI 302
as per EN 10088-3, DIN EN 10270-3
stainless springsteel, hard
as per ASTM F-899
cold drawn, in 2m bars
diam. 0.80 mm, tolerance ISO h7

bars 2mdrawnh 7

28 kg

0
Product total
Options total
Grand total
260 214 - 2.164|270 220 - 25.5000-800bars-2mdrawnh-7-en
0.70050302100700

Chronifer Special FM
no. 1.4310, X10CrNi18-8, EN10088-3
per DIN EN 10270-3, ASTM F-899, AISI 302
stainless springsteel, hard
cold finished, polished, in 2m bars
diam. 0.70 mm, tolerance ISO h7

bars 2mdrawnh 7

9 kg

0
Product total
Options total
Grand total
290 703 - 9.0600-700bars-2mdrawnh-7-en
0.60050302100600

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~AISI 301
as per DIN EN 10270-3
as per ASTM F-899
stainless springsteel, hard
cold drawn, polished, in 2m bars
diam. 0.60 mm, tolerance ISO h7

bars 2mdrawnh 7

0 kg

0
Product total
Options total
Grand total
041 110 - 0.4600-600bars-2mdrawnh-7-en
0.30050302000300

Chronifer Special FM
no. 1.4310, EN/DIN X10CrNi18-8
AISI 301/302, ASTM F899, ASTM A276
stainless springsteel, hard
cold drawn, Rm 2000 – 2200 MPa
in straight 2m bars
diam. 0.30 mm, tolerance ISO h6

bars 2mdrawnh 6

2 kg

0
Product total
Options total
Grand total
100 523 - 1.8100-300bars-2mdrawnh-6-en
3.000503008030001

Chronifer Special FM
german no 1.4310 FB, AISI 302
EN 10088-3, ASTM F-899
X10CrNi18-8, ASTM A580/A580M
NF S94090, EN10270-3
ASTM A313/A313M, ASTM A368
ASTM A478, A492, A493
stainless springsteel, hard
tensile strength Rm: 1700 MPa apprx.
cold drawn in coils of apprx. 30kg
round 3.00 mm, tolerance +/- 0.010mm

in spoolsdrawnspec.

0 kg

0
Product total
Options total
Grand total
080 408 - 766.1503-000in-spoolsdrawnspec-en
1.90050300801900

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, AISI 302
as per DIN EN 10270-3, Si max 1.0%
ASTM F-899
stainless springsteel, hard
cold drawn in coils Rm > 1900MPa
round 1.90 mm, tolerance ISO fg6

in spoolsdrawnspec.

50 kg

0
Product total
Options total
Grand total
011 299 - 49.7001-900in-spoolsdrawnspec-en
1.60050302101600

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, AISI 302
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn, in 2m bars
diam. 1.60 mm, tolerance ISO h7

bars 2mdrawnh 7

15 kg

0
Product total
Options total
Grand total
130 912 - 14.428|180 712 - 0.5581-600bars-2mdrawnh-7-en
0.75050300800750

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3
and NF S 94-090, ASTM A478
ASTM A276, A313/A313M, A368,
ASTM A479/479M, A492, A493,
ASTM A580/580M, ASTM F-899
stainless springsteel, hard
tensile strength: 2100-2300 MPa
cold drawn, on spools SH390
diam. 0.75 mm, tolerance +/-0.003mm

in spoolsdrawnspec.

0 kg

0
Product total
Options total
Grand total
221 012 - 3.7200-750in-spoolsdrawnspec-en
2.00050300702000

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
EN 10088-3, ASTM F-899-12
EN 10270-3, NF S94 090
ASTM A959, A493, A313/A313M
ASTM 348, A478, ISO 6931-1
ASTM A276-08a, A580/A580M
stainless springsteel, hard
tensile strength Rm: 1750-1950 MPa
cold drawn, polished, in coils
diam. 2.00 mm, tolerance ISO fg7

in spoolsdrawnfg 7

213 kg

0
Product total
Options total
Grand total
201 217 - 213.0002-000in-spoolsdrawnfg-7-en
0.45050300800450

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
as per DIN EN 10270-3
stainless springsteel, hard
tensile strength: 2050 – 2300 Mpa
cold drawn on spools
round 0.45 mm, tolerance +/-0.007mm

in spoolsdrawnspec.

24 kg

0
Product total
Options total
Grand total
050 805 - 23.6100-450in-spoolsdrawnspec-en
1.30050300701300

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
ASTM F-899-20, NF S94 090, ISO 6931-1
gemäss DIN EN 10088-3, ASTM A313/A313
ASTM A276, ASTM A479/A479M (chem.)
ASTM A368, A478, A492, A493
gemäss DIN EN 10270-3, ASTM A580/A580M
stainless springsteel,
precisely cold drawn, polished
tensile strenth Rm: 1950-2150 MPa
in coils of 20 +/-5kg
diam. 1.30 mm, tolerance ISO fg7

in spoolsdrawnfg 7

325 kg

0
Product total
Options total
Grand total
271 021 - 325.3501-300in-spoolsdrawnfg-7-en
1.40050300701400

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~Aisi 302
as per DIN EN 10270-3
stainless springsteel,
cold drawn, polished, hard
in coils
diam. 1.40 mm, tolerance ISO fg7

in spoolsdrawnfg 7

0 kg

0
Product total
Options total
Grand total
241 019 - 4.600|140 223 - 288.3001-400in-spoolsdrawnfg-7-en
1.80050300701800

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, Aisi 302
UNS S30200, EN10088-3
ISO 6931-1 (X9CrNi 18-8)
ASTM F-899, NF S 94040,
ASTM A580, ASTM A313/A313M
ASTM A492, A493, A959
as per DIN EN 10270-3 (NS)
stainless springsteel, hard
tensile strength Rm: 1850-2050MPa
cold drawn polished, in coils
diam. 1.80 mm, tolerance ISO fg7

in spoolsdrawnfg 7

213 kg

0
Product total
Options total
Grand total
080 818 - 213.0001-800in-spoolsdrawnfg-7-en
1.50050300701500

Chronifer Special FM
no. 1.4310, X10CrNi18-8
AISI 302 UNS S30200, EN 10088-3 12/14
DIN EN 10270-3, NF S94090
ASTM A492, ASTM A493, RoHS conforme
ASTM A276, A478, A479 (chem. only)
ASTM A313/A313M, ASTM A368
ASTM F-899, A959, ISO 6931-1
stainless springsteel, hard
cold drawn, polished, in coils
tensile strength Rm: 1950-2050 MPa
diam. 1.50 mm, tolerance ISO fg7

in spoolsdrawnfg 7

634 kg

0
Product total
Options total
Grand total
290 818 - 173.050|040 522 - 461.1001-500in-spoolsdrawnfg-7-en
2.10050300702100

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
as per DIN EN 10270-3
stainless springsteel, hard
cold drawn, in coils
round 2.10 mm, tolerance ISO fg7

in spoolsdrawnfg 7

187 kg

0
Product total
Options total
Grand total
160 409 - 186.6002-100in-spoolsdrawnfg-7-en
0.10050300800100

Chronifer Special FM
no 1.4310, X10CrNi18-8, AISI 302
per DIN EN 10270-3, EN 10088-3, ASTM F-899
stainless springsteel, hard
cold drawn, extra hard Rm: 2200-2530 MPa
on spools SH 390K (~5kg each)
diam. 0.10 mm, tolerance +/-0.003mm

in spoolsdrawnspec.

103 kg

0
Product total
Options total
Grand total
050 618 - 103.0870-100in-spoolsdrawnspec-en
0.30050300800300

Chronifer Special FM
W-Nr.1.4310, X12CrNi17-7, ~ Aisi 301
as per DIN EN 10270-3
as per ASTM F-899
stainless springsteel, hard
cold drawn in coils
diam. 0.30 mm, tolerance ISO js7

in spoolsdrawnspec.

1 kg

0
Product total
Options total
Grand total
050 805 - 0.7170-300in-spoolsdrawnspec-en
0.40050300800400

Chronifer Special FM
W-Nr.1.4310, X10CrNi18-8, AISI 302
as per DIN EN 10270-3, per ASTM F-899
stainless springsteel, hard
tensile strength: 2100 – 2350 MPa
cold drawn on K460 spools
diam. 0.40 mm, tolerance +/-0.007 mm

in spoolsdrawnspec.

8 kg

0
Product total
Options total
Grand total
050 805 - 8.0570-400in-spoolsdrawnspec-en
Werkstoff-Nr.1.4310
DINX 10 CrNi 18-8
AFNORX 10 CrNi 18-8
AISI~ 301 / 302 F 899
ISOX 10 CrNi 18-8
EuronormX 10 CrNi 18-8
Andere
C %0.05-0.15
Si %≤ 1.00
Mn %≤ 2.00
P %≤ 0.045
S %≤ 0.015
Cr %17.0-19.0
Mo %≤ 0.80
Ni %8.0-9.50
Cu %≤ 1.00
Pb %≤ 0.10
Zn %
Sn %
Fe %
O %
N %
H %
Ti %
Schnittgeschwindigkeit~ 15-25
Standardabmessung an Lager0.1-12.7 mm
