Finemac

Finemac

Short description

Klein designation: Finemac
Metal class: lead-free, hardenable, free-cutting carbon steel
Material number: (Material No. 1.1268)
UNS standard: No UNS designation
RoHS 2 – 2011/65/EU: Generally suitable for RoHS-compliant applications, as the material is lead-free; formal confirmation of compliance should be provided for each specific batch.
Machinability: Very consistent machinability and long tool life
Hardenability: Very good; wide temperature and time range during hardening, high hardness and a low risk of rejects. A hardness of approximately 850 HV5 is achieved after quenching.
Formability: Good; particularly suitable for long, slender precision components with tight tolerances
Cold forming: Very good; in particular, excellent cold-heading properties
Polishability: Good; the material is available in ground and polished condition.
Magnetism: Magnetic or ferromagnetic
Corrosion resistance: Poor; not corrosion-resistant
Applications: Finemac™ is primarily used for high-precision machined small components in precision engineering. Its main field of application is the watchmaking industry, particularly rotationally symmetrical components for mechanical watch movements.
ØSKUDescriptionExecution-ToleranceStockOrderedInventoryhf:att:pa_durchmesserhf:att:pa_ausfuehrung-2hf:att:pa_ausfuehrunghf:att:pa_toleranz
3.00010602103000

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, stress relieved
in 2m bars (+30/0 mm)
diam. 3.00 mm, tolerance ISO h7

bars 2mdrawnh 7

0 kg

0
Product total
Options total
Grand total
03-000bars-2mdrawnh-7-en
2.50010612902500

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, stress relieved, ground
in 2m bars (+30/0 mm)
pointed / chamfered
diam. 2.50 mm, tolerance ISO h5

bars 2mgroundh 5

164 kg

0
Product total
Options total
Grand total
270 418 - 157.400|310 117 - 6.8002-500bars-2mgroundh-5-en
6.50010613106500

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground,
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 6.50 mm, tolerance ISO h7

bars 3mgroundh 7

120 kg

0
Product total
Options total
Grand total
080 318 - 117.300|050 517 - 2.4006-500bars-3mgroundh-7-en
2.500106139025002

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 2.50 mm, tolerance ISO h5

bars 3mgroundh 5

263 kg

0
Product total
Options total
Grand total
290 618 - 217.800|040 419 - 45.5032-500bars-3mgroundh-5-en
3.000106139030001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 3.00 mm, tolerance ISO h5

bars 3mgroundh 5

3004 kg

2003
Product total
Options total
Grand total
081 124 - 235.363|060 325 - 289.833|020 326 - 2460.533|021 024 - 18.4703-000bars-3mgroundh-5-en
4.000106139040001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
stress relieved
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 4.00 mm, tolerance ISO h5

bars 3mgroundh 5

1418 kg

800
Product total
Options total
Grand total
041 125 - 554.716|120 226 - 863.0004-000bars-3mgroundh-5-en
5.000106139050001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished, stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered
diam. 5.00 mm, tolerance ISO h5

bars 3mgroundh 5

1067 kg

0
Product total
Options total
Grand total
081 024 - 3.500|091 024 - 146.000|251 125 - 650.000|161 123 - 189.400|100 723 - 77.900|010 519 - 0.2505-000bars-3mgroundh-5-en
6.000106139060001

Sandvik Finemac
freecutting high carbon steel, leadfree
Highend watch steel for movements
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 6.00 mm, tolerance ISO h5

bars 3mgroundh 5

4205 kg

0
Product total
Options total
Grand total
130 423 - 27.400|130 224 - 59.300|200 325 - 1001.000|201 124 - 1457.500|290 425 - 702.487|260 424 - 955.000|241 023 - 3.7626-000bars-3mgroundh-5-en
8.000106139080001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
stress relieved
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 8.00 mm, tolerance ISO h5

bars 3mgroundh 5

734 kg

0
Product total
Options total
Grand total
111 225 - 255.100|100 621 - 0.700|040 625 - 70.000|131 125 - 408.0308-000bars-3mgroundh-5-en
4.000106129040001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 2m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 4.00 mm, tolerance ISO h5

bars 2mgroundh 5

0 kg

0
Product total
Options total
Grand total
04-000bars-2mgroundh-5-en
6.500106139065001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 6.50 mm, tolerance ISO h5

bars 3mgroundh 5

79 kg

0
Product total
Options total
Grand total
121 217 - 78.8006-500bars-3mgroundh-5-en
5.500106139055001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished, stress relieved
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 5.50 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

631 kg

0
Product total
Options total
Grand total
031 221 - 0.700|240 223 - 30.400|090 626 - 600.0005-500bars-3mgroundh-5-en
2.000106129020001

Sandvik Finemac
freecutting high carbon steel
cold drawn, ground, polished
in 2m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 2.00 mm, tolerance ISO h5

bars 2mgroundh 5

457.5 kg

0
Product total
Options total
Grand total
230 326 - 457.7002-000bars-2mgroundh-5-en
7.000106139070001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished, stress relieved
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
eddycurrent crack tested per DIN ISO 683-7, cl.4
diam. 7.00 mm, tolerance ISO h5

bars 3mgroundh 5

0 kg

500
Product total
Options total
Grand total
300 426 - 0.8007-000bars-3mgroundh-5-en
9.000106139090001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 9.00 mm, tolerance ISO h5

bars 3mgroundh 5

0 kg

0
Product total
Options total
Grand total
09-000bars-3mgroundh-5-en
6.00010613106000

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 6.00 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
06-000bars-3mgroundh-7-en
6.000106130060001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 6.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
06-000bars-3mgroundh-6-en
8.50010613108500

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 8.50 mm, tolerance ISO h7

bars 3mgroundh 7

0 kg

0
Product total
Options total
Grand total
08-500bars-3mgroundh-7-en
3.500106129035001

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 2m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 3.50 mm, tolerance ISO h5

bars 2mgroundh 5

0 kg

0
Product total
Options total
Grand total
03-500bars-2mgroundh-5-en
0.500106000005002

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
cold drawn, tensile Rm 850-1000 MPa
on spools SH390
diam. 0.50 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
00-500in-spoolsdrawnh-6-en
1.000106000010002

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
cold drawn, tensile Rm 850-1000 MPa
on spools SH390
diam. 1.00 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
01-000in-spoolsdrawnh-6-en
2.000106000020001

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
precisely cold drawn,
on coils of 20-25kg
diam. 2.00 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
02-000in-spoolsdrawnh-6-en
0.500106020005001

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
powder melted
cold drawn, tensile Rm 850-1000 MPa
in 3m bars +/-10mm
diam. 0.50 mm, tolerance ISO h6

bars 2mdrawnh 6

0 kg

0
Product total
Options total
Grand total
00-500bars-2mdrawnh-6-en
1.000106020010001

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
powder melted
cold drawn, tensile Rm 850-1000 MPa
in 3m bars +/-10mm
diam. 1.00 mm, tolerance ISO h6

bars 2mdrawnh 6

0 kg

0
Product total
Options total
Grand total
01-000bars-2mdrawnh-6-en
0.40210600800402

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
cold drawn, tensile Rm 850-1000 MPa
on spools SH390
diam. 0.402 mm, tolerance ISO h6

in spoolsdrawnspec.

0 kg

0
Product total
Options total
Grand total
00-402in-spoolsdrawnspec-en
11.000106139110001

Sandvik Finemac
freecutting high carbon steel, leadfree
for watch industry, RoHS, Reach conforme
cold drawn, ground, polished, stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 11.00 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

0 kg

500
Product total
Options total
Grand total
011-000bars-3mgroundh-5-en
10.00010613910000

Sandvik Finemac
freecutting high carbon steel, leadfree
high grade watch steel, RoHS, Reach conforme
cold drawn, ground, polished
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered
diam. 10.00 mm, tolerance ISO h5

bars 3mgroundh 5

0 kg

500
Product total
Options total
Grand total
240 226 - 7.10010-000bars-3mgroundh-5-en
8.00010613008000

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 8.00 mm, tolerance ISO h6

bars 3mgroundh 6

0 kg

0
Product total
Options total
Grand total
08-000bars-3mgroundh-6-en
7.50010613907500

Sandvik Finemac
freecutting high carbon steel, leadfree
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
diam. 7.50 mm, tolerance ISO h5

bars 3mgroundh 5

41 kg

0
Product total
Options total
Grand total
201 125 - 41.0007-500bars-3mgroundh-5-en
12.00010613912000

Sandvik Finemac
freecutting high carbon steel, leadfree
for watch industry, RoHS, Reach conforme
cold drawn, ground, polished, stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl. 4
diam. 12.00 mm, tolerance ISO 286-2/h5

bars 3mgroundh 5

0 kg

500
Product total
Options total
Grand total
012-000bars-3mgroundh-5-en
0.84010600000840

Material number 9.9268
freecutting high carbon steel
an industrial version of Finemac
cold drawn, tensile Rm 900-1050 MPa
on spools type SH 460 /max.30kg/spool
diam. 0.84 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
00-840in-spoolsdrawnh-6-en
1.20010600001200

Material number 9.9268
freecutting high carbon steel
an industrial versio of Finemac
cold drawn, tensile Rm 900-1050 MPa
on spools type SH 460 /max.30kg/spool
diam. 1.20 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
01-200in-spoolsdrawnh-6-en
1.58010600001580

Material number 9.9268
freecutting high carbon steel
an industrial version of Finemac
cold drawn, tensile Rm 900-1050 MPa
on spools type SH 460 /max.30kg/spool
diam. 1.58 mm, tolerance ISO h6

in spoolsdrawnh 6

0 kg

0
Product total
Options total
Grand total
01-580in-spoolsdrawnh-6-en
2.10010600302100

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
precisely cold drawn,
on coils of 20-25kg
diam. 2.10 mm, tolerance ISO h6

in spoolsdrawnh 9

0 kg

500
Product total
Options total
Grand total
02-100in-spoolsdrawnh-9-en
1.70010600301700

Finemac
no 1.1268, ~AISI 1095
freecutting high carbon steel
precisely cold drawn,
on coils of 20-25kg
diam. 1.70 mm, tolerance ISO h6

in spoolsdrawnh 9

0 kg

500
Product total
Options total
Grand total
01-700in-spoolsdrawnh-9-en
2.000106139020001

Short description

Klein designation: Finemac
Metal class: lead-free, hardenable, free-cutting carbon steel
Material number: (Material No. 1.1268)
UNS standard: No UNS designation
RoHS 2 – 2011/65/EU: Generally suitable for RoHS-compliant applications, as the material is lead-free; formal confirmation of compliance should be provided for each specific batch.
Machinability: Very consistent machinability and long tool life
Hardenability: Very good; wide temperature and time range during hardening, high hardness and a low risk of rejects. A hardness of approximately 850 HV5 is achieved after quenching.
Formability: Good; particularly suitable for long, slender precision components with tight tolerances
Cold forming: Very good; in particular, excellent cold-heading properties
Polishability: Good; the material is available in ground and polished condition.
Magnetism: Magnetic or ferromagnetic
Corrosion resistance: Poor; not corrosion-resistant
Applications: Finemac™ is primarily used for high-precision machined small components in precision engineering. Its main field of application is the watchmaking industry, particularly rotationally symmetrical components for mechanical watch movements.
bars 3mgroundh 5

547 kg

0
Product total
Options total
Grand total
270 224 - 0.244|120 526 - 491.258|260 624 - 55.4482-000bars-3mgroundh-5-en
Werkstoff-Nr.
DIN
AFNOR
AISI
ISO
Euronorm
Andere
C % 1.0
Si % 0.27
Mn % 0.50
P % ≤ 0.03
S % 0.10
Cr % 0.45
Mo %
Ni %
Cu %
Pb %
Zn %
Sn %
Fe %
O %
N %
H %
Ti %
Schnittgeschwindigkeit
Standardabmessung an Lager
