High strength and corrosion resistance Co-Ni-Mo based multiphase alloy
Material number:
2.4782
Standard UNS:
RoHS 2 – 2011/65/EU:
Machinability:
Hardening capability:
Forming:
Cold working hardening:
Polishing ability:
Magnetism:
Corrosion resistance:
Uses:
The CarTech® MP35N Alloy is the alloy of choice when toughness, ductility, fatigue, corrosion and wear resistances are required, as in the chemical industry, or for applications as orthopedic implants, or for medical, surgical and dental instruments, and components for watches, or the aerospace industry, micro-engineering etc.
MP35N
Co-Cr Stahl, VIM-VAR umgeschmolzen
gemäss ISO 5832-6 und ASTM F562-13
AMS 5844 Rev. J 2019, AMS 2750 Rev. E 2012
AMS 2630 Class A1 Rev. D 2018
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 3m bars +30/0mm)
end of bars: pointed, chamfered
ultrasonic inspected per AMS-2630A, Rev.D
eddycurrent crack tested
diam. 6.35 mm (1/4″), tolerance ISO h8
bars 3m
ground
h 8
424 kg
260
020 625 - 269.000|271 021 - 155.190
6-350
bars-3m
ground
h-8-en
18.500
56113318500
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 2.9m bars +30/0mm)
end of bars: chamfered
ultrasonic inspected per AMS AMS 2630A,
eddycurrent crack tested
diam.18.50 mm, tolerance ISO h9
bars 3m
ground
h 9
307 kg
0
241 017 - 306.500
18-500
bars-3m
ground
h-9-en
12.700
56113312700
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
AMS 5844 Rev. J (chem. only)
cold worked, full strength (Rm>1600 MPa)
centerless ground, in 3m bars
end of bars: pointed, chamfered
ultrasonic inspected per AMS AMS 2630A, diam.12.70 mm (1/2″), tolerance ISO h9
bars 3m
ground
h 9
393 kg
0
300 625 - 392.500
12-700
bars-3m
ground
h-9-en
25.960
56111825960
MP35N
high quality Co-Cr alloy
VIM/VAR remelted, as perAMS 5844H
cold worked, full strength (> 38 HRC)
centerless ground, in 2-3m bars
internal tests: by immersion
diam. 25.96mm +/-0.063mm
special length
ground
spec.
0 kg
0
0
25-960
special-length
ground
spec-en
2.300
56113002300
9.9035 MP35N
high quality Co-Ni-Cr-Mo steel (MP35N)
ESR remelted, ASTM F-562-13,
cold worked, ground,
tensile strength Rm: 1500-2000 MPa
in 3m bars (+/- 25mm)
one end of bars: chamfered,
eddycurrent crack tested cl.4
diam. 2.30 mm, tolerance ISO h6
bars 3m
ground
h 6
59 kg
0
050 619 - 58.600
2-300
bars-3m
ground
h-6-en
1.100
56100801100
MP35N
high quality Co-Ni-Cr-Moalloy wire
as per ISO 5832-6 1997, ASTM F562-13
ESR remelted
cold worked, full strength (Rm: 1350-1500MPa)
on spools type SK370, 5kg per spool
diam. 1.10mm, tolerance 0/-0.020mm
in spools
drawn
spec.
15 kg
0
140 617 - 14.915
1-100
in-spools
drawn
spec-en
20.000
56113020000
MP35N
high quality Co-Cr alloy
VIM/VAR remelted, as per AMS 5844H
cold worked, full strength (>38HRC)
centerless ground, in 2.8-3.2m bars
end of bars: pointed, chamfered
ultrasonic inspected
diam. 20.00 mm, tolerance ISO h6
bars 3m
ground
h 6
61 kg
0
221 116 - 8.300|170 821 - 52.400
20-000
bars-3m
ground
h-6-en
0.700
56100800700
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035
cold worked, full strength (Rm: 1350-1500MPa)
on spools type SK370,
diam. 0.70 mm, tolerance 0/-0.020mm
in spools
drawn
spec.
5 kg
0
300 119 - 4.580
0-700
in-spools
drawn
spec-en
1.000
56100801000
MP35N
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035, AMS 5844J
high quality Co-Ni-Cr-Mo alloy wire
cold worked, full strength (Rm: 1350-1500MPa)
on spools type SK370,
diam. 1.00 mm, tolerance 0/-0.020mm
in spools
drawn
spec.
7 kg
0
121 218 - 6.700
1-000
in-spools
drawn
spec-en
0.800
56100800800
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035
cold worked, full strength (Rm: 1350-1500MPa)
on spools type SK370,
diam. 0.80 mm, tolerance 0/-0.020mm
in spools
drawn
spec.
3 kg
0
300 119 - 3.100
0-800
in-spools
drawn
spec-en
1.200
56100801200
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035
cold worked, full strength (Rm: 1350-1500MPa)
on spools type SK370,
diam. 1.20 mm, tolerance 0/-0.020mm
in spools
drawn
spec.
0 kg
0
0
1-200
in-spools
drawn
spec-en
0.600
56100800600
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035
cold worked, full strength (Rm: 1350-1500MPa)
on spools type SK370,
diam. 0.60 mm, tolerance 0/-0.020mm
in spools
drawn
spec.
5 kg
0
121 218 - 4.859
0-600
in-spools
drawn
spec-en
35.000
56113835000
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-13, ISO 5832-6
precision ground, in 3m bars (+25.4/0mm)
ultrasonic inspected per AMS 2630A,
diam. 35.00 mm, tolerance +0.099/0mm
bars 3m
ground
spec.
0 kg
738
310 119 - 29.477
35-000
bars-3m
ground
spec-en
10.000
56113010000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
cold worked, full strength (Rm >1600 MPa)
centerless ground, in 2.7- 3m bars
end of bars: pointed, chamfered
ultrasonic inspected per AMS AMS 2630A,
diam.10.00 mm, tolerance ISO h6
bars 3m
ground
h 6
38 kg
0
240 320 - 2.200|230 223 - 36.200
10-000
bars-3m
ground
h-6-en
2.000
56113002000
9.9035 MP35N
high quality Co-Ni-Cr-Mo steel. (MP35N)
ESR remelted, ASTM F-562-13
cold worked, ground,
tensile strength Rm: 1500-2000 MPa
in 3m bars (+/- 25mm)
one end of bar: chamfered,
eddycurrent crack tested cl. 4
diam. 2.00 mm, tolerance ISO h6
bars 3m
ground
h 6
9 kg
200
050 619 - 9.300
2-000
bars-3m
ground
h-6-en
10.200
56113310200
MP35N
high quality Co-Cr alloy, VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
as per AMS 5844 Rev. H
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 3m bars +30/0mm)
end of bars: chamfered, pencil point
ultrasonic inspected per AMS2630 Rev. D Cl. A1
diam. 10.20 mm, tolerance ISO h9
bars 3m
ground
h 9
33 kg
700
130 624 - 433.000
10-200
bars-3m
ground
h-9-en
8.150
56113308150
MP35N
high quality Co-Cr alloy, VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
as per AMS 5844 Rev. J
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 2.8 – 3m bars
end of bars: chamfered, pencil point
ultrasonic and eddycurrent inspected
as per AMS 2630 class A1, Rev. D
diam. 8.15 mm, tolerance ISO h9
bars 3m
ground
h 9
802 kg
0
070 723 - 802.000
8-150
bars-3m
ground
h-9-en
6.000
56113006000
MP35N
high quality Co-Cr alloy, VIM/VAR remelted
as per ISO 5832-6 and ASTM F-562-13
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 3m bars +30/0mm)
end of bars: chamfered, pencil point
ultrasonic inspected per AMS-2630 cl. A
eddycurrent crack tested
diam. 6.00 mm, tolerance ISO h6
bars 3m
ground
h 6
245 kg
0
180 918 - 61.472|300 620 - 184.000
6-000
bars-3m
ground
h-6-en
27.000
56113327000
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-22, ISO 5832-6, AMS 5844J
annealed centerless ground,
in 3m bars, end of bars: chamfered
100% eddycurrent crack tested
ultrasonic inspected per AMS 2630 Rev. E
diam. 27.00 mm, tolerance ISO h9
bars 3m
ground
h 9
324 kg
0
021 224 - 324.100
27-000
bars-3m
ground
h-9-en
7.100
56113207100
MP35N
high quality Co-Cr alloy, VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
as per AMS 5844 Rev. H
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 2.7m bars 0/-20mm)
end of bars: chamfered, pencil point
eddycurrent inspected,
ultrasonic inspected per AMS 2630 cl. A1
diam. 7.10 mm, tolerance ISO h8
bars 3m
ground
h 8
124 kg
0
170 821 - 124.000
7-100
bars-3m
ground
h-8-en
3.000
56113003000
9.9035 (~MP35N)
high quality Co-Ni-Cr-Mo steel (MP35N)
ASTM F-562-13, ISO 5832.6L1997, UNS R30035
cold worked, ground, polished, ESR remelted
tensile strength Rm: 1200-2000 MPa
in 3m bars (+30/0mm)
one end of bars: pointed, chamfered,
eddycurrent crack tested cl.4
diam. 3.00 mm, tolerance ISO h6
bars 3m
ground
h 6
222 kg
0
050 521 - 221.881
3-000
bars-3m
ground
h-6-en
4.000
56113004000
9.9035 MP35N
high quality Co-Ni-Cr-Mo steel (MP35N)
ASTM F-562, ISO 5832.6, UNS S30035
cold worked, ground, polished, ESR
tensile strength Rm: 1200-2000 MPa
in 3m bars (+30/0mm)
one end of bars: pointed, chamfered,
eddycurrent crack tested cl.4
diam. 4.00 mm, tolerance ISO h6
bars 3m
ground
h 6
231 kg
0
140 421 - 230.880
4-000
bars-3m
ground
h-6-en
3.500
56113003500
9.9035 ~MP35N
high quality Co-Ni-Cr-Mo steel
ESR, ASTM F-562-22, ISO 5832-6,UNS R30035
cold worked, ground, polished
tensile strength Rm: 1400- 1800 MPa
in 3m bars (+30/0mm)
one end of bars: pointed, chamfered,
eddycurrent crack tested cl.4
diam. 3.50 mm, tolerance ISO h6
bars 3m
ground
h 6
306 kg
0
191 125 - 289.400|210 421 - 16.500
3-500
bars-3m
ground
h-6-en
5.000
56113005000
9.9035 MP35N
ASTM F-562-13, ISO 5832.6-97
ESR remelted, UNS R30035
high quality Co-Ni-Cr-Mo steel (MP35N)
cold worked, ground, polished
tensile strength Rm: 1200-2000 MPa
in 3m bars (+30/0mm)
one end of bars: pointed, chamfered,
eddycurrent crack tested cl.4
diam. 5.00 mm, tolerance ISO h6
bars 3m
ground
h 6
206 kg
0
030 522 - 205.500
5-000
bars-3m
ground
h-6-en
2.800
56113002800
9.9035 MP35N
high quality Co-Ni-Cr-Mo steel (MP35N)
UNS R30035, ASTM F-562-13, ISO 5832.6:97
ESU remelted, cold worked, ground, polished
tensile strength Rm: 1200-2000 MPa
in 3m bars (+30/0mm)
one end of bars: pointed, chamfered,
eddycurrent crack tested cl.4
diam. 2.80 mm, tolerance ISO h6
bars 3m
ground
h 6
239 kg
0
240 221 - 239.000
2-800
bars-3m
ground
h-6-en
0.900
56100000900
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035
cold worked, full strength (Rm: 1400-1700MPa)
on spools type SK370,
diam. 0.90 mm, tolerance 0/-0.006mm
in spools
drawn
h 6
0 kg
0
0
0-900
in-spools
drawn
h-6-en
8.000
56113008000
MP35N
high quality Co-Cr alloy, VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
as per AMS 5844 Rev. J
cold worked, full strength (Rm >1200 MPa)
ground, polished, in 3m bars +30/0mm)
end of bars: chamfered
ultrasonic and eddycurrent inspected
diam. 8.00 mm, tolerance ISO h6
bars 3m
ground
h 6
556 kg
0
090 321 - 151.795|190 922 - 404.500
8-000
bars-3m
ground
h-6-en
3.000
56113103000
2.4964 (L-605)
Co-Cr-W-Ni Alloy, Ergiloy 2.4964HL
ASTM F90-14, High strength alloy
cold worked, ground, polished
tensile strength Rm: 1400-1600 MPa
in 3.7m bars (0/-50mm)
eddycurrent crack tested cl.3
diam. 3.00 mm, tolerance ISO h6
bars 3m
ground
h 7
88 kg
0
010 721 - 88.000
3-000
bars-3m
ground
h-7-en
2.700
56113102700
2.4964 (L-605)
Co-Cr-W-Ni Alloy, Ergiloy 2.4964HL
ASTM F90-14, High strength alloy
cold worked, ground, polished
tensile strength Rm: 1250-2000 MPa
in 3.7m bars (+50/0mm)
eddycurrent crack tested cl.3
diam. 2.70 mm, tolerance ISO h6
bars 3m
ground
h 7
0 kg
0
0
2-700
bars-3m
ground
h-7-en
21.000
56113321000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
AMS 5844 Rev J, AMS 2750 Rev. F
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 3m bars (0/-180mm)
end of bars: pointed, chamfered
ultrasonic inspected AMS AMS 2630A, Rev.D eddycurrent crack tested
diam.21.00 mm, tolerance ISO h9
bars 3m
ground
h 9
0 kg
560
0
21-000
bars-3m
ground
h-9-en
4.000
561130040001
2.4964 (L-605)
Co-Cr-W-Ni Alloy, Ergiloy 2.4964HL
CoCr20W15Ni, Alliy 25, AISI 670
gemäss ASTM F90-14, ISO 5832-5:2005
High strength alloy CoCr Alloy
cold worked, ground, polished
tensile strength Rm: 1350-1800 MPa
in 3m bars (+30/0mm)
eddycurrent crack tested cl.4
end of bars: pointed, chamfered
diam. 4.00 mm, tolerance ISO h6
bars 3m
ground
h 6
161 kg
0
300 622 - 160.700
4-000
bars-3m
ground
h-6-en
5.000
561130050001
2.4964 (L-605)
Co-Cr-W-Ni Alloy, Ergiloy 2.4964HL
CoCr20W15Ni, Alliy 25, AISI 670
gemäss ASTM F90-14, ISO 5832-5:2005
AMS 5796, AMS 5759 (chem. only)
High strength alloy
cold worked, ground, polished
tensile strength Rm: 1250-2000 MPa
in 3m bars (+30/0mm)
eddycurrent crack tested cl.4
end of bars: pointed, chamfered
diam. 5.00 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
0
5-000
bars-3m
ground
h-6-en
4.500
56113004500
2.4964 (L-605)
Co-Cr-W-Ni Alloy, Ergiloy 2.4964HL
CoCr20W15Ni, Alliy 25, AISI 670
gemäss ASTM F90-14, ISO 5832-5:2005
AMS 5796, AMS 5759 (chem. only)
High strength alloy
cold worked, ground, polished
tensile strength Rm: 1310-1800 MPa
in 3m bars (+30/0mm)
eddycurrent crack tested cl.4
end of bars: pointed, chamfered
diam. 4.50 mm, tolerance ISO h6
bars 3m
ground
h 6
206 kg
0
280 622 - 206.000
4-500
bars-3m
ground
h-6-en
1.400
56113001400
2.4964 (L-605)
Co-Cr20W15Ni alloy 25, Ergiloy 2.4964HL
as per ASTM F90-14, UNS R30605, AISI 670
AMS 5796, ASTM A5759 (chem. only)
cold worked, ground, polished
tensile strength Rm: 1500-2000 MPa
in 3m bars (+/-10mm)
eddycurrent crack tested cl.1
end of bar: chamfered
diam. 1.40 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
137 kg
0
031 122 - 136.598
1-400
bars-3m
ground
h-6-en
1.000
56103801000
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035
cold drawn, full strength, in 3m bars
diam. 1.00 mm, tolerance ISO js7 (+/-0.005)
bars 3m
drawn
spec.
2 kg
0
121 218 - 2.380
1-000
bars-3m
drawn
spec-en
7.000
56113007000
MP35N
high quality Co-Cr alloy, VIM/VAR remelted
as per ISO 5832-6 and ASTM F-562-13
as per AMS 5844 Rev. H
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 2.70 m bars 0/-20mm)
end of bars: chamfered, pencil point
eddycurrent inspected and
ultrasonic inspected per AMS 2630 cl. A1
diam. 7.00 mm, tolerance ISO h6
bars 3m
ground
h 6
263 kg
0
160 821 - 263.000
7-000
bars-3m
ground
h-6-en
15.000
56113315000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-22
AMS 5844 Rev J: 2019
strain hardened, (Rm>1200 MPa)
centerless ground, in 3m bars +30/0mm)
end of bars: chamfered
ultrasonic inspected per AMS 2630A1 Rev. E
diam.15.00 mm, tolerance ISO h9
bars 3m
ground
h 9
640 kg
0
200 125 - 639.700
15-000
bars-3m
ground
h-9-en
3.800
56113003800
9.9035 ~MP35N
high quality Co-Ni-Cr-Mo steel
ASTM F-562-13, ISO 5832.6,
ESR remelted, UNS R30035
cold worked, ground, polished
tensile strength Rm: 1400- 2000 MPa
in 3m bars (+30/0mm)
one end of bars: pointed, chamfered,
eddycurrent crack tested cl.4
diam. 3.80 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
0
3-800
bars-3m
ground
h-6-en
17.000
56113317000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
AMS 5844 Rev J: 2019
AMS 2630 Rev E: 2021 class A1
cold worked,
full strength, Rm >1200 MPa, (> 174KSI))
centerless ground, in 2.8m bars (+30/0mm)
end of bars: pointed/chamfered
ultrasonic inspected per AMS 2630A
eddycurrent crack tested
diam.17.00 mm, tolerance ISO h9
bars 3m
ground
h 9
626 kg
0
190 825 - 157.000|210 725 - 469.200
17-000
bars-3m
ground
h-9-en
31.750
56113831750
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-22, ISO 5832-6,
AMS 5844, REV J 2019,
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
strain hardened, centerless ground,
in apprx. 3m bars, end of bars: chamfered
100% eddycurrent crack tested
ultrasonic insp. per AMS 2630 REV E 21, Kl.A1
diam. 31.75 mm (1 1/4”), tolerance 0/-0.066mm
bars 3m
ground
spec.
558 kg
0
221 124 - 558.100
31-750
bars-3m
ground
spec-en
1.200
56103801200
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ESR remelted
ASTM F562-13, UNS R30035
cold drawn, full strength, in 3m bars
diam. 1.20 mm, tolerance ISO js7 (+/-0.005)
bars 3m
drawn
spec.
0 kg
0
0
1-200
bars-3m
drawn
spec-en
41.000
56111841000
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-22, ISO 5832-6, AMS 5844
REV J 2019, annealed centerless ground,
in 3.2 – 3.6m bars,
100% eddycurrent crack tested
ultrasonic insp. per AMS 2630 REV E 21, Kl.A1
diam. 41.00 mm, tolerance +/-0.20mm
special length
ground
spec.
71.7 kg
0
230 524 - 72.300
41-000
special-length
ground
spec-en
1.500
56113001500
9.9035 MP35N
high quality Co-Ni-Cr-Mo steel. (MP35N)
ISO 5832-6 2022, ASTM F-562-22
cold worked, ground,
tensile strength Rm: 1650-1850 MPa
in 3m bars (+/- 25mm)
one end of bar: chamfered,
eddycurrent crack tested cl. 4
diam. 1.50 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
50
0
1-500
bars-3m
ground
h-6-en
0.750
561000007501
MP35N
high quality Co-Ni-Cr-Mo alloy wire
as per ISO 5832-6 1997, ASTM F562-13,
UNS R30035, ESR remelted
cold drawn, on spools K200
Rm: 1800 – 2000 MPa
diam. 0.75 mm, tolerance ISO h6
in spools
drawn
h 6
0 kg
0
0
0-750
in-spools
drawn
h-6-en
2.500
56113002500
9.9035 MP35N
high quality Co-Ni-Cr-Mo steel (MP35N)
UNS R30035, ASTM F-562-22, ISO 5832.6 2022
VAR remelted, cold worked, ground, polished
tensile strength Rm: 1700-1900 MPa
in 3m bars (+30/0mm)
one end of bars: pointed, chamfered,
eddycurrent crack tested cl.4
diam. 2.50 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
332 kg
0
270 825 - 332.000
2-500
bars-3m
ground
h-6-en
25.400
56113325400
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-22, ISO 5832-6 (hard),
AMS 5844J (2019)
annealed centerless ground,
in 3m bars, end of bars: chamfered
100% eddycurrent crack tested
ultrasonic inspected per AMS 2630 Rev. E
diam. 25.40 mm (1”), tolerance ISO h9
bars 3m
ground
h 9
607 kg
0
271 125 - 606.700
25-400
bars-3m
ground
h-9-en
38.100
56113338100
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-22, ISO 5832-6 (hard),
AMS 5844J (2019)
annealed centerless ground,
in 3m bars, end of bars: chamfered
100% eddycurrent crack tested
ultrasonic inspected per AMS 2630 Rev. E
diam.38.1 mm (1.5”), tolerance ISO h9
bars 3m
ground
h 9
467 kg
694
101 025 - 467.000
38-100
bars-3m
ground
h-9-en
33.000
56113333000
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-22, ISO 5832-6 (hard),
AMS 5844J (2019)
annealed centerless ground,
in 3m bars (+50/0mm), end of bars: chamfered
100% eddycurrent crack tested
ultrasonic inspected per AMS 2630 Rev. E
diam.33.00 mm, tolerance ISO h9
bars 3m
ground
h 9
0 kg
737
0
33-000
bars-3m
ground
h-9-en
23.000
56113323000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
AMS 5844 Rev J, AMS 2750 Rev. F
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 3m bars (0/-180mm)
end of bars: pointed, chamfered
ultrasonic inspected AMS AMS 2630A, Rev.D eddycurrent crack tested
diam. 23.00 mm, tolerance ISO h9
bars 3m
ground
h 9
0 kg
698
0
23-000
bars-3m
ground
h-9-en
20.000
56113320000
MP35N
high quality Co-Cr alloy, VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
as per AMS 5844 Rev. H
cold worked, tensile Rm: 1100-1300 MPa
centerless ground, in 3m bars +30/0mm)
end of bars: chamfered, pencil point
ultrasonic inspected per AMS2630 Rev. D Cl. A1
diam. 20.00 mm, tolerance ISO h9
bars 3m
ground
h 9
0 kg
800
0
20-000
bars-3m
ground
h-9-en
10.000
56113310000
MP35N
high quality Co-Cr alloy, VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
as per AMS 5844 Rev. H
cold worked, tensile Rm: 1100-1300 MPa
centerless ground, in 3m bars +30/0mm)
end of bars: chamfered, pencil point
ultrasonic inspected per AMS2630 Rev. D Cl. A1
diam. 10.00 mm, tolerance ISO h9
bars 3m
ground
h 9
0 kg
0
0
10-000
bars-3m
ground
h-9-en
14.000
56113314000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-22
AMS 5844 Rev K: 2019
strain hardened, (Rm>1200 MPa)
centerless ground, in 3m bars +30/0mm)
end of bars: chamfered
ultrasonic inspected per AMS 2630A1 Rev. E
diam.14.00 mm, tolerance ISO h9
bars 3m
ground
h 9
573 kg
0
260 526 - 573.000
14-000
bars-3m
ground
h-9-en
16.000
56113316000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-22
AMS 5844 Rev K: 2019
strain hardened, (Rm>1200 MPa)
centerless ground, in 3m bars +30/0mm)
end of bars: chamfered
ultrasonic inspected per AMS 2630A1 Rev. E
diam.16.00 mm, tolerance ISO h9
bars 3m
ground
h 9
523 kg
0
150 426 - 523.000
16-000
bars-3m
ground
h-9-en
50.800
56113350800
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per ASTM F-562-22, ISO 5832-6 (hard),
AMS 5844J (2019)
annealed centerless ground,
in 3m bars, 100% eddycurrent crack tested
ultrasonic inspected per AMS 2630 Rev. E
diam. 50.8 mm (2”), tolerance ISO h9
bars 3m
ground
h 9
0 kg
800
0
50-800
bars-3m
ground
h-9-en
32.486
56111832480
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted, implant quality,
as per AMS 5844 Rev. K
annealed to >89 HRBW
centerless ground, in 3m bars (+200/0mm)
ultrasonic inspected per AMS AMS 2630A,
diam. 32.486 mm, tolerance +/- 0.063mm
special length
ground
spec.
21.7 kg
0
100 226 - 22.800
32-486
special-length
ground
spec-en
20.000
56113220000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
AMS 5844 Rev J, AMS 2750 Rev. F
cold worked, full strength (Rm>1200 MPa)
centerless ground, in 3m bars (0/-180mm)
end of bars: pointed, chamfered
ultrasonic inspected AMS AMS 2630A, Rev.D eddycurrent crack tested
diam.20.00 mm, tolerance ISO h8
bars 3m
ground
h 8
0 kg
709
0
20-000
bars-3m
ground
h-8-en
12.000
56113012000
MP35N
high quality Co-Cr alloy,VIM/VAR remelted,
as per ISO 5832-6 and ASTM F-562-13
AMS 5844 Rev. J (chem. only)
cold worked, full strength (Rm>1600 MPa)
centerless ground, in 3m bars
end of bars: pointed, chamfered
ultrasonic inspected per AMS AMS 2630A,
diam.12.00 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
0
12-000
bars-3m
ground
h-6-en
50.800
56111850800
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted,
as per UNS30035, MR0175, ISO 15156-3
annealed, aged, centerless ground,
tensile Rm > 1310, Rp0.2 > 1240 MPa
in 2.2 – 3m bars,
100% eddycurrent crack tested
ultrasonic insp. per AMS 2630 REV E 21, Kl.A1
diam. 50.8mm (2”), tolerance +/-0.076mm
special length
ground
spec.
0 kg
250
0
50-800
special-length
ground
spec-en
19.050
56111819050
MP35N
high quality Co-Cr alloy,
VIM/VAR remelted,
as per UNS30035, MR0175, ISO 15156-3
annealed aged, centerless ground,
in 2.2 – 3m bars,
100% eddycurrent crack tested
ultrasonic insp. per AMS 2630 REV E 21, Kl.A1
diam. 50.8mm (2”), tolerance +/-0.050mm
special length
ground
spec.
0 kg
250
0
19-050
special-length
ground
spec-en
22.000
56113022000
Brief description
Klein designation:
MP 35 N
Class of steels:
High strength and corrosion resistance Co-Ni-Mo based multiphase alloy
Material number:
2.4782
Standard UNS:
RoHS 2 – 2011/65/EU:
Machinability:
Hardening capability:
Forming:
Cold working hardening:
Polishing ability:
Magnetism:
Corrosion resistance:
Uses:
The CarTech® MP35N Alloy is the alloy of choice when toughness, ductility, fatigue, corrosion and wear resistances are required, as in the chemical industry, or for applications as orthopedic implants, or for medical, surgical and dental instruments, and components for watches, or the aerospace industry, micro-engineering etc.
The multiphase Co-Ni-Mo-based alloy CarTech® MP35N is melted VIM and remelted VAR. It allows obtaining very mechanical properties by cold working and aging preserving its very good corrosion resistance. Its high work-hardening capacity is due to the progressive micro-structural transformation of its annealed cfc-cubic phase into a twinned hcp-hexagonal phase. The final aging stabilizes its microstructure. The high corrosion resistance, fatigue resistance, designates it as implant for joint replacement, and in aerospace, medical, surgical and dental applications. The high elastic properties show it for high quality springs and components for watch movements and their exterior. This alloy is biocompatible and paramagnetic. As wires, it is well adapted for stimulation and pacer lines, drilling lines working in aggressive mediums, marine lines.
