3.7165 – Titan Grade 5 ELI EN TiAl6V4 ELI / ASTM F 136
Material number:
3.7165
Standard UNS:
R 56401, R 56400
RoHS 2 – 2011/65/EU:
Machinability:
Cutting speed: Vc ≈ 20 – 40 m / min
Feed: 0.08 – 0.15 mm / U
Rake angle: – 100 / 120°
Lubricant-coolant: individual choice
The optimal cutting conditions depend on the machine tool, the cutting tools, the chip dimensions, the lubricant-cooling fluid, as well as the tolerances and surface the
roughness to be achieved.
Hardening capability:
950 – 955°C / up to 5 h / slow cooling to 565°C / air
Forming:
warm: rough forging: 950 – 980°C, final forging: 900 – 970°C
cold: feasible, but (very) difficult
Intermediate T: intermediate temperature of 450 – 650°C can help
Cold working hardening:
Polishing ability:
Magnetism:
Corrosion resistance:
The corrosion resistance of titanium Grade 4 is excellent. It can still be reinforced by the formation of a thicker TiO2 oxide layer produced by an anodic oxidation.
Uses:
The Titan Grade 5 ELI is used as implant material, in the micro-mechanical engineering, and in the medical, surgical and dental fields, as well as for components for watch movements and the watch exterior. It has a good corrosion resistance in seawater and marine environment. Its resistance in chloride mediums indicates it for the chemical industry. The easiness of its anodic oxidation permits to produce a rich color spectrum of nuanced anodic oxidation colors and wear resistant oxide layers, that indicates it for jewelry, decorative and wear resistant parts.
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 4.75 mm (3/16″), tolerance ISO h7
bars 3m
ground
h 7
51 kg
0
200 603 - 50.932
4-750
bars-3m
ground
h-7-en
19.000
70513319000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 19.00 mm, tolerance ISO h9
bars 3m
ground
h 9
2 kg
0
020 304 - 1.690
19-000
bars-3m
ground
h-9-en
1.100
70512101100
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 2m
diam. 1.10 mm, tolerance ISO h7
bars 2m
ground
h 7
24 kg
0
081 205 - 23.675
1-100
bars-2m
ground
h-7-en
3.300
70513103300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered
diam. 3.30 mm, tolerance ISO h7
bars 3m
ground
h 7
25 kg
0
090 103 - 24.730
3-300
bars-3m
ground
h-7-en
6.500
70513006500
Titanium Grade 5
German 3.7165, Ti6Al4V (ELI),UNS R56401
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, annealed, ground, polished
stress relieved,in bars of 3m (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
Swissline (ultrasonic tested per AMS-STD
2154 + AMS 2632A + AMS 2361C)
diam. 6.50 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI),
UNS R56400 UNS R56401
ASTM F 136, ISO 5832-3, ASTM B-348
cold drawn, annealed, straightened,
stress relieved, ground, polished
in bars of 3m (+50/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 4.50 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn, ground, polished,
in bars of 2m lengths (+30/0mm)
diam. 1.20 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 2m
diam. 1.25 mm, tolerance ISO h7
bars 2m
ground
h 7
3 kg
0
290 606 - 2.900
1-250
bars-2m
ground
h-7-en
45.000
70533845000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
AMS 4930G, AMS 6932A, AMS 6931B
ASTM F-1472,Rev.08e1
annealed, ground,
in bars of 3m (+457/0mm)
ultrasonic inspected per AMS 2631A+AA
diam. 45.00 mm, tolerance ISO h11
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
ASTM F-1472, AMS 4928,AMS 4930,
annealed, ground, stress relieved
in 3m bars (0/-914mm)
100% ultrasonic inspected AMS 2631AA
diam. 50.00 mm, tolerance ISO h11
bars 3m
ground
h 11
531 kg
0
130 224 - 416.000|070 414 - 114.770
50-000
bars-3m
ground
h-11-en-2
1.900
70513101900
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished, in bars of 3m
end of bars: pointed, chamfered
diam. 1.90 mm, tolerance ISO h7
bars 3m
ground
h 7
9 kg
0
040 806 - 8.700
1-900
bars-3m
ground
h-7-en
2.100
70513102100
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
end of bars. chamfered
diam. 2.10 mm, tolerance ISO h7
bars 3m
ground
h 7
5 kg
0
290 802 - 5.248
2-100
bars-3m
ground
h-7-en
10.500
70513110500
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m lengths (+40/0mm)
pointed, chamfered, eddy current tested
diam. 10.50 mm, tolerance ISO h7
bars 3m
ground
h 7
60 kg
0
020 605 - 60.302
10-500
bars-3m
ground
h-7-en
1.200
70500201200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, on spools
diam. 1.20 mm, tolerance ISO h8
in spools
drawn
h 8
3 kg
0
070 613 - 2.989
1-200
in-spools
drawn
h-8-en
1.400
70512101400
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 2m
diam. 1.40 mm, tolerance ISO h7
bars 2m
ground
h 7
0 kg
0
1-400
bars-2m
ground
h-7-en
1.500
70513001500
Titanium Grade 5
W.Nr. 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F136,ASTM B-348, UNS R56401
ISO 5832-3, ASTM F1472, UNS R56400
drawn, annealed, ground
stress relieved,in bars of 3m (+30/0 mm)
eddycurrent crack tested FT 0.4mm
diam. 1.50 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, hard, etched
tensile strength Rm 900-1200 MPa
on spools SH 370, ~5kg each
diam. 1.00 mm, tolerance ISO h8
in spools
drawn
h 8
14 kg
0
040 515 - 13.532
1-000
in-spools
drawn
h-8-en
1.700
70513101700
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
diam. 1.70 mm, tolerance ISO h7
bars 3m
ground
h 7
0 kg
0
1-700
bars-3m
ground
h-7-en
8.000
70513108000
Titanium Grade 5
Ti6Al4V (ELI), ASTM F 136-13, Grade 23
ISO 5832-3, ASTM B348, ASTM F1472-14
SE 209779, Rev.AB, MS-50401002 Rev.D
MS-401 Rev.C, MAT 006 Rev.9, EN4267-01
Q.20.013 Rev. N, Q.26.509 Rev. D
centerless ground, polished
in bars of 3m (0/-156mm),
end of bars: chamfered
ultrasonic inspected as per AMS 2631D cl.AA
diam. 8.00 mm, tolerance ISO h7
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
chamfered
diam. 2.30 mm, tolerance ISO h7
bars 3m
ground
h 7
34 kg
0
080 307 - 33.900
2-300
bars-3m
ground
h-7-en
2.400
70513102400
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
chamfered
diam. 2.40 mm, tolerance ISO h7
bars 3m
ground
h 7
1 kg
0
070 906 - 0.840
2-400
bars-3m
ground
h-7-en
5.000
70513005000
Titanium Grade 5
German no 3.7165, Ti6Al4V(ELI),
UNS 56401,ASTM F 136, UNS 56400
ISO 5832-3, ASTM B-348 Grade 23
conforme per ROHS,directive
drawn, annealed, ground,
polished, stress relieved
in bars of 3m lengths (+50/0 mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 5.00 mm, tolerance ISO h6
Titanium Grade 5
German 3.7165, Ti6Al4V ELI (Gradfe 23)
as per UNS R56401
ASTM F 136, ISO 5832-3, ASTM B-348
ASTM F-1472-14 (chem. only), Grade 23
drawn, annealed, ground, polished
stress relieved,in bars of 3m (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
Swissline execution
per AMS-STD 2154A, AMS 2632A,
diam. 6.00 mm, tolerance ISO h6
bars 3m
ground
h 6
483 kg
0
090 425 - 333.200|080 818 - 149.985
6-000
bars-3m
ground
h-6-en
16.000
70513116000
Titanium Grade 5
no de mat. 3.7165, Ti6Al4V (ELI)
ASTM F 136-13, ISO 5832-3: 2016
AMS 6932 Rev. C, EN 4267
AMS 4930 Rev. L, AMS 4928 Rev. W
AMS 6931 Rev. D, ASTM B 348 Grade 23
ASTM F-1472-20, NF A47-410,
drawn, ground, stress relieved
in bars of 3m (+150/0mm)
pointed, chamfered, 100% UT at finish AMS 2631AA, Rev. E
diam. 16.00 mm, tolerance ISO h7
bars 3m
ground
h 7
218 kg
0
280 721 - 217.800
16-000
bars-3m
ground
h-7-en
4.000
70513104000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136-13, ISO 5832-3 (2016)
ASTM B-348-13 MS-50401002 Rev. 8,
MS-401 Rev. C, Q.26.509 Rev. E, BMS 136 Re. 30
drawn, ground, in bars of 3m (0/-156mm)
pointed, chamfered, eddy current tested
diam. 4.00 mm, tolerance ISO h7
bars 3m
ground
h 7
249 kg
0
100 424 - 234.500|090 623 - 14.760
4-000
bars-3m
ground
h-7-en
5.500
70513105500
Titanium Grade 5
W.Nr. 3.7165, Ti6Al4V (ELI), AMS 4930 Rev.H
ASTM F 136-13, ISO 5832-3, ASTM B348
Q.20.013, Rev: M, Q.26.509 rev.C, Grade 23
ground, polished, in bars of 3m (0/-156 mm)
end of bars: chamfered, eddy current tested
diam. 5.50 mm, tolerance ISO h7
bars 3m
ground
h 7
82 kg
0
291 118 - 83.180
5-500
bars-3m
ground
h-7-en
40.000
70533840000
Titan Grade 5
W.Nr. 3.7165, Ti6Al4V (ELI) Grade 23
ASTM F 136, ISO 5832-3, AMS 4930 Rev.G
AMS 5632.A, ASTM B348, ASTM F-1472
ultrasonic inspected per AMS 2631AA
annealed, ground, in bars of appr. 3m
diam. 40.00 mm, tolerance ISO h11
bars 3m
scaled
spec.
7 kg
0
111 114 - 7.000
40-000
bars-3m
scaled
spec-en
12.000
70513112000
Titan Grade 5 ELI
W.Nr. 3.7165, Ti6Al4V (ELI),
ASTM F 136-13, ISO 5832-3:2016,
ASTM F-1472:2020a, EN 4267 Rev. 2001
MS-50401002 Rev.8, Q.20.013, Rev.P,
Q.26.509 Rev: F, ASTM B 348
cold drawn, ground, polished N6
in bars of 3m (+50/0mm)
End of bars: chamfered (0/-50mm)
ultrasonic inspected per AMS 2631 Kl. AA, Grade 1
diam. 12.00 mm, tolerance ISO h7
bars 3m
ground
h 7
147 kg
0
191 121 - 146.600
12-000
bars-3m
ground
h-7-en
3.300
70513203300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F-136
drawn, ground, in bars of 3m
pointed, chamfered
diam. 3.30 mm, tolerance ISO h8
bars 3m
ground
h 8
1 kg
0
120 595 - 0.920
3-300
bars-3m
ground
h-8-en
12.000
70513212000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, stress relieved
in bars of 3m
end of bars: pointed, chamfered,
eddy current tested, ultrasonic inspected
diam. 12.00 mm, tolerance ISO h8
bars 3m
ground
h 8
542 kg
0
240 224 - 418.000|220 224 - 123.500
12-000
bars-3m
ground
h-8-en
16.000
70513216000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM F1472
ASTM B-348 Gr.23, AMS 4928 Rev.U
EN 4267 Rev. 2001
drawn, ground, in bars of 3m (0/-100mm)
end of bars: chamfered
100% ultrasonic tested as per AMS2631 Rev.D
diam. 16.00 mm, tolerance ISO h8
bars 3m
ground
h 8
371 kg
0
210 916 - 267.200|191 216 - 103.396
16-000
bars-3m
ground
h-8-en
4.600
70513104600
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 4.60 mm, tolerance ISO h7
bars 3m
ground
h 7
6 kg
0
020 503 - 6.200
4-600
bars-3m
ground
h-7-en
5.800
70513105800
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 5.80 mm, tolerance ISO h7
bars 3m
ground
h 7
0 kg
0
5-800
bars-3m
ground
h-7-en
20.000
70513120000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), EN4267
ASTM F 136-13, ISO 5832-3, ASTM B-348
AMS 4928 Rev: W, MS-50401002 Rev: 7
MS-401 Rev: C Q.20.013 Rev. P,
BMS 136 Rev:30, MAT006 Rev. 9
annealed, ground, polished,
in bars of 3m (+156/0mm)
end of bars: pointed, chamfered,
ultrasonic inspected to AMS 2631
diam. 20.00 mm, tolerance ISO h7
bars 3m
ground
h 7
3 kg
0
050 819 - 2.500
20-000
bars-3m
ground
h-7-en
22.000
70513122000
Titanium Grade 5
W.Nr. 3.7165, Ti6Al4V (ELI),
ASTM B-348 Grade 23
ASTM F 136, ISO 5832-3
Q.26.509, Q.20.013
warmworked, annealed, ground, stress relieved
tensile strength Rm: > 860 MPa
in bars of 3m (0/-156mm)
end of bars: chamfered,
ultrasonic inspected as per AMS 2631
diam. 22.00 mm, tolerance ISO h7
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ground, polished
in bars of 3m lengths 0/-156mm
end of bars: pointed, chamfered,
100% eddy current crack tested
Swissline execution (ultrasonic tested)
diam. 15.00 mm, tolerance ISO h7
bars 3m
ground
h 7
4 kg
0
170 413 - 3.757
15-000
bars-3m
ground
h-7-en
9.600
70513209600
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 9.60 mm, tolerance ISO h8
bars 3m
ground
h 8
48 kg
0
061 103 - 47.950
9-600
bars-3m
ground
h-8-en
1.000
70500801000
Titanium Grade 5
no. 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, on spools
diam. 1.00 mm, tolerance ISO s6
in spools
drawn
spec.
0 kg
0
1-000
in-spools
drawn
spec-en
3.300
70513003300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished, in bars of 3m
end of bares: pointed, chamfered
100% eddy current crack tested
diam. 3.30 mm, tolerance ISO h6
bars 3m
ground
h 6
113 kg
0
070 110 - 92.000|031 106 - 21.014
3-300
bars-3m
ground
h-6-en
8.500
70513108500
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished, in bars of 3m
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 8.50 mm, tolerance ISO h7
bars 3m
ground
h 7
1 kg
0
220 905 - 0.850
8-500
bars-3m
ground
h-7-en
6.350
70513106350
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 6.35 mm (1/4″), tolerance ISO h7
bars 3m
ground
h 7
5 kg
0
040 506 - 5.486
6-350
bars-3m
ground
h-7-en
9.200
70513109200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 9.20 mm, tolerance ISO h7
bars 3m
ground
h 7
0 kg
0
9-200
bars-3m
ground
h-7-en
9.000
70513109000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m (+40/0mm)
pointed, chamfered, eddy current tested
diam. 9.00 mm, tolerance ISO h7
bars 3m
ground
h 7
24 kg
0
180 610 - 0.500|310 111 - 0.100|070 404 - 23.300
9-000
bars-3m
ground
h-7-en
2.600
70513002600
Titanium Grade 5
German no 3.7165,Ti6Al4V (ELI) Grade 23
UNS R56401, UNS R56400
ASTM F 136, ISO 5832-3, ASTM B-348
drawn,annealed, stress relieved,
ground, polished, in bars of 3m +30/0mm
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 2.60 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, etched, tensile Rm: 900-1200MPa
on spools Typ SH370
diam. 0.60 mm, tolerance ISO h8
in spools
drawn
h 8
1 kg
0
310 118 - 1.429
0-600
in-spools
drawn
h-8-en
1.000
70502801000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, in bars of 2m
diam. 1.00 mm, tolerance +/-0.022 mm
bars 2m
drawn
spec.
0 kg
0
1-000
bars-2m
drawn
spec-en
0.900
70502800900
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
ASTM F-1472
drawn, in bars of 2m
diam. 0.90 mm, +/-0.022 mm
bars 2m
drawn
spec.
6 kg
0
130 105 - 5.577
0-900
bars-2m
drawn
spec-en
1.800
70513001800
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ground, polished, stress relieved
in 3m bars (+30/0 mm)
EC crack tested, EN10277-1,Tab.1, Kl.1
diam. 1.80 mm, tolerance ISO h6
bars 3m
ground
h 6
207 kg
0
200 716 - 191.000|200 416 - 15.800
1-800
bars-3m
ground
h-6-en
4.000
70513004000
Titanium Grade 5
no 3.7165, Ti6Al4V (ELI), UNS R56401
ASTM B-348, Grade 23,ASTM F1472-14 chem
ASTM F 136,ISO 5832-3
titanium alloy, RoHS conform
drawn, annealed ground, polished,
stress relieved, in bars of 3m (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested FT<0.1mm
diam. 4.00 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
919 kg
500
191 224 - 907.550|161 024 - 11.657
4-000
bars-3m
ground
h-6-en
0.800
70512000800
Titanium Grade 5
no. 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 2m
diam. 0.80 mm, tolerance ISO h6
bars 2m
ground
h 6
8 kg
0
021 121 - 7.852
0-800
bars-2m
ground
h-6-en
0.900
70512000900
Titanium Grade 5
German no 3.7165, TiAl6V4 (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 2m
diam. 0.90 mm, tolerance ISO h6
bars 2m
ground
h 6
2 kg
0
040 320 - 1.890|060 716 - 0.410
0-900
bars-2m
ground
h-6-en
10.000
70513010000
Titanium Grade 5
mat. no 3.7165, Ti6Al4V (ELI) Grade 23
UNS S56400, UNS S56401, ASTM F 136-13,
ASTM B-348-13, ISO 5832-3
drawn, annealed, stress relieved,
ground, polished, in bars of 3m length (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
SWISSLINE execution ultrasonic tested
AMS-STD 2154A,AMS2632A AMS 2631D
diam. 10.00 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Grade 23
UNS R56400, UNSR56401, ASTM F 136,
ISO 5832-3, ASTM B-348, RoHS conform
drawn, annealed, ground, polished, stress relieved
in bars of 3m (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested FT 0.1mm
diam. 3.50 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Grade 23
ASTM F 136-13, ISO 5832-3 (2021)
UNS B-348-13, UNS R56401, UNS R56400
alloyed titanium for implants, RoHS conforme
drawn, annealed, ground, polished,
stress relieved
in bars of 3m (+30/0mm)
end of bars: pointed, chamfered
eddy current crack tested FT0.1mm max
diam. 3.80 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
304 kg
0
151 123 - 258.000|220 906 - 45.650
3-800
bars-3m
ground
h-6-en
2.500
70513802500
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in 1.5m bars
diam. 2.50 mm 0/-0.005 mm
bars 3m
ground
spec.
0 kg
0
2-500
bars-3m
ground
spec-en
8.800
70513108800
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 8.80 mm, tolerance ISO h7
bars 3m
ground
h 7
0 kg
0
8-800
bars-3m
ground
h-7-en
9.500
70513109500
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m (+40/0mm)
pointed, chamfered, eddy current tested
diam. 9.50 mm, tolerance ISO h7
bars 3m
ground
h 7
0 kg
0
9-500
bars-3m
ground
h-7-en
3.000
70513003000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ISO 5832-3,UNS 56401, Grade 23.
ASTM F-1472 (chem. only)
ASTM F 136, ASTM B-348,
RoHS directive conforme
cold drawn,annealed, ground, polished
stress relived
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 3.00 mm, tolerance ISO h6
bars 3m
ground
h 6
556 kg
300
300 425 - 305.194|301 123 - 250.793
3-000
bars-3m
ground
h-6-en
2.500
70513002500
Titanium Grade 5
German 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136-13, ISO 5832-3, ASTM B348-13
UNS R56400, UNS R56401, RoHS conforme
drawn, annealed, straightened,
stress relieved, ground polished
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 2.50 mm, tolerance ISO 286-2/h6
Titanium Grade 5
~German no. ~3.7165, Ti6Al4V (ELI), ASTM F-1472
ASTM F 136, ISO 5832-3, BMS 136, UNS R56401
Q.20.013, EN 4267, AMS 4928, AMS 4930
annealed, ground, stress relieved
in bars of 3m (+100/0mm), end of bars: chamfered
ultrasonic inspected per AMS 2631 class AA
diam. 25.20 mm, tolerance ISO h9
bars 3m
ground
h 9
1442 kg
0
280 125 - 1442.000
25-200
bars-3m
ground
h-9-en
35.000
705138350001
Titanium Grade 5
no. 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
ASTM F-1472, Q.20.013 Rev.N,
AMS4928, EN 4267
drawn, ground, in bars of 3m (0/-300mm)
100% eddycurrent crack tested
diam. 35.00 mm, tolerance ISO h11
Titanium Grade 5
~no. 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136, ISO 5832-3, BMS 136
annealded, ground, in bars of 3m (+500/0mm)
end of bars: chamfered
ultrasonic inspected per AMS 2631 class AA
diam. 25.40 mm (1”), tolerance +/-0.05 mm
bars 3m
ground
spec.
229 kg
0
121 021 - 229.000
25-400
bars-3m
ground
spec-en
12.700
70513312700
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
annealed, ground, in bars of 2.5-3m
end of bars: pointed and chamfered
diam. 12.70 mm (1/2″), tolerance ISO h9
bars 3m
ground
h 9
131 kg
0
080 606 - 131.300
12-700
bars-3m
ground
h-9-en
27.000
70513427000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 2.5-3.1 m
pointed, chamfered
diam. 27.00 mm, tolerance ISO h11
bars 3m
ground
h 11
2 kg
0
140 911 - 2.100
27-000
bars-3m
ground
h-11-en-2
23.000
70513323000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Grade 23,
UNS R56401, UNS R56400, ASTM B-348-13
ASTM F 136-13, ISO 5832-3: 2016
drawn, ground, in bars of 3m
pointed, chamfered, crack tested
Swissline (US gepr. AMS-STD 2154A, 2632A)
diam. 23.00 mm, tolerance ISO h9
bars 3m
ground
h 9
32 kg
0
271 221 - 31.700
23-000
bars-3m
ground
h-9-en
17.000
70513317000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, crack tested
diam. 17.00 mm, tolerance ISO h9
bars 3m
ground
h 9
0 kg
0
17-000
bars-3m
ground
h-9-en
3.600
70513003600
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, ground, polished, in bars of 3m
pointed, chamfered, ddy current tested
diam. 3.60 mm, tolerance ISO h6
bars 3m
ground
h 6
106 kg
0
270 808 - 105.700
3-600
bars-3m
ground
h-6-en
2.800
70513002800
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F-136, ISO 5832.3
drawn, ground, in bars of 3m
chamfered at both ends
eddycurrent crack tested
diam. 2.80 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in bars of 2.5-2.75m
pointed, chamfered, eddy current tested
diam. 7.50 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Gr. 23
ASTM F 136, ISO 5832-3, ASTM B-348
UNS R56400, UNS R 56401, RoHs conforme
drawn, annealed, stress relieved
ground, polished,
in bars of 3m lengths (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current inspected
Swissline execution (AMS-STD 2154A +AMS 2632A +AMS 2631D)
diam. 8.50 mm, tolerance ISO h6
bars 3m
ground
h 6
373 kg
0
040 320 - 238.000|070 318 - 134.600
8-500
bars-3m
ground
h-6-en
9.000
70513009000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Grade 23
ASTM F 136, ISO 5832-3, ASTM B-348
RoHS conforme, UNS 56400, UNS 56401
drawn, ground, polished in bars of 3m (+40/0mm)
pointed, chamfered, eddy current tested
Swissline, ultrasonic inspected as per
AMS-STD 2154, AMS2632A, AMS2631C
diam. 9.00 mm, tolerance ISO h6
bars 3m
ground
h 6
181 kg
0
290 517 - 180.850
9-000
bars-3m
ground
h-6-en
0.800
70500100800
Titanium Grade 5
German no 3.7165, Ti6Al4V
ASTM F 136, ISO 5832-3
round wire, precisely drawn,
tensile strength Rm: 900 – 1200 MPa
on spool type SH390K
diam. 0.80 mm, tolerance ISO h7
in spools
drawn
h 7
8 kg
0
150 617 - 7.739
0-800
in-spools
drawn
h-7-en
1.600
70513001600
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136-13a, ISO 5832-3, ASTM B-348-13
UNS R56400, UNS R56401, RoHS conform
annealed, stress relieved,
ground, polished, in bars of 3m (0/-50mm)
eddycurrent crack tested EN10277-1,cl.1
diam. 1.60 mm, tolerance ISO h6
Ergitan 3.7165 MG
TiAl6V4 (ELI), ISO 5832-3, UNS S56401
ASTM F 136-13 und ASTM B-348-13
drawn, annealed, straightened, stress relieved
ground, polished, in bars of 3m (+30/0mm)
end of bars: pointed, chamfered
eddycurrent crack tested
diam. 2.30 mm, tolerance ISO h6
bars 3m
ground
h 6
47 kg
0
210 218 - 28.500|020 817 - 18.445
2-300
bars-3m
ground
h-6-en
1.700
70513001700
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Grade 23
ASTM F 136, ISO 5832-3, ASTM B348
drawn, ground, in bars of 3m
diam. 1.70 mm, tolerance ISO 286-2 h6
bars 3m
ground
h 6
99 kg
150
160 720 - 98.770
1-700
bars-3m
ground
h-6-en
2.700
70513002700
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F-136, ISO 5832.3
drawn, ground, in bars of 3m
chamfered at both ends
eddycurrent crack tested
diam. 2.70 mm, tolerance ISO h6
bars 3m
ground
h 6
123 kg
0
120 407 - 123.000
2-700
bars-3m
ground
h-6-en
20.000
70513020000
Titanium Grade 5
German no 3.7165, ISO 5832-3
Ti6Al4V (ELI) Grade 23, UNS R56401
ASTM F 136-13, ASTM B-348-13
drawn, ground, polished
in bars of 3m length (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic inspected per AMS 2631C
diam. 20.00 mm, tolerance ISO h6
bars 3m
ground
h 6
176 kg
0
170 719 - 178.984
20-000
bars-3m
ground
h-6-en
0.650
70502800650
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, in bars of 2m
diam. 0.65 mm, tolerance +/-0.005 mm
bars 2m
drawn
spec.
1 kg
0
310 507 - 1.385
0-650
bars-2m
drawn
spec-en
11.500
70513011500
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 11.50 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
11-500
bars-3m
ground
h-6-en
18.000
70513218000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m lengths (+400mm/0)
end of bars: pointed, chamfered
100% ultrasonic tested
diam. 18.00 mm, tolerance ISO h8
Titanium Grade 5
German 3.7165, Ti6Al4V ELI) UNS R56401
UNS R56400, ASTM F136,ASTM B-348,
Grade 23, ISO 5832-3, RoHS conforme
drawn, annealed, straightened
ground, polished, stress relieved
in bars of 3m (+30/0mm)
end of bars: chamfered
100% eddycurrent crack tested
diam. 2.00 mm, tolerance ISO 286-2/h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, ground, in bars of 3m
end of bars: pointed, chamfered
diam. 1.75 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
1-750
bars-3m
ground
h-6-en
0.700
70500200700
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3 (chem. only)
annealed, etched, tensile Rm: 900-1200MPa
on spool type DIN 370
diam. 0.70 mm, tolerance ISO h8
in spools
drawn
h 8
17 kg
0
100 916 - 10.738|090 916 - 6.210
0-700
in-spools
drawn
h-8-en
7.000
70513007000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
UNS 56400, UNS 56401, ASTM F 136-13,
ASTM B-348-13, ISO 5832-3
drawn, annealed ground, polished
stress relieved
in bars of 3m (+50/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
Swissline with ultrasonic test as per
AMS-STD 2154, AMS2632A, AMS2631C
diam. 7.00 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
519 kg
0
290 524 - 3.430|240 424 - 515.690
7-000
bars-3m
ground
h-6-en
2.200
70513002200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, annealed, ground, polished
stress relieved
in bars of 3m (+30/0 mm)
end of bars: chamfered
eddycurrent crack tested
diam. 2.20 mm, tolerance ISO h6
bars 3m
ground
h 6
136 kg
0
290 116 - 102.000|290 813 - 34.050
2-200
bars-3m
ground
h-6-en
14.000
70513014000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ground, polished
in bars of 3m (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 14.00 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ground, in bars of 3m (+/-150mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested
diam. 21.00 mm, tolerance ISO h7
bars 3m
ground
h 7
227 kg
0
210 515 - 227.400
21-000
bars-3m
ground
h-7-en
13.000
70513013000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136, ISO 5832-3, ASTM B-348
UNS R56400, UNS R56401
RoHS, DFARS conform
drawn, annealed, ground, stress relieved
in bars of 3m (+40/0mm)
end of bars: pointed, chamfered,
eddy current tested (FT <0.10mm)
Swissline execution, (ultrasonic inspected per
AMS-STD 2154A AMS 2630C/AMS 2631D
diam. 13.00 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136,ASTM B-348, ISO 5832-3
alloyed Titantium for implants
drawn, ground, polished
in bars of 3m (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
Swissline (ultrasonic inspected AMS-STD 2154A,
AMS 2630C, AMS 2631D )
diam. 15.00 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
UNS R56400, UNS R56401
ASTM F 136:13, ISO 5832-3:2016, ASTM B348-13
annealed, ground, in bars of 3m (+50/0mm)
end of bars: chamfered, eddy current tested FT0.1mm
Swissline (AMS-STD 2154, AMS2630C/AMS2631D)
diam. 19.00 mm, tolerance ISO h6
bars 3m
ground
h 6
189 kg
0
220 420 - 158.400|090 920 - 30.800
19-000
bars-3m
ground
h-6-en
11.000
70513011000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, UNS S56401
drawn, ground, polished, stress relieved
in bars of 3m (+50/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
Swissline (AMS-STD 2154,AMS2632A,2631C)
diam. 11.00 mm, tolerance ISO h6
bars 3m
ground
h 6
377 kg
0
240 925 - 257.000|270 624 - 119.609
11-000
bars-3m
ground
h-6-en
1.200
70500101200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM B-348-13, ISO 5832-3 1996
drawn, annealed,
tensile strength Rm 900-1100 MPa
in coils of apprx. 3kg each
diam. 1.20 mm, tolerance ISO h7
in spools
drawn
h 7
31 kg
0
121 016 - 30.925
1-200
in-spools
drawn
h-7-en
25.000
70513225000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ASTM B 348 Gr 23 Rev: 19
EN 4267 AMS 4928 Rev: W; Q.26.509 Rev: F;
AMS 2631 Rev: F; 030.8.021. ISO 5832-3
drawn, ground, stress relieved, in bars of 3m
pointed, chamfered, eddy current tested
diam. 25.00 mm, tolerance ISO h8
bars 3m
ground
h 8
226 kg
0
080 822 - 225.650
25-000
bars-3m
ground
h-8-en
0.400
70500100400
Titanium Grade 5,
Ti-6Al-4V ELI, as per ISO 5832-3
ASTM F 136 (chem. only),
cold drawn, annealed, etched
on spools as per DIN 160
diam. 0.40 mm, tolerance h7
in spools
drawn
h 7
7 kg
0
210 316 - 6.837|050 309 - 0.349
0-400
in-spools
drawn
h-7-en
25.000
70513025000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F136-13, ISO 5832-3, ASTM B-348-13
as per UNS S56401
as per AMS 4930 and AMS 6932
drawn, ground, polished,
in bars of 3m lengths +50/0 mm
end of bars: pointed, chamfered
100% eddy current crack tested cl.4
ultrasonic crack tested AMS2631D cl.A1
diam. 25.00 mm, tolerance ISO h6
bars 3m
ground
h 6
3 kg
0
130 814 - 0.750|160 720 - 2.558
25-000
bars-3m
ground
h-6-en
1.300
70512001300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136, ASTM B-348, ISO 5832-3$
UNS R56400, UNS R56401
drawn, stress relieved, ground, polished
in bars of 2m (+30/0mm)
eddycurrent crack tested
diam. 1.30 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V
ASTM B-348, ISO 5832-3, AMS 4928 R
centerless ground,
in bars of apprx. 3m lengths
ultrasonic crack tested per AMS 2631B
diam. 28.00 mm, tolerance ISO h9
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ASTM B-348, ISO 5832-3
drawn, ground, in bars of 3m +40/0mm
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 9.53 mm (3/8″) tolerance ISO h6
bars 3m
ground
h 6
92 kg
0
210 710 - 91.500
9-530
bars-3m
ground
h-6-en
26.000
70513326000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136-13, ISO 5832-3, ASTM F-1472
EN 4267, ASTM B-348-21, AMS 4928 Rev.W
AMS 4930 Rev. L, Q.20.013 Rev. R
drawn, ground, stress relieved,
in bars of 3m (+50/-250mm)
end of bars: pointed, chamfered,
ultrasonic inspected per AMS 2631, cl. AA, Rev. G
diam. 26.00 mm, tolerance ISO h9
bars 3m
ground
h 9
0 kg
0
26-000
bars-3m
ground
h-9-en
35.000
70513335000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
tensile strength Rm > 860 MPa
ground, in bars of 3m +/- 300mm
100% ultrasonic tested as per AMS2631
diam. 35.00 mm, tolerance ISO h9
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
UNS R56400, UNS R56401, Grade 23
drawn, ground, polished, stress relieved
in bars of 3m (+30/0mm) lengths
end of bares: pointed, chamfered
100% eddy current crack tested
diam. 3.10 mm, tolerance ISO h6
bars 3m
ground
h 6
240 kg
0
200 520 - 164.000|100 419 - 75.900
3-100
bars-3m
ground
h-6-en
70.000
70513470000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
annealed, ground, in 3m bars (+0/-914 mm)
diam. 70.00 mm, Tol. h11
bars 3m
ground
h 11
81 kg
0
070 414 - 80.905
70-000
bars-3m
ground
h-11-en-2
21.000
70513221000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m lengths (+/-305mm)
end of bars: pointed, chamfered
100% eddycurrent and ultrasonic tested
diam. 21.00 mm, tolerance ISO h8
bars 3m
ground
h 8
102 kg
0
101 110 - 22.950|220 212 - 79.300
21-000
bars-3m
ground
h-8-en
23.000
70513223000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m lengths (+/-150mm)
end of bars: chamfered
100% ultrasonic crack tested
diam. 23.00 mm, tolerance ISO h8
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136, ISO 5832-3
warmworked, annealed, ground
in bars of 3m lengths (0/-156mm)
end of bars: chamfered at both ends
100% eddycurrent and ultrasonic tested AMS2631
diam. 22.00 mm, tolerance ISO h8
bars 3m
ground
h 8
182 kg
0
040 419 - 48.400|030 316 - 133.962
22-000
bars-3m
ground
h-8-en
24.000
70513224000
Titanium Grade 5
German no 3.7165, Ti6Al4V ELI (Grade 23)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m lengths (+/-305mm)
end of bars: chamfered
100% eddycurrent and ultrasonic tested
diam. 24.00 mm, tolerance ISO h8
bars 3m
ground
h 8
435 kg
0
101 110 - 4.370|190 421 - 430.400
24-000
bars-3m
ground
h-8-en
26.000
70513226000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ground, polished
in bars of 3m lengths (+/-305mm)
end of bars: chamfered
100% eddycurrent and ultrasonic tested
Swissline execution
diam. 26.00 mm, tolerance ISO h8
bars 3m
ground
h 8
34 kg
0
110 315 - 32.850|140 710 - 1.200
26-000
bars-3m
ground
h-8-en
28.000
70513228000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m lengths (+/-305mm)
end of bars: chamfered
100% eddycurrent and ultrasonic tested
diam. 28.00 mm, tolerance ISO h8
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, polished
in bars of 3m lengths (+/-305mm)
end of bars: chamfered
100% eddycurrent and ultrasonic tested
diam. 29.00 mm, tolerance ISO h8
bars 3m
ground
h 8
134 kg
0
140 710 - 133.800
29-000
bars-3m
ground
h-8-en
1.050
70500201050
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3 (chemistry only)
drawn, etched, tensile Rm: 900-1200 MPa
on spools type HR 370
diam. 1.05 mm, tolerance ISO h8
in spools
drawn
h 8
8 kg
80
310 118 - 0.126|300 519 - 7.469
1-050
in-spools
drawn
h-8-en
55.000
70513855000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
annealed, ground, in bars of ca. 3m
ultrasonic crack tested
diam. 55.00 mm, tolerance ISO h11
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3 (chem. only)
cold drawn, in 2m bars
diam. 0.60 mm, tolerance ISO h8
bars 2m
drawn
h 8
5 kg
0
011 004 - 0.977
0-600
bars-2m
drawn
h-8-en
75.000
70513475000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
ASTM F-1472, AMS 4930,
annealed, ground, in 2-2.5 m bars
ultrasonic crack tested
diam. 75.00 mm, tolerance ISO h11
Titanium Grade 5,
Ti6Al4V (ELI) as per ISO 5832-3
ASTM F 136 (chem. only)
drawn, annealed, etched,
on spools as per DIN 160
diam. 0.50 mm, tolerance h7
in spools
drawn
h 7
1 kg
0
310 118 - 0.253|091 222 - 0.782
0-500
in-spools
drawn
h-7-en
30.000
70513330000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F 136, ISO 5832-3, ASTM F-1472
Zimmer Q.20.013, AMS 4928 (except pt. 3.8)
as per ASTM B-348
drawn, ground, in bars of 3m (0/-150mm)
end of bars: chamfered at both ends
Stress relived
ultrasonic inspected per AMS 2631 cl. AA
diam. 30.00 mm, tolerance ISO h9
bars 3m
ground
h 9
312 kg
0
140 120 - 310.946|200 812 - 1.550
30-000
bars-3m
ground
h-9-en
1.250
70500201250
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, tensile Rm: 900 – 1200 MPa
on spools with ~3-4kg each
diam. 1.25 mm, tolerance ISO h8
in spools
drawn
h 8
14 kg
0
120 111 - 13.628
1-250
in-spools
drawn
h-8-en
0.300
70500100300
Titanium Grade 5,
Ti-6Al-4V ELI, as per ISO 5832-3
ASTM F 136 (chem. only),
cold drawn, annealed, etched
on spools as per DIN 160
diam. 0.30 mm, tolerance h7
in spools
drawn
h 7
4 kg
0
210 316 - 4.141
0-300
in-spools
drawn
h-7-en
1.400
70512001400
Titanium Grade 5
mat. no 3.7165, Ti6Al4V (ELI),UNS 56401
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, annealed, ground, polished,
stress relieved
in bars of 2m lengths (+30/0mm)
diam. 1.40 mm, tolerance ISO h6
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, stress relieved, ground, polished,
in bars of 3m lengths (+30/0mm)
pointed, chamfered, end of bars
100% eddy current crack tested
diam. 2.40 mm, tolerance ISO h6
bars 3m
ground
h 6
275 kg
0
120 612 - 99.540|200 313 - 175.500
2-400
bars-3m
ground
h-6-en
2.300
70500802300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, in coils
diam. 2.30 mm, +/-0.0254mm
in spools
drawn
spec.
0 kg
0
2-300
in-spools
drawn
spec-en
1.100
70500301100
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM B-348-13, ISO 5832-3 (chem. only)
drawn, annealed, surface greased, smooth
tensile strength Rm < 900 MPa
in coils of apprx. 10kg
diam. 1.10 mm, tolerance +/-0.025mm
in spools
drawn
h 9
0 kg
50
1-100
in-spools
drawn
h-9-en
0.200
705001002001
Titanium Grade 5,
German no 3.7165, Ti6Al4V
ASTM F 136, ISO 5832-3
drawn, in spools
diam. 0.20 mm, tolerance h7
in spools
drawn
h 7
5 kg
0
120 309 - 4.588
0-200
in-spools
drawn
h-7-en
6.300
70513006300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ASTM B-348, ISO 5832-3
drawn, ground, in bars of 3m
pointed, chamfered, eddy current tested
diam. 6.30 mm, tolerance ISO h6
bars 3m
ground
h 6
9 kg
0
040 506 - 9.100
6-300
bars-3m
ground
h-6-en
3.200
70513003200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ASTM B-348,
as per ISO 5832-3
cold drawn, annealed ground, polished
stress relieved
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 3.20 mm, tolerance ISO h6
Titan Grade 5
W.Nr. 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ultrasonic washed surfac
tensile strength rm > 900 MPa
on spool SH390K
diam. 1.18 mm, tolerance ISO h6
in spools
drawn
h 6
9 kg
0
180 424 - 9.316
1-180
in-spools
drawn
h-6-en
60.000
70513460000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3,
ASTM B-348, AMS 4928
annealed, ground, in 3m bars (0/-914mm)
ultrasonic crack tested
diam. 60.00 mm, tolerance ISO h11
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, ground, in 2-3 m bars
ultrasonic crack tested
diam. 65.00 mm, tolerance ISO h11
bars 3m
ground
h 11
519 kg
0
281 118 - 504.200|140 316 - 14.750
65-000
bars-3m
ground
h-11-en-2
27.000
70513827000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
centerless drawn, ground
in bars of apprx. 3m lengths
100% eddycurrent and ultrasonic tested
as per AMS 2631 Rev.D
diam. 27.00 mm +/- 0.08 mm
bars 3m
ground
spec.
139 kg
0
240 214 - 139.100
27-000
bars-3m
ground
spec-en
32.000
70513332000
Titanium Grade 5
German no 3.7165, Ti6Al4V
ASTM B-348, ISO 5832-3
centerless ground, in 3m bars 0/-600mm
100% ultrasonic crack tested as
per AMS 2631 rev. B
diam. 32.00 mm, tolerance ISO h9
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
AMS 4928 and AMS 4930
annealed, ground,
in bars of 3m +/- 300mm
ultrasonic crack proved
diam. 38.00 mm, tolerance ISO h11
bars 3m
ground
h 11
157 kg
0
050 515 - 157.129
38-000
bars-3m
ground
h-11-en-2
30.000
70513430000
Titan Grade 5
W.Nr. 3.7165, Ti6Al4V (ELI), ASTM F-1472
as per ASTM F136, ISO 5832-3,
and ASTM B-348, AMS 4928, AMS 4930
annealed, ground, in bars of 3m (+450/0mm)
end of bars: chamfered at both ends
100% eddy current crack tested
diam. 30.00 mm, tolerance ISO h11
bars 3m
ground
h 11
359 kg
0
270 619 - 354.600|111 214 - 4.869
30-000
bars-3m
ground
h-11-en-2
0.500
70502100500
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
cold drawn, in 2m bars
diam. 0.50 mm, tolerance ISO h7
bars 2m
drawn
h 7
1 kg
0
310 118 - 1.052|040 810 - 0.003
0-500
bars-2m
drawn
h-7-en
1.200
70500001200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
precisely cold drawn, on Spools SH 390 K
diam. 1.20 mm, tolerance ISO h6
in spools
drawn
h 6
26 kg
0
050 320 - 26.120
1-200
in-spools
drawn
h-6-en
1.500
70500001500
Titanium Grade 5 ELI
Ti6Al4V, ASTM F-136-13, ISO 5832-3
precisely drawn, in coils of apprx. 3-5 kg
tensile strength Rm: 900 – 1150 MPa
diam. 1.50 mm, tolerance ISO h6
in spools
drawn
h 6
6 kg
0
300 916 - 6.109
1-500
in-spools
drawn
h-6-en
1.450
70513001450
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ASTM B-348,
UNS 56401, ISO 5832-3, ASTM F1472
drawn, annealed, ground
stress relieved,in bars of 3m (+30/0 mm)
eddycurrent crack tested
diam. 1.45 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
1-450
bars-3m
ground
h-6-en
1.310
70512001310
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, ground, in bars of 2m
diam. 1.31 mm, tolerance ISO h6
bars 2m
ground
h 6
0 kg
0
1-310
bars-2m
ground
h-6-en
1.300
70500201300
Titanium Grade 5
Ti6Al4V (ELI) ASTM F 136,
ISO 5832-3 (chemistry only)
annealed, etched, on spools HR 370
tensile strength: 900-1200 MPa
diam. 1.30 mm, tolerance ISO h8
in spools
drawn
h 8
1 kg
0
180 416 - 1.066
1-300
in-spools
drawn
h-8-en
1.800
70500001800
Titanium Grade 5 ELI
Ti6Al4V, ASTM F-136-13,
ISO 5832-3, ASTM B-348-13
round wire, precisely drawn, annealed
tensile strength Rm: > 900 MPa
on Spools SH 460 of 5-10 kg
diam. 1.80 mm, tolerance ISO h6
Titanium Grade 5
Ti6Al4V (ELI) ASTM F 136,
ISO 5832-3 (chemistry only)
annealed, etched, on spools HR 370
tensile strength: 900-1200 MPa
diam. 1.61 mm, tolerance ISO h8
in spools
drawn
h 8
4 kg
0
180 416 - 3.942
1-610
in-spools
drawn
h-8-en
1.300
70500001300
Titanium Grade 5 ELI
Ti6Al4V, ASTM F-136-13, ASTM B-348
round wire, precisely drawn
tensile strength Rm: > 900 MPa
on spools SH460K of < 15 kg
diam. 1.30 mm, tolerance ISO h6
in spools
drawn
h 6
41 kg
0
110 620 - 34.140|050 320 - 7.190
1-300
in-spools
drawn
h-6-en
0.600
70500000600
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
cold drawn, on spools
tensile strength Rm: 900 – 1200 MPa
diam. 0.60 mm, tolerance ISO h6
in spools
drawn
h 6
0 kg
0
0-600
in-spools
drawn
h-6-en
1.800
70500101800
Titanium Grade 5 ELI
Ti 6Al4V, no. 3.7165
ASTM F136-13, ASTM B-348
cold drawn, annealed
tensile strength Rm >900 MPa
in coils of apprx. 3 kg
diam. 1.80 mm, tolerance ISO h7
in spools
drawn
h 7
22 kg
0
291 124 - 18.460|120 522 - 3.800
1-800
in-spools
drawn
h-7-en
0.940
70512100940
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
ASTM B-348, UNS R56401
drawn, annealed, ground,
stress relieved, in bars of 2m (+50/0mm)
diam. 0.94 mm, tolerance ISO h7
bars 2m
ground
h 7
0 kg
0
0-940
bars-2m
ground
h-7-en
0.400
70502100400
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
cold drawn, in 2m bars
diam. 0.40 mm, tolerance ISO h7
bars 2m
drawn
h 7
0 kg
0
0-400
bars-2m
drawn
h-7-en
23.000
70513023000
Titanium Grade 5
German 3.7165,Ti6Al4V (ELI), ASTM B348-13
ASTM F 136-13, ISO 5832-3: 2016
Grade 23, UNS R56400, UNS R56401
drawn, annealed, ground, stress relieved
tensile strength Rm: > 860 MPa
in bars of 3m (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current tested (FT 0.1mm)
Swissline,AMS-STD 2154A, AMS 2632A, 2631D
diam. 23.00 mm, tolerance ISO h6
bars 3m
ground
h 6
101 kg
0
030 419 - 100.800
23-000
bars-3m
ground
h-6-en
33.000
70513433000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), ISO 5832-3
ASTM F 136, ASTM B-348, ASTM F-1472
EN 4267, Zimmer Q.20.013, AMS 4928
ground, in bars of 3m (0/-156mm)
100% ultrasonic tested as per AMS 2631
diam. 33.00 mm, tolerance ISO h11
bars 3m
ground
h 11
626 kg
0
191 217 - 333.550|030 919 - 292.100
33-000
bars-3m
ground
h-11-en-2
0.000
70577800000
Titan Grade 23
Ti6Al4V ELI,
implant quality for 3D printers
Oxygene content < 0.11%
in Powder shape, PSD (15 - 53 my)
in 1lbs (0.454kg) plastic bottles
powder
powder
spec.
54 kg
0
241 017 - 54.000
0-000
powder
powder
spec-en
80.000
70503880000
Titan Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136-13, AMS 4930G,
SP 047 Rev AAK, TE 502 7
ISO 5832-3 (chem. only), NF S94-080-1
annealed, ground
ultrasonic instpected as per AMS 2631D
in bars of 2.5-3.8m lengths
round 80.00 mm, tolerance 0/-0.46mm
bars 3m
drawn
spec.
140 kg
0
230 418 - 139.750
80-000
bars-3m
drawn
spec-en
100.000
705334100000
Titanium Grade 5
German no 3.7165,
Ti6Al4V (ELI), ASTM F 136,
annealed, ground, in bars of apprx. 3m
diam. 100.00 mm, tolerance h11
bars 3m
scaled
h 11
0 kg
0
100-000
bars-3m
scaled
h-11-en-2
0.620
70511000620
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, ground, in 1m bars
diam. 0.62 mm, tolerance ISO h6
special length
ground
h 6
0 kg
0
0-620
special-length
ground
h-6-en
2.500
70500202500
Titanium Grade 5
Ti6Al4V alloyed titanium
German no 3.7165
tensile strength Rm 900-1100MPa
drawn, in coils of apprx. 15kg
diam. 2.50 mm, tolerance ISO h8
in spools
drawn
h 8
0 kg
0
2-500
in-spools
drawn
h-8-en
2.000
70500202000
Titanium Grade 5
Ti6Al4V alloyed titanium
German no 3.7165
tensile strength Rm 900-1100MPa
drawn, in coils of apprx. 15kg
diam. 2.00 mm, tolerance ISO h8
in spools
drawn
h 8
0 kg
0
2-000
in-spools
drawn
h-8-en
28.000
70513428000
Titan Grade 5
W.Nr. 3.7165, Ti6Al4V (ELI), Grade 23
ASTM F-136 Rev. 13, ASTM B-348, ISO 5832-3
EN 4267 Rev. 2001, MS-401 Rev: C, Q.26.509 Rev. E
030.8.021 per Except. Rev: 5, MS-50401002 Rev. 7
BMS 136 Rev.3, AMS 4928 Rev: W,
ground, polished N8-N7
in bars of 3m lengths (0/-156 mm)
end of bars: chamfered
ultrasonic inspected per AMS 2631
diam. 28.00 mm, tolerance ISO h11
bars 3m
ground
h 11
283 kg
0
141 218 - 275.657|261 018 - 7.200
28-000
bars-3m
ground
h-11-en-2
1.000
70500001000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ASTM B-348
drawn, on spools
diam. 1.00 mm, tolerance ISO h6
in spools
drawn
h 6
4 kg
0
250 225 - 3.695
1-000
in-spools
drawn
h-6-en
1.400
70500001400
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, tensiles strength Rm > 900 MPa
on spools SH460K, < 15kg/spool
diam. 1.40 mm, tolerance ISO h6
in spools
drawn
h 6
10 kg
0
160 920 - 10.420
1-400
in-spools
drawn
h-6-en
1.600
70500001600
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn to tensile Rm > 900 MPa
on spools of apprx. 3 kg
diam. 1.60 mm, tolerance ISO h6
in spools
drawn
h 6
45 kg
0
090 120 - 45.420
1-600
in-spools
drawn
h-6-en
2.000
70500002000
Titanium Grade 5 ELI
Ti6Al4V, ASTM F-136-13, ASTM B-348-13
round wire, precisely drawn, annealed
tensile strength Rm: > 900 MPa
in coils of apprx. 5 kg
diam. 2.00 mm, tolerance ISO h6
in spools
drawn
h 6
38 kg
0
120 120 - 37.670
2-000
in-spools
drawn
h-6-en
0.700
70502200700
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3 (chem. only)
annealed, etched, tensile Rm: 900-1200MPa
in 2m lengths
diam. 0.70 mm, tolerance ISO h8
bars 2m
drawn
h 8
5 kg
0
100 916 - 4.545
0-700
bars-2m
drawn
h-8-en
2.900
70513002900
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Grade 23
ISO 5832-3,UNS R56401, UNS R56400
ASTM F 136-13, ASTM B-348-13, ISO 5832-3
RoHS directive EG/2002/95 conforme
cold drawn,annealed, ground,
polished,stress relived
in bars of 3m lengths (+30/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 2.90 mm, tolerance ISO h6
bars 3m
ground
h 6
67 kg
0
051 218 - 67.000
2-900
bars-3m
ground
h-6-en
1.050
70502801050
Titanium Grade 5 (Grade 23)
no. 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3 (chem. only)
annealed, etched, in 2m bars (+/- 50mm)
diam. 1.05 mm, tolerance +/-0.0127mm
bars 2m
drawn
spec.
15 kg
0
310 519 - 14.577
1-050
bars-2m
drawn
spec-en
1.100
70512001100
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), UNS R56400
ASTM F-136, ISO 5832-3, UNS R56401
ASTM B-348 Grade 23
drawn, annealed, ground, stress relieved
in bars of 2m (+/- 10mm) lengths
diam. 1.10 mm, tolerance ISO h6
bars 2m
ground
h 6
71 kg
0
190 321 - 59.483|180 321 - 11.466
1-100
bars-2m
ground
h-6-en
0.980
70500000980
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136,
drawn, on spools
diam. 0.98 mm, tolerance ISO h6
in spools
drawn
h 6
0 kg
0
0-980
in-spools
drawn
h-6-en
22.000
70513022000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
ASTM B348-13, ASTM F 136-13, ISO 5832-3
UNS R56400 and UNS R56401
drawn, annealed, ground, stress relieved
tensile strength Rm: > 860 MPa
in bars of 3m (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current tested (FT 0.1mm)
Swissline,AMS-STD 2154A,AMS 2632A, 2631D
diam. 22.00 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
22-000
bars-3m
ground
h-6-en
1.000
70503201000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, hard,
tensile strength Rm 900-1200 MPa
in bars of 3m (+30/0mm)
diam. 1.00 mm, tolerance ISO h8
bars 3m
drawn
h 8
3 kg
0
040 515 - 3.307
1-000
bars-3m
drawn
h-8-en
1.300
70513001300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI), Grade 23
UNS56401, UNS 56400, RoHS conforme
ASTM F136, ASTM B-348,
ISO 5832-3, ASTM F1472
drawn, annealed, ground
stress relieved,in bars of 3m (+30/0 mm)
eddycurrent crack tested FT 0.4mm
diam. 1.30 mm, tolerance ISO h6
bars 3m
ground
h 6
1 kg
0
220 519 - 0.623
1-300
bars-3m
ground
h-6-en
1.700
70500001700
Titanium Grade 5 ELI
Ti6Al4V, ASTM F-136, ASTM B-348
round wire, precisely drawn, annealed
tensile strength Rm: > 900 MPa
on spools type SH-390
diam. 1.70 mm, tolerance ISO h6
in spools
drawn
h 6
0 kg
0
1-700
in-spools
drawn
h-6-en
1.000
705120010001
Titanium Grade 5
no. 3.7165, Ti6Al4V (ELI)
ASTM F 136 (chem.), ISO 5832-3 (chem.)
drawn, ground, in 2m bars
diam. 1.00 mm, tolerance ISO h6
bars 2m
ground
h 6
24 kg
0
310 118 - 24.399
1-000
bars-2m
ground
h-6-en
0.900
70500200900
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
Astm F 136, ISO 5832-3
drawn, edged, tensile Rm: Rm: 900 – 1200 MPa
on spools DIN 370
diam. 0.90 mm, tolerance ISO h8
in spools
drawn
h 8
25 kg
0
021 121 - 24.640
0-900
in-spools
drawn
h-8-en
1.300
70500301300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM B-348-13, ISO 5832-3 (chem. only)
drawn, annealed, surface greased, smooth
tensile strength Rm < 900 MPa
in coils of apprx. 10kg
diam. 1.30 mm, tolerance +/-0.025mm
in spools
drawn
h 9
0 kg
50
1-300
in-spools
drawn
h-9-en
1.600
70500301600
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348 (chem.)
drawn, annealed, lubrificated, smooth
tensiles strength Rm > 900 MPa
in coils of apprx. 10kg
diam. 1.60 mm, tolerance +/- 0.025mm
in spools
drawn
h 9
0 kg
50
1-600
in-spools
drawn
h-9-en
40.000
70513440000
Titan Grade 5
mat.no 3.7165, Ti6Al4V (ELI) Grade 23
ASTM F 136, ISO 5832-3, AMS 4928, EN4267
AMS 4930, ASTM B348, ASTM F-1472
Q.20.013, Microstructur per ETTC12: A1-A9
titanium alloy for implants
ultrasonic inspected per AMS 2631AA
annealed, stress relieved,
ground, in bars of appr. 3m
diam. 40.00 mm, tolerance ISO h11
bars 3m
ground
h 11
1048 kg
0
050 525 - 757.000|150 621 - 290.519
40-000
bars-3m
ground
h-11-en-2
0.620
70500800620
Titanium Grade 5
German no 3.7165, Ti6Al4V
ASTM F 136, ASTM B-348
round wire, precisely drawn,
tensile strength Rm: >900 MPa
on spool type SH390K
diam. 0.62 mm, tolerance +/-0.015mm
in spools
drawn
spec.
0 kg
0
0-620
in-spools
drawn
spec-en
0.540
70500800540
Titanium Grade 5
German no 3.7165, Ti6Al4V
ASTM F 136, ISO 5832-3
round wire, precisely drawn,
tensile strength Rm: 1100-1300 MPa
on spool type SH390K
diam. 0.54 mm, tolerance +/-0.003mm
in spools
drawn
spec.
0 kg
0
0-540
in-spools
drawn
spec-en
2.100
70513002100
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3
drawn, annealed, ground, polished
stress relieved
in bars of 3m (+30/0 mm)
end of bars: chamfered
eddycurrent crack tested
diam. 2.10 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
2-100
bars-3m
ground
h-6-en
1.200
70500301200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn, tensiles strength Rm > 900 MPa
on spools SH390K
diam. 1.20 mm, tolerance ISO h9
in spools
drawn
h 9
0 kg
0
1-200
in-spools
drawn
h-9-en
1.000
70500301000
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn, tensiles strength Rm > 900 MPa
on spools SH390K
diam. 1.00 mm, tolerance ISO h9
in spools
drawn
h 9
0 kg
0
1-000
in-spools
drawn
h-9-en
2.500
70500302500
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn, tensiles strength Rm > 900 MPa
in coils of apprx. 15kg
diam. 2.50 mm, tolerance ISO h9
in spools
drawn
h 9
0 kg
0
2-500
in-spools
drawn
h-9-en
2.400
70500002400
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn, tensiles strength Rm > 900 MPa
in coils of apprx. 12kg
diam. 2.40 mm, tolerance ISO h6
in spools
drawn
h 6
24 kg
0
050 422 - 23.600
2-400
in-spools
drawn
h-6-en
2.200
70500002200
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn, tensiles strength Rm > 900 MPa
in coils of apprx. 12kg
diam. 2.20 mm, tolerance ISO h6
in spools
drawn
h 6
25 kg
0
050 422 - 24.620
2-200
in-spools
drawn
h-6-en
2.300
70500002300
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B348
drawn, tensiles strength Rm > 900 MPa
in coils of apprx. 12kg
diam. 2.30 mm, tolerance ISO h6
in spools
drawn
h 6
24 kg
0
080 322 - 24.040
2-300
in-spools
drawn
h-6-en
23.000
70513123000
Titanium Grade 5
German 3.7165,Ti6Al4V (ELI), ASTM B348-13
ASTM F 136-13, ISO 5832-3: 2016
Grade 23, UNS R56400, UNS R56401
drawn, annealed, ground, stress relieved
tensile strength Rm: > 860 MPa
in bars of 3m (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current tested (FT 0.1mm)
Swissline,AMS-STD 2154A, AMS 2632A, 2631D
diam. 23.00 mm, tolerance ISO h7
bars 3m
ground
h 7
17 kg
0
241 221 - 17.000
23-000
bars-3m
ground
h-7-en
9.520
70513009520
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI) Grade 23
ASTM F 136-13, ISO 5832-3, ASTM B-348-13
RoHS conforme, UNS 56400, UNS 56401
drawn, annealed, stress relieved,ground, polished
in bars of 3m (+40/0mm)
pointed, chamfered, eddy current tested
Swissline, ultrasonic inspected as per
AMS-STD 2154, AMS2632A, AMS2631D
diam. 9.52 mm (3/8”), tolerance ISO h6
bars 3m
ground
h 6
176 kg
0
050 422 - 88.200|060 422 - 88.100
9-520
bars-3m
ground
h-6-en
1.100
70500001100
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM B-348-13, ISO 5832-3 1996
drawn, annealed,
tensile strength Rm 900-1100 MPa
in coils of apprx. 3kg each
diam. 1.10 mm, tolerance ISO h6
in spools
drawn
h 6
3 kg
0
090 925 - 2.560
1-100
in-spools
drawn
h-6-en
1.380
70500001380
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
drawn, tensiles strength Rm > 900 MPa
on spools SH 390K, < 15kg/spool
diam. 1.38 mm, tolerance ISO h6
in spools
drawn
h 6
0 kg
0
091 122 - 0.258
1-380
in-spools
drawn
h-6-en
0.595
7050000595
Titanium Grade 5
German no 3.7165, Ti6Al4V
ASTM F 136, ISO 5832-3
round wire, precisely drawn,
tensile strength Rm: 1100-1300 MPa
on spool type SH390K
diam. 0.595 mm, tolerance +/-0.003mm
in spools
drawn
h 6
1 kg
0
140 622 - 1.020
0-595
in-spools
drawn
h-6-en
4.760
70513004760
Titanium Grade 5
German no 3.7165, Ti6Al4V(ELI),
UNS 56401,ASTM F 136, UNS 56400
ISO 5832-3, ASTM B-348 Grade 23
conforme per ROHS,directive
drawn, annealed, ground,
polished, stress relieved
in bars of 3m lengths (+50/0 mm)
end of bars: pointed, chamfered
100% eddy current crack tested
diam. 4.76mm (3/16″), tolerance ISO h6
bars 3m
ground
h 6
248 kg
0
260 423 - 248.000
4-760
bars-3m
ground
h-6-en
3.800
71513003800
Titanium Grade 5
no 3.7165, Ti6Al4V (ELI), UNS R56401
ASTM B-348, Grade 23,ASTM F1472-14 chem
ASTM F 136,ISO 5832-3
titanium ally, RoHS conform
drawn, annealed ground, polished,
stress relieved, in bars of 3m (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested FT<0.1mm
diam. 3.80 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
0 kg
0
3-800
bars-3m
ground
h-6-en
4.200
70513104200
Titanium Grade 5
ASTM F 136-13, ISO 5832-3 (2016) Ti 6Al 4V
ASTM B-348-13, MS-50401002 Rev. 8,
MS-401 Rev. C, Q.26.509 Rev. F, Q.20.013 Rev.P
BMS 136 Re. 30, SE 209779, GBLF06022 Rev. 4 CF-0639 Rev. 17
drawn, ground, annealed
in bars of 3m (0/-156mm)
pointed, chamfered, eddy current tested
diam. 4.20 mm, tolerance ISO h7
bars 3m
ground
h 7
232 kg
0
100 424 - 232.250
4-200
bars-3m
ground
h-7-en
90.000
70531890000
Titan Grade 5
Ti6Al4V (ELI), ASTM F 136-92,
gem. BS 7252 Pt 3, 1990
a product of Timet
warm worked execution
in bars of apprx. 900 mm lengths
ultrasonic tested to ETTC 7 NAQ
round 90.00 mm, tolerance +1/0 mm
special length
scaled
spec.
53 kg
0
130 823 - 53.000
90-000
special-length
scaled
spec-en
31.000
70513231000
Titanium Grade 5 ELI
~German no. ~3.7165, Ti6Al4V (ELI), ASTM F-1472
ASTM F 136, ISO 5832-3, BMS 136, UNS R56401
Q.20.013, EN 4267, AMS 4928, AMS 4930
annealed, ground, stress relieved
in bars of 3m (+100/0mm), end of bars: chamfered
ultrasonic inspected per AMS 2631 class AA
diam. 31.00 mm, tolerance ISO h8
bars 3m
ground
h 8
42 kg
0
200 125 - 41.784
31-000
bars-3m
ground
h-8-en
34.000
70513234000
Titanium Grade 5
~German no. ~3.7165, Ti6Al4V (ELI), ASTM F-1472
ASTM F 136, ISO 5832-3, BMS 136, UNS R56401
Q.20.013, EN 4267, AMS 4928, AMS 4930
annealed, ground, stress relieved
in bars of 3m (+100/0mm), end of bars: chamfered
ultrasonic inspected per AMS 2631 class AA
diam. 34.00 mm, tolerance ISO h8
bars 3m
ground
h 8
272 kg
0
110 225 - 272.000
34-000
bars-3m
ground
h-8-en
37.000
70513237000
Titan Grade 5
~W.Nr. 3.7165, Ti6Al4V (ELI),
ASTM F-1472 Rev. : 23, BMS 136 Rev. 30,
ASTM F 136 Rev. 13 (2021) el, ISO 5832-3 2021 UNS R56401 per ASTM F136
Q.20.013 Rev. R, EN 4267 Rev. 2001,
ASTM B 348 Gr. 5 Rev. 21 AMS 4928 Rev. W,
AMS 4930 Rev. L
annealed, ground, stress relieved
in bars of 3m (+100/0mm), end of bars: chamfered
ultrasonic inspected per AMS 2631 class AA
diam. 37.00 mm, tolerance ISO h8
bars 3m
ground
h 8
249 kg
0
280 125 - 249.000
37-000
bars-3m
ground
h-8-en
36.000
70513236000
Titanium Grade 5
~German no. ~3.7165, Ti6Al4V (ELI), ASTM F-1472
ASTM F 136, ISO 5832-3, BMS 136, UNS R56401
Q.20.013, EN 4267, AMS 4928, AMS 4930
annealed, ground, stress relieved
in bars of 3m (+100/0mm), end of bars: chamfered
ultrasonic inspected per AMS 2631 class AA
diam. 36.00 mm, tolerance ISO h8
bars 3m
ground
h 8
387 kg
0
110 225 - 387.000
36-000
bars-3m
ground
h-8-en
25.400
70513325400
Titanium Grade 5
~German no. ~3.7165, Ti6Al4V (ELI)
ASTM F-1472 Rev. 23, BMS 136 Rev. 30
ASTM F 136 Rev. 13 (2021) el
ISO 5832-3 Rev. 2021 EN 4267 Rev. 2001
UNS R56401 per ASTM F136
Q.20.013 Rev. 13, ASTM B 348 Gr. 5 Rev. 2021,
AMS 4928 Rev. W, AMS 4930 Rev. L
annealed, ground, stress relieved
in bars of 3m (+100/0mm), end of bars: chamfered
ultrasonic inspected per AMS 2631 class AA
diam. 25.40 mm (1”), tolerance ISO h9
bars 3m
ground
h 9
352 kg
0
171 224 - 352.046
25-400
bars-3m
ground
h-9-en
48.000
70513348000
Titanium Grade 5
~German no. ~3.7165, Ti6Al4V (ELI), ASTM F-1472
ASTM F 136, ISO 5832-3, BMS 136, UNS R56401
Q.20.013, EN 4267, AMS 4928, AMS 4930
annealed, ground, stress relieved
in bars of 3m (+200/0mm),
ultrasonic inspected per AMS 2631 class AA
diam. 48.00 mm, tolerance ISO h9
bars 3m
ground
h 9
434 kg
0
110 225 - 434.000
48-000
bars-3m
ground
h-9-en
52.000
70513352000
Titanium Grade 5
~German no. ~3.7165, Ti6Al4V (ELI), ASTM F-1472
ASTM F 136, ISO 5832-3, BMS 136, UNS R56401
Q.20.013, EN 4267, AMS 4928, AMS 4930
annealed, ground, stress relieved
in bars of 3m (+200/0mm),
ultrasonic inspected per AMS 2631 class AA
diam. 52.00 mm, tolerance ISO h9
bars 3m
ground
h 9
356 kg
0
110 225 - 355.500
52-000
bars-3m
ground
h-9-en
25.000
705130250001
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136-13, ISO 5832-3, ASTM F-1472
EN 4267, ASTM B-348-21, AMS 4928 Rev.W
AMS 4930 Rev. L, Q.20.013 Rev. R
drawn, ground, stress relieved,
in bars of 3m (+50/-250mm)
end of bars: pointed, chamfered,
ultrasonic inspected per AMS 2631,cl.AA,Rev. G
diam. 25.00 mm, tolerance ISO h6
bars 3m
ground
h 6
672 kg
0
171 224 - 672.400
25-000
bars-3m
ground
h-6-en
3.000
705138030001
Titanium Grade 5
German no 3.7165, Ti6Al4V (ELI)
ASTM F 136, ISO 5832-3, ASTM B-348
UNS R56400, UNS R56401, Grade 23
drawn, ground, polished, stress relieved
in bars of 3m (+30/0mm) lengths
end of bares: pointed, chamfered
100% eddy current crack tested
diam. 3.00 mm, tolerance -0.006/-0.014mm
bars 3m
ground
spec.
0 kg
0
3-000
bars-3m
ground
spec-en
8.000
70513008000
Brief description
Klein designation:
TITAN GRADE 5 ELI
Class of steels:
3.7165 – Titan Grade 5 ELI EN TiAl6V4 ELI / ASTM F 136
Material number:
3.7165
Standard UNS:
R 56401, R 56400
RoHS 2 – 2011/65/EU:
Machinability:
Cutting speed: Vc ≈ 20 – 40 m / min
Feed: 0.08 – 0.15 mm / U
Rake angle: – 100 / 120°
Lubricant-coolant: individual choice
The optimal cutting conditions depend on the machine tool, the cutting tools, the chip dimensions, the lubricant-cooling fluid, as well as the tolerances and surface the
roughness to be achieved.
Hardening capability:
950 – 955°C / up to 5 h / slow cooling to 565°C / air
Forming:
warm: rough forging: 950 – 980°C, final forging: 900 – 970°C
cold: feasible, but (very) difficult
Intermediate T: intermediate temperature of 450 – 650°C can help
Cold working hardening:
Polishing ability:
Magnetism:
Corrosion resistance:
The corrosion resistance of titanium Grade 4 is excellent. It can still be reinforced by the formation of a thicker TiO2 oxide layer produced by an anodic oxidation.
Uses:
The Titan Grade 5 ELI is used as implant material, in the micro-mechanical engineering, and in the medical, surgical and dental fields, as well as for components for watch movements and the watch exterior. It has a good corrosion resistance in seawater and marine environment. Its resistance in chloride mediums indicates it for the chemical industry. The easiness of its anodic oxidation permits to produce a rich color spectrum of nuanced anodic oxidation colors and wear resistant oxide layers, that indicates it for jewelry, decorative and wear resistant parts.
bars 3m
ground
h 6
933 kg
0
140 524 - 566.800|050 723 - 366.205
8-000
bars-3m
ground
h-6-en
20.300
70513220300
Titanium Grade 5
German no 3.7165, ISO 5832-3
Ti6Al4V (ELI) Grade 23, UNS R56401
ASTM F 136-13, ASTM B-348-13
drawn, ground, polished
in bars of 3m length (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
ultrasonic inspected per AMS 2631C
diam. 20.30 mm, tolerance ISO h8
Titan Grade 5 ELI is the ELI (Extra Low Interstitials) version of Ti Grade 5, the worldwide most used Titanium alloy. Titan Grade 5 ELI is a clean alloy, VAR melted and remelted. The contents of the interstitials elements and Fe are kept low. This alloy has a good corrosion resistance, particularly in chloride containing mediums. This Titan Grade 5 ELI is used when severe requirements must be met, as for implants for example. It is biocompatible. It can be easily anodic oxidized. It permits the realization of a broad spectrum of decorative colors and wear resistant TiO2 protective oxide layers. The Titan Grade 5 ELI is ROHS compatible.
